Pfeiffer Vacuum ASM 390 User manual

OPERATING INSTRUCTIONS
EN
Translation of the original instructions
ASM 390 - ASM 392
Leak detector

Table of contents
2
Table of contents
1 About this manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
1.1 Validity. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
1.1.1 Applicable documents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
1.2 Conventions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
1.2.1 Safety instructions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
1.2.2 Pictograp s . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
1.2.3 Instructions/Abbreviations used . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
1.2.4 Labels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
2 Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
2.1 Safety precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
2.2 Protective equipment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
2.3 Proper use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
2.4 Improper use. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
3 Transport and storage. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
3.1 Unpacking / repacking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
3.2 Transport. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
3.3 Storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
4 Product description. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
4.1 Product identification. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
4.1.1 Scope of delivery. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
4.1.2 Variants . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
4.2 Interface connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
5 nstallation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
5.1 Prerequisites for optimising measurement . . . . . . . . . . . . . . . . . . . . . . . . 18
5.2 Operating conditions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
5.3 Set-up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
5.4 Purge and inlet vent connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
5.4.1 Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
5.5 Connection to t e mains power supply . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
5.6 Operating for t e first time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
5.6.1 Familiarise yourself wit t e control panel . . . . . . . . . . . . . . . . . . 20
5.6.2 Become familiar wit t e detector . . . . . . . . . . . . . . . . . . . . . . . . . 20
5.7 Connecting t e part/installation to be tested. . . . . . . . . . . . . . . . . . . . . . . 20
5.8 Connecting t e ex aust . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
5.9 Control panel fixing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
5.10 Hose older fixing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
5.11 Storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
6 Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
6.1 Control panel. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
6.1.1 Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
6.1.2 Contrast - Brig tness - Screen Saver . . . . . . . . . . . . . . . . . . . . . . 25
6.1.3 Application screens . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
6.1.4 "Standard" screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
6.1.5 "Settings" screen. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
6.1.6 "Grap " screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
6.1.7 "Vacuum circuit" screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
6.1.8 "Measurement" window. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
6.1.9 Function keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
6.2 Prerequisites to use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
6.3 Switc ing t e detector on . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
6.3.1 Switc on. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
6.3.2 Starting a test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
6.3.3 Test launc ed automatically upon start-up . . . . . . . . . . . . . . . . . . 29
6.4 Monitoring operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
6.5 S utdown t e detector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Table of contents
3
6.6 Saving and downloading t e product’s configuration . . . . . . . . . . . . . . . . 29
6.6.1 Saving t e configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
6.6.2 Downloading t e configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
6.7 Calibration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
6.7.1 Calibration in Hard Vacuum test . . . . . . . . . . . . . . . . . . . . . . . . . . 30
6.7.2 Calibration in Sniffing test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
7 Advanced settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
7.1 "Grap " screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
7.1.1 Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
7.1.2 Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
7.1.3 Scales setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
7.1.4 Grap clearing. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
7.1.5 Recording . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
7.1.6 Saving a recording . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
7.1.7 Viewing a recording. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
7.2 Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
7.2.1 Tree diagram of t e "Settings" menus. . . . . . . . . . . . . . . . . . . . . . 38
7.3 Set points Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
7.3.1 Audio alarm and digital voice . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
7.3.2 Pollution function. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
7.3.3 Hard Vacuum reject point . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
7.3.4 Sniffing reject set point . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
7.3.5 Probe clogged set point . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
7.3.6 Ot er Set points . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
7.3.7 Ot er Pressure set point . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
7.4 “Test” Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
7.4.1 Test met ods. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
7.4.2 Correction factor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
7.4.3 Test mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
7.4.4 Type of probe . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
7.4.5 Automatic Cycle End. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
7.4.6 Inlet vent . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
7.4.7 Memo function. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
7.4.8 Zero activation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
7.4.9 Bypass Option. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
7.4.10 Regeneration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
7.4.11 Massive mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
7.5 Spectro Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
7.5.1 Tracer gas . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
7.5.2 Filament parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
7.5.3 Calibrated leak . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
7.6 Maintenance Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
7.6.1 Detector. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
7.6.2 Timers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
7.6.3 Detector Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
7.6.4 Pump Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
7.6.5 Event istory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
7.6.6 Calibration istory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
7.6.7 Burn-in. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
7.6.8 Maintenance for t e analyzer cell and t e secondary pump. . . . . 51
7.6.9 Last maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
7.7 Configuration Menu. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
7.7.1 Time - Date - Unit - Language. . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
7.7.2 Function keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
7.7.3 Application screens . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
7.7.4 Screen Settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
7.7.5 Access - Password . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
7.8 Advanced Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
7.8.1 Leak Detection Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
7.8.2 Leak Detection: Start-up timer. . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
7.8.3 Leak detection: Background suppression . . . . . . . . . . . . . . . . . . . 58
7.8.4 Leak Detection: Crossover Pressures. . . . . . . . . . . . . . . . . . . . . . 59
7.8.5 Leak Detection: Calibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
7.8.6 Leak detection: Analyzer cell . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
7.8.7 Leak Detection: Internal Pirani gauge calibration . . . . . . . . . . . . . 60
7.8.8 Leak Detection: External gauge . . . . . . . . . . . . . . . . . . . . . . . . . . 61
7.8.9 Leak Detection: Purge valve . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
7.8.10 Input/Output menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
7.8.11 Input/Output: Serial Link 1 and Serial Link 2. . . . . . . . . . . . . . . . . 62

