Philips Selecon PL3 LED Luminaires Instruction Manual

Philips Selecon Offices
The material in this manual is for information purposes only and is subject to change without notice. Philips
Selecon assumes no responsibility for any errors or omissions which may appear in this manual. For comments and
suggestions regarding corrections and/or updates to this manual, please visit the Philips Selecon web site at
www.seleconlight.com or contact your nearest Philips Selecon office.
El contenido de este manual es solamente para información y está sujeto a cambios sin previo aviso. Philips
Selecon no asume responsabilidad por errores o omisiones que puedan aparecer. Cualquier comentario, sugerencia
o corrección con respecto a este manual, favor de dirijirlo a la oficina de Philips Selecon más cercana.
Der Inhalt dieses Handbuches ist nur für Informationszwecke gedacht, Aenderungen sind vorbehalten. Philips
Selecon uebernimmt keine Verantwortung für Fehler oder Irrtuemer, die in diesem Handbuch auftreten. Für
Bemerkungen und Verbesserungsvorschlaege oder Vorschlaege in Bezug auf Korrekturen und/oder
Aktualisierungen in diesem Handbuch, moechten wir Sie bitten, Kontakt mit der naechsten Philips Selecon-
Niederlassung aufzunehmen.
Le matériel décrit dans ce manuel est pour information seulement et est sujet à changements sans préavis. La
compagnie Philips Selecon n'assume aucune responsibilité sur toute erreur ou ommission inscrite dans ce manuel.
Pour tous commentaires ou suggestions concernant des corrections et/ou les mises à jour de ce manuel, veuillez s'il
vous plait contacter le bureau de Philips Selecon le plus proche.
Note: Information contained in this document may not be duplicated in full or in part by any person without prior written
approval of Philips Selecon. Its sole purpose is to provide the user with conceptual information on the equipment mentioned. The
use of this document for all other purposes is specifically prohibited.
Document Number: 02.9693.0001 A
Version as of: 25 August 2011
PL3 LED Luminaire Installation & User’s Manual
©2011 Philips Group. All rights reserved.
Philips Selecon - Dallas
10911 Petal Street
Dallas, TX 75238
Tel: [phone]
Fax: [phone]
Philips Selecon - Auckland
19-21 Kawana Street
Northcote, Auckland 0627
New Zealand
Tel: [phone]
Fax: [phone]
Philips Selecon - New York
267 5th Ave, 4th Floor
New York, NY 10016
Tel: [phone]
Fax: [phone]
Philips Selecon - Europe
Marssteden 152
Enschede 7547 TD
The Netherlands
Tel: [phone]
Fax: [phone]
Philips Selecon - Asia Limited
Room 6-10, 20/F Delta House 3 On Yiu Street
Shatin, N.T. Hong Kong
Tel: + 852 2757 3033
Fax: + 852 2757 1767
Website:
www.seleconlight.com

1
PL3 LED Luminaires Installation & User’s Manual
IMPORTANT INFORMATION
Warnings and Notices
Additional Resources for DMX512
For more information on installing DMX512 control systems, the following publication is available for purchase
from the United States Institute for Theatre Technology (USITT), "Recommended Practice for DMX512: A Guide
for Users and Installers, 2nd edition" (ISBN: 9780955703522). USITT Contact Information:
USITT
315 South Crouse Avenue, Suite 200
Syracuse, NY 13210-1844
Phone: [phone] or [phone]
www.usitt.org
Philips Selecon Limited Three-Year Warranty
Philips Selecon offers a three-year limited warranty of its luminaires against defects in materials or workmanship
from the date of delivery. A copy of Philips Selecon three-year limited warranty containing specific terms and
conditions can be obtained from the Philips Selecon web site at www.seleconlight.com or by contacting your local
Philips Selecon office.
PL3’s powerful LED engine offers exceptional performance and life. Under normal operating conditions, our LED
engine has a life expectancy in excess of 25,000 hours, however under worst case operating conditions with the
luminaire set to continuous full output it is possible that a small percentage of LED’s may require replacement
sooner. The Philips Selecon three-year limited warranty includes our guarantee against premature failure of the
LED engine.
When using electrical equipment, basic safety precautions should always be followed including the following:
a. READ AND FOLLOW ALL SAFETY INSTRUCTIONS.
b. For indoor, dry locations use only. Do not use outdoors.
c. Do not mount near gas or electric heaters.
d. Equipment should be mounted in locations and at heights where it will not readily be subjected to
tampering by unauthorized personnel.
e. The use of accessory equipment not recommended by the manufacturer may cause an unsafe
condition.
f. Not for residential use. Do not use this equipment for other than intended use.
g. Refer service to qualified personnel.
SAVE THESE INSTRUCTIONS.
WARNING: This equipment is intended for installation in accordance with the National Electric
Code® and local regulations. It is also intended for installation in indoor applications only. Before
any electrical work is performed, disconnect power at the circuit breaker or remove the fuse to avoid
shock. It is recommended that a qualified electrician perform this installation.

