Pitco SE14 User manual

Project_________________________
Item No.________________________
Quantity________________________
Pitco Frialator, Inc P.O. Box 501, Concord, NH 03302-0501 509 Route 3A, Bow, NH 03304
603-225-6684 FAX: [phone] www.pitco.com
L10-146 Rev 4 08/11 Printed in the USA
SOLSTICE ELECTRIC (SE) Series
SE14, 14T, 148 (R,X), 18 (R), 184 (R) Fryer
STANDARD FEATURES
Tank - stainless steel construction
Cabinet - stainless steel front, door and sides.
Fixed heating elements for EnergyStarTM**
performance
Solid State T-Stat (SSTC) w/melt cycle & boil out
mode
Mercury Free heating contactors
High Temperature safety limit switch
Drain valve interlock
1 ¼” (3.2 cm) Full port drain valve for fast draining
9” (22.9 cm) adjustable legs, easier access to clean
Element rack
Removable basket hanger, requires no tools
Drain Line Clean out rod
Fryer cleaning brush
Fryer cleaner sample packet
Choice of basket options:
2 Twin baskets
1-Full basket (not available on 14T or Basket Lifts)
APPLICATION
For High Production Electric frying specify Pitco Solstice Electric
Models SE14, 14T, 148 (RX) or 18 (R),184 (R) fryers with
multiple heat input (kilowatt) options for that EnergyStarTM**
performance to meet your frying demands. The Solstice electric
fryer comes in numerous sizes to match different product frying
applications and uses highly reliable fixed heating elements and
environmentally friendly mercury-free contactors. For precise
temperature control the fryer comes standard with a behind the
door solid state thermostat with melt cycle and boil out modes.
For additional timer capability the optional digital control and the
elastic time computer are available and can be used with our
optional labor saving highly reliable basket lift system.
MODELS AVAILABLE
SE14 Series (40-50 lbs, 14 x 14" fry area)
SE14** 17kW/hr
SE14R** 22kW/hr
SE14X** 14kW/hr
SE14T Series (20-25 lbs, 7 x 14-9/32" fry area per
side for this twin vat fryer)
SE14T 17kW/hr (8.5kW per tank side)
SE14TR 22kW/hr (11kW per tank side)
SE14TX 14kW/hr (7kW per tank side)
SE148 Series (60 lbs, 14 x 18" fry area)
SE148 17kW/hr
SE148R 22kW/hr
SE148X 14kW/hr
SE184 Series (60 lbs, 18 x 14" fry area)
SE184** 17kW/hr
SE184R 22kW/hr
SE18 Series (70-90 lbs, 18 x 18" fry area)
SE18 17kW/hr
SE18R 22kW/hr
OPTIONS & ACCESSORIES (AT ADDITIONAL COST)
Digital Controller (2 timers w/ melt cycle & boil out mode)
Intellifry I12 Computer (12 elastic timers w/ melt cycle & boil out)
Backup thermostat (only on Digital and I12 computer)
Basket Lift (must be ordered with Digital control or Computer)
Stainless steel back (not available with basket lift)
9" (22.9 cm) adjustable rear and front locking casters
Tank cover
3-Triple Baskets (not available on 14T)
Consult Factory for other basket configurations
Splash Guard reversible 6" 8" 12" 18"
Work shelves call factory for specifications and availability.
