Precor EFX524 User manual

Light Commercial EFX®Owner’s Manual
COMMERCIAL PRODUCTS DIVISION

page 2
COMMERCIAL PRODUCTS DIVISION
When using the EFX®, basic precautions should always be followed, includ-
ing the following:
• To ensure your safety and to protect the unit, read all the instructions
before assembling and using the self-powered EFX®524.
• To ensure the proper use and safety of the EFX, make sure that all users
read this manual. Please make this manual a part of your staff’s training
program. Remind the users that before beginning any fitness program,
he or she should obtain a complete physical examination from his or her
physician.
Il est conseillé de subir un examen médical complet avant d’entre-prendre
tout programme d’exercise. Si vous avez des étourdissements ou des
faiblesses, arrêtez les exercices immédiatement.
DANGER —
WARNING —
• Do not allow children or those unfamiliar with its operation on or near
the EFX. Do not leave children unsupervised around the EFX.
• Never leave the EFX unattended with the optional battery recharger
plugged in. Unplug the unit from the outlet when it is not in use, before
cleaning it, and before putting on or taking off parts.
• Assemble and operate the EFX on a solid level surface. Locate the EFX
a few feet from walls or furniture. Check the unit before each use and
verify that all fasteners are secure. Maintain the EFX in good working condi-
tion. (See the Maintenance section).
• Use the EFX only for its intended use as described in this manual. Do
not use accessory attachments that are not recommended by the manu-
facturer—such attachments might cause injuries.
• Use care when getting on or off the EFX. Use the stationary handrail
whenever possible. Keep your body and head facing forward. Never
attempt to turn around on the EFX.
• Wear proper exercise clothing and shoes during a workout—no loose
clothing.Tie long hair back.
• Do not rock the unit. Do not stand on the display console or casing.
• Never drop or insert any object into any opening. Keep towels and
hands away from moving parts.
• If you purchased the optional POLAR®chest strap, review the guide-
lines found in the Precor Heart Rate Option Owner’s Manual that is
supplied with that option.
• Do not overexert yourself or work to exhaustion. If you feel any pain or
abnormal symptoms, stop your workout immediately and consult your
physician.
IMPORTANT SAFETY INSTRUCTIONS
To reduce the risk of electrical shock, always unplug the
optional battery recharger from its power source before clean-
ing or performing any maintenance tasks.
To reduce the risk of burns, fire, electric shock, or injury to
persons, take the following precautions:
IMPORTANT SAFETY INSTRUCTIONS

page 3
COMMERCIAL PRODUCTS DIVISION
•Keep all electrical components away from liquids to prevent shock. Do not
set anything on the casing, handrails, or display console. Place liquids,
books, or magazines in the appropriate receptacles.
• Never place your hand(s) or feet in the path of the roller arm because
injury may occur to you or damage may occur to the equipment.
• Never operate the unit if it is damaged, if it is not working properly, if it
has been dropped, or dropped in water. Return the unit to a service
center for examination and repair.
• Keep the optional battery recharger cord away from heated surfaces.
• Do not operate where aerosol (spray) products are being used or where
oxygen is being administered.
• Do not use outdoors.
• Do not attempt to service the EFX yourself other than the assembly and
maintenance instructions found in this manual. Refer to Obtaining Service .
HAZARDOUS MATERIALS AND PROPER DISPOSAL
The EFX524 has an internal battery which must be removed before the EFX is
scrapped.The battery contains materials which are considered hazardous to the
environment. Proper disposal of the battery is required by federal law.
To remove the battery from the EFX, take the following steps:
CAUTION: Unplug the battery recharger and disconnect it from
its receptacle at the rear of the EFX.
Tools required: Phillips head screwdriver and hex wrench set.
1. Remove both the right and left rear covers from the EFX.
2. Remove the top rear cover.
3. Unplug the black and red battery wires from the circuit board.
4. Separate the circuit board from the battery by removing four screws.
5. The battery is held in place with a metal bracket. Lift the battery away from
the bracket.
6. Dispose of the battery according to the federal Hazardous Waste Regulations.
SAFETY APPROVAL
When identified with the ETL-c logo, the EFX has been tested and conforms to
the requirements of CAN/CSA-E-335-1/3-94, Safety of Household and Similar
Electrical Appliances.
IMPORTANT SAFETY INSTRUCTIONS
IMPORTANT SAFETY INSTRUCTIONS
SAVE THESE INSTRUCTIONS

