Philips ColorDial Pro User manual

ColorDial PRO
Designed in the USA, Made in China.
ColorDial Pro Installation Instructions
Instructions d’installation
Installationsanweisungen
Instrucciones de instalación
Istruzioni per l’installazione
Installatie-instructies
インストール手順
安装指示
A Must be installed by a qualified electrician in
accordance with all national and local electrical and
construction codes and regulations.
Doit être installé par un électricien qualifié conformément aux codes et
réglementations électriques nationaux et locaux du bâtiment.
Muss von einem geprüften Elektriker in Übereinstimmung mit allen
nationalen und örtlichen elektrischen Codes und Regelungen installiert
werden.
La instalación debe realizarla un electricista calificado siguiendo todos
los códigos y normativas eléctricas y de construcción, tanto nacionales
como locales.
Devono essere installati da un elettricista qualificato in conformità con
le norme locali e nazionali vigenti in materia di costruzioni edilizie e
installazione di impianti elettrici.
Moet door een gekwalificeerd elektricien overeenkomstig alle nationale
en lokale elektrische verordeningen worden geïnstalleerd.
国または地域の建築コードおよび規制にすべて従い、資格のある電
気技師が設置してください。
必须根据所有国家和地方的电气和施工准则及规范，由符合资格的
电工进行安装。
Ewww.colorkinetics.com/support
PUB-000243-00 R03
Wire cable into junction box
Câblez à la boîte de dérivation
Spannen Sie das Kabel in die Abzweigdose
Conecte el cable a la caja de conexiones
Collegare il cavo nella scatola di giunzione
Sluit kabel aan op kabeldoos
ケーブルをジャンクションボックスに配 線します。
将电缆接入接线盒
Confirm all components received
Confirmez la réception de l’intégralité des composants
Bestätigen Sie, dass Sie alle Bestandteile erhalten haben
Compruebe si ha recibido todos los componentes
Confermare tutti i componenti ricevuti
Controleer alle ontvangen componenten
すべてのコンポーネントが揃っていることを確認します。
确认收到了所有部件
Connect
Brancher
Verbinden
Conecte
Effettuare il collegamento
Verbinden
接続
连接
CAT 5e

2 ColorDial Pro Installation Instructions
POE
IEEE 802.3af COMPLIANT
ETHERNET SWITCH
(PoE Port)
ETHERNET SWITCH
IEEE 802.3af
COMPLIANT
SINGLE PORT
INJECTOR
IN
OUT
< 100 m (328 ft)
ColorDial PRO
Designed in the USA, Made in China.
Designed in the USA, Made in China.
< 100 m (328 ft)
ColorDial PRO
Connect to IEEE 802.3af compliant Ethernet switch or…
Branchez au commutateur Ethernet de norme IEEE 802.3af ou…
An einen IEEE 802.3af-konformen Ethernet-Switch anschließen oder...
Conéctelo con el interruptor Ethernet en cumplimiento con IEEE 802.3af o…
Effettuare il collegamento allo switch Ethernet conforme allo standard IEEE 802.3af oppure…
Verbind met IEEE 802.3af compatibele Ethernet Switch of…
IEEE 802.3afに適合したEthernetスイッチ、または
连接到符合 IEEE 802.3af 标准的以太网交换器或…
POE
IEEE 802.3af COMPLIANT
ETHERNET SWITCH
(PoE Port)
ETHERNET SWITCH
IEEE 802.3af
COMPLIANT
SINGLE PORT
INJECTOR
IN
OUT
< 100 m (328 ft)
ColorDial PRO
Designed in the USA, Made in China.
Designed in the USA, Made in China.
< 100 m (328 ft)
ColorDial PRO
…connect to IEEE 802.3af compliant Power over Ethernet Injector and Ethernet switch.
…à l’injecteur de puissance Ethernet (PoE) et au commutateur Ethernet de norme IEEE 802.3af
…an einen IEEE 802.3af-konformen Power-over-Ethernet-Injektor und Ethernet-Switch anschließen
…conéctelo con la alimentación del inyector Ethernet y el interruptor Ethernet en cumplimiento con IEEE 802.3af
…effettuare il collegamento allo switch Ethernet o all’iniettore Power over Ethernet conforme allo standard IEEE 802.3af
…verbind met IEEE 802.3af compatibele Power over Ethernet Injector en Ethernet Switch
…IEEE 802.3afに適合したPower over Ethernet InjectorとEthernetスイッチに接続
…连接到符合 IEEE 802.3af 标准的以太网供电馈电器和以太网交换器

