PLANEPRINT V-TURN User manual

PRINTING & CONSTRUCTION MANUAL
• Our first self designed wing in 3D super lightweight construction.
• Real 1 wall construction (Currently only supported by CURA!).
• Wingspan 1400 mm (55 inches).
WATCH OUT!
This 3D print model
is specially optimized
for CURA.V1.3 2020
STL DATA FOR DOWNLOADING
AT www.planeprint.com
EN
PRINTING & CONSTRUCTION MANUAL
EN
Plnprnt V-TURN

V-TURN
2
PRINTING & CONSTRUCTION MANUAL
© PLANEPRINT
EN
     
You may wonder why this 3D model is suitable exclusively for CURA right?
The most important thing about small RC model airplanes is always the ratio of size to weight.
The lighter a model is, the better its flight characteristics and also the flight time is significantly
increased.
With our unique design process, we manage to make Weights relevant items in a true 1-wall prin-
ting process for the outer skin but also for the filling offer. So we save weight while maintaining the
necessary stability.
Here we show you how to get started from a standard CURA profile Make settings. For this model
we only need 4, easy to create profiles.
It is absolutely necessary to observe the information provided by PLANEPRINT.com in order:
to slice the component correctly. However, it may make sense to perfect your 3D printing by
additionally performing several hiring activities depending on your printer and the filament used.
The development of a complex, airworthy RC flight model to express on any standard 3D printer is
a very complex and extensive process. Therefore, we appeal to your fairness not to forward the STL
data you have acquired to third parties. Our STL files are provided with indelible copyright water-
marks that can be verified at any time.
Thank you for your understanding and have fun with your PLANEPRINT MODEL!
Importnt for th
1-wll-prnt
In order to print airfoils of the lowest possi-
ble weight with high stability, it is necessa-
ry to print with only one wall line (Nozzle 0.4
mm). Decisive here is the adhesion between
the layers! To achieve this, you must print at
a much higher temperature than normal. As
a guideline, 230 ° C is a good starting point.
The parts-cooling fan should be set to 0% or
a maximum of 20%. Since not every printer
works the same, it may be necessary to make
small adjustments to these settings.
For slcng ll Plnprnt
modls, four profls hv
to b crtd n Cur
PROFILE P1_fullbod
PROFILE P2_hollowbod
PROFILE P3_surfc
PROFILE P4_flx
You cn fnd th dscrpton t
wwwplnprntcom/prnt

V-TURN
3
PRINTING & CONSTRUCTION MANUAL
© PLANEPRINT
EN
 

V-TURN 4
PRINTING & CONSTRUCTION MANUAL
© PLANEPRINT
EN
 1_
The following parts must be sliced with the profile P1_FULLBODY.
Recommended additional settings are listed in the screenshots.
INFO
STL: Interconnects_profile1.stl
Material: PLA
Weight: ~ 2 g
ADDITIONAL SETTINGS
• Use transparent PLA, then they
are not visible
INFO
STL: Motorframe_profile1.stl
Material: PLA
Weight: ~ 5 g
ADDITIONAL SETTINGS
None nessesery

V-TURN 5
PRINTING & CONSTRUCTION MANUAL
© PLANEPRINT
EN
 1_
The following parts must be sliced with the profile P1_FULLBODY.
Recommended additional settings are listed in the screenshots.
INFO
STL: Servocover-X_profile1.stl
Material: PLA
Weight: ~ 5 g
ADDITIONAL SETTINGS
None nessesery
INFO
STL: Spinner3blade plate_profile1.stl
or Spinner2blade plate_profile1.stl
Material: PLA
Weight: ~ 1 g
ADDITIONAL SETTINGS
None nessesery

V-TURN 6
PRINTING & CONSTRUCTION MANUAL
© PLANEPRINT
EN
 1_
The following parts must be sliced with the profile P1_FULLBODY.
Recommended additional settings are listed in the screenshots.
INFO
STL: Light_profile1.stl
Material: PLA
Weight: ~ 1 g
ADDITIONAL SETTINGS
• Wall Line Count 20
The lights should be printed sepa-
rately, then the result is nicer be-
cause the print head does not have
to switch between the two parts.

V-TURN 7
PRINTING & CONSTRUCTION MANUAL
© PLANEPRINT
EN
INFO
STL: Starter car_profile2.stl
Material: PLA
Weight: ~ 29 g
ADDITIONAL SETTINGS
• Wall Line Count 4
• Top Layers 3
• Bottom Layers 3
 2_
The following parts must be sliced with the profile P2_HOLLOWBODY.
Recommended additional settings are listed in the screenshots.

