Philips HF8420/00 User manual

HF8420

2

3
F
G
H
I
A
B
E
C
D
1

4

HF8420
ENGLISH 6
FRANÇAIS (CANADA) 18

6
IMPORTANT
SAFETY
INSTRUCTIONS
When using an electric appliance, basic precautions
should always be followed, including the following:
Read all instructions before
using this appliance.
DANGER
To reduce the risk of electric shock:
1 Always unplug this appliance from the electrical
outlet immediately after using and before
cleaning.
2 Do not use an extension cord with this
appliance.
3 Unplug the charger before cleaning.
4 Do not reach for a charger that has fallen into
water. Unplug immediately.
5 Do not place or store the charger where it can
fall or be pulled into a bathtub, sink or toilet. Do
not place the charger in or drop into water or
other liquid.
6 The massager is intended for external use only.
Do not use the massager for penetration.
ENGLISH

WARNING
To reduce the risk of burns, re, electric shock, or
injury to persons:
1 An appliance should never be left unattended
when plugged in. Unplug from outlet when not
in use, and before putting on or taking off parts.
2 Do not use over insensitive skin areas or in the
presence of poor circulation.The unattended use
of heat by children or incapacitated persons may
be dangerous.
3 Do not operate under blanket or pillow.
Excessive heating can occur and cause re,
electric shock, or injury to persons.
4 Close supervision is necessary when this
appliance is used by, on, or near children, invalids
or disabled persons.
5 Use this appliance only for its intended
household use as described in this manual. Do
not use attachments not recommended by
Philips Electronics North America Corporation.
6 Never operate this appliance if it has a damaged
cord or plug, if it is not working properly, if it has
been dropped, damaged or dropped into water.
7 Do not carry this appliance by the supply cord
or use the cord as a handle.
8 Keep the cord away from heated surfaces.
9 Do not use outdoors.
10 Do not operate where aerosol (spray) products
are being used or where oxygen is being
administered.
11 To disconnect, turn off all controls to the off
position, then remove the plug from outlet.
12 To prevent possible damage to the cord, do not
wrap the cord around the appliance.
13 Charge, store and use the appliance at a
temperature between 5°C/40°F and 35°C/95°F.
ENGLISH 7

14 Do not place anything on the charger other than
the massager.
15 The massager is water-resistant and can be used
in the shower or tub. Do not submerge the
massager in water or any other liquid for more
than one hour.
16 If the massager produces an abnormal sound,
turn the massager off and do not use it.
SAVETHESE INSTRUCTIONS
IMPORTANT:To reduce the risk of electric shock,
this appliance has a polarized plug (one blade is
wider than the other). This plug will t in a polarized
outlet only one way. If the plug does not t fully
in the outlet, reverse the plug. If it still does not t,
contact a qualied electrician to install the proper
outlet. Do not change the plug in any way.
IMPORTANT:The power plug contains a
transformer. Do not cut off the power plug to
replace it with another plug, as this will cause a
hazardous situation.
Important
Caution
1 Consult your doctor before you use the
appliance in the following cases:
- During pregnancy or shortly after delivery
- If you have irritated skin or a skin disease
- If you have other health problems.
2 If using the massager causes an allergic reaction,
stop using it and consult your doctor.
3 Do not use the massager on the eyes or
arteries.
4 Do not massage any single area for more than
15 minutes.
ENGLISH8

5 This massager is not intended as a medical
appliance.
6 To reduce the risk of spreading sexually
transmitted diseases and infections, put a
condom around the massager when it is in
contact with intimate areas. Change the condom
when you move the massager to another body
part.
7 If you want to use the massager in combination
with a lubricant or massage oil, only use a
water-based or silicone-based type. Do not
use scented and/or alcohol-based lubricants or
massage oils, as they may cause damage.
8 Always clean the massager after each use
to reduce the risk of infections (see chapter
‘Cleaning’).
9 Do not expose the massager and its charger
to direct sunlight or UV light (such as a tanning
appliance) for a long period of time and never
expose it to extreme heat.
10 Be careful not to drop the massager. If dropped,
or damaged in any way, discontinue using the
massager.
Note:The charger may interfere with radio-controlled
clocks. Keep the charger away from such clocks.
Thermal cut-off
For your safety, this Philips massager is equipped
with a thermal cut-off, which switches off the
appliance automatically if overheating occurs.When
the thermal cut-off has been activated, the light ring
ashes repeatedly. Let the appliance cool down to
room temperature before you continue using it.
ENGLISH 9

