Pickering 60-600 User manual

pickeringtest.com
Issue 4.4 November 2020
60-600 User Manual
LXI 10 Amp 1-Pole Matrix

Page (II) LXI 10 AMP 1-POLE POWER MATRIX 60-600
pickering
Page (II) REED RELAY MODULE 40-110/115/120/125
pickering
© COPYRIGHT (2020) PICKERING INTERFACES. ALL RIGHTS RESERVED.
No part of this publication may be reproduced, transmitted, transcribed, translated or stored in any form, or by
any means without the written permission of Pickering Interfaces.
Technical details contained within this publication are subject to change without notice.
ISO 9001
Reg No. FM38792

Page (III)
LXI 10 AMP 1-POLE POWER MATRIX 60-600
pickering
Page (III)
REED RELAY MODULE 40-110/115/120/125
pickering
TECHNICAL SUPPORT
For Technical Support please contact Pickering Interfaces either by phone, the website or via e-mail.
WARRANTY
All products manufactured by Pickering Interfaces are warranted against defective materials and workmanship for a period of
three years, excluding programmable power supplies, from the date of delivery to the original purchaser. Any product found to be
defective within this period will, at the discretion of Pickering Interfaces be repaired or replaced.
Products serviced and repaired outside of the warranty period are warranted for ninety days.
Extended warranty and service are available. Please contact Pickering Interfaces by phone, the website or via e-mail.
ENVIRONMENTAL POLICY
Pickering Interfaces operates under an environmental management system similar to ISO 14001.
Pickering Interfaces strives to full all relevant environmental laws and regulations and reduce wastes and releases to the
environment. Pickering Interfaces aims to design and operate products in a way that protects the environment and the health and
safety of its employees, customers and the public. Pickering Interfaces endeavours to develop and manufacture products that can
be produced, distributed, used and recycled, or disposed of, in a safe and environmentally friendly manner.
Worldwide Technical Support and Product Information
pickeringtest.com
Germany
Tel: [phone]
E-mail: [email protected]
Sweden
Tel: [phone]
E-mail: [email protected]
USA
Tel: (West) [phone]
Tel: (East) [phone]
E-mail: [email protected]
Czech Republic
Tel: [phone]
E-mail: [email protected]
France
Tel [phone]
E-mail [email protected]
Pickering Interfaces Headquarters
Stephenson Road Clacton-on-Sea CO15 4NL United Kingdom
Tel: [phone]
E-Mail: [email protected]
China
Tel: [phone]
E-mail: [email protected]

Page (IV) LXI 10 AMP 1-POLE POWER MATRIX 60-600
pickering
Page (IV) REED RELAY MODULE 40-110/115/120/125
pickering
MEANING / DESCRIPTION SYMBOL
PROTECTIVE EARTH (GROUND)
To identify any terminal which is intended for connection to an external conductor for
protection against electric shock in case of a fault, or the terminal of a protective earth
(ground) electrode.
DANGEROUS VOLTAGE
To indicate hazards arising from dangerous voltages.
WARNING / CAUTION
An appropriate safety instruction should be followed or caution to a potential hazard
exists.
Refer to the relevant instructions detailed within the product manual.
HEAVY
If this product is heavy reference should be made to the safety instructions for
provisions of lifting and moving.
STATIC SENSITIVE
To indicate that static sensitive devices are present and handling precautions should
be followed.
!
kg
SAFETY SYMBOLS
PRODUCT SAFETY
The following safety symbols may be used on the product and throughout the product documentation.