Installation & User’s Manual PL3 LED Luminaires
2TABLE OF CONTENTS
TABLE OF CONTENTS
Philips Selecon Offices........................................................................................................................... Inside Front Cover
IMPORTANT INFORMATION
Warnings and Notices......................................................................................................................................................... 1
Additional Resources for DMX512.................................................................................................................................... 1
Philips Selecon Limited Three-Year Warranty .................................................................................................................. 1
TABLE OF CONTENTS
PREFACE
About this Manual ...................................................................................................................................................................... 3
ACCESSORIES.......................................................................................................................................................................... 3
PL3 LED LUMINAIRE OVERVIEW
PL3 LED Luminaire Components.............................................................................................................................................. 4
Luminaire Components....................................................................................................................................................... 4
LCD Display / Menu........................................................................................................................................................... 4
INSTALLATION AND SET UP
Power Requirements................................................................................................................................................................... 5
Connecting Power....................................................................................................................................................................... 5
Connecting to the DMX512 Network......................................................................................................................................... 5
Mounting..................................................................................................................................................................................... 6
Pan & Tilt Adjustments .............................................................................................................................................................. 7
OPERATION AND PROGRAMMING
User Interface.............................................................................................................................................................................. 8
Function Keys............................................................................................................................................................................. 9
Fixture Status Screens................................................................................................................................................................. 9
Menu Options ........................................................................................................................................................................... 10
Menu Structure ................................................................................................................................................................. 10
Security..................................................................................................................................................................................... 12
Passwords.......................................................................................................................................................................... 12
Security Levels ................................................................................................................................................................. 13
Locking Fixture................................................................................................................................................................. 13
Presets....................................................................................................................................................................................... 13
Presets Types .................................................................................................................................................................... 13
Editing Preset Names........................................................................................................................................................ 14
Settings...................................................................................................................................................................................... 14
DMX CONTROL
16-Bit Mode.............................................................................................................................................................................. 16
Pan & Tilt DMX Operation Notes.................................................................................................................................... 18
8-Bit Mode................................................................................................................................................................................ 19
DMX 3-Channel (3-Chan) Mode.............................................................................................................................................. 21
Lighting Console Settings for Preset White ............................................................................................................................. 22
PL3 Luminaire DMX Timing Channel Detail.......................................................................................................................... 22
INFRARED REMOTE CONTROL
Infrared Remote Control Overview.......................................................................................................................................... 28
Infrared Remote Control Features .................................................................................................................................... 28
CLEANING AND CARE
Special Cleaning and Care Instructions.................................................................................................................................... 30
Lens Cleaning ........................................................................................................................................................................... 30
Front Lens (Exterior) ........................................................................................................................................................ 30
Service and Maintenance.......................................................................................................................................................... 31
Accessories ............................................................................................................................................................................... 31
TROUBLESHOOTING
Troubleshooting Guide ............................................................................................................................................................. 32
TECHNICAL SPECIFICATIONS
PL3 LED Luminaire Specifications.......................................................................................................................................... 33
PL3 LED Luminaire Dimensions ............................................................................................................................................. 33

About this Manual 3
PL3 LED Luminaires Installation & User’s Manual
PREFACE
1. About this Manual
The document provides installation and operation instructions for the following products:
• PL3 LED Luminaires (part number: PL3)
Please read all instructions before installing or using this product. Retain this manual for future reference. Additional
product information and descriptions may be downloaded at www.seleconlight.com.
Note: All PL3 luminaires ship with a "bare-end" 39 inch/1 meter power input cable. Add -GR, -GP, or -GTL to the
part number to have a connector installed. All other accessories sold separately.
Product accessories can be found in "ACCESSORIES".
2. ACCESSORIES
Contact your Authorized Philips Selecon Dealer for price and availability of all accessories for PL3 LED Luminaires.
Additional information can be found on the Philips Selecon web site at www.seleconlight.com.
PL3 LED Luminaire IR Remote
PL3 LED Luminaire Pan & Tilt Motor Kit / Clamps
Note: Do Not install the PL3 LED Luminaire using C-Clamp (82019 or USCLAMP). This Luminaire requires the
longer bolt utilized in clamps Molded Yoke Rated C-Clamp (SC) or Mega Claw (MC).
PL3 LED Luminaire Barndoors & Holders
PL3 LED Luminaire Connectors
PL3 LED Luminaire Spare Power Input Cables
Part Number Description
PL3IRR PL3 LED Luminaire Handheld IR Preset Programmer
Part Number Description
PL3MKIT Pan & Tilt Motor Kit (note, includes all hardware, wiring and truss hook)
SC Selecon Molded Yoke Rated C-Clamp
MC Mega Claw, Black Anodized
Part Number Description
PL3ACH PL3 LED Luminaire Accessory Holder with Frame
20BDSF2020 Barndoor, Black
20BDSF20208 Barndoor, 8 Way, Black
20CFSF2020 Spare Color Frame
Part Number Description
GR 15A NEMA 5-15P Male Edison Connector
GP 20A, Male Stage Pin Connector
GTL 20A, NEMA L5-20P Male Twist-Lock Connector
Part Number Description
PL3BE PL3 Luminaire AC Power Input Cable (39 inches / 1 meter), Powercon (luminaire AC in) with no
connector (bare end - user to supply connector)
PC1GP PL3 Luminaire AC Power Input Cable (39 inches / 1 meter), Powercon (luminaire AC in) with Stage
Pin Connector (to power source)
PC1GTL PL3 Luminaire AC Power Input Cable (39 inches / 1 meter), Powercon (luminaire AC in) with
Twistlock Connector (to power source)
PC1GR PL3 Luminaire AC Power Input Cable (39 inches / 1 meter), Powercon (luminaire AC in) with Edison
Connector (to power source)

