Perlesmith PSLTK2 User manual

V1.0
suppor[email protected]
LARGE TILT TV WALL MOUNT
PSLTK2
V2.0

02
01 03
616 630 645 845
816
x4 x4 x4 x4 x4 x4 x8 x8
T1 T2 T3 T4 T5 T6 T7 T8 x4 x4 x4
W1 W2 W3
[email protected]
perlesmith
1

STEP2 Install TV bracket
Check TV screws
Please select the proper screw length for your TV by hand tightening to check your plat pance thread depth.
The small and medium assembly option is for smaller TVs where the full assembly may
stick out on either side. The mount is shipped in the medium assembly option.
STEP1 Check the VESA pattern of your TV
Width
Height
2
75 mm ≈2 7/8 in
100 mm ≈4 in
200 mm ≈7 7/8 in
300 mm ≈11 3/4 in
400 mm ≈15 3/4 in
600 mm ≈23 5/8 in
400mm (15 3/4 in)
Max 600mm（23 5/8 in）
Max

STEP3 Mount TV to Bracket
STEP4 Assemble Mount(optional)
Larger TVs may
not tilt the full 15°
without including
the spacers.
T8/T7 T8/T7
T6 T6
T1
T2
T8/T7
T6
T3 T4
T5
616
630 645 845
816
Medium 16”Studs
VESA:100x100-400x400mm
24”Studs
VESA:100x100-600x400mm
Large
3

Mark Holes
Use Wall Anchors
Drill Holes
Secure Mount
W3 W1
B: Concrete
10mm Drill bit
8mm Drill bit
STEP5 Wall Plate Install
W3 W1
CAUTION! Over tightening lag bolts
CAUTION! Over tightening lag bolts
may cause heads to snap off
may cause heads to snap off
Mark Holes
Install Screws
Drill Holes
A: Wood Stud
3mm Drill Bit
5mm Drill Bit
！
4

[email protected]
Adjust tilt and plug in connections
before mounting to the wall bracket
as it can be difficult to fit one’s
hand behind the TV once mounted.
STEP6 Hang TV
Thank you for choosing our product! We strive to provide the best quality
and services for our customers. Would you kindly share your experience
on Amazon if you are satisfied? Should you have any issues, please don't
hesitate to contact us.
Telephone：[phone] Mon-Fri 10am - 6pm (PST) (USA)
Email：[email protected]（US/CA/DE/UK/FR/IT/ES/JP/AU)
5
Made in china
Pull down to release lock
www. perlesmith.com .