Introduction
Congratulations on your purchase and welcome to
Philips!
Philips is dedicated to producing high-quality
products that add value to your life.We bring you a
sensual massager that lets you explore new ways to
arouse each other.
General description (Fig. 1)
AMassager to stimulate you and your partner
BMode selection button
CDecrease button
DIncrease button
E Light rings
FCharging light
GCharger
HAdaptor
ISmall plug
Charging
Only use the adaptor and charger provided to
charge the massager.
The massager and its charger become warm during
charging.
Never cover the charger with anything (e.g. a towel
or clothing) while plugged in or charging.
Note:When you unpack the massager, the battery
usually contains enough energy for a ‘quickie’. In some
cases, however, the battery may be empty due to
environmental conditions.
It takes about 4 hours to fully charge the massager.A
full charge gives you and your partner up to 5 hours
to explore each other.
ENGLISH10

The actual operating time may vary over time,
depending on the selected vibration mode and
speed level.
Charge the massager when the light rings
start ashing slowly to indicate that the battery is
almost empty.
1 Make sure that all parts (massager and charger)
are dry.
2 Insert the small plug into the charger and put
the adaptor in the wall socket.
3 Place the massager on the charger. It only ts
properly on the charger with the moulded
surface facing up and the buttons on the side.
The massager switches off automatically when you
place it on the charger.
,The massager slowly vibrates for a few seconds
to get into the correct position for optimal
charging.
Note:The charger does not work when the massager is
placed incorrectly on the charger.
,The charging light on the charger starts ashing
to indicate that the massager is being charged.
Note: When you charge the massager for the rst
time or after a long period of non-use, it may take a
few minutes before the light rings start ashing. This is
normal.
Note: The appliance may produce a smell the rst few
times you charge it.This is normal.
,When the battery is fully charged, the
light rings go out.
ENGLISH 11

Using the appliance
Use this appliance for its intended household use
as described in this manual.
Thoroughly clean the massager before rst use,
after every use and when you use it on another
body area, to reduce the risk of infection (see
chapter ‘Cleaning’).
1 Press any button to switch on the massager.
Note: If the massager has not been used for more
than 7 days, you can only switch it on by pressing the
+ button.
,The light rings go on.
,The massager starts operating in the default
mode (mode 1) and at the default vibration
speed.
Tip:You can adjust the speed and select a mode you
like once you have familiarized yourself with the
options available.
2 Press the mode selection button to adjust
the vibration to your own preference.The
massager has 4 vibration modes:
1 Glow – the massager vibrates in a steady,
continuous way
2 Wave – a slow, relaxing pattern of pulses that
rises and falls in intensity
3 Heart beat – a steady pulse, like a rapidly beating
heart
4 Thrill – a more intense, exciting pattern of pulses
that rise and fall in intensity
ENGLISH12

3 Press the increase or decrease button one or
more times to adjust the vibration speed of the
massager to your own preference.
The appliance has 5 speed levels.
4 You can hold the massager in different ways.
Experiment to nd the most comfortable way
to use the massager.
Tip: For suggestions, consult the enclosed welcome
booklet.
Tip:You can also use the massager in combination with
a water-based or silicone-based lubricant or massage
oil. Do not use scented and/or alcohol-based lubricants
or massage oils, as they may cause damage.
Tip:You can also use the massager in the shower or in
the bath. Do not immerse the massager for more than
one hour.
Make sure the adaptor and charger do not get wet
or come near water.
5 To switch off the massager, press and hold the
mode selection button or the decrease button.
Travel lock
It is possible to lock the massager, for example if
you are going to travel.The travel lock prevents the
massager from being switched on by accident.
1 Switch off the massager.
2 Simultaneously press the increase button and
the mode selection button to activate the
travel lock.
,The light rings ash once to indicate that the
massager is locked.
ENGLISH 13