Installation & User’s Manual PL3 LED Luminaires
4PL3 LED LUMINAIRE OVERVIEW
PL3 LED LUMINAIRE OVERVIEW
1. PL3 LED Luminaire Components
Luminaire Components
WARNING! The PL3 luminaire produces heat. At an ambient temperature of 22oC, the exterior (rear metal grill) of
the luminaire reaches 51oC after 5 minutes; 55oC at steady state. In high ambient temperatures, the luminaire
temperature will be higher. Handle with care.
LCD Display / Menu
1) LCD Display Menu (see "LCD Display /
Menu" on page 4 for more information)
2) Lens (Head) Assembly
3) Tilt Locking Knob
4) Yoke Assembly
5) DMX512 In/Out Connections (see detail)
6) Power Input Connection (PowerCon)
4
AC Input Power and DMX512 In / Out Connections
5
3
6
1
2
Product Label (on yoke assembly)
MENU
OK
INTENSITY FOCUS
PRESET
ESC
Pan/Tilt
1) LCD Display (Menu System)
2) Menu Navigation Buttons
3) Function (Menu System) Select Push
Buttons / Intensity / Luminaire Focus /
Preset Buttons
1
Note: For Menu operation and programming
details, refer to "User Interface" on page 8.
2 3

Power Requirements 5
PL3 LED Luminaires Installation & User’s Manual
INSTALLATION AND SET UP
1. Power Requirements
The PL3 LED Luminaire operates on 120 to 240 volts AC (+/- 10%, auto-ranging). The luminaire contains an auto-
ranging power supply. Depending on supply voltage, each luminaire can draw up to 4.60 amps.
2. Connecting Power
If the unit is supplied with an AC input cable (PL3BE), Table 1 describes how to connect power to your PL3 LED
Luminaire. Field wiring of the PL3 LED Luminaire is straight forward. A total of 3 wires/conductors need to be
brought to the unit. For detailed power specifications, see "PL3 LED Luminaire Specifications" on page 33. The
following wiring scheme is required:
Table 1: PL3 LED Luminaire AC Input Connections
3. Connecting to the DMX512 Network
Basic DMX512 installation consists of connecting multiple PL3 LED Luminaires together in "daisy-chain" fashion.
A cable runs from the control console (or DMX512 control source) to the DMX connector on the first PL3 LED
Luminaire. Another cable runs from the other DMX connector on the first unit to a DMX connector on the next PL3
LED Luminaire (or DMX512 device to be controlled).
Note: For more information on DMX512 networking and systems, refer to "Additional Resources for DMX512" on
page 1. For PL3 LED Luminaire DMX Mapping, refer to "DMX CONTROL" on page 16.
Wire Color Purpose
Brown Main / Line (120 to 240VAC)
Blue Neutral
Green/Yellow Ground / Earth
DMX512
DMX512 (out from first
to second luminaire)
PL3 LED Luminaires
DMX512 Connections
Note: Remaining pins on each connector are not used.
DMX512 Signal XLR Pin
Common (Drain) 1
DMX512 - 2
DMX512 + 3
(from console or
control device)
DMX512 (out to the next luminaire or
DMX512 controlled device)

Installation & User’s Manual PL3 LED Luminaires
6INSTALLATION AND SET UP
4. Mounting
PL3 LED Luminaires offer a plastic monocoque yoke design for mounting by theatrical clamps or hooks (sold
separately).
Note: Do Not install the PL3 LED Luminaire using C-Clamp (82019 or USCLAMP). This Luminaire requires the
longer bolt utilized in clamps Molded Yoke Rated C-Clamp (SC) or Mega Claw (MC).
WARNING! Before attempting any installation or service, disconnect all power at power source. Turning off the
luminaire does not disconnect power. Installation and service should only be performed by trained and qualified
personnel. You must follow local and national codes for fixture installation.
1/2-inch (13 mm) Clamp Mounting Hole. Clamp sold separately.
See “PL3 LED Luminaire Pan & Tilt Motor Kit / Clamps” chapter
WARNING! Safety cable (integrated into the luminaire handle assembly) should be used per local or
national code.
Luminaire Handle
Luminaire Handle
Rear View

Pan & Tilt Adjustments 7
PL3 LED Luminaires Installation & User’s Manual
5. Pan & Tilt Adjustments
WARNING! Before adjusting pan or tilt, the luminaire should be mounted per local and national safety codes.
To adjust tilt:
Step 1. Locate yoke lock handle, as illustrated in Figure 1, on side of yoke assembly.
Figure 1: PL3 Yoke Lock Handle
Step 2. Loosen yoke lock handle by hand.
Step 3. Position luminaire tilt (up or down) as desired.
Note: Each luminaire contains a tilt indicator near the yoke lock handle to allow setting of luminaires at same angle.
Step 4. Hand-tighten, but do not over tighten, yoke lock handle.
To adjust pan:
Step 1. Loosen, but do not remove, nut securing clamp to yoke assembly.
Step 2. Position luminaire pan (left or right) as desired.
Step 3. Retighten clamp nut.
Note: If Pan and Tilt Motors (PL3MKIT, sold separately) are installed, see "Focus Button (also for manual Pan &
Tilt control*)" on page 9 for manual control operation or "DMX CONTROL" on page 16 for DMX512 control
parameters.
Yoke Lock Handle
Yoke Assembly
Luminaire Tilt Indicator