V-TURN 8
PRINTING & CONSTRUCTION MANUAL
© PLANEPRINT
EN
INFO
STL: Canopy2_profile3.stl
Material: PLA
Weight: ~ 12 g
ADDITIONAL SETTINGS
Depending on your printer,
a brim may not be nessesery.
 3_
The following parts must be sliced with the profile
PROFILE P3_SURFACE (1 Wall Print). Recommended
additional settings are listed in the screenshots.
PLEASE NOTE
In profile P3_SURFACE, there
should not be more than one STL
on the buildplate at the same time,
otherwise slicing errors can occur!
INFO
STL: Canopy1_profile3.stl
Material: PLA
Weight: ~ 20 g
ADDITIONAL SETTINGS
• brim
• use transparent PLA

V-TURN 9
PRINTING & CONSTRUCTION MANUAL
© PLANEPRINT
EN
INFO
STL: Fuselage2_profile3.stl
Material: PLA
Weight: ~ 98 g
ADDITIONAL SETTINGS
Depending on your printer,
a brim may not be nessesery.
INFO
STL: Fuselage1_profile3.stl
Material: PLA
Weight: ~ 45 g
ADDITIONAL SETTINGS
Reduce Nozzle heat a little and
more fan around the nose.
Depending on your printer,
a brim may not be nessesery.
PLEASE NOTE
In profile P3_SURFACE, there
should not be more than one STL
on the buildplate at the same time,
otherwise slicing errors can occur!
 3_
The following parts must be sliced with the profile
PROFILE P3_SURFACE (1 Wall Print). Recommended
additional settings are listed in the screenshots.

V-TURN 10
PRINTING & CONSTRUCTION MANUAL
© PLANEPRINT
EN
INFO
STL: Fuselage3_profile3.stl
Material: PLA
Weight: ~ 46 g
ADDITIONAL SETTINGS
Depending on your printer,
a brim may not be nessesery.
PLEASE NOTE
In profile P3_SURFACE, there
should not be more than one STL
on the buildplate at the same time,
otherwise slicing errors can occur!
 3_
The following parts must be sliced with the profile
PROFILE P3_SURFACE (1 Wall Print). Recommended
additional settings are listed in the screenshots.
INFO
STL: Aileron-left_profile3.stl
Aileron-right_profile3.stl
Material: PLA
Weight: ~ 15 g
ADDITIONAL SETTINGS
Depending on your printer,
a brim may not be nessesery.

V-TURN 11
PRINTING & CONSTRUCTION MANUAL
© PLANEPRINT
EN
INFO
STL: Wing 2-left_profile3.stl
Wing 2-right_profile3.stl
Material: PLA
Weight: ~ 55 g
ADDITIONAL SETTINGS
Depending on your printer,
a brim may not be nessesery.
INFO
STL: Wing 1-left_profile3.stl
Wing 1-right_profile3.stl
Material: PLA
Weight: ~ 41 g
ADDITIONAL SETTINGS
Depending on your printer,
a brim may not be nessesery.
PLEASE NOTE
In profile P3_SURFACE, there
should not be more than one STL
on the buildplate at the same time,
otherwise slicing errors can occur!
 3_
The following parts must be sliced with the profile
PROFILE P3_SURFACE (1 Wall Print). Recommended
additional settings are listed in the screenshots.

V-TURN 12
PRINTING & CONSTRUCTION MANUAL
© PLANEPRINT
EN
INFO
STL: Wing 3-left_profile3.stl
Wing 3-right_profile3.stl
Material: PLA
Weight: ~ 37 g
ADDITIONAL SETTINGS
Depending on your printer,
a brim may not be nessesery.
INFO
STL: Wing 4-left_profile3.stl
Wing 4-right_profile3.stl
Material: PLA
Weight: ~ 37 g
ADDITIONAL SETTINGS
Depending on your printer,
a brim may not be nessesery.
PLEASE NOTE
In profile P3_SURFACE, there
should not be more than one STL
on the buildplate at the same time,
otherwise slicing errors can occur!
 3_
The following parts must be sliced with the profile
PROFILE P3_SURFACE (1 Wall Print). Recommended
additional settings are listed in the screenshots.

V-TURN 13
PRINTING & CONSTRUCTION MANUAL
© PLANEPRINT
EN
INFO
STL: Winglets_profile3.stl
Material: PLA
Weight: ~ 16 g
ADDITIONAL SETTINGS
Depending on your printer,
a brim may not be nessesery.
INFO
STL: Wing 5-left_profile3.stl
Wing 5-right_profile3.stl
Material: PLA
Weight: ~ 16 g
ADDITIONAL SETTINGS
Depending on your printer,
a brim may not be nessesery.
PLEASE NOTE
In profile P3_SURFACE, there
should not be more than one STL
on the buildplate at the same time,
otherwise slicing errors can occur!
 3_
The following parts must be sliced with the profile
PROFILE P3_SURFACE (1 Wall Print). Recommended
additional settings are listed in the screenshots.