3 To deactivate the travel lock, press the
increase button and the mode selection button
simultaneously again.
,The light rings ash once to indicate that the
massager is unlocked.
Note:When you place the massager on the plugged-in
charger, the travel lock is automatically deactivated.
Tip:When you travel with the sensual massager, pack
the charger and the massager separately to prevent
them from scratching each other.
Cleaning
Thoroughly clean the massager before rst
use, after every use and when you use it on
another body area, to reduce the risk of infection.
Do not use aggressive or abrasive cleaning agents,
chemical substances or alcohol-based disinfectants
to prevent damage to the massager.
Do not clean the massager with materials or
tools that could cause damage, e.g. metal or sharp
kitchen utensils or scouring pads.
Never immerse the charger in water or any other
liquid, or rinse it under the tap.
The massager and charger are not dishwasher-safe.
1 Switch off the massager and unplug the charger.
2 Clean the massager with a moist cloth soaked
in lukewarm water with mild anti-bacterial
soap and rinse it under the tap. Dry the
massager thoroughly after cleaning it.
Tip: Use a non-alcohol-based disinfectant to reduce the
risk of infections.
ENGLISH14

Do not immerse the massager in water for more
than one hour.
3 Clean the charger with a damp cloth and dry
thoroughly.
This appliance has no user-serviceable parts.
Storage
- If the massager will not be used for an extended
period of time, remove the cord from the outlet
and store it in a safe, dry location where it will not
be crushed, banged or subject to damage.
- Do not wrap the cord around the massager or
charger when storing.
1 Switch off the massager and unplug the charger
from the outlet.
2 Make sure the massager is clean before storing.
(See chapter ‘Cleaning’).
3 Place the massager on the charger and store it
in a safe, dry place away from sunlight.
Battery removal
- This Philips massager contains rechargeable
Lithium-ion batteries, which must be disposed of
properly.
ENGLISH 15

Full Two-Year Warranty
Philips Electronics North America Corporation
(USA) and Philips Electronics Ltd (Canada) warrant
each new Philips product, model HF8420 against
defects in materials or workmanship for a period
of two years from the date of purchase, and agree
to repair or replace any defective product without
charge.
IMPORTANT:This warranty does not cover damage
resulting from accident, misuse or abuse, lack of
reasonable care, or the afxing of any attachment
not provided with the product.
NO RESPONSIBILITY IS ASSUMED FOR ANY
SPECIAL, INCIDENTAL OR CONSEQUENTIAL
DAMAGES.
In US Manufactured for: Philips Consumer Lifestyle,
A Division of Philips Electronics North America
Corporation, 1600 Summer Street – 5th Floor,
Stamford, CT 06905-5125.
In Canada Imported for: Philips Electronics LTD,
281 Hillmount Road, Markham, Ontario L6C 2S3.
Trademarks owned by The Philips Group.
©2009 Koninklijke Philips Electronics N.V. All Rights
Reserved.
ENGLISH16

Troubleshooting
This chapter summarizes the most common problems you could
encounter with the appliance.
Problem Possible cause Solution
The massager does not
work.
The rechargeable battery
is empty.
Charge the massager (see chapter
‘Charging’).
The charger is still charging. It takes 4 hours to charge the
massager fully.When fully charged,
the massager has an operating time
of up to 5 hours, depending on
the modes you apply (see chapter
‘Charging’).
The travel lock is active. Deactivate the travel lock (see
chapter ‘Using the appliance’).
The thermal cut-off has
been activated.
Let the appliance cool down to
room temperature before you
continue using it.
The charger does not
work.
The charger is not plugged
in.
Insert the small plug into the
charger and put the adaptor in the
wall outlet.
You have not placed the
massager on the charger
properly.
Place the massager properly on the
charger (see chapter ‘Charging’).
The massager and its
charger become warm
during charging.
This is normal. No further action required.
The massager suddenly
switches off.
The rechargeable battery
is empty.
Charge the massager (see chapter
‘Charging’).
You have pressed the mode
selection button or the
decrease button for some
time and switched off the
massager.
Press any button to switch on the
massager again.
The massager suddenly
switches on when I place
it onto the charger.
When you place the
massager in the charger, it
vibrates for a few seconds to
get into the correct position
for optimal charging.
No further action required.
ENGLISH 17