Installation & User’s Manual PL3 LED Luminaires
8OPERATION AND PROGRAMMING
OPERATION AND PROGRAMMING
1. User Interface
The PL3 LED Luminaire’s LCD Display and Menu System provides local control for accessing all the fixture’s status
information, menu options, and settings.
Note: If there are multiple luminaires in a system, changes would need to be made at each LCD Menu as desired.
Upon power up, the LCD will display the main screen showing the product type/name. If DMX is enabled, the
programmed address will appear after power up.
Figure 2: LCD Display and Menu System
MENU
OK
INTENSITY FOCUS
PRESET
ESC
Pan/Tilt
Up/Down/Left/Right Arrow Buttons -
Navigates menu system and used for
Menu / Escape Button -
Enters menu options. Navigates
OK (Enter) Button -
Accesses details, activates
a field, or enters a setting
depending on the current menu item.
selecting and setting options.
(backs up) one menu level.
PRESET Button -
Allows the recall of
Intensity Button -
Allows the customization of
current intensity (light output).
LCD Display -
Displays all menu parameters and
option settings. Also displays DMX512
address (DMX models only).
Focus Button -
Allows adjustment of the
luminaire’s lens zoom.
stored presets.
Pan/Tilt Control Port -
(For use with PL3MKIT
- sold separately)

Function Keys 9
PL3 LED Luminaires Installation & User’s Manual
2. Function Keys
These keys provide single touch access to commonly changed parameters of the fixture.
Intensity Button
Once pressed the [UP ARROW] or [DOWN ARROW] keys can be used to change the Intensity level of the Fixture's
output. Press the [LEFT ARROW] or [RIGHT ARROW] keys to scroll between the primary colors to change their
level. Press [OK] to save, or press [ESC] to Cancel changes; and exit.
Preset Button
Once pressed a list of available Presets is displayed, use the [UP ARROW] or [DOWN ARROW] keys to scroll to the
desired Preset. The output changes to the levels stored in the Preset, as you scroll. Press [OK] to Exit and save, or
press [ESC] to Cancel selection; and exit screen.
Focus Button (also for manual Pan & Tilt control*)
Note: * The Focus Button is also used to access manual control of Pan & Tilt operation (requires installation of
PL3MKIT pan/Tilt Motor Kit - sold separately).
For manual Focus or Pan / Tilt control:
Step 1. At luminaire menu panel, press FOCUS button. Zoom Screen appears.
Step 2. Use [UP ARROW] and [DOWN ARROW] keys to switch between ZOOM, PAN, or TILT screens.
Step 3. Use [LEFT ARROW] or [RIGHT ARROW] keys to control ZOOM, PAN, or TILT settings.
Step 4. Press [OK] when adjustment is complete to exit screen.
Note: For DMX512 Control of Zoom (Beam) or Pan / Tilt operation, see "DMX CONTROL" on page 16.
3. Fixture Status Screens
To navigate the Fixture Status Screens:
Press [LEFT ARROW] or [RIGHT ARROW] keys to scroll between the available Status Screens (Note: depending
on scrolling direction Screens may appear in reverse order).
a. DMX Address (Note: If fixture is UNLOCKED, hit [OK] to change DMX address; Screen is not
displayed if DMX id disabled)
b. Fixture Hours (Displays fixture, outputting light, ON time)
c. Fixture Power (Displays Present power to the LEDs (in watts))
d. Fixture Status (Displays, Current Preset, Temperature Status, LED Status, and Fan Status)
e. Splash Screen (Displays Serial Number, Software version, and Status Icons)
Press [ESC] at anytime to access the Menu Options
Note: The default Status Screen is DMX Address, if DMX is Enabled; otherwise the Splash Screen is the Default.
To make one of the other screens the Default Screen, scroll to that screen and press [OK], a "tack" icon will appear to
the right of the Screen's Name, at the top of the screen. Press [OK] again to remove "tack" and return to default
operation.

Installation & User’s Manual PL3 LED Luminaires
10 OPERATION AND PROGRAMMING
4. Menu Options
The menu provides access to numerous Screens to control the Fixtures operation and configuration.
• Press [MENU], while at one of the Status Screens to display the Menu List.
• Use the [UP ARROW] and [DOWN ARROW] keys to select the Menu option, then press [OK] to go to that sub
screen.
• Press [ESC] to close the Menu without making a selection.
• Use the navigation keys to view and change information on the Sub Screen(s). Use [OK], or the appropriate
"screen button", to save any changes; use [ESC], or the appropriate "screen button", to cancel changes.
Note: Depending on the security settings, certain menu items may be password protected. You must enter the
PassPIN in order to access these items. Locked items will have a "Key" icon displayed next to them.
Menu Structure
Note: See "To navigate the Fixture Status Screens:" on page 9 to learn how to access menus. To save changes, hit
[OK]. Press [ESC] to cancel any changes you made.
MAIN MENU
Save as Preset
Sub Menu Options Comments
Select Preset to Save - (Option)
Scrolls and sets current user-defined
color mix to various recallable presets
in the fixture using arrow buttons.
Note: To edit a current (set) preset,
see Edit Presets.
Off Users can:
• Save the current settings (look) to
a specific recallable Preset in the
fixture’s memory.
• Edit the levels (values) for Red,
Green, Blue, White, and Intensity
values (in percent%) by using the
arrow buttons. Once the values
are adjusted, the preset is saved
as desired.
*Only intensities may be stored on
White Color Temperature presets.
RGBW in these presets cannot be
edited or changed.
Scratch Pad
Warm White*
Cool White*
Day Light*
Preset X (5 through 31)
Continued next page

