Blackwire®C435
Headset
User guide

2
ContentsContentsContents
Welcome 3
System requirements 3
Registering your product online 3
Technical assistance 3
What’s in the box 4
Headset features 5
Accessories 6
Using your headset 7
Connecting the headset 7
Wearing the headset 7
In-line controls 9
Useful tips 10
Clothing clip 10
Stereo cable tidy 10
Hook and eye cable tidy 11
Troubleshooting 12

3
Welcome
Congratulations on purchasing your new Plantronics product. This guide contains instructions
for using your Blackwire C435 headset.
Please refer to the safety instructions found in the Quick Start Guide for important product
safety information prior to installation or use of the product.
System requirements
Computer
Supported operating systems: Windows XP®, Windows Vista®, Windows® 7
Processor: 400 MHz Pentium® processor or equivalent (Minimum); 1 GHz Pentium processor or
equivalent (Recommended)
RAM: 96 MB (Minimum); 256 MB (Recommended)
Hard disk: 280 MB (Minimum); 500 MB (Recommended)
Microsoft Windows XP - Service Pack 3 (SP3) or later (Recommended)
Microsoft Windows Vista - Service Pack 1 (SP1) or later (Recommended)
Display
At least 800 x 600, 256 colours
We recommend: 1024 x 768 high colour, 32-bit (Recommended)
Browser
Internet Explorer® V6 or better must be on the user’s system (Required)
Registering your product online
Visit plantronics.com/productregistration to register your product online
so we can provide you with the best possible service and technical support.
Technical assistance
Visit our web site at plantronics.com/support for technical support including frequently asked
questions, compatibility and accessibility information.

Large and small ear gels and mono connector cover
Carrying caseBlackwire C435 headset
4
What’s in the box

5
Headset features
1
14
1 Noise-cancelling microphone
2 Right speaker
3 Right ear loop
4 Ear gel (fitted)
5 Left ear loop
6 Ear gel (fitted)
7 Left speaker
8 Stereo cable tidy
9Mono/stereo connection
10 In-line control
11 Mute/unmute
12 Volume up/volume down
13 Call answer/end
14 USB connector
2 3 4 5 6 7
131198 1210

6
Accessories
(Sold separately)
Headband and case For those who would prefer a neckband wearing style. An accessory (with
its own larger case) is available as an option.

7
Connecting the headset
Simply plug the headset into the USB port on your PC.
NOTE For call control and other features, download Plantronics software at
http://www.plantronics.com/businesssoftware.
Wearing the headset
The headset comes fitted with the ear loop and medium ear gel.
1 To wear the headset, simply place the ear gel in your ear with the loop at the top of your ear
and rotate the microphone boom forwards. The microphone should be pointed to the corner of
your mouth. If it cannot be comfortably positioned there, you can rotate the ear loop and gel to
fit your ear.
Using your headset

8
2 The headset comes configured with the microphone on the left but it’s very simple to switch
the microphone to your right ear if you prefer that configuration. Simply pull the ear loops off
the speaker, rotate them and replace.
3 The headset comes with medium ear gels already fitted. If you find that the headset is
uncomfortable or unstable, you can easily change the gel to suit. Simply unpeel the gel that is
on the speaker and replace with a different one.
Large Small
4 Once the headset is positioned on your head, adjust the flexible boom to place the tip closer to
the corner of your mouth. The boom can be shaped to follow the curvature of your face.
2"
50.8
mm

9
5 For those users who do not want speakers in both ears (all the time or just occasionally),
you can disconnect the second speaker at the connection point shown below. This will
automatically change the headset from stereo to mono (and vice versa when reconnecting).
*
*The headset is supplied with a cover for the connector when configured as a mono headset
In-line controls
Call answer/end Can be used to answer or end a call directly from the headset with a single press.
LED will flash green when a call is coming in and be solid green when on a call.
Volume Volume up and down are available.
Mute A single press of the mute button will mute the microphone. A red LED will be on
when you are muted. Pressing this button again will take the microphone off mute.
NOTE For call control and other features, download Plantronics software at
http://www.plantronics.com/businesssoftware.
IMPORTANT For your safety, do not use headset at high volumes for extended periods
of time. Doing so can cause hearing loss. Always listen at moderate levels. For more
information on headsets and hearing visit: plantronics.com/healthandsafety.
