PLANEPRINT AERON Programming manual

PRINTING & ASSEMBLING MANUAL
NOTE:
Slicing works best
with CURA!
www.planeprint.com
the ONLY place where you can get
original Planeprint STL files legally!
High-performance motor and glider version

AERON 2
PRINTING & ASSEMBLING MANUAL
© PLANEPRINT
PLALW-PLA TPU CARBON

AERON
3
PRINTING & ASSEMBLING MANUAL
© PLANEPRINT
Required accessoires
Filament
• LW-PLA (cannot be replaced by PLA!), ~800 grams
• PLA oder better Tough PLA, ~300 grams
• TPU A95, ~10 grams
Materials
• some tapping screws
(search for: M2 flat head tapping screw assortment)
• CA super glue (liquid and liquid medium)
• CA activator
• Carbon tube Ø8mm*1000mm (inside 6mm), 2 pieces
• Carbon rod Ø6*1000mm, 1 piece
• Carbon fiber strips (flat profile) 1*5*1000mm, 6 pieces
• Steel wire Ø0.8*1000mm, 3 pieces
• Rod connection, 6 pieces
• Servo cable and soldering accessories
• MPX Connector, 2 pairs
• Self-adhesive Velcro tape
• Some lead (about 150 grams for the glider version)
Tools
Cutter knife, small Philips screwdriver, Sandpaper, Metal saw,
Needle nose pliers, Soldering tool
Rod connection
MPX Connector
Tapping screws 2mm
Carbon fiber strips

AERON 4
PRINTING & ASSEMBLING MANUAL
© PLANEPRINT
RC Components
ENGINE DUALSKY XMotor XM2838EG-11 GLIDER 1100 K/V Brushless Motor
or comparable motors.
You can also use any other motor variant!
NOTE The larger the prop the hotter the engine! Always remember that the motor is mounted
directly on PLA and use it only for short climbs. Or use a slightly smaller prop.
Check in the beginning how hot your motor is after the flight!
FOLDING PROP 11x6 (We recommend a Ø40 mm spinner with cooling function)
BEC-CONTROLLER 50 A (must fit the engine!)
RECEIVER 7 Channel
BATTERY 3S Lipo, 1000 MaH (The battery should have a weight of 400 to 450 grams)
SERVOS 6 pieces like KST DS215 V3 MG Digital HV or comparable
Dimensions (The optimal distance between screws is 28 mm):
23 mm max. 12 mm
max. 30 mm
max. 30 mm
max. 43 mm
Front mounting
44 mm
130 mm
The motor can also be
longer, but check whet-
her there is still enough
space for the controller
and battery.
Space for controller and battery

AERON
5
PRINTING & ASSEMBLING MANUAL
© PLANEPRINT
Printing the parts – Printing profiles
For the new PROFILE P5_Gyroid it is essential to use Cura Version 5 or later, It will work with
older versions, but the weight of the parts will be higher and the printing time longer.
This manual is constantly being improved and supplemented, we recommend downloading
the latest version from our website before building.
The development of a complex, airworthy RC flight model to express on any stan-
dard 3D printer is a very complex and extensive process. Therefore, we appeal to
your fairness not to forward the STL data you have acquired to third parties.
Thank you for your understanding and have fun with your PLANEPRINT MODEL!
Important for the
1-wall-print (P3, P5)!
In order to print airfoils of the lowest possi-
ble weight with high stability, it is necessa-
ry to print with only one wall line (Nozzle 0.4
mm). Decisive here is the adhesion between
the layers! To achieve this, you must print at
a much higher temperature than normal. As
a guideline, 230° C is a good starting point.
The parts-cooling fan should be set to 0% or
a maximum of 20%. Since not every printer
works the same, it may be necessary to make
small adjustments to these settings.
For slicing all Planeprint
models, these profiles have
to be created in Cura:
PROFILE P1_Fullbody
PROFILE P2_Hollowbody
PROFILE P3_Surface (Not necessary for this plane)
PROFILE P4_Flex
PROFILE P5_Gyroid
You can find the description at
www.planeprint.com/print
PROFILE P5_Gyroid
It is essential for the necessary stability of the LW parts
printed with PROFILE_5 are as stable as possible. Please
use a test part to check the strength by fracture tests. It must
not break along the layer lines under any circumstances! Also
note that the printing temperature for LW-PLA is as low as
possible to obtain a wall thickness of 0.4 to 0.6 mm at a flow
of 60 to 70 % (depending on brand).
Caution: at too high temperatures, LW-PLA becomes brittle
and breaks more easily.