Page (V)
LXI 10 AMP 1-POLE POWER MATRIX 60-600
pickering
Copyright Statement ......................................................................II
Technical Support and Warranty..................................................III
Product Safety .............................................................................. IV
Contents (this page)...................................................................... V
Warnings and Cautions .............................................................. VII
Section 1
Technical Specication...............................................................1.1
Section 2
Technical Desctiption..................................................................2.1
Functional Description ....................................................2.1
Maximum Frequency of Operations at Full Load......... 2.2
Section 3
Installation....................................................................................3.1
Pre Operation Checks .....................................................3.1
Hardware Installation.......................................................3.1
Setting The IP Address....................................................3.2
Installing The Software....................................................3.3
Soft Front Panel Operation .............................................3.3
Section 4
Programming Guide....................................................................4.1
Programming Options for LXI Units...............................4.1
Programming the 60-600 .................................................4.2
Command Line Control ...................................................4.6
Using The Soft Front Panel...........................................4.13
Section 5
Connections.................................................................................5.1
Section 6
Trouble Shooting .........................................................................6.1
LXI Status Indicators .......................................................6.1
LAN Reset.........................................................................6.2
Section 7
Maintenance Information............................................................7.1
Relay Look-Up Tables......................................................7.1
60-600 Parts List ............................................................7.13
General Maintenance.....................................................7.16
Relay Replacement ........................................................7.19
Appendix A
Fitting Rack Mounting Flanges .................................................A.1
CONTENTS

Page (VI) LXI 10 AMP 1-POLE POWER MATRIX 60-600
pickering
THIS PAGE INTENTIONALLY BLANK

Page (VII)
LXI 10 AMP 1-POLE POWER MATRIX 60-600
pickering
Page vii
LXI HIGH VOLTAGE 2-POLE MATRIX 60-310
pickering
WARNINGS & CAUTIONS
WARNING - HAZARDOUS ENVIRONMENTS SYMBOL
This product is not specically designed for use in hazardous environments, for example in explosive
atmospheres. If the product is to be used in hazardous environments we recommend that the user
ensures suitable protective measures are taken.
!
CAUTION - HANDLING OF ELECTROSTATIC-SENSITIVE DEVICES SYMBOL
Certain semiconductor devices used in this equipment are liable to damage due to static voltage.
Observe the following precautions when handling these devices in their unterminated state, or
sub-assemblies containing these devices:
1. Persons removing sub-assemblies from equipment using these devices must be earthed by a
wrist strap and a resistor at the point provided on the equipment.
2. Soldering irons used during the repair operations must be low voltage types with earthed tips and
isolated from the mains voltage by a double insulated transformer.
3. Outer clothing worn must be unable to generate static charges.
4. Printed Circuit Boards (PCBs) tted with these devices must be stored and transported in
anti-static bags.
WARNING - DANGER OF ELECTRIC SHOCK SYMBOL
This unit may contain hazardous voltages. Before removing the unit from the rack remove all supplies
and disconnect user I/O signals.
If the unit has removable modules, unused slots in the chassis must be populated with blanking
panels to prevent access to user I/O signals that may be present. Blanking panels are available to
order from Pickering. If the product is not used in this manner for example by using an extender card
then additional care must be taken to avoid contact with exposed signals.
Not to be used in safety critical circuits, refer to the Pickering Interfaces’ terms & conditions of sale.
This unit must not be used for the switching of Mains Circuits. For the switching of voltages up to the
unit’s full specication, Secondary Circuit power supplies and the Device Under Test must be fully
isolated from the Mains Circuit and the safety earth.
The chassis must be correctly installed and be connected to mains or factory safety ground,
please refer to the installation section of this manual.
Diagram Showing Separation Between The Mains Circuit and Secondary Circuit / DUT
For the purposes of this document, a Mains Circuit is an installation classied as Overvoltage
Category II up to 300V. Separation between the Secondary Circuit and Mains Circuit is achieved
by a transformer in which the primary windings are separated from the secondary windings by
reinforced insulation, double insulation, or a screen connected to the protective conductor terminal.
Switching
Function
Device
Under Test
Power
Supply
Power
Supply
LXI Unit’s Chassis
Secondary Circuit
Mains
Circuit
Mains
Circuit
Mains/Factory
Safety Ground