Table of contents
4
7.8.12 Input/Output: I/O connector. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
7.8.13 SD Card menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
7.8.14 Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
8 Maintenance / replacement. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
8.1 Maintenance intervals and responsibilities . . . . . . . . . . . . . . . . . . . . . . . . 63
9 Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
10 Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
11 Technical data and dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
11.1 General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
11.2 Tec nical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
11.3 Units of measurement. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
11.4 Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
12 Appendix . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
12.1 Tree diagram of t e "Settings" menus . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
Certification to UL 61010-1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76
Certification to SEM S2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
Declaration of conformity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78

About t is manual
5
1 About this manual
1.1 Validity
T is operating manual is for customers of Pfeiffer Vacuum. It describes t e functioning
of t e designated product and provides t e most important information for safe use of
t e unit. T e description follows applicable EU guidelines. All information provided in t is
operating manual refers to t e current state of t e product's development. T e documen-
tation remains valid as long as t e customer does not make any c anges to t e product.
Up-to-date operating instructions can also be downloaded from
www.pfeiffer-vacuum.com.
T is manual covers products wit t e following part numbers:
1.1.1 Applicable documents
Documents relevant for t e use of options and/or accessories, and for product mainte-
nance are t e following:
*also available at www.pfeiffer-vacuum.com
Part number Description
CSGB01GxMM9x ASM 390
ESGB02GxMM9x ASM 392
200479 ASM 392 EUV
ASM 390-392 Operating instructions
ASM 390-392 Maintenance instructions P/n 126348M
RS-232 Operating instructions P/n 122215*
Operating instructions for t e 15 pin I/O board P/n 121776*
Operating instructions for t e 37 pin I/O board (Wi-Fi + Et ernet + USB) P/n 123894*
External Communication Box WiFi Operating instructions P/n 126169
Standard Sniffer Probe Operating instructions P/n 121780*
Smart Sniffer Probe Operating instructions P/n BG5268B
Standard Sniffer Probe Operating instructions P/n 121781*
RC10 Remote Control Operating instructions P/n 124628
Bypass Operating instructions P/n PL0004B
Bottle older kit Operating instructions P/n126760
Declaration of conformity CE Included wit t is manual
Declaration of conformity SEMI Included wit t is manual
Certification UL 61010-1 Included wit t is manual

6
About t is manual
1.2 Conventions
1.2.1 Safety instructions
Operating manual safety instructions Pfeiffer Vacuum are based on t e UL, CSA, ANSI
Z-535, SEMI S2, ISO 3864 and DIN 4844 certification standards. T is document de-
scribes t e following information and danger levels:
1.2.2 Pictographs
1.2.3 nstructions/Abbreviations used
DANGER
mminent danger
Indicates an imminent azardous situation t at will result in deat or serious injury.
WARN NG
Possibly imminent danger
Indicates an imminent azardous situation t at can result in deat or serious injury.
CAUT ON
Possibly imminent danger
Indicates an imminent azardous situation t at can result in minor or moderate injury.
NOTICE
Command or note
Command to perform an action or information about properties, t e disregarding of
w ic may result in damage to t e product.
Pro ibition of an action to avoid any risk of accidents, t e disregarding
of w ic may result in serious accidents
Warning of a displayed source of danger in connection wit operation of
t e unit or equipment
Command to perform an action or task associated wit a source of dan-
ger, t e disregarding of w ic may result in serious accidents
 or Work instruction: you must perform an operation ere.
[XXXX] You must press t e XXXX key on t e control panel.
Example: press t e "Home" key on t e control panel to return to t e «Standard» screen.
I/O Inputs/Outputs
4
He Helium 4
3
He Helium 3
H
2
Hydrogen