AERON
6
PRINTING & ASSEMBLING MANUAL
© PLANEPRINT
P1_Fairing Aileron_ae and
P1_Fairing flap_ae.stl
MATERIAL PLA, Weight: ~ 3 g
ADDITIONAL SETTINGS
• Wall Line Count: 1
• Bottom Layers: 0
• Infill Density: 0 %
• prints two of both STL
PROFILE P1_Fullbody PLA or Tough PLA
The following parts should be sliced with the PROFILE P1_Fullbody.
Please note the additional settings for the individual parts!
P1_Cowling_ae.stl
MATERIAL PLA, Weight: ~ 16 g
ADDITIONAL SETTINGS
• Brim may be needed here

AERON
7
PRINTING & ASSEMBLING MANUAL
© PLANEPRINT
P1_Fuselage 1 motor_ae.stl
MATERIAL PLA, Weight: ~ 30 g
ADDITIONAL SETTINGS
This part is only needed if you want
to print the motor version.
PROFILE P1_Fullbody PLA or Tough PLA
The following parts should be sliced with the PROFILE P1_Fullbody.
Please note the additional settings for the individual parts!
P1_Fuselage 1 glider_ae.stl
MATERIAL PLA, Weight: ~ 40 g
ADDITIONAL SETTINGS
This part is only needed if you want
to print the glider version.

AERON
8
PRINTING & ASSEMBLING MANUAL
© PLANEPRINT
P1_Interconnects_ae.stl
MATERIAL PLA, Weight: ~ 2 g
ADDITIONAL SETTINGS
None required
PROFILE P1_Fullbody PLA or Tough PLA
The following parts should be sliced with the PROFILE P1_Fullbody.
Please note the additional settings for the individual parts!
P1_Fuselage 2_ae.stl
MATERIAL PLA, Weight: ~ 24 g
ADDITIONAL SETTINGS
None required

AERON
9
PRINTING & ASSEMBLING MANUAL
© PLANEPRINT
P1_Motor mount 16/19_ae.stl
MATERIAL PLA, Weight: ~ 2 g
ADDITIONAL SETTINGS
This part is only needed if you want
to print the motor version.
If your engine needs different hole
positions there are alternative STL
P1_MPX connectors_ae.stl
MATERIAL PLA, Weight: ~ 5 g
ADDITIONAL SETTINGS
None required
PROFILE P1_Fullbody PLA or Tough PLA
The following parts should be sliced with the PROFILE P1_Fullbody.
Please note the additional settings for the individual parts!

AERON
10
PRINTING & ASSEMBLING MANUAL
© PLANEPRINT
P1_Protector Fuselage_ae.stl
MATERIAL PLA, Weight: ~ 14 g
ADDITIONAL SETTINGS
None required
PROFILE P1_Fullbody PLA or Tough PLA
The following parts should be sliced with the PROFILE P1_Fullbody.
Please note the additional settings for the individual parts!
P1_Protective wall_ae.stl
MATERIAL PLA, Weight: ~ 2 g
ADDITIONAL SETTINGS
This part is only needed if you want
to print the motor version.

AERON
11
PRINTING & ASSEMBLING MANUAL
© PLANEPRINT
P1_Servo mount ailerons_ae.stl
MATERIAL PLA, Weight: ~ 13 g
ADDITIONAL SETTINGS
None required
PROFILE P1_Fullbody PLA or Tough PLA
The following parts should be sliced with the PROFILE P1_Fullbody.
Please note the additional settings for the individual parts!
P1_Protector Wing_ae.stl
MATERIAL PLA, Weight: ~ 21 g
ADDITIONAL SETTINGS
None required

AERON
12
PRINTING & ASSEMBLING MANUAL
© PLANEPRINT
PROFILE P1_Fullbody PLA or Tough PLA
The following parts should be sliced with the PROFILE P1_Fullbody.
Please note the additional settings for the individual parts!
P1_Servo mount flaps_ae.stl
MATERIAL PLA, Weight: ~ 14 g
ADDITIONAL SETTINGS
None required
P1_V-Tail parts_ae.stl
MATERIAL PLA, Weight: ~ 7 g
ADDITIONAL SETTINGS
None required

AERON
13
PRINTING & ASSEMBLING MANUAL
© PLANEPRINT
PROFILE P1_Fullbody PLA or Tough PLA
The following parts should be sliced with the PROFILE P1_Fullbody.
Please note the additional settings for the individual parts!
P1_Wing belt_ae.stl
MATERIAL PLA, Weight: ~ 7 g
ADDITIONAL SETTINGS
None required
P1_Wing hinges L_ae.stl and
P1_Wing hinges R_ae.stl
MATERIAL PLA, Weight: ~ 5 g
ADDITIONAL SETTINGS
None required

