Philips HD3802 User manual

HD3802

2

1
3
6
7
8
9
12
5
2
1
3
4
18
19
17
16
13
11
10
22
21
20
14
15
AD
B C

4

HD3802
ENGLISH 6
繁體中文 18

6
Introduction
Congratulations on your purchase and welcome to Philips! To fully benet
from the support that Philips offers, register your product at www.philips.
com/welcome.
General description (Fig. 1)
1 Filter housing
2 Filtered water outlet
3 Swivel arm
4 Filter cover
5 Hose
6 Attachment nut
7 Tap adapter (A-type 16mm)
8 Rubber washer
9 Stainless steel screen
10 Hose joint
11 Water selection lever
12 Water selection unit
13 Suction cups on bottom
14 Fasteners
15 Tap adapters
AA-type
BB-type
CC-type
DD-type
16 Unltered water inlet
17 Granular activated coral
18 Granular activated carbon
19 Hollow bre
20 Swivel nozzle
21 Filtered stream (turn nozzle clockwise)
22 Filtered spray (turn nozzle anticlockwise)
ENGLISH

Important
Read this user manual carefully before you use the water purier and
save it for future reference.
Warning
This water purier is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities, or lack
of experience and knowledge, unless they have been given
supervision or instruction concerning use of the appliance by a
person responsible for their safety.
Children should be supervised to ensure that they do not play with
the water purier.
Do not let water hotter than 50°C run through the water purier, as
this may damage the water purier.
Do not let the water purier freeze.
Before daily use
To prevent quick clogging of the lter cartridge, let the water run at
the unltered setting for around 5 seconds before every use.
If the water is highly coloured or turbid due to work on your water
network, do not let the water run at the ltered setting until the
water is clear.
Cautions:
1 Let the water run at the ltered setting for 10 seconds before use
each day.
2 Let the water run at the ltered setting for 60 seconds before use if
you have not used the water purier for more than two days.
3 If you have not used the water purier for more than two weeks, let
the water run at the ltered setting for 2-3 minutes before use. If the
lter cartridge emits an unpleasant smell, replace it with a new one.
During use
Only use the water purier to lter water that meets drinking water
standards.
Do not block the ltered water outlet or connect other devices to it.
-
-
-
-
-
-
-
-
-
ENGLISH 7

If the water pressure is very high, reduce the water ow of the tap to
prevent damage to the cartridge.
Keep the water purier away from heat to avoid distortion or
breakage.
Do not tamper with the water purier.
Do not remove the lter cartridge while you use the water purier
Do not use the water purier without a lter cartridge.
Do not place the water purier near a window where it is exposed
to direct sunlight.
This water purier does not soften water.
Do not use ltered water in aquariums. Tap water, ltered or
unltered, can be harmful to sh.
Do not store puried water to avoid contamination. Air contact
contaminates puried water quickly. If you want to store puried
water, use a clean container and keep it in the refrigerator. Do not
keep it in the refrigerator longer than 1 day to avoid contamination.
Features
Philips’ multi-ltration system consists of a primary lter, a secondary
lter, a high-tech hollow-bre membrane lter, a granular activated
carbon lter and a granular activated coral lter.
The hollow bre membrane contains more than 1200 billion
micropores that are small enough to remove particles down to
0.1µm. It eliminates 99.99%* of bacteria, rust and other particles
larger than the micropore size from your tap water without removing
calcium, magnesium and other minerals that are vital to your body. (*
tested according to Japanese Water Purier Association (JWPA)
standard).
The granular activated carbon removes unpleasant chlorine smell, bad
taste and odours from your tap water.
The granular activated coral enriches your ltered water with natural
minerals to improve the taste and to make it healthier.
The 360° swivel arm and the swivel nozzle provide ultimate control
of the ltered water ow.
-
-
-
-
-
-
-
-
-
-
-
-
-
-
ENGLISH8