Page (VIII) LXI 10 AMP 1-POLE POWER MATRIX 60-600
pickering
Page viii
LXI HIGH VOLTAGE 2-POLE MATRIX 60-310
pickering
CAUTION - PRODUCT DOCUMENTATION SYMBOL
Suitably qualied & trained users should ensure that the accompanying documentation is fully read
and understood before attempting to install or operate the product.
!
SAFETY INSTRUCTIONS
SAFETY INSTRUCTIONS
All cleaning and servicing requires the equipment to be isolated and disconnected from the power source and user I/O
signals (refer to the Maintenance Section).
• Appropriate manual handling procedures should be followed as dictated by the weight of the individual module or
the combined weight of the modules & chassis.
• Should a fault occur with the module or chassis, immediately isolate and disconnect the incoming power to the
chassis and the user I/O signals.
• Ensure the equipment is installed, operated and maintained by trained and authorised personnel.
• For suitably equipped products in the event of an emergency press the red “emergency stop” button situated on
the front of the unit.
WARNING - RACK MOUNTING
If it is required to t this unit into a 19 inch rack, its weight must be
supported by side brackets, runners or a suitable equipment shelf.
The xing holes in the front panel anges are designed only for
securing the device in the rack and must NOT be used to support
the weight of the whole device.
Please refer to Appendix A for the procedure for tting the
supplied anges to either side of the front panel.
!
HIGH VOLTAGE SAFETY WARNING
THIS UNIT IS CAPABLE OF SWITCHING VOLTAGES AND CURRENTS THAT CAN
CAUSE SERIOUS INJURIES. IN APPLICATIONS INVOLVING HIGH VOLTAGES IT
IS STRONGLY RECOMMENDED THAT UNUSED CONNECTORS ARE CAPPED
TO PREVENT ACCIDENTAL CONTACT WHILE IN USE. SYSTEM INTEGRATORS
AND USERS SHOULD CONNECT TO THE FRONT PANEL CONNECTORS WITH
CONNECTORS OR CABLE ASSEMBLIES THAT ENSURE OPERATORS WILL NOT
INADVERTENTLY COME IN CONTACT WITH HIGH VOLTAGES.

Page 1.1
LXI 10 AMP 1-POLE POWER MATRIX 60-600
pickering SECTION 1 - TECHNICAL SPECIFICATION
SECTION 1 - TECHNICAL SPECIFICATION
pickeringtest.com
LXI 10A 1-Pole Matrix 60-600
ISSUE 3.6 NOV 2020
• Single Pole Power Matrix
Available in a Variety of Configurations
• 10A Current Rating WIth 300W/2500VA
Maximum Power
• Hot Switch to 125VDC/250VAC, Cold Switch to
400VDC/250VAC
• Uses Electro-Mechanical Power Relays
• 1U Rack Mountable Enclosure
• LXI Standard 1.4 Compliant
• IVI & Direct I/O Drivers
• 3 Year Warranty
60-600-001 10 Amp 16x16 1-Pole Matrix
Y1
Y2
Y3
Y4
Y5
Y6
Y7
Y8
Y9
Y10
X13 X11 X9 X12 X10 X8 X7 X6 X1
X3
X2 X4 X5
Y11
Y12
Y13
Y14
Y15
Y16
X16 X14 X15
1-Pole
Crosspoint
The 60-600 is a high power single pole matrix suitable for
power signal routing in large ATE systems. It is available with
a selection of X and Y sizes as well as partially populated
congurations. Connections to the X and Y buses are via 8-pin
power D-type connectors.
The matrix congurations are as follows:
• 60-600-001 - Single 16x16 1-Pole Matrix
• 60-600-002 - Single 32x8 1-Pole Matrix
• 60-600-003 - Single 64x4 1-Pole Matrix
• 60-600-004 - Dual 16x8 1-Pole Matrix
• 60-600-005 - Dual 32x4 1-Pole Matrix
• 60-600-006 - Single 16x8 1-Pole Matrix
• 60-600-007 - Single 32x4 1-Pole Matrix
• 60-600-008 - Single 16x4 1-Pole Matrix
It is designed in accordance with the LXI Standard 1.4 and is
supplied in a 1U high, full rack width case with 500mm depth. It
is programmable via the LAN interface using Pickering Interfaces
generic switch driver. Standard (W3C) web browsers can be
used to access and change conguration information and provide
access to the soft front panels.
The 60-600 is ideal for applications where a simple start-up
process is required and for applications requiring control over
large distances.