AERON
14
PRINTING & ASSEMBLING MANUAL
© PLANEPRINT
PROFILE P1_Fullbody PLA or Tough PLA
The following parts should be sliced with the PROFILE P1_Fullbody.
Please note the additional settings for the individual parts!
P1_wingconnector_ae.stl
MATERIAL PLA, Weight: ~ 29 g
ADDITIONAL SETTINGS
None required
IMPORTANT Before you glue this part,
please make sure that the 8 mm carbon
tubes fit inside. They should be stiff at the
beginning and go easily after a few times
back and forth. There are small differences in
the diameter of the tubes. If it does not fit,
please reprint this part with slightly reduced
Horizontal Expansion (-0.1 mm or less).
NOTE This part must be absolutely stable,
because it absorbs the forces of the wings.
P1_Clips 1mm wire.stl
MATERIAL PLA, Weight: ~ 1 g
ADDITIONAL SETTINGS
None required

AERON
15
PRINTING & ASSEMBLING MANUAL
© PLANEPRINT
P2_RC Frame glider_ae.stl
MATERIAL PLA, Weight: ~ 45 g
ADDITIONAL SETTINGS
• Top Layers: 3
• Bottom Layers: 3
This part is only needed if you want
to print the glider version.
PROFILE P2_Hollowbody PLA or Tough PLA
The following parts should be sliced with the PROFILE P2_Hollowbody.
Please note the additional settings for the individual parts!
P2_Fairing mount_ae.stl
MATERIAL PLA, Weight: ~ 3 g
ADDITIONAL SETTINGS
None required

AERON
16
PRINTING & ASSEMBLING MANUAL
© PLANEPRINT
P2_Servo frame_ae.stl
MATERIAL PLA, Weight: ~ 3 g
ADDITIONAL SETTINGS
None required
PROFILE P2_Hollowbody PLA or Tough PLA
The following parts should be sliced with the PROFILE P2_Hollowbody.
Please note the additional settings for the individual parts!
P2_RC Frame motor_ae.stl
MATERIAL PLA, Weight: ~ 43 g
ADDITIONAL SETTINGS
This part is only needed if you want
to print the motor version.

AERON
17
PRINTING & ASSEMBLING MANUAL
© PLANEPRINT
PROFILE P2_Hollowbody PLA or Tough PLA
The following parts should be sliced with the PROFILE P2_Hollowbody.
Please note the additional settings for the individual parts!
P2_V-Tail center_ae.stl
MATERIAL PLA, Weight: ~ 15 g
ADDITIONAL SETTINGS
• Infill Pattern: Gyroid

AERON
18
PRINTING & ASSEMBLING MANUAL
© PLANEPRINT
PROFILE P4_Flex
The following parts should be sliced with the PROFILE P4_Flex.
Please note the additional settings for the individual parts!
P4_Hinges_ae.stl
MATERIAL TPU A95, Weight: ~ 1 g
ADDITIONAL SETTINGS
None required
P4_Wing belt flex_ae.stl
MATERIAL TPU A95, Weight: ~ 4 g
ADDITIONAL SETTINGS
• Infill Density: 100 %

AERON
19
PRINTING & ASSEMBLING MANUAL
© PLANEPRINT
P5_AIL 1 L_ae.stl and
P5_AIL 1 R_ae.stl
MATERIAL LW-PLA, ~ 5 g*
*Weighed (approximate guideline)
ADDITIONAL SETTINGS
None required
TIP Label the Aileron parts with
adhesive tape so you don‘t mix them up
during assembly.
P5_AIL 2 L_ae.stl and
P5_AIL 2 R_ae.stl
MATERIAL LW-PLA, ~ 8 g*
*Weighed (approximate guideline)
ADDITIONAL SETTINGS
None required
PROFILE P5_Gyroid Light-Weight LW-PLA!
The following parts must be sliced with the PROFILE P5_Gyroid. Please note the additional settings
for the individual parts! It is essential to print these parts with LW-PLA!
Basic settings for LW-PLA: Please follow the instructions in our WINGTEST AND CALIBRATION TOOL
on our website for correct adjustment!

AERON
20
PRINTING & ASSEMBLING MANUAL
© PLANEPRINT
P5_AIL 3 L_ae.stl and
P5_AIL 3 R_ae.stl
MATERIAL LW-PLA, ~ 4 g*
*Weighed (approximate guideline)
ADDITIONAL SETTINGS
None required
P5_AIL 4 L_ae.stl and
P5_AIL 4 R_ae.stl
MATERIAL LW-PLA, ~ 7 g*
*Weighed (approximate guideline)
ADDITIONAL SETTINGS
None required
PROFILE P5_Gyroid Light-Weight LW-PLA!
The following parts must be sliced with the PROFILE P5_Gyroid. Please note the additional settings
for the individual parts! It is essential to print these parts with LW-PLA!
Basic settings for LW-PLA: Please follow the instructions in our WINGTEST AND CALIBRATION TOOL
on our website for correct adjustment!
