Philips AC2887/30 User manual

1
B
A
C
ED F
G
2
H J K M NL PO QI
AC2887
I N OH J MK L AC2882
EN User manual 1
ID Buku Petunjuk Pengguna 17
TH คู่มือผู้ใช้ 34
ZH-T 使用手冊 47
© 2021 Philips Domestic Appliances Holding B.V.
All rights reserved.
3000 059 80861
AC2887, AC2882

3s
3s 3s
3s
3s
3s
3
11
7
15
19
5
13
9
17
21
6
14
10
18
22
4
12
8
16
20
23
31
27
25
29
33
26
30
34
24
28
32

1EN
English
Contents
1 Important 2
Safety 2
2 Your air purier 5
Product overview (g.a) 5
Controls overview (g.b) 5
3 Getting started 6
Installing lters 6
4 Using the appliance 6
Understanding the air quality light 6
Switching on and o 6
Changing the Auto mode setting 7
Changing the fan speed 7
Setting the timer 8
Using the light on/o function 8
5 Cleaning 9
Cleaning schedule 9
Cleaning the body of the
appliance 9
Cleaning the air quality sensor 9
Cleaning the pre-lter (g.v) 9
6 Replacing the lter 10
Understanding the healthy air
protect lock 10
Replacing the lters (g.y) 10
Filter force reset 11
Filter type change 11
7 Troubleshooting 13
8 Guarantee and service 15
Order parts or accessories 15
9 Notices 15
Electromagnetic elds (EMF) 15
Recycling 16

2EN
1 Important
Safety
Read this user manual carefully before
you use the appliance, and save it for
future reference.
Danger
• Do not let water or any
other liquid or flammable
detergent enter the
appliance to avoid electric
shock and/or a fire
hazard.
• Do not clean the
appliance with water,
any other liquid, or a
(flammable) detergent to
avoid electric shock and/
or a fire hazard.
• Do not spray any
flammable materials
such as insecticides or
fragrance around the
appliance.
Warning
• Check if the voltage
indicated on the
appliance corresponds to
the local power voltage
before you connect the
appliance.
• If the power cord is
damaged, you must have
it replaced by Philips, a
service center authorized
by Philips, or similarly
qualified persons in order
to avoid a hazard.
• Do not use the appliance
if the plug, the power
cord, or the appliance
itself is damaged.
• This appliance can be
used by children aged
from 8 years and above
and persons with reduced
physical, sensory or
mental capabilities or
lack of experience and
knowledge if they have
been given supervision or
instruction concerning use
of the appliance in a safe
way and understand the
hazards involved. Child
shall not play with the
appliance. Cleaning and
maintenance shall not be
made by children without
supervision.
• Do not block the air inlet
and outlet, e.g. by placing
items on the air outlet or
in front of the air inlet.

3EN
English
• Make sure that foreign
objects do not fall into the
appliance through the air
outlet.
Caution
• This appliance is not
a substitute for proper
ventilation, regular
vacuum cleaning, or use
of an extractor hood or
fan while cooking.
• If the power socket used
to power the appliance
has poor connections,
the plug of the appliance
becomes hot. Make
sure that you plug the
appliance into a properly
connected power socket.
• Always place and use the
appliance on a dry, stable,
level, and horizontal
surface.
• Leave at least 20cm free
space behind and on both
sides of the appliance
and leave at least 30cm
free space above the
appliance.
• Do not place anything on
top of the appliance.
• Do not sit or stand on
the appliance. Sitting or
standing on the appliance
may lead to potential
injuiry.
• Do not place the
appliance directly below
an air conditioner to
prevent condensation
from dripping onto the
appliance.
• Make sure all filters
are properly installed
before you switch on the
appliance.
• Only use the original
Philips filters specially
intended for this
appliance. Do not use any
other filters.
• Combustion of the filter
may cause inreversible
human hazard and/or
jeopardize other lives. Do
not use the filter as fuel or
for similar purpose.
• Avoid knocking against
the appliance (the air inlet
and outlet in particular)
with hard objects.
• Always lift or move the
appliance by the handle
on back side of the
appliance.