Page 1.2 LXI 10 AMP 1-POLE POWER MATRIX 60-600
pickering
SECTION 1 - TECHNICAL SPECIFICATION
LXI 10 Amp 1-Pole Matrix – 60-600
pickeringtest.com
Overview
60-600-002 10 Amp 32x8 1-Pole Matrix
60-600-004 10 Amp
Dual 16x8 1-Pole Matrix
60-600-005 10 Amp Dual 32x4 1-Pole Matrix
60-600-003 10
Amp 64x4
1-Pole Matrix
X13
X11
X9
X12
X10
X8
X7
X6
X1
X3
X2
X4
X5
X16
X14
X15
X28
X26
X24
X27
X25
X23
X22
X21
X18
X17
X19
X20
X31
X29
X30
X32
Y1
Y3
Y2 Y4
X45
X43
X41
X44
X42
X40
X39
X38
X33
X35
X34
X36
X37
X48
X46
X47
X60
X58
X56
X59
X57
X55
X54
X53
X50
X49
X51
X52
X63
X61
X62
X64
1-Pole
Crosspoint
Y1
Y2
Y3
Y4
Y5
Y6
Y7
Y8
X13 X11 X9 X12 X10 X8 X7 X6 X1
X3
X2 X4 X5
X16 X14 X15
X28 X26 X24 X27 X25 X23 X22 X21
X18
X17 X19 X20
X31 X29 X30
X32
1-Pole
Crosspoint
Y1.1
Y1.2
Y1.3
Y1.4
Y1.5
Y1.6
Y1.7
Y1.8
X1.13 X1.11 X1.9 X1.12 X1.10 X1.8 X1.7 X1.6 X1.1
X1.3
X1.2 X1.4 X1.5
X1.16 X1.14 X1.15
Y2.1
Y2.2
Y2.3
Y2.4
Y2.5
Y2.6
Y2.7
Y2.8
X2.13 X2.11 X2.9 X2.12 X2.10 X2.8 X2.7 X2.6 X2.1
X2.3
X2.2 X2.4 X2.5
X2.16 X2.14 X2.15
1-Pole
Crosspoint
Y1.1
Y1.2
Y1.3
Y1.4
X1.13 X1.11 X1.9 X1.12 X1.10 X1.8 X1.7 X1.6 X1.1
X1.3
X1.2 X1.4 X1.5
X1.16 X1.14 X1.15
X1.28 X1.26 X1.24 X1.27 X1.25 X1.23 X1.22 X1.21
X1.18
X1.17 X1.19 X1.20
X1.31 X1.29 X1.30
X1.32
Y2.1
Y2.2
Y2.3
Y2.4
X2.13 X2.11 X2.9 X2.12 X2.10 X2.8 X2.7 X2.6 X2.1
X2.3
X2.2 X2.4 X2.5
X2.16 X2.14 X2.15
X2.28 X2.26 X2.24 X2.27 X2.25 X2.23 X2.22 X2.21
X2.18
X2.17 X2.19 X2.20
X2.31 X2.29 X2.30
X2.32
1-Pole
Crosspoint
Y1
Y2
Y3
Y4
Y5
Y6
Y7
Y8
X13 X11 X9 X12 X10 X8 X7 X6 X1
X3
X2 X4 X5
X16 X14 X15
1-Pole
Crosspoint
Y1
Y2
Y3
X13 X11 X9 X12 X10 X8 X7 X6 X1
X3
X2 X4 X5
X16 X14 X15
1-Pole
Crosspoint
Y4
Y1
Y2
Y3
Y4
X13 X11 X9 X12 X10 X8 X7 X6 X1
X3
X2 X4 X5
X16 X14 X15
X28 X26 X24 X27 X25 X23 X22 X21
X18
X17 X19 X20
X31 X29 X30
X32
1-Pole
Crosspoint
60-600-008 10 Amp
Single 16x4 1-Pole Matrix
60-600-007 10 Amp Single 32x4 1-Pole Matrix
60-600-006 10 Amp
Single 16x8 1-Pole Matrix