About t is manual
7
1.2.4 Labels
T is c apter lists all t e labels t at could appear on t e product as well as t eir meaning.
Safety label: guarantee t at t e packing as not
been opened since leaving t e factory.
Indicates an electric s ock azard in case of con-
tact:
do not use t e product if t e power cable is not
eart ed,
disconnect t e electrical power supply before
working on t e product.
Indicates an electrical s ock azard in case of
contact:
disconnect t e electrical power supply before
removing t e cover and working on t e prod-
uct.
Indicate t at t e detector ex aust port s ould not
be blocked.
Locate a grounding point on t e product.
Customization label for t e product according to
t e customer’s request.
Quality: certifies t at t e product as been certi-
fied compliant wit quality control upon leaving
t e factory.
Indicates w et er t e Bluetoot , Wi-Fi or Et er-
net options ave been installed on t e products,
and t eir MAC addresses.
For service centers use only.
Indicates t e firmware versions installed on t e
product.
1) Firmware name
2) Firmware version
3) Firmware c ecksum
4) Publication date
Product identification label (see 4.1).
asssurance qualié / quality control
PRODUIT PERSONNALISE
CUSTOMIZED PRODUCT
HLD1302577 - RS232
Bluetooth MAC address
XXXXXX / None
Network MAC address
xx:xx:xx:xx:xx:xx / None
Pu_GL : 1 Pu_N : 1
Mu_GL : 12856 Mu_N : 31
Mu_Cal : 1 Mu_LDS : 1800
Factory Firmware /Logiciel usine
L0232 V3302 E17D
L0264 V3200 FD87E7D
L0285 V3200 8C9D
DD-MM-YY
1 2 3
4
3 4
1 8 9
7
5 6
98 avenue de brogny F-74000 ANNECY
Kg
P/N :
S/N :
Ind. :
V Hz W
2

8
About t is manual
Labels localisation (1) / (2) / (3)
(1) (2) (3)
1
3
2

Safety
9
2 Safety
2.1 Safety precautions
Obligation to inform
Any person responsible for installing, using or maintaining t e product must first read
t e security instructions in t is operating manual and comply wit t em.
It is t e operating customer’s responsibility to protect all operators against t e dan-
gers associated wit t e product, wit t e media pumped and wit t e entire instal-
lation.
nstallation and use of the accessories
T e products can be fitted wit special accessories. T e installation, use and refurbis -
ment of t e connected accessories are described in detail in t e respective manuals.
Only use original accessories.
Accessory part numbers: see Accessories.
WARN NG
Hazard associated with non-compliant electrical installation
Safe operation after installation is t e operator’s responsibility.
Connect t e product to an installation t at is compliant wit local safety standards.
Do not carry out any alterations or modifications to t e product on your own initiative.
For specific questions, contact your service center.
WARN NG
Electric shock hazard in case of contact
W en t e product's circuit breaker is set at O, some internal components still ave an
electrical c arge.
Make sure t at t e mains connection is always visible and accessible so t at it can
be unplugged at any time.
Disconnect t e power cable from all power sources before starting any work on t e
product.
WARN NG
Risk associated with process gases
A leak detection operation must be carried out under environmental conditions t at do
not present any risks to t e operator and t e equipment. T e user and/or integrator of
t e product are fully responsible for t e operational safety conditions of t e equipment.
T erefore t e user of t e detector must:
not test parts or equipment wit traces of ars , c emical, corrosive, inflammable, re-
active, toxic, or explosive substances, nor condensable vapours even in small
amounts. Do not use t e purge system to dilute t ese azardous products: t at is not
w at it is intended for!
apply specific safety instructions in accordance wit local regulations. For more infor-
mation, contact your service center.
CAUT ON
Risk of pinching
W en andling t e storage tank cover, t ere is a risk of fingers becoming pinc ed.
Keep ands away from t e sides w en opening t e cover.
Keep ands away from t e front of t e cover w en closing it.