Menu Options 11
PL3 LED Luminaires Installation & User’s Manual
Menu Structure (continued)
Edit a Preset
Sub Menu Options Comments
Select Preset to Edit - (Option)
Selects a current preset and outputs
the preset, so preset can be edited.
Note: To save a specific look of the
fixture, see Save Presets.
Off Users can:
• Edit the current settings (look) to a
specific recallable Preset in the fix-
ture’s memory.
• Edit the values for Red, Green,
Blue, White, and Intensity values
(in percent%) by using the arrow
buttons.
• Once the values are adjusted, the
"Save Preset" menu option
appears to save the edits.
NOTES:
*Only intensities may be stored on
White Color Temperature presets.
RGBW in these presets cannot be
edited or changed.
**If a Calibrated Preset's Color Mix is
changed (5 thru 25), an asterisk '*' is
appended to the end of the name to
indicate that it has been modified.
This only happens if the name
matches the original calibrated name,
stored in EEPROM. This does not
happen if the Intensity is changed,
only the color mix.
Scratch Pad
Warm White*
Cool White*
Day Light*
Preset X (5 through 31)**
Color Mix
Sub Menu Options Comments
Select Color or Intensity to Adjust -
(Option)
Red
Users can:
• Edit Red, Green, Blue, White, and
Intensity values (in percent%) by
using the arrow buttons.
• Once the values are adjusted,
press [OK] to save the edits.
Green
Blue
White
Intensity
Continued next page
Continued from previous page
Fan Control
Sub Menu Options Comments
Select and Set Fan Speed - (Option)
Note, hit Cancel to cancel any
changes you made.
Max Highlight "Max" button and hit [OK] button on menu. Sets the maximum
speed of the fan.
Level
Level sets the fan toa constant speed
(will not vary). Adjust level (on fan
speed level bar) using Left and Right
arrow buttons, highlight "Level" button
in menu, and hit [OK] on menu to use
user-defined level.

Installation & User’s Manual PL3 LED Luminaires
12 OPERATION AND PROGRAMMING
Menu Structure (continued)
5. Security
Unwanted changes to the Fixture's Configuration or Setting can be controlled by setting a security level, or Locking
the Fixture. Three levels of security are available in addition to completely Locking the Fixture.
PL3 luminaires are shipped with default passwords. Users may set their own password (four-digit number). When
setting a password, write it down and keep it in a secure location. Note, Philips Selecon does not have records of
passwords established by users or owners.
Note: Contact Philips Selecon technical support if a unit is locked and the password is lost for instructions on how to
reset luminaire.
Note: If the Fixture is locked when it is powered down the fixture will remain in the locked state when powered up.
Passwords
Establishing or Changing Passwords
Step 1. At a Status Screen, press [MENU] and scroll to "Settings", press [OK].
Step 2. Go to the Security section.
Continued from previous page
Settings
Sub Menu Options Comments
SETTINGS - (Option)
Scrolls and sets the various fixture
settings using arrow buttons.
See "Settings" on page 14 for details.
Lock Fixture
Sub Menu Options Comments
LOCK - Are you sure? Yes (to Lock Fixture) / No
Use arrow buttons to make selection.
Press [OK] to accept. Note, a
password must be established (set) in
order to lock a fixture. Locking the
fixture will disable access to changing
menu settings.
LED Status
Sub Menu Options Comments
LED Status Information
Scrolls through the various levels
using arrow buttons as indicated on
menu screen. Depending on the
arrow button pressed, the screens
may appear in a different order that
shown in "Options".
LED 1
Displays LED’s current status (in
percentage%) of Intensity, Red,
Green, Blue, and White elements of
the LED). Also displays current color
temperature (i.e., WARM WHITE),
Fan Speed, operational LED junction
temperature, power settings.
Levels Displays DMX levels for each LED element (Red, Green, Blue, and
White) and total power.
Enter Password
Sub Menu Options Comments
Enter Pass PIN Enter four-digit password For details, refer to "Security" on
page 12.

Presets 13
PL3 LED Luminaires Installation & User’s Manual
Step 3. Select a Level to change ( Level 1 PIN / Level 2 PIN / Level 3 PIN).
Step 4. Press [OK] to edit using the [UP ARROW], [DOWN ARROW], [LEFT ARROW] or [RIGHT ARROW]
keys to enter a four-digit password (using 0 to 9).
Step 5. Press [OK] to save changes. If you hit [ESC] (Escape) password will not be stored and process must be
repeated.
Step 6. Password is set.
Note: The current security level is displayed next to the Security heading. Only Passwords at, or below, that level
will be displayed for modification. The level can be changed by entering a higher level Password on the "Enter
PassPIN line directly below the Security heading, like Step 4 above.
Security Levels
Locking Fixture
To lock the fixture:
Step 1. At a Status Screen, press [MENU] and scroll to "Lock Fixture".
Step 2. Press [OK].
Step 3. Use [LEFT ARROW] or [RIGHT ARROW] keys to highlight "YES" ", press [OK].
Step 4. Fixture is now locked.
Note: When the Fixture is Locked only the [ESC]/[MENU] key is functional. Pressing this key will display a request
for a password. When a valid password is entered the fixture is unlocked to the security level of the entered password.
6. Presets
Presets are Color Mixes that are stored in the Fixture, they can be recalled to reproduce a specific output from the
fixture. Presets are made up of a Color Mix; Red, Green, Blue, and White. They also have Intensity associated with
them.
Presets can be recalled via the User interface or by a DMX channel, when under DMX control. The Preset’s Intensity
is applied if the User Interface is used; if DMX, the DMX Intensity channel is used for Intensity.
Presets Types
Presets are classified as Locked, Protected, or User. The type of preset determines what aspects of the Preset can be
modified.
Locked
Locked Presets are factory Calibrated, and their Color Mix cannot be changed by the user. Their Intensity can be
changed. Three Presets (2-4), "Warm White', "Cool White", and "Day Light", are Locked.
Security Level Description Default PassPIN
0System is locked; the only key that is active is the Menu/ESC Key. When this key is pressed a
PassPIN is requested. Not Applicable
1All keys are Active.
You can select any Preset, and change Intensity, set DMX Address. 1111
2 Editing and Saving of Presets is added to Level 1 functionality. 2222
3 Operationally the same as level 2, however all settings are available on the Settings screen. 3333