Page 1.3
LXI 10 AMP 1-POLE POWER MATRIX 60-600
pickering SECTION 1 - TECHNICAL SPECIFICATION
LXI 10 Amp 1-Pole Matrix – 60-600
pickeringtest.com
Specifications
Switching Specification
Switch Type Electro-mechanical
Contact Type: Gold ash over silver alloy
Cold Switching Capacity
Maximum Current:
Maximum Voltage:
10A
400VDC/250VAC*
Hot Switching Capacity
Maximum Current:
Maximum Voltage:
Maximum Power:†
Minimum Switching Capacity:
10A
125VDC/250VAC*
300W/2500VA
10mA, 5VDC
Initial On Path Resistance:
Off Path Resistance:
<100mΩ (50mΩ typical)
>109Ω
Operate Time: 10ms typical
Expected Life (operations) ‡
Mechanical Life:
At Max Hot Switch Capacity:
>5x107
>1x105
* For full voltage rating, signal sources to be switched must be fully
isolated from mains supply and safety earth.
† For variation of maximum hot switching capacity of voltage with
current refer to plot.
‡ As switch life deteriorates rapidly when hot switching signals
above 30VDC, it is advisable to only cold switch above this level.
Power Relay Type
The 60-600 is constructed with high quality electro-mechanical
power relays. 4 spare relays are included inside the unit to allow
easy maintenance with minimum downtime.
Power Source
Universal AC mains supply, 90-120/200-240V 50-60Hz
Power Inlet: Male IEC connector
Power Rating: 100VA maximum
Fuse Rating: 2.5A, 250V
Operating/Storage Conditions
Operating Conditions
Operating Temperature:
Humidity:
Altitude:
0°C to +55°C
Up to 90% non-condensing
5000m
Storage and Transport Conditions
Storage Temperature:
Humidity:
Altitude:
-20°C to +75°C
Up to 90% non-condensing
15000m
Safety & CE Compliance
All products are fully CE compliant and meet applicable EU
directives: Low-voltage safety EN61010-1:2010, EMC Immunity
EN61326-1:2013, Emissions EN55011:2009+A1:2010.
Mechanical Characteristics
Supplied with front panel ears to enable rack mounting on a shelf or
other rear support mechanism.
Dimensions: 1U high, full rack width, 500mm depth
3D models for all versions in a variety of popular le formats are
available on request.
Connectors
• X connections via 8-pin male power D-types.
• Y connections via 8-pin male power D-types.
(The number of connectors depends upon the total X and Y sizes
of the matrix).
For pin outs please refer to the operating manual.
LAN Interface
Compliant to LXI Standard 1.4, the 60-600 has a 1000Base-T
Ethernet Interface via a standard RJ-45 connector mounted on the
rear panel with an LCD display showing the unit’s IP address.*
*Note: Legacy units may not have 1000Base-T support or be tted
with an LCD display.
30VDC / 250VAC Resisve
30VDC / 250VAC
Inducve
60-600 Current/Operating Life Plot
60-600 Current/Voltage Plot
AC Resisve
AC Inducve
DC Resisve
DC Inducve

Page 1.4 LXI 10 AMP 1-POLE POWER MATRIX 60-600
pickering
SECTION 1 - TECHNICAL SPECIFICATION
LXI 10 Amp 1-Pole Matrix – 60-600
pickeringtest.com
Ordering Information
Product Order Codes
LXI 10A 1-Pole Matrix, Single 16x16
LXI 10A 1-Pole Matrix, Single 32x8
LXI 10A 1-Pole Matrix, Single 64x4
LXI 10A 1-Pole Matrix, Dual 16x8
LXI 10A 1-Pole Matrix, Dual 32x4
LXI 10A 1-Pole Matrix, Single 16x8
LXI 10A 1-Pole Matrix, Single 32x4
LXI 10A 1-Pole Matrix, Single 16x4
60-600-001
60-600-002
60-600-003
60-600-004
60-600-005
60-600-006
60-600-007
60-600-008
Product Customization
Pickering LXI units are designed and manufactured on our own
exible manufacturing lines, giving complete product control and
enabling simple customization to meet very specic requirements.
Customization can include:
• Alternative relay types
• Mixture of relay types
• Alternative number of relays
• Different performance specications
All customized products are given a unique part number, fully
documented and may be ordered at any time in the future. Please
contact your local sales ofce to discuss.
Support Products
Spare Relay Kits
Kits of replacement relays are available for the majority of
Pickering’s PXI switching products, simplifying servicing and
reducing down-time.
Product Relay Kit
60-600 - All Versions 91-100-085
For further assistance, please contact your local Pickering sales
ofce.
Mating Connectors & Cabling
For connection accessories for the 60-600 please refer to the
90-012D 8-pin Power D-type Connector Accessories data sheet
where a complete list and documentation can be found for
accessories, or refer to the Connection Solutions catalog.