Fish Grids only available on SE18 and SE18R
Institutional Prison security package
BNB Dump Station, see BNB spec sheet for details
Filter System Options
Filter Drawer see spec sheet for details
SoloFilter see spec sheet for details
6’ Power Cord (14KW and 17KW 3ph, 208V or 240V 3Phase
only)
SOLSTICE ELECTRIC (SE) Series SE14, 14T, 148 (R,X), 18 (R) ,184 (R) Fryer
** EnergySta
r
Qualified Model
SE14 (R,X)
w/ standard
SSTC
SE14T (R,X)
w/ optional
rear casters
SE148 (R,X)
w/ optional
Digital Control
SE18 (R)
w/ optional
I12 Computer &
Basket Lifts,
front / rear casters

SOLSTICE ELECTRIC (SE) Series SE14, 14T, 148 (R,X), 18 (R), 184 (R) Fryer
Pitco Frialator, Inc P.O. Box 501, Concord, NH 03302-0501 509 Route 3A, Bow, NH 03304
603-225-6684 FAX: [phone] www.pitco.com
L10-146 Rev 4 08/11 Printed in the USA
SOLSTICE ELECTRIC (SE) Series SE14, 14T, 148 (R,X), 18 (R), 184 (R) Fryer
SHIPPING INFORMATION (Approximate)
45 x 19 x 36 in
114.3 x 48.3 x 91.4 cm
59 x 23 x 44 in
149.8 x 58.4 x 111.7 cm
17.8 ft
3
0.5 m3
17.8 ft3
0.5 m3
17.8 ft3
0.5 m3
34.6 ft3
1.0 m3
Shipping
Cube
Shipping Crate Size
H x W x L
226 lbs
(103 kg)
60 lbs
(27 kg)
70-90 lbs
(32-41 kg)
45 x 19 x 36 in
114.3 x 48.3 x 91.4 cm
45 x 19 x 36 in
114.3 x 48.3 x 91.4 cm
200 lbs
(91 kg)
230 lbs
(104 kg)
250 lbs
(113 kg)
280 lbs
(127 kg)
265 lbs
(120 kg)
Model
40-50 lbs
(18-23 kg)
20-25Lbs *
(9-11.5 kg)
Cooking Area & Depth Oil Capacity Shipping
Weight Shipping Weight w B/L
7 x 14 9/32 x 4 in *
(17.8 x 36.3 x 10.2 cm) 215 lbs
(97.5 kg)
SE (18, 18R)
14 x 18 x 4 in
(35.6 x 45.7 x 10.2 cm)
18 x 18 x 4-3/4 in
(45.7 x 45.7 x 12.1cm)
48
276 lbs
(125 kg)
3 Phase (3 wire + ground)
SE (14, 14T, 148, 18, 184) 480V 82 78 92 46 62
Model KW/Hr 208V 220V 230V 240V 480V
Provide Pitco Solstice Electric Model (SE xxx) electric fryer. Fryer shall be xx-xx lbs oil capacity, xxx kW/hr, "xx by xx" cook area, SS peened tank,
stainless front, door,sides. Fixed immersion type heating elements with high temp alloy sheath, mercury-free contactors, drain valve interlock, 1-1/4"
full port drain, 3/16" bottom hinge with standard behind the door solid state thermostat with melt cycle and boil out (or specify optional digital or
computer controls). Provide options and accessories as follows.
SHORT FORM SPECIFICATIONS
45 41 21
58 53 27 32
Note: 1. Each fryer requires it's own separate power cord. 2. Power supply for Basket Lifts is wired into the fryer's high voltage line terminal block,
except for 480V which requires another separate 115V (2 amp) power cord connection to the unit.
208V 220V
74 71 36
INDIVIDUAL FRYER SPECIFICATIONS
380/220V
17 400/230V 415/240V240V 3 Phase "Y" (4 wire + ground)
Nominal Amps Per Line (50/60 HZ)
ELECTRICAL REQUIREMENTS
SE (14X, 14TX, 148X) 14 67.3 64.7 20.2 19.516.8
24
31
26
34 25
36.7 33.7 21.360.9 58.3 29.2 38.9
SE (14R, 14TR, 148R, 18R, 184R)
SE (14, 14R, 14X) 14 x 14 x 4 in
(35.6 x 35.6 x 10.2 cm)
SE (14T,14TR,14TX)
* per Tank side
SE (148, 148R,148X)
Single Phase (2 wire + ground)
22 106 100 96
276 lbs
(125 kg) 59 x 23 x 44 in 149.8 x 58.4 x 111.7 cm 34.6 ft3
1.0 m3
SE (184, 184R) 18 x 14 x 4-3/4 in
(45.7 x 35.6 x 12.1cm) 60 lbs (27 kg) 226 lbs (103 kg)
OPTIONAL POWER CORD
NEMA 15-60-P PLUG, 4/4 CORD
43
8
[11.1]
3415
32 [87.5]
IN [CM]
34 [86.4]
NOM.
125
32
[4.5]
3813
32 [97.5]
393
4
[101.0]
4815
32
[123.1]
2129
32 [55.6]
9 [22.9]
NOM.
121
2
[31.8]
5
8[1.6]
OPTIONAL
BASKET LIFT
BC