Installation & User’s Manual PL3 LED Luminaires
14 OPERATION AND PROGRAMMING
Preset 0, the "off" preset is also Locked to the OFF value.
Protected
Protected Presets are also Factory Calibrated, and by default are Protected from changes to their Color Mix. Their
Intensity can be changed. Protected Presets are Presets 5-25. They can be Un-Protected by setting "Protected" to
"No"; see section on Settings. If Un-Protected these presets function like User Presets.
The Factory Calibrated values for the protected presets can be re-loaded to the original factory calibration settings by
setting "Load Factory" to "Yes" "; see section on Settings.
User
User Presets can have their Color Mix and Intensity changed without restriction.
Note: If the Color Mix of a Factory Calibrated Preset is changed, by turning protection Off, an '*' is appended to the
end of the Preset's Name to indicate that the Calibrated values have been changed.
Editing Preset Names
On the Edit Preset screen, the option is available to edit the name of a preset, via Screen button. However, the names
of Presets 0-4 cannot be edited.
Use the [LEFT ARROW] and [RIGHT ARROW] keys to select the character to be changed and use the [UP
ARROW] and [DOWN ARROW] keys to change that character. The Character Scroll order is A-Z, space, 0-9. If you
are scrolling up the Alpha character displays as Upper Case; if you are scrolling down the Alpha character displays as
Lower Case. Stop on the character you want, ignoring case, then press the opposite [UP ARROW] or [DOWN
ARROW] key if you want to change the case. [OK] to save changes, [ESC] to cancel changes.
7. Settings
The following Parameters can be changed on the Settings Screen.
The first column "Security Level" is the minimum security level you have to be at before the line is displayed for
editing in the Settings screen.
To edit a value on the Setting Screen, use the [UP ARROW] or [DOWN ARROW] keys to move the highlight to the
settings value you wish to change. Press [OK] to begin editing that value. Use the [UP ARROW], [DOWN
ARROW], [LEFT ARROW] or [RIGHT ARROW] keys to make changes to the value. Press [OK] when complete to
save changes, or [ESC] to cancel changes to that value.
When done making changes on the Settings Screen press [ESC] to re-boot fixture and implement changes. Fixture
will not re-boot if nothing was changed.
Security Level Parameter Values Default Description
Security
1Enter
PassPIN 4-Digits (0 to 9) **** There are 4 levels of security, this allows
you to change the level while in the
Settings Screen.
3 Level 1 PIN 4-Digits (0 to 9) 1111 Sets Level 1 PassPIN
3 Level 2 PIN 4-Digits (0 to 9) 2222 Sets Level 2 PassPIN
3 Level 3 PIN 4-Digits (0 to 9) 3333 Sets Level 3 PassPIN
3 Power-Up 1 - 3 or Locked 3 Security Level after Power-Up, if not
Locked (Level 0)

Settings 15
PL3 LED Luminaires Installation & User’s Manual
Note: To Exit the Settings screen, use the [ESC] key. [ESC] and [OK] can be used to cancel or save changes to an
individual parameter. However, once a parameter has been accepted, by pressing [OK] that change cannot be undone/
canceled by pressing the [ESC] key.
General
1 Power-Up
Off, Scratch Pad,
Warm White, Cool
White, Day Light,
Preset30, Preset31,
Last Set
Cool White
When the Fixture Powers-Up what does it
output. Scratch Pad is an automatically
saved Preset. Last Set is the last thing
coming out of the fixture, this could be
Warm White with the intensity changed
from that of the Preset.
3 IR Enabled No, Yes Yes Turns IR/Laser detection On/Off
3 Reset Hours No, Yes No Resets luminaire’s operational hours.
Presets
3 Protected No, 5 - 25 Yes Determines if the factory Calibrated Presets' Color Mix is protected from
changes.
3 Load Factory No, Yes No Reload Factory Calibrated Presets,
Intensity changes will also be reloaded.
DMX
3 DMX Enabled No, Yes, or Wireless (if
equipped) Yes
Enables or disabled DMX communication
through the luminaires DMX512 ports.
Sets the DMX feature to Wireless DMX (if
wireless DMX option is installed - sold
separately).
1 Address 001 to 512 001 DMX512 address. Note, it can be set if
displayed.
2 Map 8-bit, 16-bit, or 3-Chan 16-bit
Defines size/precision of DMX map. Color
Mixing/Intensity in 16-bit provides higher
resolution for precision control. 3-Chan
provides minimal channel usage.
2 When no DMX Off, Hold, Hold 8hr (8
hours), or Power-Up Hold
If DMX is detected and then goes away,
thisdefineswhatwillhappentothe output.
At end of 8Hr hold Fixture goes to Power-
Up setting.
Fan
3 Normal / Quiet Normal or Quiet Quiet
NormalNormal - (Normal Mode) Normal
Mode Provides higher cooling margin for
thermally challenging applications.
Recommended for full power (RGBW @
100%) applications with large and
numerous changes in power. Quiet -
(Quiet Mode) Quite Mode is similar to
Normal mode, but it controls fan tightly to
reduce fan noise.
3 Max% 0 to 100% 100 Sets the maximum fan speed
3 Min% 0 to 100% 1 Sets the minimum fan speed
Display
3 Flip Display No, Yes No Flips (inverts) Display and Keypad Arrows.