Page 1.5
LXI 10 AMP 1-POLE POWER MATRIX 60-600
pickering SECTION 1 - TECHNICAL SPECIFICATION
LXI 10 Amp 1-Pole Matrix – 60-600
pickeringtest.com
Supporting Products & Software
We also offer customized cabling and have a free online Cable Design Tool that can
be used to create custom cable solutions for many applications.
Visit: pickeringtest.com/cdt to start your design.
Mass Interconnect
We recommend the use of a mass interconnect solution when an Interchangeable
Test Adapter (ITA) is required for a PXI or LXI based test system. Our modules are
fully supported by both Virginia Panel and MacPanel.
Pickering Reed Relays
We are the only switch provider with in-house reed relay manufacturing capability
via our Relay Division. These instrument grade reed relays feature SoftCenter™
technology, ensuring long service life and repeatable contact performance.
To learn more, please go to: pickeringrelay.com
Connectivity Solutions
We provide a full range of supporting cable and connector solutions for all our switching products—20 connector families with 1200+
products. We offer everything from simple mating connectors to complex cables assemblies and terminal blocks. All assemblies are
manufactured by Pickering and are guaranteed to mechanically and electrically mate to our modules.
Connectors & Backshells Multiway Cable Assemblies RF Cable Assemblies Connector Blocks
Programming
All LXI devices are supplied with built-in software drivers, web pages for conguration and soft front panels as required by the LXI
specication. A variety of drivers are provided (C, .NET, IVI, SOAP) which are compatible with all Microsoft supported versions of Windows
and popular older versions. For a list of all supporting operating systems, please see: pickeringtest.com/os
The drivers may be used in many commonly used programming environments and applications including:
• Pickering Interfaces Switch Path Manager
• National Instruments products (LabVIEW, LabWindows/CVI, Switch Executive, MAX, TestStand, VeriStand, etc.)
• Microsoft Visual Studio products (Visual Basic, Visual C++, Visual C#)
• Keysight VEE and OpenTAP
• Mathworks Matlab
• Marvin ATEasy
• MTQ Testsolutions Tecap Test & Measurement Suite
As well as various open source environments such as:
• Sharp Develop
• Dev-C++
To learn more about software drivers and development environments, please go to: pickeringtest.com/software

Page 1.6 LXI 10 AMP 1-POLE POWER MATRIX 60-600
pickering
SECTION 1 - TECHNICAL SPECIFICATION
LXI 10 Amp 1-Pole Matrix – 60-600
pickeringtest.com
Supporting Products & Software
© Copyright (2020) Pickering Interfaces. All Rights Reserved Pickering Interfaces maintains a commitment to continuous product development, consequently we reserve the right to vary from the description given in this data sheet.
Signal Routing Software
Our signal routing software, Switch Path Manager, automatically selects and energizes switch
paths through Pickering switching systems. Signal routing is performed by simply dening
test system endpoints to be connected together, greatly accelerating Test System software
development.
To learn more, please go to: pickeringtest.com/spm
Diagnostic Relay Test Tools
eBIRST Switching System Test Tools are designed specically for our PXI, PCI or LXI
products, these tools simplify switching system fault-nding by quickly testing the system
and graphically identifying the faulty relay.
To learn more, please go to: pickeringtest.com/ebirst
Three Year Warranty
All standard products manufactured by Pickering Interfaces are warranted against
defective materials and workmanship for a period of three years from the date of delivery to the original purchaser. Extended warranty and
service agreements are available for all our modules and systems with various levels to suit your requirements. Although we offer a 3-year
warranty as standard, we also include guaranteed long-term support—with a history of supporting our products for typically 15-20 years. To
learn more, please go to: pickeringtest.com/support
Available Product Resources
We have a large library of product resources including success stories, product and support videos, articles, as well as complete product
catalogs and product reference maps to assist when looking for the switching, simulation and cable and connector solutions you need.
We have also published handy reference books on Switching Technology and for the PXI and LXI standards.
To view, download or request any of our product resources, please visit: pickeringtest.com/resources