Preparing for use
Mounting the water selection unit
When you exchange the adapter, beware the screw thread of the tap is
sharp.
Before you install the water purier, make sure all tap adapters you
require are present.
The tap must have a diameter of 13mm-25mm.
Determine what type of tap you have and select the appropriate
tap adapter.
The tap adapters supplied make the water purier suitable for almost
any kitchen tap. However, the water purier may not t some
uncommon types of taps.
The tap water pressure has to be between 0.7kgf/cm² and 3.5kgf/cm².
If you use the water purier at a water pressure below this range, the
ltered water ow is either extremely low or there is no ow at all.
On the other hand, if the water pressure exceeds this range, the
water purier gets damaged.
Installation A-type adapter
For taps with a round spout with a diameter of 16mm, 17.5mm or
19mm (Fig. 2).
1 Remove the attachment nut and the adapter from the water
selection unit (Fig. 3).
2 Pass the attachment nut over the tap spout (Fig. 4).
3 Place the matching adapter (A-type) over the tip of the spout.The
16mm adapter is attached to the water selection unit when you
unpack it. Replace this adapter with the 17.5mm adapter or 19mm
adapter to t the diameter of your tap (Fig. 5).
4 Tighten the attachment nut rmly onto the water
selection unit (Fig. 6).
Installation B-type adapter
For taps with an aerator (threaded on the outside) (Fig. 7).
-
-
-
-
-
-
-
ENGLISH 9

1 Remove the attachment nut and the adapter from the water
selection unit (Fig. 3).
2 Remove the aerator cap from the tap and pass the attachment nut
over the spout.Take out the original adapter and screw the
matching adapter (B-type) onto the tap (Fig. 8).
3 Tighten the adapter further with a coin (Fig. 9).
4 Tighten the attachment nut rmly onto the water selection
unit (Fig. 10).
Installation C-type adapter
For taps with an aerator (threaded on the inside) (Fig. 11).
1 Remove the attachment nut and the adapter from the water
selection unit (Fig. 3).
2 Remove the aerator cap from the tap.Take out the original adapter
and screw the matching adapter (C-type) onto the tap through the
attachment nut. (Fig. 12)
3 Tighten the adapter further with a coin (Fig. 13).
4 Tighten the attachment nut rmly onto the water selection
unit (Fig. 14).
Installation D-type adapter
For taps other than A, B or C. (Fig. 15)
1 Remove the attachment nut and the adapter from the water
selection unit (Fig. 3).
2 Screw the D-type adapter about halfway onto the water selection
unit. Make sure to leave enough room in order to tighten the tting
at a later step. (Fig. 16)
3 Push the water selection unit rmly onto the tap from below and
tighten the 4 screws evenly. Make sure that you keep the tap in the
center of the screw fastener.At the same time maintain pressure
on the water purier housing from below. (Fig. 17)
-
-
ENGLISH10

4 Tighten the attachment nut rmly onto the water selection
unit (Fig. 18).
Make sure the rubber washer is rmly pushed against the tap to prevent
water leakage.
Connecting the hose to the water selection unit
1 Make sure the tap is closed.
2 Set the water selection lever to the unltered stream
position (Fig. 19).
3 Cut the hose to the required length (Fig. 20).
4 Remove the hose joint from the water selection unit (Fig. 21).
5 Push the hose through the hose joint (1). Push the hose onto the
connection point until it does not go any further (2) (Fig. 22).
6 Tighten the hose joint (Fig. 23).
7 Use the nylon fasteners to fasten the hose along the tap (Fig. 24).
Using the water purier
The water selection unit has 4 settings: ltered spray, ltered stream,
unltered spray and unltered stream.
The unltered spray and stream come out of the water selection unit.
The ltered water comes out of the swivel nozzle. The swivel nozzle
has two settings: ltered spray and ltered stream.
Do not let water hotter than 50°C run through the water purier, as
this may damage the water purier.
Filtered water (spray or stream)
Select this setting for drinking, washing vegetables or fruits and
for cooking.
1 Turn the swivel arm to the desired position.
2 Turn the water selection lever on the water selection unit until the
ltered water symbol is aligned with the indicator (Fig. 25).
-
-
ENGLISH 11