V-TURN 14
PRINTING & CONSTRUCTION MANUAL
© PLANEPRINT
EN
INFO
STL: Spinner3blade_profile3.stl
or Spinner2blade_profile3.stl
Material: PLA
Weight: ~ 3 g
ADDITIONAL SETTINGS
Depending on your printer,
a brim may not be nessesery.
PLEASE NOTE
In profile P3_SURFACE, there
should not be more than one STL
on the buildplate at the same time,
otherwise slicing errors can occur!
 3_
The following parts must be sliced with the profile
PROFILE P3_SURFACE (1 Wall Print). Recommended
additional settings are listed in the screenshots.

V-TURN 15
PRINTING & CONSTRUCTION MANUAL
© PLANEPRINT
EN
 4_
The following parts must be sliced with the profile PROFILE P4_FLEX (flexible materials).
Recommended additional settings are listed in the screenshots.
INFO
STL: Hinges_profile4.stl
Material: TPU soft
Weight: ~ 1 g
INFO
STL: Wheel_profile4.stl
Material: TPU soft
Weight: ~ 9 g
ADDITIONAL SETTINGS
None nessesery
ADDITIONAL SETTINGS
• Wall line Count 10

V-TURN 16
PRINTING & CONSTRUCTION MANUAL
© PLANEPRINT
EN
 
MATERIALS
• some tapping screws Ø2*8mm
2 mm
8 mm
• CA super glue, liquid and liquid medium
• Activator
• servo extension cable
• Carbon rod Ø 3 mm 1 Piece
• Carbon tube Ø8*1000mm 1 Piece
• Steel wire Ø1mm
• Neodym-Super-Magnet
5x5x5mm 4 Pieces
• rod connection 3 Pieces
2 mm
• Velcro and fastening tape
for the battery pack and receiver
TOOLS
• Cutter knife
• Philips screwdriver
• Drill Ø3mm, Ø1,5mm
RC COMPONENTS
Servo 2 Pieces: • Hitec HS-55 or EMAX ES08A
max. 12 mm
(0.47 inches)
max. 22,5 mm
(0.88 inches)
Engine: • Turnigy D2826-10 1400kv Brushless
• Torcster Brushless Gold A2826/10-1400
BEC-Controller: 3S, min. 25A, BEC
Prop: 7045 7x4.5“ 3-blade Counter Rotating
Propeller CW CCW Blade-Black
(can be used left and right turning when
the motor direction is reversed)
or a suitable 2-blade prop
Battery pack: 3S LiPo-Akku 1.500 – 2.200 mAh
TIPP
We recommend the
purchase of a small range of
screws, which can be used
for all future PLANEPRINT
models.
Simply search the Internet
for: M2 Flat Head Tapping
Screw Assortment …

V-TURN 17
PRINTING & CONSTRUCTION MANUAL
© PLANEPRINT
EN
 

V-TURN 18
PRINTING & CONSTRUCTION MANUAL
© PLANEPRINT
EN
IMPORTANT!
For a strong connection, the adhesive surfaces
should be sanded.
Please only use fresh CA glue and activator
spray for curing!
The adhesive connections must hold perfectly!
To glue the fuselage and wing parts
well, use medium-liquid CA adhesive.
First check whether the parts go well
together. Then apply a lot of CA glue
to the part with the connections and all
surfaces that will touch later (except the
bowden tubes). Put the parts together
and align the parts perfectly. If glue co-
mes out, wipe with a cloth. Then spray
activator spray on the glue points.
This surfaces
should be sanded
Connections
Gluing the parts

V-TURN 19
PRINTING & CONSTRUCTION MANUAL
© PLANEPRINT
EN
Assembly of the wings
Wing1
Wing2
Wing3
Wing4
Wing5
Winglet
Use the flat interconnects
to position the Winglets
First remove
the support
from wing 5
Be careful
when handling
the cutter!

V-TURN 20
PRINTING & CONSTRUCTION MANUAL
© PLANEPRINT
EN
Fuselage1
Canopy1
Canopy2
Fuselage2
Fuselage3
Use the interconnects
to position fuselage2
and fuselage3
Use the interconnects
to position fuselage2
and fuselage3
Assembling the fuselage
Assembling the canopy
