USER GUIDE
CS50-R
......................................................................................
WIRELESS OFFICE HEADSET SYSTEM

2
TABLE OF CONTENTS
REGISTER YOUR PRODUCT ONLINE
Package Contents
Features
Setup
Positioning
Adjusting Fit
Charging
3
4
6
7
8
7
9
Making/Answering/Ending Calls 8
Headset Controls
Volume
Mute
11
10
9
Troubleshooting
13
Base Indicator Lights
11
Battery Replacement
13
System Reset
14
15
Subscription
15
15
Maintenance
Technical Assistance
Regulatory Notices
Visit www.plantronics.com/productregistration to register your CS50-R product online so
we can provide you with the best possible service and technical support.

3
PACKAGE CONTENTS
Headset
Earloops
Headband
CS50
CS55
Base
AC Charger
AC Charger
Headset and Wearing Options
Base
You can wear your new headset either over your head or over the ear. You may change
your wearing style as often as you like.

4
FEATURES
Charge Indicator Light (red)
Subscription
Button Access
Hole (paperclip
required)
Charge Contacts
Status Indicator Light (green)
Headset Docking Cradle
AC Charger Port
Back and Side
Front

5
FEATURES
Front:
Rear:
Listening
Volume/Mute
Talk Indicator Light
Speaker
Battery Cover
Call Control Button
Microphone
Headset
Telephone Cord Jack
Telephone Handset Jack
Speaking Volume
Major Adjust
AC Charging Jack
Handset Lifter Jack
RingerSwitchOn/Off
Stand Pegs
3.5mm
Connector
Base
Headset

6
SETUP
Plug the cord that is connected to the CS50-R base into the 3.5mm jack on the CS50-R
compatible phone.
CAUTION: Your phone may have two similar jacks. Put the cord only in the jack that fits,
it's the one furthest toward the back of the phone.
Plug the AC charger into an outlet and into the base’s AC charging jack.
1
2
Before starting the setup of the CS50-R headset system, install your CS50-R compatible
phone and be sure it is working properly. For installation details regarding your phone,
refer to the user guide that came with it.

HEADSET MUTE
To mute headset, press the listening volume/mute button straight in. Press again
to unmute.
You will hear 3 rapid beeps every 30 seconds to indicate mute is on.
LISTENING VOLUME
Rock the headset volume control back and forth to adjust listening volume.
NOTE: Be sure to set your telephone’s volume at the mid range before adjusting the
CS50-R volume.
9

10
HEADSET CONTROLS
Making/answering/
ending calls
Ascending/descending
tones, 3 tones at limit
2 tones every 15 seconds
Short key press
Short key press
straight in
Rock back
and forth
Mid tone
Low battery
warning (5 minutes of
talk time remaining)
Return headset
to charging cradle 1 tone every 10 seconds
Out of range
warning - when on
an active call
Move closer
to base 2 tones just before range
limit. 3 tones beyond
range limit and active
call will be suspended.
1 tone will sound when
returning within range;
call will be re-established
if within 15 minutes
Incoming call
notification*
Press call control
button to answer call 3 repetitive tones
Mute
Listening volume
Key Feature Action Tone