page 4
COMMERCIAL PRODUCTS DIVISION
Important Safety Information ...........................................2
Hazardous Materials and Proper Disposal .............................. 3
Safety Approval ..................................................................... 3
RFI — Radio Frequency Interference ..................................... 6
European Applications ........................................................... 6
EFX®Self-powered Features .................................................. 7
Obtaining Service ................................................................... 7
About this Manual .................................................................. 8
Unpacking the EFX®.................................................................................................. 9
Standard Equipment ............................................................... 9
Other Equipment .................................................................... 9
Acquiring the Appropriate Tools .............................................. 9
Hardware Kit .......................................................................... 10
Setting Up the EFX .........................................................11
Installation Requirements ....................................................... 11
Assembly Instructions ........................................................... 11
Removing the Locking Pin...................................................... 23
Supplying Power To the EFX®524 ........................................... 23
Testing the Heart Rate Display ............................................... 24
Custom Settings Mode ..................................................25
Changing the Custom Settings ............................................... 25
Determining the Units of Measure .......................................... 26
Setting a Workout Time Limit.................................................. 27
Setting a Pause Time Limit .................................................... 27
Viewing the Odometer, Hours of Use,
Software Version, and Error Log ............................................. 27
Using CSAFE Standard Equipment ........................................ 28
The EFX®524 Display .....................................................29
Features on the Display Console ............................................ 29
User Setup Prompts ............................................................... 30
Using QUICKSTARTTM During the Setup Prompts .................. 31
SmartRate®Display ............................................................... 32
Center Display........................................................................ 32
CrossRamp®Display .............................................................. 33
Informational Displays Prior to Shutdown ............................... 33
Keys on the Display Console .................................................. 34
Table of Contents

page 5
COMMERCIAL PRODUCTS DIVISION
Table of Contents
Exercising on the EFX®..................................................................................... 36
Removing the Locking Pin...................................................... 36
The Heart Rate Feature .......................................................... 36
Utilizing the SmartRate®Feature ............................................ 37
Workout Tips .......................................................................... 37
Using the Stationary Handrail ................................................. 38
Changing the Display Features using the SELECT Key .......... 38
Quick Steps to Working Out ................................................... 39
Cooling Down After a Workout ................................................ 40
Pause, Cool Down and Exit Features ..................................... 40
Inserting the Locking Pin ....................................................... 41
Courses...........................................................................42
Manual Mode and the QuickStart Key .................................... 42
Gluteal Course ....................................................................... 42
Interval Course ....................................................................... 43
Cross Training Course ............................................................. 44
Weight Loss Course ............................................................... 44
Maintenance ...................................................................45
Inspection .............................................................................. 45
Cleaning the Equipment ......................................................... 45
Storing the POLAR®Chest Strap ........................................... 46
Servicing the EFX and Long Term Storage ............................. 46
Symptoms of a Low Battery ................................................... 46
Using the Battery Recharger and Its Power Cord .................... 46
Replacing the Battery ............................................................. 47
Exploded Views ...................................................................... 49
Commercial Warranty Registration Card ................................. 57
Commercial Warranty Card ..................................................... 59
Specifications ............................................................back cover

page 6
COMMERCIAL PRODUCTS DIVISION
RFI — RADIO FREQUENCY INTERFERENCE
Federal Communications Commission Part 15
The EFX has been tested and found to comply with,
• the IEC EMC Directive (international electromagnetic compatibility certification)
• the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful
interference in a commercial installation. The EFX generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance
with the owner’s manual instructions, may cause harmful interference to radio
communications. Operation of the EFX in a residential area is likely to cause
harmful interference. If this occurs, the user will be required to correct the
interference at his or her own expense.
CAUTION —
Canadian Department of Communications
This digital apparatus does not exceed the Class A limits for radio noise emissions
from digital apparatus set out in the Radio Interference Regulations of the Canadian
Department of Communications.
Le présent appareil numérique n’émet pas de bruits radioéélectriques dépassant les
limites applicables aux appareils numériques de la Class A prescrites dans le
Règlement sur le brouillage radioélectrique édicté par le ministére des Communica-
tions du Canada.
EUROPEAN APPLICATIONS
This product conforms to the requirements of the European Council Directive 89/336/
EEC, Electromagnetic Compatibility and has been tested to the following standards:
EN55022, Limits & Methods of Measurement of Radio Interference, Information
Technology Equipment (Class A).
EN50082-1, Generic Immunity Standard for Residential, Commercial and Light
Industrial Products (Class A).
This product additionally conforms to the requirements of the European Council Directive
73/23/EEC, Low Voltage Directive and has been tested to the following standard:
IEC 335-1, Safety of Household and similar Electrical Appliances.
European Applications
This product has been tested to the requirements of EN55022, “Limits & Methods of
Measurement of Radio Interference, Information Technology Equipment.” Per that
standard, the EFX524 is a Class A product. In a domestic environment, this product
may cause radio interference, in which case the user is responsible to take adequate
measures to alleviate the interference.
Per FCC rules, changes or modifications to the EFX
not expressly approved by Precor, could void the
user’s authority to operate the equipment.