ColorDial Pro Installation Instructions 3
Attach faceplate to ColorDial Pro
Fixez la plaque frontale sur ColorDial Pro
Befestigen Sie die Abdeckung an dem ColorDial
Pro-Gerät
Sujetar la tapa al ColorDial Pro
Collegare il coperchio ColorDial Pro
Verbind frontplaat met ColorDial Pro
表面カバーを ColorDial Pro に取り付けます
将面板连接到 ColorDial Pro
Mount ColorDial Pro to junction box Montez le ColorDial Pro à la boîte de dérivation
Befestigen Sie das ColorDial Pro an der Abzweigdose Monte ColorDial Pro en la caja de conexiones
Montare il ColorDial Pro alla scatola di giunzione Bevestig ColorDial Pro aan de kabeldoos
ColorDial Proをジャンクションボックスに マウントします。 将键盘安装到接线盒
Configure
Congurez
Kongurieren
Congurar
Congurare
Congureer
設定します
配置
PoE Injector
IN
OUT
Ethernet Switch
ColorDial Pro
Data Enabler Pro
PoE Port
Ethernet Switch
POE
iColor Cove MX Powercore fixtures
ColorDial Pro
Data Enabler Pro
iColor Cove MX Powercore fixtures

4 ColorDial Pro Installation Instructions
BDo not attempt to install or use until you read
and understand the installation instructions and safety
labels.
Assurez-vous d’avoir lu et compris les instructions d’installation et les
autocollants de sécurité avant l’installation ou l’utilisation.
Installieren oder verwenden Sie einen Beleuchtungskörper erst,
nachdem Sie die Installationsanweisungen und Sicherheitsetiketten
gelesen haben.
No intente instalar ni utilizar hasta haber leído y comprendido las
instrucciones de instalación y las etiquetas de seguridad.
Non installare o utilizzare se non sono state lette e comprese le
istruzioni per l’installazione e le etichette di sicurezza.
Voer geen poging uit tot installeren of gebruik totdat u de installatie-
instructies en veiligheidslabels hebt gelezen en begrepen.
設置手順と安全ラベルの内容を読み、理解してから設置または使
用を始めてください。
请先阅读并理解安装说明和安全标签，再进行安装或使用。
BDo not use if the product housing or power cables
are damaged.
N’utilisez pas l’appareil si le boîtier ou des câbles d’alimentation sont
endommagés.
Nicht verwenden, wenn das Produktgehäuse oder die Netzkabel
beschädigt sind.
No utilice el producto si la carcasa o los cables de alimentación están
dañados.
Non utilizzare se l’alloggiamento del prodotto o i cavi di
alimentazione sono danneggiati.
Niet gebruiken indien de behuizing of stroomkabels zijn beschadigd.
製品のハウジング、または電源ケーブルが損傷している場合は、使
用しないでください。
如果产品的灯壳或电缆受损，切勿使用。
BDo not modify or alter the product. Doing so will
void the warranty.
Ne transformez pas et ne modifiez pas le produit.Toute modification
annule la garantie.
Nehmen Sie keineVeränderungen an dem Produkt vor.
Nichtbeachtung entwertet die Garantie.
No modifique ni altere el producto. Si lo hace, se anulará la garantía.
Non modificare né alterare il prodotto, in caso contrario la garanzia
verrà invalidata.
Wijzig of verander niets aan het product. Hierdoor zal de garantie
vervallen.
製品を改ざんしたり、変造したりしないでください。改ざんや変造
を行うと、 保証が無効になります。
切勿修改或更改产品。否则将使质保失效。
C This equipment has been tested and found to comply with
the limits for a Class A digital device, pursuant to Part 15 of
the FCC Rules.These limits are designed to provide reasonable
protection against harmful interference when the equipment is
operated in a commercial environment.This equipment gener-
ates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instruction manual,
may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to
cause interference in which case the user will be required to
correct the interference at his own expense.
CThis Class A digital apparatus complies with Canadian
ICES-003. Cet appareil numerique de la classe A est
conforme a la norme NMB-003 du Canada.
CWarning - This is a class A product. In a domestic
environment this product may cause radio frequency
interference in which case the user may be required to take
adequate measures.
CThis device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions: (1)
this device may not cause harmful interference, and (2) this
device must accept any interference received, including inter-
ference that may cause undesired operation.
C声明
此为A级产品,在生活环境中,该产品可能会造成无线电
干扰.在这种情况下,可能需要用户对其它干扰采取切实
可行的措施.