3 Set the swivel nozzle to spray or stream.
To select the ltered spray, turn nozzle anti-clockwise.
To select the ltered stream, turn nozzle clockwise.
4 Move the swivel nozzle until it is in the desired position
5 Open the tap.
Filtered spray or stream comes out of the swivel nozzle.
If you lter water between 35°C and 50°C, the water may have an
unpleasant smell. The lter cartridge has absorbed this smell during
ltering, but releases it again if you lter water hotter than 35°C.
Unltered water (spray or stream)
Spray
Select this setting for washing dishes and other jobs that require a gentle
water ow.
1 Turn the water selection lever on the water selection unit until the
unltered spray symbol is aligned with the indicator (Fig. 26).
2 Open the tap.
Unltered spray comes out of the water selection unit.
Unltered stream
Select this setting for a strong water ow.
1 Turn the water selection lever on the water selection unit until the
unltered stream symbol is aligned with the indicator (Fig. 19).
2 Open the tap.
Unltered stream comes out of the water selection unit.
Cleaning
Never use scouring pads, abrasive cleaning agents or aggressive liquids
such as petrol or acetone to clean the water purier. These substances
may cause cracking, discolouration or distortion.
1 Wipe the water selection unit and the lter housing with a damp
cloth.
-
-
,
,
,
ENGLISH12

2 Clean the ltered water outlet with a clean soft brush and wipe off
any contamination with a clean cloth.
Note: Do not use a used toothbrush, as it may transfer bacteria to the water
outlet.
3 Regularly clean the stainless steel screen under a running tap with a
clean and soft brush.
Replacement
New lter cartridges are available under type number HD3902.
Replace the lter cartridge if it is clogged to prevent damage to the
water purier.
No part of the lter cartridge can be reused. Discard the used
cartridge and replace it with a new one.
When to replace lter cartridge
The actual lifetime of the lter cartridge depends on the quality of the
local water and the water pressure.
For optimal performance of the water purier, replace the lter cartridge
if one of the following situations occurs:
A You have used the lter cartridge for twelve months.
B The volume of puried water decreases substantially.
C The ltered water still has an unpleasant smell or is still turbid
after purication.
Reduced lter cartridge life
The lter cartridge has a shorter life and should be replaced more
frequently in the following situations:
The water pressure is very low.
The pipes and water tank are worn.
The tap water is contaminated due to plumbing activities or cleaning
of the water tank.
When you use cloudy water immediately after heavy rain.
-
-
-
-
ENGLISH 13

How to replace the lter cartridge
1 Close the tap and set the water selection lever to the unltered
stream position (Fig. 19).
2 Turn the cover anticlockwise to remove it from the lter
housing (Fig. 27).
3 Remove the cover with the lter attached from the lter
housing (Fig. 28).
4 Turn the lter cartridge clockwise to remove it (Fig. 29).
5 Screw the new lter cartridge anticlockwise into the cover of the
lter housing (Fig. 30).
6 Insert the cover with the cartridge attached into the lter
housing (Fig. 31).
7 Turn the cover clockwise to tighten it (Fig. 32).
Make sure the cover is tightened rmly.
Environment
Do not throw away the water purier with the normal household
waste at the end of its life, but hand it in at an ofcial collection point
for recycling. By doing this, you help to preserve the
environment (Fig. 33).
Guarantee & service
If you need service or information or if you have a problem, please visit
the Philips website at www.philips.com or contact the Philips Consumer
Care Centre in your country (you nd its phone number in the
worldwide guarantee leaet). If there is no Consumer Care Centre in
your country, go to your local Philips dealer.
-
ENGLISH14