Installation & User’s Manual PL3 LED Luminaires
16 DMX CONTROL
DMX CONTROL
This section contains information for operating the luminaire using DMX control in 16-Bit, 8-Bit, or 3-Channel (3-
Chan) modes. For Menu options and detailed information, see "Settings" on page 14.
Note: These tables assume a DMX start address of 1. When a different starting address is used, this address becomes
channel 1 function and other functions follow in sequence.
1. 16-Bit Mode
Table 2 provides DMX channel mapping of all DMX512 control values when the PL3 LED Luminaire is in 16-bit
DMX512 mode (as set by the luminaire’s menu system).
Table 2: PL3 Luminaire DMX Channel Mapping (16-Bit Mode)
DMX
Channel Parameter Range DMX Range% Default - recom-
mended console
default values Description
1 Intensity - High 0 - 65535 0 - 100% 0 16-bit control for Intensity of LED settings.
2 Intensity - Low
3 Red - High Byte 0 - 65535 0 - 100% 0 16-bit control of Red LEDs from 0 to full.
4 Red - Low Byte
5 Green - High Byte 0 - 65535 0 - 100% 0 16-bit control of Green LEDs from 0 to full.
6 Green - Low Byte
7 Blue - High Byte 0 - 65535 0 - 100% 0 16-bit control of Blue LEDs from 0 to full.
8 Blue - Low Byte
9 White - High Byte 0 - 65535 0 - 100% 0 16-bit control of White LEDs from 0 to full.
10 White - Low Byte
11
Preset Color Selection
Notes:
• Color Presets 5
through 25 are cali-
brated factory col-
ors and can be
reloaded if needed
throughthefixture’s
menu system.
• These colors have
been matched to
precise X and Y
coordinates at the
center of the beam
at wide angle, we
have given you the
ability to adjust
these colors as
your personal per-
ception may vary.
0 - 255 0 - 100% 0
Used to access presets stored in fixture
firmware, such as CCT presets, defined gel
presets, and more.
No Preset Activated = DMX 0 - 3
Color Preset 0 (Off) = DMX 4 - 7
Color Preset 1 (Scratch Pad) = DMX 8 - 11
Color Preset 2 (Warm White) = DMX 12 - 15
Color Preset 3 (Cool White) = DMX 16 - 19
Color Preset 4 (Daylight) = DMX 20 - 23
Color Preset 5 (Arc White) = DMX 24 - 27
Color Preset 6 (Red) = DMX 28 - 31
Color Preset 7 (Yellow) = DMX 32 - 35
Color Preset 8 (Daylight Blue) = DMX 36 - 39
Color Preset 9 (Magenta) = DMX 40 - 43
Color Preset 10 (Kelly Green) = DMX 44 - 47
Color Preset 11 (Medium Amber) = DMX 48 - 51
Color Preset 12 (Lavender) = DMX 52 - 55
Color Preset 13 (Blue) = DMX 56 - 59
Color Preset 14 (Light Pink) = DMX 60 - 63
Color Preset 15 (Green) = DMX 64 - 67
Color Preset 16 (Pink) = DMX 68 - 71
Color Preset 17 (Amber White) = DMX 72 - 75
Color Preset 18 (Dark Fuchsia) = DMX 76 - 79
Color Preset 19 (Light Amber) = DMX 80 - 83
Color Preset 20 (Steel Blue) = DMX 84 - 87
Color Preset 21 (Lt. Green/Blue) = DMX 88 - 91
Color Preset 22 (Orange) = DMX 92 - 95
Color Preset 23 (Medium Pink) = DMX 96 - 99
Color Preset 24 (Cyan) = DMX 100 - 103
Color Preset 25 (Purple) = DMX 104 - 107
Color Preset 26 (Custom) = DMX 108 - 111
Color Preset 27 (Custom) = DMX 112 -115
Color Preset 28 (Custom) = DMX 116 - 119
Color Preset 29 (Custom) = DMX 120 - 123
Color Preset 30 (Custom) = DMX 124 - 127
Color Preset 31 (Custom) = DMX 128 - 131
12 Not used (for future use)
- Continued next page -