4EN
such as TVs, radios, and
radio-controlled clocks.
• The appliance is only
intended for household
use under normal
operating conditions.
• Do not use the appliance
in wet surroundings or in
surroundings with high
ambient temperatures,
such as the bathroom,
toilet, or kitchen.
• The appliance does
not remove carbon
monoxide (CO) or radon
(Rn). It cannot be used
as a safety device in
case of accidents with
combustion processes
and hazardous chemicals.
• If you need to move the
appliance, disconnect the
appliance from the power
supply first.
• Do not move the
appliance by pulling its
power cord.
• Always cleanse your
hands after changing the
filters.
• Do not insert your fingers
or objects into the air
outlet or the air inlet to
prevent physical injury
or malfunctioning of the
appliance.
• Do not use this appliance
when you have used
indoor smoke-type insect
repellents or in places
with oily residues, burning
incense, or chemical
fumes.
• Do not use the appliance
near gas appliances,
heating devices or
fireplaces.
• Always unplug the
appliance after use
and before cleaning,
or carrying out other
maintenance or replacing
the filters.
• Do not use the appliance
in a room with major
temperature changes,
as this may cause
condensation inside the
appliance.
• To prevent interference,
place the appliance at
least 2 meters away from
electrical appliances that
use airborne radio waves

5EN
English
Controls overview (g.b)
For AC2887
HOn/Off button
ILight dimming button
JAuto mode button
KDisplay screen
LPollution mode icon
MAllergen mode icon
NBacteria&Virus mode icon
OFan speed button
PTimer button
QReset button
For AC2882
HOn/Off button
IAuto mode button
JDisplay screen
KPollution mode icon
LAllergen mode icon
MBacteria&Virus mode icon
NFan speed button
OReset button
2 Your air purifier
Congratulations on your purchase, and
welcome to Philips!
To fully benefit from the support that
Philips offers, register your product at
www.philips.com/welcome.
Product overview (g.a)
AControl panel
BAir quality light
CAir quality sensors
DNanoProtect filter HEPA Series 3
(FY2422)*
ENanoProtect filter AC (FY2420)*
FPre-filter
GFront panel
* Hereinafter referred to as air
purification filter

6EN
4 Using the
appliance
Understanding the air
quality light
Air quality light
color
Air quality level
Blue Good
Blue-violet Fair
Red-purple Unhealthy
Red Very unhealthy
The air quality light automatically goes
on when the appliance is switched on,
and lights up all colors in sequence.
In a short time the air quality sensors
select the color that corresponds to the
ambient air quality.
Switching on and o
1 Put the plug of the appliance in the
power socket.
2 Touch to switch on the appliance
(fig.i).
»The appliance beeps.
»The appliance operates under
the pollution mode by default.
»After measuring the air quality
for a short time, the air quality
sensor automatically selects the
color of the air quality light.
»For AC2887, " " displays on
the screen when the appliance
is warming up. After measuring
the particle matters in the air,
the appliance goes to auto
mode with displayed on the
screen (fig. j).
3 Getting started
Installing lters
Note
• Make sure that the appliance is
unplugged before installing the filters.
Before using the appliance, remove all
packaging materials of the filters and
place the filters into the appliance as
described as follows.
Note
• Make sure that the side with the tag is
pointing towards you.
1 Remove all packaging materials of
the air purification filters (fig.c).
2 Pull the bottom part of the front
panel to remove it from the
appliance (fig.d).
3 Press the two clips down and pull
the pre-filter towards you (fig.e).
4 Put the unpacked air purification
filters back into the appliance
(fig.f).
5 Put the pre-filter back into the
appliance (fig.g).
Note
• Make sure that the side with the two
clips is pointing towards you, and that
all hooks of the pre-filter are properly
attached to the purifier.
6 To reattach the front panel, mount
the panel onto the top of the
appliance first (1). Then, gently push
the panel against the body of the
appliance (2) (fig.h).