10
Safety
T e potential azards concerning a leak detector involve electricity and t e tracer gas.
● Only qualified personnel trained in safety rules (EMC, electrical safety, c emical pol-
lution) may carry out t e installation and maintenance described in t is manual. Our
service centers can provide t e necessary training.
● Do not remove t e blanked-off flange from t e inlet port w ile t e product is not in use.
● Do not expose any part of t e uman body to t e vacuum.
● Comply wit all safety and risk prevention instructions in accordance wit local safety
standards.
● Regularly c eck compliance wit all precautionary measures.
● Do not turn on t e product if t e covers are not in place.
2.2 Protective equipment
In some situations, personal protective equipment must be worn w en andling t e de-
tector and its components. Customers must provide operators wit t e necessary equip-
ment. T is equipment must be c ecked regularly and used in accordance wit t e sup-
plier's recommendations.
CAUT ON
Risk of pinching
W en andling t e work surface cover, t ere is a risk of fingers becoming pinc ed.
Keep ands away from t e sides w en andling t e cover. Keep fingers away from
t e fastening latc es w en closing t e cover and t e work surface.
WARN NG
Risk of injury in the event of a fall
Product s ould be removed from its packaging only by personnel qualified and trained
in andling eavy materials.
Ensure a space equivalent to t e lengt of t e detector is free in alignment wit t e
access ramp.
Always old t e detector by its andle to guide it and slow it on t e access ramp.
kg
WARN NG
Risk of injury due to falling objects
W en transporting parts/components and during maintenance t ere is a danger of loads
slipping and falling down.
Carry small and medium-size parts/components wit bot ands.
Carry parts/components > 20 kg wit a suitable lifting device.
Wear safety s oes wit a steel toe in accordance wit directive EN 347.
WARN NG
Risk of injury through hot surfaces
T e products are designed so as not to present a t ermal risk for t e operator's safety.
However, specific operating conditions may exist t at require extra caution from users
due to t e ig temperatures (surfaces > 70 °C for parts inside t e covers).
Leave t e part to cool before working on t e product.
If necessary wear protective gloves according to directive EN 420.

Safety
11
2.3 Proper use
● T e leak detector is designed to detect and/or quantify a possible installation or com-
ponent leak by searc ing for t e presence of a tracer gas in t e pumped gases.
● Only t e tracer gases identified in t is manual may be used.
● T e product may be used in an industrial environment.
2.4 mproper use
Improper use will cause all claims for liability and warranties to be forfeited. Improper use
is defined as usage for purposes deviating from t ose mentioned above, especially:
● pumping ars , c emical, corrosive, inflammable, reactive, toxic or explosive fluids
● pumping of liquids
● pumping of condensing vapors
● pumping dust or solids
● operation in potentially explosive areas
● analysis of gas wit a ydrogen concentration ig er t an 5 %
● testing parts t at are soiled or t at ave traces of water, vapours, paint, ad esive, de-
tergent or rinsing products
● use of accessories or spare parts, w ic are not named in t is manual
● use of accessories or spare parts, w ic are not sold by t e manufacturer
T e product is not designed to carry people or loads and is not for use as a seat, step-
ladder or any ot er similar purpose.
NOTICE
EC conformity
T e manufacturer's declaration of conformity becomes invalid if t e operator modifies
t e original product or installs additional components.
Following installation into a plant and before commissioning, t e operator must c eck
t e entire system for compliance wit t e valid EU directives and reassess it accord-
ingly.

12
Transport and storage
3 Transport and storage
3.1 Unpacking / repacking
Upon delivery, c eck t at t e product as not been damaged during transport. If t e
product is damaged, take t e necessary measures wit t e carrier and notify t e manu-
facturer. In all situations we recommend:
Keeping t e product in its original packaging so it stays as clean as it was w en dis-
patc ed by us. Only unpack t e product once it as arrived at t e location w ere it will
be used.
Keeping t e packaging (recyclable materials) in case t e product needs to be trans-
ported or stored.
Keeping t e blanked-off plate on t e inlet port w en t e product is not in use.
Unpacking Remove t e box.
Remove t e cover and t e protective foam.
– A foam ramp (1) attac ed to t e pallet will unfold. T is is used to remove t e detec-
tor from t e pallet.
Remove t e box containing t e accessories (see 4.1.1).
Release t e brakes on t e rear w eels of t e detector.
Remove t e detector from t e transport pallet: slide t e detector on t e ramp (1), old-
ing it by t e andle to slow it down.

