Revolabs Single Channel System - Polycom VSX7000e Setup Guide
NOTES AND CAUTIONS:
This setup guide will guide you through the steps needed to properly connect a
Revolabs Single Channel System to a Polycom VSX7000e video codec.
1. Connecting the Cables
2. Configuring the VSX7000e Video Codec
Note: It is important to carefully follow these instructions in order and completely.
Otherwise your Single Channel System and/or the video codec may not function
properly. Please read through these instructions completely before proceeding.
Contact Revolabs technical support if you have any questions.
Requirements for connecting systems:
1. Revolabs Single-Channel System
2. Revolabs 2.5mm to RCA Audio Cable (included with Single -Channel)
3. Polycom VSX7000e video codec

Connecting the Cables
CONNECTING A REVOLABS SINGLE CHANNEL SYSTEM TO POLYCOM VSX7000e VIDEO CODEC
1. Connect a Revolabs 2.5mm to RCA audio cable between the 2.5mm analog
output on the Single Channel System and the red “LINE INPUT” port on the
VSX7000e.
Configuring the VSX7000e Video Codec
CONFIGURING THE A UDIO MENUS OF THE VSX7000e VIDEO CODEC
1. Select SYSTEM
2. Select ADMIN SETTINGS
3. Select AUDIO
4. Set Red LINE INPUT to AUDIO MIXER
5. ENABLE Echo Canceller
6. DISABLE Polycom microphones by removing checkmark on ENABLE POLYCOM
MICROPHONES