7EN
English
»For AC2882, after measuring the
particle matters in the air, the
appliance goes to auto mode
with displayed on the screen
(fig.k).
3 Touch and hold for 3 seconds to
switch off the appliance.
Note
• After the appliance is switched off by
the on/off button , if the plug is still
in the power socket, the appliance will
operate under the previous settings
when it is switched on again.
Changing the Auto mode
setting
You can choose the Pollution mode
( ), the Allergen mode ( ) and the
Bacteria&Virus mode ( ).
Pollution mode
The specially designed pollution
mode can effectively remove airborne
pollutants such as pm2.5.
• Touch the Auto mode button to
select the Pollution mode (fig.k).
»Auto (A) and display on the
screen.
Allergen mode
The specially designed allergen mode
can effectively remove common
allergens such as pollen and pet
dander.
• Touch the Auto mode button to
select the Allergen mode (fig.l).
»Auto (A) and display on the
screen.
Bacteria&Virus mode
The specially designed bacteria&virus
mode can effectively remove bacteria
& viruses such as staphylococcus albsp
and H1N1.
• Touch the Auto mode button
to select the Bacteria&Virus mode
(fig.m).
»Auto (A) and display on the
screen.
Changing the fan speed
There are several fan speeds available.
You can choose the sleep mode (SL),
speed 1, 2, 3 or turbo mode (t).
Sleep (SL)
In sleep mode, the appliance operates
quietly under very low speed.
• Touch the fan speed button to
select the sleep mode (SL) (fig.n).
Note
• In sleep mode, "SL" displays on the
screen for one minute. After that,all the
lights will go off and the display screen
will be dimmed with" " displayed.
• You can turn on the lights manually by
touching .
Manual
• Touch the fan speed button
repeatedly to select the fan speed
you need (fig.p).
Turbo (t)
In turbo mode, the appliance operates
under the highest speed.
• Touch the fan speed button to
select the turbo mode (t) (fig.o).

8EN
Setting the timer
Note
• The timer function is only applicable
for AC2887.
With the timer, you can let the
appliance operate for a set number of
hours. When the set time has elapsed,
the appliance will automatically switch
off.
• Touch the timer button
repeatedly to choose the number
of hours you want the appliance to
operate (fig.q).
»The timer is available from 1 to
12 hours.
To deactivate the timer, touch the timer
button repeatedly until "---"displays
on the screen.
Note
• If you have set the timer once, next
time when you use the timer, it starts
from the previous setting time.
Using the light on/o
function
Note
• The light dimming function is only
applicable for AC2887.
With the light dimming button, you can
switch on or off the air quality light,
the display screen and the function
indicators if needed.
1 Touch the light dimming button
once, the air quality light will be
dimmed.
2 Touch the light dimming button
again, the air quality light will go off.
The display screen and the function
indicators will still be on, but the
lights will be dimmed with " "
displayed on the screen.
3 Touch the light dimming button
for the third time, all lights will be on
again.

9EN
English
5 Cleaning
Note
• Always unplug the appliance before
cleaning.
• Never immerse the appliance in water
or any other liquid.
• Never use abrasive, aggressive, or
flammable cleaning agents such as
bleach or alcohol to clean any part of
the appliance.
• Only the pre-filter is washable. The air
purification filter is not washable nor
vacuum cleanable.
Cleaning schedule
Frequency Cleaning method
When necessary
Wipe the surface
of the appliance
with a soft dry
cloth
When F0
displays on the
screen
Clean the
pre-filter
Every two
months
Clean the air
quality sensors
Cleaning the body of the
appliance
Regularly clean the inside and outside
of the appliance to prevent dust from
collecting.
1 Wipe away dust with a soft dry cloth
from the body of the appliance.
2 Clean the air outlet with a soft dry
cloth.
Cleaning the air quality
sensor
Clean the air quality sensor every
2 months for optimal functioning of the
purifier. Clean them more frequently
if you use the purifier in a dusty
environment.
Note
• When the humidity level in the
room is very high, it is possible that
condensation develops on the air
quality sensor. As a result, the air
quality light may indicate that the air
quality is bad even though it is good.
In this case you have to clean the
air quality sensor or use one of the
manual speed settings.
1 Clean the air quality sensor inlet
and outlet with a soft brush (fig.r).
2 Remove the air quality sensor cover
(fig.s).
3 Clean the air quality sensor, the
dust inlet and the dust outlet with
a lightly moistened cotton swab
(fig.t).
4 Dry them with a dry cotton swab.
5 Reattach the air quality sensor
cover (fig.u).
Cleaning the pre-lter
(g.v)
Filter alert light
status
Follow this
F0 displays on the
screen
Clean the pre-
filter