Remove t e yellow protective film from t e front w eels.
Remove t e protective film from t e control panel.
Repacking C eck t at t e storage boxes are empty (see 5.11).
If t e leak detector is fitted wit accessories connected to t e inlet port or any ot er
customisation, remove t em.
Install a blank-off flange on t e inlet port.
If t e leak detector is fitted wit t e bottle older accessory, remove it and refit t e an-
dle in t e initial position (see bottle holder operating instructions).
Place t e detector on t e transport pallet: slide t e detector on t e foam ramp (1)
pus ing it wit t e andle and immobilise t e front of t e detector against t e foam
stop (2) on t e transport pallet.
Apply t e brakes on t e detector’s rear w eels.
Fit t e cover and t e protective foam.
– Lift t e foam ramp (1) before putting on t e cover.
Put on t e box and strap t e box and pallet.
2
1

Transport and storage
13
W en sending t e detector to a service centre, keep t e accessories delivered wit t e
detector (see 4.1.1). Do not return t em wit t e product.
3.2 Transport
T e product is not designed to carry people or loads and is not for use as a seat, step-
ladder or any ot er similar purpose.
Move t e product using t e andle or t e gripping area located at t e front of t e work
surface.
Do not move t e product using t e bumper, t e control panel (or its arm) or t e inlet port.
3.3 Storage
Storing a new product If a new detector must be stored:
leave it in its packaging,
leave t e blanked-off flange in place on eac port,
store it in a clean, dry environment, in accordance wit t e temperature conditions
specified in t e Technical Characteristics (see 11.2).
WARN NG
Risk of tipping over
Alt oug t e appliance meets EEC safety regulations (normal range ± 10°), it is advis-
able to guard against t e risk of tilting during andling, installation, and use.
Do not place t e product on a plane wit an incline greater t an 3° (or 6%): its weig t
could cause t e operator to be dragged.
Use castors to move it.
Place it on a flat, ard floor.
Do not pus it sideways or press on its side faces.
Do not leave objects leaning on t e side of it.
WARN NG
Risk of injury in the event of a fall
Product s ould be removed from its packaging only by personnel qualified and trained
in andling eavy materials.
Ensure a space equivalent to t e lengt of t e detector is free in alignment wit t e
access ramp.
Always old t e detector by its andle to guide it and slow it on t e access ramp.
NOTICE
Work/Handling the detector
T e operator must not work on t e product to move it or carry out maintenance until it
as come to a complete s utdown! W en t e circuit breaker is set at O, you must:
Unplug t e power cable.
Wait for t e control panel screen to turn off completely before working on t e product
and/or removing t e covers.
NOTICE
Obligation to inform
We took care to provide you wit a clean product. So t at it stays clean, we recommend
storing it in its original packaging.

14
Transport and storage
Beyond 3 mont s, factors suc as temperature, umidity, salt in t e air, etc., could dam-
age some components (elastomers, lubricants, etc.). If t is appens, contact your ser-
vice centre.
Extended storage Recommended s utdown procedure before extended storage:
Place t e blanked-off flange on t e inlet port.
In t e menu [Test], c eck:
– t at t e ’ ard vacuum’ test met od is selected,
– t at t e air inlet valve is set to ’Operator’
Start a test by pressing : wait until t e detector reac es t e most sensitive test
mode.
Make sure t at t e inlet vent is inactive.
Stop t e test by pressing .
S ut down t e detector: circuit breaker to O.
Wait for t e control panel turn off.
Unplug t e power cable.
In t is way, t e detector is under a vacuum, reducing t e degassing time spent w en it
is switc ed on again.

