Plum Z515 User manual

Z515 Might Plus 2
User Manual

Content
Key points󰦗..................................................................................................1
Packing List:..................................................................................................2
Product Specification.....................................................................................2
Charging your device󰦗.................................................................................4
Battery Saving ...............................................................................................4
Connecting to a PC:.......................................................................................5
Connecting a USB device:.............................................................................5
Inserting the MicroSD card :..........................................................................6
Connecting to the Network: ...........................................................................6
Power On.......................................................................................................7
Sleep Mode....................................................................................................7
Power off and Reboot ....................................................................................7

Operation of Touch Panel ............................................
Home Screen ...............................................................................................10
Change of Wallpaper ...................................................................................11
Add shortcut on Home screen......................................................................11
Add Widget in Home Screen .......................................................................11
Relocate the shortcut on Home screen .........................................................11
Cancel shortcut on Home screen..................................................................11
Notification screen.......................................................................................13
Applications.................................................................................................13
Browsing webpage ......................................................................................14
Email ...........................................................................................................15
Sending outgoing message...........................................................................16
Check email message...................................................................................16
Audio player ................................................................................................17
Video player ................................................................................................17
............................... 7

File Manager................................................................................................19
FM Radio.....................................................................................................21
Phone...........................................................................................................22
Messaging....................................................................................................23
Contacts.......................................................................................................23
Commonly used settings SIM Card Management........................................24
More… ........................................................................................................25
Sound&notification .........................................................................................26
Display ........................................................................................................27
Wallpaper ....................................................................................................27
Font size ......................................................................
Screen time out ............................................................................................27
Storage.........................................................................................................28
Apps ............................................................................................................28
Location ................................................................
................................ 27
................................ 28
....

Language&Input..........................................................................................28
Backup and reset..........................................................................................29
Accounts......................................................................................................29
Date& time ..................................................................................................29
Scheduled power on and off ........................................................................29
Accessibility ................................................................................................30
About phone ................................................................
Troubles Shooting........................................................................................32
................................31

1
Key points󰦗
This manual includes security measures and correct operating methods. For personal safety, please
make sure to read this manual before using. Thank you!
The machine adopts capacitive touch screen, you can just touch it by finger or click with capacitive
pen for operation. (Never use the sharp objects to click the screen, or the touch screen may be
damaged).
Do not put the device at any high temperature, high humidity or dusty place.
Do not drop or crash the device to prevent the violent impacting between the display and the
capacitive touch screen. Or the customers have to take the consequence by themselves.
Please choose the suitable volume and never make the too loud volume .If you feel uncomfortable
please turn down the volume or stop to use the device soon.
Please charge if you meet those situations as below:
A、Low battery on the battery icon. B、The system turns off automatically.
C、The keys do not work. D、―‖ is battery charging.
󰆜Note󰆝:Don’t use the different type charger or it may make the device burned. We assume no
liability for the damage. Please contact with our agent if you need the original adaptor.
In the charging process，the device may be warning up a little (not too hot), this is normal, and it
won’t effect functions.
Do not disconnect the device while formatting, downloading or uploading, or it may make the error.
Do not dismantle this device by yourself, and do not polish it with alcohol, dilution, or benzene.
Do not use this device where electronics is forbidden, such as on the airplane.
Do not use this device while walking and driving, avoiding traffic accident.
USB is for transferring data.
For any support needed for this device please contact the company or the authorized distributor.
Any unauthorized dismantling of the device will make the warranty null and void.

2
Packing List:
Please check box for the following items
1. Device
2. User Manual
3. Earphone
4. Power Adaptor
5. USB Cable
Product Specification
CPU Cortex: MT6580A
OS:Android 5.1
Size: 146.15*73.9*9.00mm
RAM: 512MB RAM GB DDRIII
ROM: 4GB ROM
External Maximum 32GB
3G : WCDMA:B2/B4/B5
2G: GSM:850,1900
Camera : Front 2.0M px󰦘Rear 8.0M px
FM: 87.5MHZ-108.0MHZ
Music format: MP3
Video format: MPEG4
Picture format: JPEG
Battery : 2000mAh

3
Device description
1 Touch screen:You can click and drag in the touch screen.
2 Front Camera:You can take photos and videos etc..
3 Earphone jack: 3.5mm standard earphone jack.
4Micro USB, Micro-5 pin connector & Connect the power able
to charge to the device.
5 Rear Camera:You can take photos and videos etc..
6 Glittering:Will flash when taking pictures
7 Speaker
8 Micro SD/TF card:Micro SD/TF card slot.
9 POWER󰦗Keep pressing button over 2 seconds
for power on/ off, press button once to turn on
screen from sleep mode .
10 Volume +:Turn up the volume
Volume -:Turn down the volume
11 SIM Card:Insert/Pull out SIM Card
󰆜TIPS 󰆝󰦗1. When the battery is low, it will power off automatically.
2. Shutdown illegally, when you restart, device would scan and repair the disk. The
screen will stay at the progress bar for a long time.