10 EN
6 Replacing the
filter
Understanding the
healthy air protect lock
This appliance is equipped with the
healthy air protect lock to make sure
that the air purification filter is in
optimal condition when the appliance
is operating. When the filters are almost
expired, the filter code displays on the
screen to indicate that you need to
replace the filters.
If the filters are not replaced in 14 days,
the appliance will stop operating and
get locked.
Replacing the lters
(g.y)
Note
• The air purification filters are not
washable nor vacuum cleanable.
• Switch off the appliance before
replacing the filters.
1 Pull the bottom part of the front
panel to remove it from the
appliance (fig.d).
2 Press the two clips down and pull
the pre-filter towards you (fig.e).
3 Wash the pre-filter under a running
tap. If the pre-filter is very dirty, use
a soft brush to brush away the dust
(fig.w).
4 Air dry the pre-filter.
Note
• Make sure that the pre-filter is
completely dry. If it is still wet, bacteria
may multiply in it and shorten the
lifetime of the pre-filter.
• Cleanse your hands after changing the
filter.
5 Put the pre-filter back into the
appliance (fig.g).
Note
• Make sure that the side with the two
clips is pointing towards you, and that
all hooks of the pre-filter are properly
attached to the purifier.
6 To reattach the front panel, mount
the panel onto the top of the
appliance first (1). Then, gently push
the panel against the body of the
appliance (2) (fig.h).
7 Touch and hold the reset button
for 3 seconds to reset the pre-filter
cleaning time (fig.x).

11EN
English
Filter alert light
status
Follow this
A3 displays on the
screen
Replace the
NanoProtect filter
HEPA Series 3
(FY2422)
C7 displays on the
screen
Replace the
NanoProtect filter
AC (FY2420)
A3 and C7 display
on the screen
alternately
Replace both
filters
1 Take out the expired air purification
filter according to the filter code
displayed on the screen, and gently
put the expired filter into the trash
bin (fig.z).
Note
• Do not touch the pleated filter surface,
or smell the filters as they have
collected pollutants from the air.
2 Remove all packaging material of
the new filters (fig.c).
3 Place the new filters into the
appliance (fig.f).
4 Touch and hold the reset button
for 3 seconds to reset the filter
lifetime counter (fig.{).
Note
• Cleanse your hands after changing the
filter.
Filter force reset
1 Touch and simultaneously
for 3 seconds to enter the filter force
reset mode (fig.|).
»Code (A3) of the NanoProtect
filter HEPA Series 3 displays on
the screen.
2 Touch and hold for 3 seconds to
force reset the filter lifetime of the
NanoProtect filter HEPA Series 3
(fig.{).
3 Code (C7) of the NanoProtect filter
AC displays on the screen after the
lifetime of the NanoProtect filter
HEPA Series 3 has been reset(fig.}).
4 Touch and hold for 3 seconds to
force reset the filter lifetime of the
NanoProtect filter AC and exit the
filter force reset mode (fig.~).
Filter type change
1 Touch and simultaneously
for 3 seconds to enter the filter type
change mode (fig.|).
»Code (A3) of the NanoProtect
filter HEPA Series 3 displays on
the screen.
2 Touch to select the filter code of
the new filter you will use (fig.).
3 Touch and hold for 3 seconds to
confirm the filter code of the new
filter (fig.€).
Note
• After you have selected the filter code
of the new filter using the button,
if you do not touch any other buttons
in 10 seconds, the appliance will
automatically confirm the filter code of
the new filter.
4 Code (C7) of the Nanoprotect
filter AC displays on the screen
after the first filter type has been
changed(fig.}).
5 Touch to select the new filter
code of the second filter (fig.).
6 Touch and hold for 3 seconds
to confirm the filter code of the

12 EN
second filter and exit the filter type
change mode (fig.‚).
Note
• After you have selected the filter code
of the new filter using the button,
if you do not touch any other buttons
in 10 seconds, the appliance will
automatically confirm the filter code of
the new filter.
Note
• Refer to the separate leaflet that comes
with the filter for more information on
different filter combinations for your
choice.