Page 2.1
LXI 10 AMP 1-POLE POWER MATRIX 60-600
pickering SECTION 2 - TECHNICAL DESCRIPTION
SECTION 2 - TECHNICAL DESCRIPTION
FUNCTIONAL DESCRIPTION
The 60-600 is a 1-pole 10 Amp matrix available in 16x16, 16x8, 16x4, 32x8, 32x4, 64x4, dual 16x8 or dual 32x4
formats as well as custom congurations. The chassis contains an embedded processor assembly, power supply
and between one and four matrix cards. Each matrix card contains the relays and driver circuit for a 1-pole 16x4
matrix capable of handling 10 Amps. The matrix signals are hard wired to the front panel mounted connectors.
Switch setting information for the matrix is sent from the Embedded Processor to the relay drivers on the matrix
PCBs via a Distribution Card. Programming information for the processor is sent to the unit via the LAN interface
from a remote computer using the unit’s unique Ethernet address. Programming documentation for the unit as well
as data for Pickering’s other LXI compatible switching products is stored in the embedded processor and can be
downloaded over the LAN interface. Status LEDs on the front of the chassis indicate the condition of the unit and
the LAN connection.
X-BUS
LAN
INTERFACE
PWR
RDY
ERR
LAN
ACT
STATUS LEDs
RJ45
SOCKET
EMBEDDED
PROCESSOR
FRONT PANEL X-BUS
CONNECTORS - Xa1 to Xa16
MATRIX CARD #1 MATRIX CARD #2 MATRIX CARD #3
RELAY DRIVERS RELAY DRIVERS RELAY DRIVERS
16 x 4 RELAY MATRIX 16 x 4 RELAY MATRIX 16 x 4 RELAY MATRIX 16 x 4 RELAY MATRIX
X-BUS X-BUS X-BUS
MATRIX CARD #4
FRONT PANEL X-BUS
CONNECTORS - Xa17 to Xa32
FRONT PANEL X-BUS
CONNECTORS - Xb1 to Xb17
FRONT PANEL X-BUS
CONNECTORS - Xb17 to Xb32
Y-BUS
FRONT PANEL Y-BUS
CONNECTOR - Yb1 to Yb4
FRONT PANEL Y-BUS
CONNECTOR - Ya1 to Ya4
POWER
SUPPLY
LOGIC
SUPPLY
RELAY
COIL
SUPPLY
DISTRIBUTOR
CARD
Y-BUS
Figure 2-1. Block Diagram for the 60-600-005 Dual 32x4 10 Amp Matrix

Page 2.2 LXI 10 AMP 1-POLE POWER MATRIX 60-600
pickering
SECTION 2 - TECHNICAL DESCRIPTION
MAXIMUM FREQUENCY OF OPERATIONS AT FULL LOAD
At full load breaking contacts can create a signicant amount thermal load inside the relays by the generation of
strong signal arcs. If the relays are operated near full load then the rate of operations (a complete on and off cycle)
should be limited to a repetition rate of 0.3Hz to avoid the resulting heat damaging the relay plastic components.
Repeated operation at closer time intervals under full load will result in premature relay failure.