Product description
15
4 Product description
4.1 Product identification
To correctly identify t e product w en communicating wit Pfeiffer Vacuum, always ave
t e information from t e rating plate available.
4.1.1 Scope of delivery
● 1 leak detector
● 1 documentation set (USB key, operating instruction, plastic coated memos for t e de-
tector and t e RS-232)
● 1 power cable for Europe (France/Germany) and/or 1 power cable for US
● 1 calibration certificate for t e internal calibrated leak
● 1 maintenance kit
● 1 grounds eet (in t e storage box) (not supplied wit ASM 392 EUV)
● 1 batc of partitions for compartmentalisation (in t e storage box)
● 1 Quality Control label
● 1 ose older
● 1 adaptor for using t e Smart sniffer probe
● 1 D-Sub male connector cover (15 or 37 pins, depending on option)
● 1 D-Sub male connector (15 or 37 pins, depending on option)
4.1.2 Variants
ASM 390-392 leak detectors are mobile, ig -performance dry pumping detectors.
T ey are designed for applications for w ic ultra-cleanliness and a ig pumping speed
are essential (semiconductor, coating, etc.).
● ASM 390: wit a tracer gas pumping speed of over 10 l/s, ASM 390 offers a fast re-
sponse time.
● ASM 392: equipped wit two turbomolecular pumps, ASM 392 offers t e ig est trac-
er gas pumping speed on t e market in order to satisfy t e needs of ig ly demanding
applications.
Fig. 1: Nameplate example
1 Part number
2Description
3Weig t
4Operating voltage
5Operating frequency
6Maximum power consumption
7Serial number
8Index
9Date of manufacture
3 4
1 8 9
7
5 6
98 avenue de brogny F-74000 ANNECY
Kg
P/N :
S/N :
Ind. :
V Hz W
2

16
Product description
4.2 nterface connection
10
1
8
7 711
6 5 2 4
2 3
9
9
12
Fig. 2: Human-machine interface
Mains power supply 2 RS 232 connector D-Sub 9 pins
(SER AL)
Detector inlet (Inlet port) 3 Interface Connector- I/O D-Sub 15 pins
( NPUTS / OUTPUTS)
(1)
Primary pump Ex aust (EXHAUST) 4 Interface Connector- I/O D-Sub 37 pins
( NPUTS / OUTPUTS)
(1)
Switc /Circuit breaker 5 USB plug (USB)
Inlet vent 6 Et ernet plug (NETWORK)
(1)
Gas inlet (purge) 7 Hose older fixing point
SD card 8 Brakes
Standard sniffer probe connection (STAN-
DARD SNIFFER)
(2)
9 Bottle older fixing point
(2)
V

Product description
17
(1) Accessory or option (at t e customer's expense)
(2) Accessory (at t e customer's expense)
Smart sniffer probe connection (SMART
SN FFER)
(2)
10 Fastener for power cable safety
1 Standard remote control connector
(2)
11 Work plan
12 Storage boxes
Fig. 2: Human-machine interface

18
Installation
5 nstallation
5.1 Prerequisites for optimising measurement
To optimise pumping and measurement speed:
● Use pipe wit a diameter equal to t e diameter of t e detector's inlet. T e pipes s ould
be as s ort as possible and completely sealed.
● Do not use plastic oses suc as compressed air pipes.
● C eck t at t e connected part/installation is impermeable to tracer gas.
● Test only clean, dry parts/installations wit no trace of water, vapour, paint, detergent
or rinsing products.
● Test t at t e entire line is completely sealed w en t e detector is attac ed to t e
pumping circuit, to ensure t at t e connections are correct (pump, pipe, valves, etc.).
5.2 Operating conditions
Environmental conditions (see 11.2).
5.3 Set-up
T e leak detector must be installed on a orizontal flat surface resting on its w eels.
DANGER
Explosion hazard.
For detecting leaks wit ' ydrogen' tracer gas, t e operator must use ydrogenated ni-
trogen (mix of 95 % N
2
and 5 % H
2
).
NOTICE
Risk of pollution from solid substances
W en applications generate particles, we recommend protecting t e detector's inlet.
Install a inlet filter (see Accessories chapter).
NOTICE
Detector ventilation
If t ere is insufficient ventilation, over eating could cause damage to t e components:
Comply wit t e ambient operating temperature.
Do not obstruct t e air vents.
Let a free space of 10 cm (4 inc es) minimum all around t e leak detector.
Store not ing under t e detector.
WARN NG
mmobilisation of the detector
T e detector must be immobilised w en it is being used or maintained.
 Immobilise t e leak detector by setting t e brakes on t e rear w eels.
NOTICE
Tracer gas concentration
You are advised to perform leak detection in a ventilated room.