13EN
English
7 Troubleshooting
This chapter summarizes the most common problems you could encounter with the
appliance. If you are unable to solve the problem with the information below, contact
the Consumer Care Center in your country.
Problem Possible solution
The appliance
does not work
even though it is
plugged in.
• The filter replacement code has been displaying on the
screen but you have not replaced the corresponding filter
yet. The appliance will be locked if you keep using the
expired filter. In this case, replace the filter and reset the
filter lifetime counter.
The appliance
does not work
even though it is
switched on.
• The filter replacement code has been on continuously but
you have not replaced the corresponding filter, and the
appliance is now locked. In this case, replace the filter and
reset the filter lifetime counter.
The appliance
accidentally
powers o.
• The appliance restarts automatically and goes to the
previous mode when the power resumes.
The airow that
comes out of
the air outlet
is signicantly
weaker than
before.
• The pre-filter is dirty. Clean the pre-filter (see chapter
"Cleaning").
The air quality
does not improve,
even though the
appliance has
been operating for
a long time.
• One of the filters has not been placed in the appliance.
Make sure that all filters are properly installed in the
following order, starting with the innermost filter:
1) NanoProtect filter HEPA Series 3; 2) pre-filter.
• The air quality sensor is wet. The humidity level in your
room is high and causes condensation. Make sure that the
air quality sensor is clean and dry (see chapter "Cleaning").
The color of the air
quality light always
stays the same.
• The air quality sensor is dirty. Clean the air quality sensor
(see chapter "Cleaning").

14 EN
Problem Possible solution
The appliance
produces a strange
smell.
• The first few times you use the appliance, it may produce
a plastic smell. This is normal. However, if the appliance
produces a burnt smell even if removing filters, contact
your Philips dealer or an authorized Philips service center.
The appliance may also produce an unpleasant smell
when the filter is dirty. In this case, clean or replace the
filter concerned.
The appliance is
extra loud.
• If the appliance is too loud, you can change the fan speed
to a lower fan speed level. When using the appliance in a
bedroom at night, choose the sleep mode.
The appliance still
indicates that I
need to replace a
lter, but I already
did.
• Perhaps you did not reset the filter lifetime counter. Plug
in the appliance, touch to switch on the appliance, and
touch and hold the reset button for 3 seconds.
Error codes "E1",
"E2", "E3" or "E4"
displays on the
screen.
• The appliance has malfunctions. Contact the Consumer
Care Center in your country.

15EN
English
9 Notices
Electromagnetic elds
(EMF)
This Philips appliance complies with all
applicable standards and regulations
regarding exposure to electromagnetic
fields.
Compliance with EMF
Philips Domestic Appliances Holding
B.V. manufactures and sells many
products targeted at consumers, which,
like any electronic apparatus, in general
have the ability to emit and receive
electromagnetic signals.
One of Philips' leading Business
Principles is to take all necessary health
and safety measures for our products,
to comply with all applicable legal
requirements and to stay well within the
EMF standards applicable at the time of
producing the products.
Philips is committed to develop,
produce and market products that
cause no adverse health effects. Philips
confirms that if its products are handled
properly for their intended use, they
are safe to use according to scientific
evidence available today.
Philips plays an active role in the
development of international EMF
and safety standards, enabling Philips
to anticipate further developments in
standardization for early integration in
its products.
8 Guarantee and
service
If you need information or if you have a
problem, please visit the Philips website
at www.philips.com or contact the
Philips Consumer Care Center in your
country (you find its phone number
in the worldwide guarantee leaflet). If
there is no Consumer Care Centre in
your country, go to your local Philips
dealer.
Order parts or
accessories
If you have to replace a part or want to
purchase an additional part, go to your
Philips dealer or visit www.philips.com/
support.
If you have problems obtaining the
parts, please contact the Philips
Consumer Care Center in your country
(you can find its phone number in the
worldwide guarantee leaflet).

16 EN
Recycling
Do not throw away the product with
the normal household waste at the
end of its life, but hand it in at an
official collection point for recycling.
By doing this, you help to preserve the
environment.
Follow your country's rules for the
separate collection of electrical and
electronic products. Correct disposal
helps prevent negative consequences
for the environment and human health.

17TH
ภาษาไทย

1  35
 35
2  37
 ( a)37
 ( b) 37
3  38
 38
4  38
 38
 38
 39
 39
 40
/ 40
5  40
 40
 40

 41

( v) 41
6  42
 42
 ( y) 42
 42
 43
7  44
8  46
 46
9  46
 (EMF) 46
 46

18 TH
1 




• 

 
/
•   
 ()
 
/

•   
 


• 



•  
 Philips, 
 Philips 
 


•  
 
•  8  

 

 



 


• 

• 



• 
 
 


• 
 
 

• 
  

• 
 20 .
 30 .
•  