Page 3.1
LXI 10 AMP 1-POLE POWER MATRIX 60-600
pickering SECTION 3 - INSTALLATION
INSTALLING THE POWER MATRIX
The 60-600 may be mounted on a desk top or tted into a standard 19 inch rack (rack mounting anges are supplied
with the unit and can be tted to either side of the front panel). When tting into a rack it is important to provide
adequate support using side brackets or runners, the mounting holes in the front panel anges are designed
only for securing the unit in the rack and must NOT be used to support the weight of the whole unit.
The 60-600 relies upon forced air cooling for the power supply, processor and relay circuit boards. Internal fans
draw air through slots milled in the front panel of the chassis and expell air through vents on the rear panel. When
positioning the chassis, make sure that there is adequate clearance to allow unrestricted air ow through these
vents. The locations of the air intakes and outlets are shown in Figures 3-1, 3-2 and 3-3.
Power is supplied to the rear of the unit using a standard IEC power lead and the power on/off switch is located next
to the power inlet socket. The unit is supplied with a suitable Earthed mains power lead, If a different lead is used it
is important to ensure that an adequate Earth connection is present. When mounted in a rack, provision should be
made to allow access to the rear of the unit. This is to enable the operation of the power on/off switch and the Reset
button. The rear panel layout is shown below.
The Power Matrix is controlled by the host computer via an Ethernet interface. The RJ45 socket on the rear of
the unit can be connected to a hub or switch via an Ethernet cable to allow control over a local area or wide area
network. Alternatively a crossover Ethernet cable can be used to connect the unit to a laptop PC and local control
can be carried out isolated from a network. The IP address of the unit has to be manually or automatically congured
before it can be used on a network, please refer to the following section “Setting the IP Address” and the “LXI Getting
Started Guide” document to carry out this process.
Figure 3-1. Rear view of the Power Matrix showing the mains supply connection,
LAN socket and cooling air outlet
Page 3.1
LXI HIGH VOLTAGE 2-POLE MATRIX 60-310
pickering SECTION 3 - INSTALLATION
SECTION 3 - INSTALLATION
Refer to the Warnings and Cautions at the front of this manual
The product is designed for indoor use only.
!
kg
PREOPERATION CHECKS (UNPACKING)
1. Check the module for transport damage and report any damage immediately to Pickering Interfaces.
Do not attempt to install the product if any damage is evident.
2. Ensure that the designated area for the product is of a at and solid construction to support its weight.

Page 3.2 LXI 10 AMP 1-POLE POWER MATRIX 60-600
pickering
SECTION 3 - INSTALLATION
SETTING THE IP ADDRESS
To use the 60-600 LXI Power Matrix over a LAN connection it should be set up and congured as described in the
“LXI Getting Started Guide” document.
If the IP address is to be set manually and before connecting to a network, contact your IT department so they can
give you the correct settings for:
• IP Address
• Subnet Mask
• Default Gateway
• DNS Server(s)
Once you have the required information, the IP conguration window is used to manually set the IP address. This is
shown in Figure 3-5.
The current IP address setting of the 60-600 is indicated on an LCD display on the rear panel of the chassis.
Figure 3-2. Front view of the Power Matrix showing the intake slots for cooling air
Figure 3-3. Front view of the Power Matrix version with 4 front panel connectors
showing the intake slots for cooling air
Incorrect setting will result in a loss of communication and may also be indicated by a red LAN LED on the front
panel. If this does occur press and hold the LAN Reset button on the back panel of the device for a full factory reset
(see Section 6 “Troubleshooting” for details).
Figure 3-4. Display for IP Address on Rear Panel

Page 3.3
LXI 10 AMP 1-POLE POWER MATRIX 60-600
pickering SECTION 3 - INSTALLATION
SOFT FRONT PANEL OPERATION
The 60-600 LXI Power Matrix can be programmed using the Soft Front Panel. This can be run as a Java Applet from
the device’s LXI home page. You must have the Java Runtime environment loaded from Sun Microsystems to use
this facility. This application can be downloaded from www.sun.com/java .
To access the Soft Front Panel, rst select Instrument Control from the Instrument Home Page, then click the
relevant icon in the displayed window to launch the Java applet.
For a description of the controls, refer to “Using The Soft Front Panel” at the end of Section 4.
INSTALLING THE SOFTWARE
From the device web page, select ‘Driver Download’ from the menu at the left of the page. This will retrieve the driver
from the instrument and install it on your PC.
Alternatively, the driver may be found on the DVD shipped with the product in the ‘Drivers_LXI’ folder: Series-60-
Setup.exe.
This driver may also be found on the Pickering Interfaces web-site at:
http://www.pickeringtest.info/downloads/drivers/Sys60/
or from the Software Downloads section at:
www.pickeringtest.com
Figure 3-5. Example conguration window used to manually set the IP address of a Pickering LXI device

Page 3.4 LXI 10 AMP 1-POLE POWER MATRIX 60-600
pickering
SECTION 3 - INSTALLATION
THIS PAGE INTENTIONALLY BLANK