18
INSTRUCTIONS
DE SÉCURITÉ
IMPORTANTES
Quand vous utilisez un appareil électrique, observez
toujours les précautions de base suivantes :
Lisez toutes les instructions
avant d’utiliser cet appareil.
DANGER
An de réduire le risque d’électrocution :
1 Débranchez toujours cet appareil de la prise
électrique immédiatement après l’avoir utilisé et
avant de le nettoyer.
2 N’utilisez pas de rallonge avec cet appareil.
3 Débranchez le chargeur avant le nettoyage.
4 Ne touchez pas le chargeur s’il est tombé dans
l’eau. Débranchez-le immédiatement.
5 Ne placez ou ne rangez pas le chargeur là où
il peut tomber dans une baignoire, un évier
ou une toilette, ou y être tiré. Ne placez ou
n’échappez pas le chargeur dans l’eau ou dans
un autre liquide.
6 Le masseur est uniquement destiné à un usage
externe. Ne l’utilisez pas pour la pénétration.
FRANÇAIS (CANADA)

AVERTISSEMENT
Pour réduire tout risque de brûlure,
d’électrocution, d’incendie ou de blessure :
1 Ne laissez jamais un appareil sans surveillance
lorsqu’il est branché. Débranchez-le quand il
n’est pas en usage, et avant d’y ajouter ou d’en
enlever des pièces.
2 N’utilisez pas le masseur sur des zones de
peau sans sensation ou là où la circulation
est mauvaise. L’utilisation de chaleur sans
surveillance par des enfants ou des personnes
handicapées pourrait être dangereuse.
3 N’utilisez pas le masseur sous une couverture
ou un oreiller. Un excès de chaleur pourrait
se produire et poser un risque de feu,
d’électrocution ou de blessures.
4 Pour les enfants ou les personnes handicapées,
une surveillance attentive est nécessaire lorsque
cet appareil est utilisé par eux, sur eux, ou près
d’eux.
5 Ne vous servez de cet appareil que pour
son utilisation prévue, telle qu’elle est décrite
dans ce mode d’emploi. N’utilisez pas d’autres
accessoires que ceux recommandés par Philips
Electronics North America Corporation.
6 N’utilisez jamais cet appareil si son cordon
d’alimentation ou sa che sont endommagés,
s’il ne fonctionne pas correctement, s’il a été
échappé, endommagé ou s’il est tombé dans
l’eau.
7 N’utilisez pas le cordon d’alimentation de cet
appareil pour le transporter ou comme une
poignée.
8 Tenez le cordon d’alimentation à l’écart des
surfaces chauffantes.
9 N’utilisez pas cet appareil à l’extérieur.
FRANÇAIS (CANADA) 19

10 Ne faites jamais fonctionner le masseur près de
produits en aérosol (vaporisateur) ou dans un
endroit où l’on administre de l’oxygène.
11 Pour le débrancher, mettre d’abord tous les
contrôles à la position Arrêt, et retirez ensuite la
che de la prise.
12 Pour prévenir des dommages possibles au
cordon, ne l’enroulez pas autour de l’appareil.
13 Chargez, conservez et utilisez l’appareil à une
température comprise entre 5 °C et 35 °C.
14 Ne placez rien d’autre que le masseur sur le
chargeur.
15 Le masseur est résistant à l’eau et peut être
utilisé dans la douche ou la baignoire. Ne
l’immergez pas dans l’eau ou dans tout autre
liquide pendant plus d’une heure.
16 Si le masseur produit un bruit anormal, éteignez-
le et ne l’utilisez pas.
CONSERVEZ CES
INSTRUCTIONS
IMPORTANT : An de réduire le risque
d’électrocution, cet appareil comporte une che
polarisée (une broche est plus large que l’autre).
Cette che ne s’insère dans une prise polarisée que
dans une seule position. Si la che ne s’insère pas
complètement dans la prise, inversez-la et réessayez.
Si elle ne s’insère toujours pas, communiquez avec
un électricien qualié pour faire installer une prise
appropriée. Ne modiez la che d’aucune manière.
IMPORTANT : La che d’alimentation contient un
transformateur. Ne pas couper la che d’alimentation
en vue de la remplacer par une autre che an
d’éviter tout risque de blessure.
FRANÇAIS (CANADA)20