Installation
19
5.4 Purge and inlet vent connection
T e detector is equipped wit an automatic purge optimizing t e detector functioning.
● Inlet vent and purge are connected to t e ambient air if no system is connected. Purge
maintains air flow inside t e leak detector.
● T e inlet vent status (open or closed) depends on parameters set by t e operator (see
7.4.6).
T e connector of t e purge and inlet vent is delivered equipped wit a protection filter
(see 4.2).
In addition to t e purge, it is advised (not compulsor) to use t e "Pollution" function (see
7.3.2).
5.4.1 Connection
Instead of t e protection filter, it is possible to connect t e detector to a nitrogen line (at
t e customer's expense). To use nitrogen allows to decrease t e background noise of
t e leak detector
Flow To guarantee best performance, t e nitrogen supply must be clean and filtered, wit t e
following c aracteristics:
– relative excess pressure: 200 Pa
– flow rate: 5000 sccm (if pressure= 1 bar (absolute) at t e inlet)
Usage pressure ● 0 to 0.3 bar relative (≈ 0 to 4.5 psig)
● 1.1 to 1.3 bar absolute (≈ 14.5 to 19 psig)
f the purge gas pressure is too high, the inlet valve could always be stay closed.
Procedure Remove t e filtrer from t e connector (see 4.2).
Attac t e nitrogen pipe to t e connector (see 4.2).
5.5 Connection to the mains power supply
CAUT ON
Risk of pollution
T e leak detector must not be used in an environment wit strong concentration in trac-
er gas. T e user as to make sure of t e good ventilation on t e place of use of t e de-
tector.T e manufacturer s all not be eld liable for any pollution of t e product wit trac-
er gas.
WARN NG
Pressurised circuit
To work safely on t e product, t e operator must:
Install a manual valve on t e nitrogen circuit at a distance of 3 m from t e product, so
t at t e nitrogen supply can be locked.
WARN NG
Risk of electromagnetic disturbance
T e product’s EMC be avior is guaranteed only if t e relevant EMC standards are fol-
lowed during installation.
Use s ielded cables and connections for t e interfaces in interference-prone environ-
ments.

20
Installation
T e leak detector is Class 1 equipment and t erefore must be eart ed.
5.6 Operating for the first time
Attac t e electrical network to t e connector using t e power cable delivered wit
t e detector.
Set t e circuit breaker to .
Set t e language, unit, time and date (t e operator can modify t is at a later time(see
7.7.1)).
Wait for t e detector to enter Stand-by mode.
5.6.1 Familiarise yourself with the control panel
Control panel description (see 6.1.1).
Press several times to familiarise yourself wit t e application screens.
Press several times to see t e 2 levels of function keys available.
For eac level, press or t e control panel function key to access t e function.
5.6.2 Become familiar with the detector
You can carry out a ard vacuum test and learn about your detector simply by performing
a test on t e equipment itself.
Leave t e blanked-off flange included wit t e product in place on t e detector's inlet.
Start a test by pressing . T e measured leak rate is displayed: t is is t e detec-
tor's background.
Stop t e test by pressing .
To remove t e blanked-off flange from t e detector's inlet, press [ nlet vent].
5.7 Connecting the part/installation to be tested
● T e inlet pressure must be no ig er t an atmosp eric pressure. Pressure t at is too
ig can damage t e product.
● T e detector's performance depends on t e type of accessories used and on t e qual-
ity of t e mec anical connections.
● W en assembling t e vacuum circuit, use accessories to s ut off t e product and
make maintenance easier (inlet s ut off valves, purge systems, etc.).
● Comply wit t ese recommendations (see 5.1) to optimise measurement.
● T e maximum permitted weig t at t e detector's inlet must be no more t an 18 kg and
t e maximum torque must be 25 N·m.
WARN NG
Hazard associated with non-compliant electrical installation
Safe operation after installation is t e operator’s responsibility.
Connect t e product to an installation t at is compliant wit local safety standards.
Do not carry out any alterations or modifications to t e product on your own initiative.
For specific questions, contact your service center.
NOTICE
Limit of operation
Make sure t at t e parts or c ambers connected to t e inlet of our products wit stand
a negative pressure of 1·10
3
Pa in relation to atmosp eric pressure.