Troubleshooting
This chapter summarises the most common problems you could
encounter with the water purier. If you are unable to solve the problem
with the information below, contact the Consumer Care Centre in your
country.
Problem Solution
Water leaks from
the attachment nut.
Perhaps you have not installed the water
purier properly. Reinstall the water
purier according to the instructions in this
user manual.
Perhaps the attachment nut or the tap adapter
is damaged. Contact an authorised Philips
service centre.
Perhaps the tap water pressure is higher than
specied.
You may need to wind some Teon
tape around the thread of the tap adapter.
Water leaks from the
bottom of the lter
housing unit.
Perhaps the lter cartridge is not properly
installed. Reinstall the lter cartridge. See
chapter ‘Preparing for use’, section ‘Installing the
lter cartridge’.
The water ow is
weak at the unltered
setting.
Perhaps the stainless steel screen under the
rubber washer inside the water selection unit is
clogged. Clean it with a soft brush and rinse it.
The water ow is
weak at the ltered
setting.
Perhaps the lter cartridge is clogged. Replace
the lter cartridge. See chapter ‘Replacement’,
section ‘How to replace the lter cartridge’.
Perhaps the tap water pressure is lower than
specied.
ENGLISH 15

Problem Solution
The water ows from
the safety valve when
ltered water is
selected.
The water pressure is too high. Reduce the
water volume.
Technical specications
The specications below are according to Japanese Industrial Standards
(JIS) s 3201.
Product specications
Product name and type
number
Countertop water purier HD3802
Major lter
components
Polysulphone hollow-bre membrane,
granular activated carbon and granular
activated coral
Initial water ow rate 4ltrs/min. (water pressure at 1kgf/cm2, water
temperature at 20°C)
Chlorine reduction
capacity
8,000ltrs (water density at 2ppm)
Turbidity reduction
capacity
4,000ltrs (water turbidity at 10NTU)
Filter lifetime Approximately 1 year at 20ltrs a day (the
actual lifetime depends on the quality of the
local water and the water pressure)
Replacement lter
cartridge
HD3902
ENGLISH16

Product specications
Minimum water
pressure
0.7kgf/cm² (7 metres of water column/70kPa)
Maximum water
pressure
3.5kgf/cm² (35 metres of water column/
350kPa)
Accessories HD3902 lter cartridge, 8 tap-mounting
adapters
Appliance dimensions Height: 240mm; diameter: 116mm
Packaging dimensions 250mm x 192mm x 140mm (H x W x D)
Weight Approximately 1.3kg
Country of origin Japan
ENGLISH 17

18
簡介
恭喜您購買本產品並歡迎加入飛利浦！請於 www.philips.com/
welcome 註冊您的產品，來善用飛利浦提供的支援。
一般說明(圖1)
1 濾芯外殼
2 過濾水出水口
3 旋轉式懸臂
4 濾網護蓋
5 軟管
6 連接螺帽
7 自來水轉接頭 (A 型 16 公釐)
8 橡膠墊圈
9 不鏽鋼網
10 軟管接頭
11 選水調整鈕
12 水流切換組件
13 底部吸盤
14 扣件
15 自來水轉接頭
A A 型
B B 型
C C 型
D D 型
16 未過濾水注水口
17 顆粒狀活性珊瑚
18 顆粒狀活性碳
19 中空絲膜
20 旋轉式噴嘴
21 已過濾水直流式 (順時鐘方向旋轉噴嘴)
22 已過濾淋灑式 (逆時鐘方向旋轉噴嘴)
重要事項
使用淨水器前，請先仔細閱讀使用手冊，並保留說明以供日後參
考。
繁體中文