Setting up for the first time
Charging your device󰦗
For first-time use, you need to charge the device for ten hours.
After that you can recharge the device as needed.
Connect the DC-in jack to your device and plug the AC
adapter into any AC outlet.
󰆜TIPS󰆝:
1. This device adopts built-in polymer battery. Only the specified
charger should be used.
2. It is normal for the device’s surface to become warm during
charging or long periods of use. All devices are factory tested
before release.
3. If you do not use this set for a long time, please charge/release it once
One month to avoid deep discharge. The damage caused by battery over-consuming
is not included in the warranty.
Battery Saving
To save battery running life, please see below key points. With below suggestions, battery can run
longer time after fully charged
each time.
1. When device is not in use, press power button once to go to sleep mode.
2. Shut down the applications when not in use.
3. Turn off WLAN when not in use
4. Shut off application sync selection
5. Set a shorter time for display backlight
6. Reduce brightness of display 4

Connecting to a PC:
You can connect with PC by USB cable attached with the device.
You can transfer your personal data to the PC.
Connect the PC and the device, it will change to
the USB mode, in this state, realize the files
transfer function between the PC and the device
Connecting a USB device:
USB devices are supported, such as a keyboard,
mouse through the USB port.
View media files on USB storage with installed
photo, music or video applications.
󰆜Caution󰆝: Before removing this USB storage, make
sure your device is not accessing data from the USB
storage
.
5

Inserting the Micro SD card :
You may install a Micro SD card to expand your device’s
storage space.
1. This device supports Micro SD card up to 32GB capacity.
2. Insert the Micro SD card as shown.
󰆜Note󰆝: Ensure that the Micro SD card is inserted all the
way into the card slot.
󰆜Caution󰆝: Before removing this card, make sure your device
is not accessing data on the card.
Connecting to the Network:
WLAN wireless setup:
Enter the setting interface, and turn on the WLAN
item. The device will automatically search any
accessible nearby wireless networks.
6

7
Power On
Keep pressing power button over 2 seconds, device will start up opening screen; Android system is
activating and enter the main screen.
Sleep Mode
After devise is on, press power button once and it goes to sleep mode. The screen is now on standby
and under low battery consumption. To wake up device, press one more time power button.
Power off and Reboot
When you are not using the device, keep pressing power button over 2 seconds, the screen will
display two options: ―Power off‖and ―Reboot‖.Select Power off ,the phone will shun down while
selecting Reboot, it will restart.
Click -- Use finger or capacity panel pen to touch once, so as to select or activate function, or select
menu or turn on applications.

8
Tap and hold -- Tap over 2 seconds, it will turn on option list
Slide -- Slide up, down, left or right for fast scrolling browsing page and display screen
Drag –drag an icon and relocate the position

9
Double Click –Double click to enlarge or shrink the display size of picture
Shut --Use two fingers at same time on touch panel, to enlarge or to shrink the display scale.

10
Home Screen
1 Google search 2 Google voice search 3 Back key
4 Home key 5 Menu key 6 Status bar
7 Settinges App 8 Enter apps interface

11
Home screen with a set of 3 screens, slide left/ right to view individual screen
Change of Wallpaper
1. Click Menu key on home screen , it will pop-up wallpaper selection
2. Select preloaded wallpapers or picture as wallpaper
3. Click ―Set wallpaper‖ to confirm
Add shortcut on Home screen
1. Enter in application menu, tap and hold the icon of the application
2. Drag the icon to home screen where you want to placed and release
Add Widget in Home Screen
1. Click Menu key on Home screen
2. Select ―WIDGETS‖to enter widget screen
3. Tag designated widget and locate it in home screen
Remark󰦗Some widgets is linked to internet service, be careful it will occur data cost
some widgets might only be used in certain countries or under assigned service providers
Relocate the shortcut on Home screen
1. Tag the application icon and move
2. Move icon to the designated position
Cancel shortcut on Home screen
1. Long press one icon of application on home screen until you see ―X Remove‖icon
display on top of home screen
2. Drag icon into the ―X Remove‖icon

12
3. When icon changes to red, let go

13
Notification screen
On top of the main screen, check device status and set up below options󰦗
Icon Icon Description
WLAN signal WLAN connection, icon is full under strong signal
Battery Show the status of battery or if device is being charged
USB Connection To show if USB port is connected
Soft keyboard Turn on soft keyboard, for word typing Screen
shot After taking screen shot, show picture saved
Applications
Internet Browsing
Browse internet and bookmark the website
Remark 󰦗Web browser and bookmark might be different in different countries or different service
providers

14
Browsing webpage
1. Enter application page, select ‖Browser‖ Icon
2. To brows certain webpage, select URL and input website address, and select ―confirm‖
3. See below browsing options:
3.1 Input address: On top of interface, you can tap to input address
3.2 Go to Previous page：Tap this icon：
3.3 Go to Next page: Tap this icon:
3.4 Open new tabs: Tap this icon:
3.5 View Bookmarks/History/Saved pages: Tap this icon:

15
‖
Browser settings
When browsing webpage, click Menu key to enter browser settings
Enter application page, click ‖Browser‖
1. Select bookmark current visited history
2. Select webpage
Email
Send and Receive email
Setting of email account
1. Enter application page and click ‖Email‖
2. Enter email address and password
3. Select next step ( for personal email account) or manual setting (for commercial email account)
4. Follow and input the requested setting
After email account setting, message will be received in device. For more than one email account,
switch email account for operation, to receive and send out message.