16-Bit Mode 17
PL3 LED Luminaires Installation & User’s Manual
13 Intensity Time 0 - 255 0 - 100% 255
Allows for luminaire timing of intensity. Profile
should default to DMX 255 for smoothest
console fade times. Refer to "PL3 Luminaire
DMX Timing Channel Detail" on page 22 for
more information on timing values.
14 Color Time 0 - 255 0 - 100% 255
Allows for luminaire timing of LEDs. Profile
should default to DMX 255 for smoothest
console fade times.Refer to "PL3 Luminaire DMX
Timing Channel Detail" on page 22 for more
information on timing values.
15 Control 0 - 255 0 - 100% 0
Used to set different modes, parameters, and
functions of the luminaire. Set control channel
value for desired action. Hold value for at least 3
seconds. Set control channel value to 0 without
any scaling.
Default Setting on Console = DMX 0
Display On/Off = DMX 3 - 4
Reset All to Defaults = DMX 5 - 7
Quiet Mode = DMX 11 - 13
Normal Mode = DMX 14 - 15
Preset 1 Store = DMX 20 - 21
Preset 2 Store (Intensity Only) = DMX 22 - 23
Preset 3 Store (Intensity Only) = DMX 24 - 25
Preset 4 Store (Intensity Only) = DMX 26 - 27
Preset 5 Store = DMX 28 - 29
Preset 6 Store = DMX 30 - 31
Preset 7 Store = DMX 32 - 33
Preset 8 Store = DMX 34 - 35
Preset 9 Store = DMX 36 - 37
Preset 10 Store = DMX 38 - 39
Preset 11 Store = DMX 40 - 41
Preset 12 Store = DMX 42 - 43
Preset 13 Store = DMX 44 - 45
Preset 14 Store = DMX 46 - 47
Preset 15 Store = DMX 48 - 49
Preset 16 Store = DMX 50 - 51
Preset 17 Store = DMX 52 - 53
Preset 18 Store = DMX 54 - 55
Preset 19 Store = DMX 56 - 57
Preset 20 Store = DMX 58 - 59
Preset 21 Store = DMX 60 - 61
Preset 22 Store = DMX 62 - 63
Preset 23 Store = DMX 64 - 65
Preset 24 Store = DMX 66 - 67
Preset 25 Store = DMX 68 - 69
Preset 26 Store = DMX 70 - 71
Preset 27 Store = DMX 72 - 73
Preset 28 Store = DMX 74 - 75
Preset 29 Store = DMX 76 - 77
Preset 30 Store = DMX 78 - 79
Preset 31 Store = DMX 80 - 81
Fixture Reset* = DMX 250 - 255
16 Beam 0 - 255 0 - 100% DMX 127 (50%,
Motor Stop)
Controls zoom mechanism motor in 3 speeds,
forward and backwards as follows . . .
Motor Stop = DMX 0 - 15
Motor <<< Fast = DMX 16 - 49
Motor << Medium = DMX 50 - 84
Motor < Slow = DMX 85 - 119
Motor Stop = DMX 120 - 135
Motor > Slow = DMX 136 - 170
Motor >> Medium = DMX 171 - 204
Motor >>> Fast = DMX 205 - 238
Motor Stop = DMX 239 - 255
17
Pan
(See "Pan & Tilt DMX
Operation Notes" on
page 18 for more
information).
0 - 255 0 - 100% DMX 127 (50%,
Motor Stop)
Controls Pan motor in 3 speeds, forward and
backwards as follows . . .
Motor Stop = DMX 0 - 15
Motor <<< Fast = DMX 16 - 49
Motor << Medium = DMX 50 - 84
Motor < Slow = DMX 85 - 119
Motor Stop = DMX 120 - 135
Motor > Slow = DMX 136 - 170
Motor >> Medium = DMX 171 - 204
Motor >>> Fast = DMX 205 - 238
Motor Stop = DMX 239 - 255
Table 2: PL3 Luminaire DMX Channel Mapping (16-Bit Mode)
- Continued next page -

Installation & User’s Manual PL3 LED Luminaires
18 DMX CONTROL
Pan & Tilt DMX Operation Notes
• PL3MKIT is an accessory and is sold separately. PL3MKIT must be installed in order to use this feature.
• Under DMX Control, the PAN and TILT are interlocked, you cannot move both at the same time. In order to move
PAN, TILT and BEAM the level for each axis of movement must be set to 50% (DMX 127) to start. To initiate
movement, from the starting point of 50% (DMX 127) the user must set values above or below this level. Increas-
ing the value above 50% starts movement in one direction and entering a value below 50% moves the luminaire or
the focus in the opposite direction. The greater the change in value the faster the luminaire will move (see table).
To stop movement return the control to the 50%.
• The very ends of the DMX ranges 0-15 and 239-255, represent the end of travel stop ranges; if that range is entered
you must return to 50% (DMX 127) before it will move again. This was done so that if a DMX control device uses
sliders, 0 is stopped and moving back towards 50% (DMX 127) will not cause the fixture to move.
• All Strand Lighting Palette and Light Palette consoles feature fixture libraries to simplify control of these lumi-
naires. The luminaire attribute map is published in this manual and has been provided to all console manufacturers
to allow them to create fixture libraries. Contact your console manufacturer for a library if you do not have one in
your control system.
18
Tilt
(See "Pan & Tilt DMX
Operation Notes" on
page 18 for more
information).
0 - 255 0 - 100% DMX 127 (50%,
Motor Stop)
Controls Tilt motor in 3 speeds, forward and
backwards as follows . . .
Motor Stop = DMX 0 - 15
Motor <<< Fast = DMX 16 - 49
Motor << Medium = DMX 50 - 84
Motor < Slow = DMX 85 - 119
Motor Stop = DMX 120 - 135
Motor > Slow = DMX 136 - 170
Motor >> Medium = DMX 171 - 204
Motor >>> Fast = DMX 205 - 238
Motor Stop = DMX 239 - 255
Table 2: PL3 Luminaire DMX Channel Mapping (16-Bit Mode)