警示
本淨水器不適合供下列人士 (包括小孩) 使用：身體官能或心智
能力退化者，或是經驗與使用知識缺乏者。他們需要有負責其
安全的人員在旁看護，或指示產品的使用方法，方可使用。
請看管孩童，避免他們將淨水器當成玩具。
通過淨水器的水請勿高於 50°C，否則可能會損壞淨水器。
請勿讓淨水器結冰。
每日使用前
為防止濾芯快速阻塞，每回使用之前，請先在未過濾的設定下
讓水流出約 5 秒時間。
若水管由於施工而造成水的顏色很深或者混濁，請先等待水清
澈之後，再開始設定過濾水源。
警告：
1 每日使用之前，請先讓水從過濾的設定下流出 10 秒。
2 淨水器若有兩天以上不曾使用，請先讓水從過濾的設定下流出
60 秒。
3 淨水器若有兩週以上不曾使用，請先讓水從過濾的設定下流出
2-3 分鐘之後再使用。如果濾芯發出異味，請更換新濾芯。
使用期間
本淨水器限於用來過濾符合飲用水標準的水。
請勿堵住過濾水出水口，或連接其它裝置。
如果水壓非常高，請減少水龍頭的水流量，以免損壞濾芯。
淨水器請保持遠離熱源，以免變形或損壞。
請勿改裝淨水器。
使用淨水器時請勿取出濾芯
尚未安裝濾芯前，請勿使用淨水器。
請勿將淨水器置於窗戶附近，使其直接曝曬在陽光下。
本淨水器無法軟化水質。
請勿將過濾後的水用於水族箱。自來水無論過濾與否，對魚類
都可能有害。
請勿儲存濾淨後的水，以免水質遭受污染。空氣的接觸會快速
污染濾淨後的水，若您想儲存濾淨後的水，請使用乾淨的容器
然後將其放入冰箱內。在冰箱中，請勿放置超過 1 天以上，以
免遭受污染。
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
繁體中文 19

功能
飛利浦的多重過濾系統共計有主要過濾層、輔助過濾層、高科
技的中空絲膜過濾層、顆粒狀活性碳過濾層，和顆粒狀活性珊
瑚過濾層。
中空絲膜含有超過 1.2 兆個微孔，小到足以去除小至 0.1 微米
的顆粒。能去掉自來水中 99.99%* 的細菌、鐵銹與大於微孔尺
寸的其它微粒，並留下人體所需的鈣、鎂等等礦物質 (* 依照日
本淨水器協會 (JWPA) 標準測試通過)。
顆粒狀活性碳能將自來水中氯所造成的不好氣味與味道去除。
顆粒狀活性珊瑚可以在過濾後的水質中加入自然礦物質，不僅
可以增添風味，也能夠增進健康。
360 度旋轉式懸臂與旋轉式噴嘴可以讓您完全操控過濾後的水
流。
使用前準備
安裝選水調整組件
在更換轉接頭時，請小心水龍頭的螺紋非常銳利。
在您安裝本淨水器之前，請先確定所需的自來水轉接頭都已備
齊。
水龍頭的直徑必須為 13 - 25 公釐。
請判斷您的水龍頭屬於哪種類型，再選取適當的自來水轉接
頭。
隨附的自來水轉接頭讓本淨水器幾乎適用於所有廚房水龍頭。
然而，本淨水器可能無法適合某些少見類型的水龍頭。
自來水水壓必須在 0.7kgf/cm² 到 3.5kgf/cm² 之間。若您以低
於此範圍的水壓使用本淨水器，則過濾後的水流可能極小，或
者沒有水流跑出來。另一方面，若水壓超過此範圍，本淨水器
則會受損。
安裝A型轉接頭
適合直徑為 16 公釐、17.5 公釐或 19 公釐的圓口水龍
頭。 (圖 2)
1 將連接螺帽與轉接頭從選水調整組件上取下。 (圖 3)
2 將連接螺帽穿過水龍頭的口。 (圖 4)
-
-
-
-
-
-
-
-
-
-
-
繁體中文20