page 7
COMMERCIAL PRODUCTS DIVISION
EFX®SELF-POWERED FEATURES
The power source for the EFX is the user.When a person works out on the EFX and
moves the foot pedals at a stride rate above 40 strides per minute, the power that
is generated allows the EFX to function properly.
Informational displays appear when the battery is low or when the user has stopped
pedaling during a workout. The display provides minimal instructions to let you
know what to do to retain power. If the messages are ignored, the EFX will begin
shutdown procedures to maintain the charge of the battery. Refer to page 33,
Informational Displays Prior to Shutdown .
An optional battery recharger can be purchased and provides sustained power to
the EFX. If you plan to customize your unit, the optional battery recharger is highly
recommended.To purchase the optional battery recharger, check with your dealer.
OBTAINING SERVICE
Do not attempt to service the self-powered EFX®yourself except for the
maintenance tasks described in this manual.The EFX does not contain any user-
serviceable parts. For information about product operation or service, contact an
authorized Precor Commercial Products Customer Support Representative at
1-888-665-4404.
Diagram 1 EFX serial number location.
Serial number label location
To help Customer Support personnel expedite your call, have your serial number
available.The serial number can be found on a label near the power receptacle on
the rear cover. Refer to Diagram 1. If you have any questions regarding the EFX,
use the model and serial numbers whenever you call your Precor dealer or servicer.
Model number: EFX®524
Unit number: _____ Serial number: _____________________________
Unit number: _____ Serial number: _____________________________
Unit number: _____ Serial number: _____________________________

page 8
COMMERCIAL PRODUCTS DIVISION
ABOUT THIS MANUAL
Inside this manual, you will find instructions for installing and using the self-powered
EFX. To maximize the use of the EFX, please study this manual thoroughly. The
manual uses the following conventions for identifying special information:
“Note:”Contains additional information that applies to the preceding text.
“Important:”Indicates information to which you should pay special attention.
“CAUTION:” Indicates steps or information necessary to prevent harm to
yourself or damage to the equipment.
“WARNING:”Provides instructions to prevent electrical damage to the
equipment and prevent injuries to yourself.
“DANGER:”Indicates steps you must take to prevent electrical shock.

page 9
COMMERCIAL PRODUCTS DIVISION
Thank you for purchasing the self-powered Precor EFX®524.
Important: Before using the EFX, we urge you to familiarize yourself and your
staff with the entire Owner’s Manual. Understanding this manual will help you and
your customers use the EFX safely and successfully.
Your EFX is carefully inspected before shipment so it should arrive in good operating
condition. Precor ships the unit in the following pieces:
❑Base frame assembly ❑Base frame stabilizers (left and right)
❑Upright support ❑Display console assembly
❑Handrails (left and right) ❑Bracket and side covers
❑Hardware kit and owner’s manual
CAUTION: This unit weighs over 207 pounds (94 kilograms). To prevent
injury to yourself or damage to the equipment, obtain appropriate assistance
before removing the unit from the pallet.
If any items are missing, contact your Precor Commercial Products Service Repre-
sentative at 1-888-665-4404.
STANDARD EQUIPMENT
The EFX®524 incorporates the Precor SmartRate®and Heart Rate features into its
display console. Devices, such as FitLinxx®, that are CSAFE compatible, can also
be attached.
Note: An optional POLAR® chest strap can be purchased and worn during a workout.
The chest strap transmits the user’s heart rate to the display console’s receiver.
OTHER EQUIPMENT
Optional equipment available through your dealer includes:
• Battery recharger
• POLAR®chest strap.
If you are interested in obtaining Precor option kits for your unit, check with your
dealer. For Customer Support, see Obtaining Service on page 7.
ACQUIRING THE APPROPRIATE TOOLS
Obtain the following tools before assembling the EFX.
❑Wire cutter ❑Phillips head screwdriver
❑Rubber mallet ❑Hex torque wrench
❑Two 9/16" combination wrenches (open-end and box)
❑SAE Standard socket set with socket extension for 1/2-inch and
9/16-inch bolts
Unpacking the EFX®

page 10
COMMERCIAL PRODUCTS DIVISION
Diagram 2 EFX524
Hardware kit
HARDWARE KIT
Carefully unpack the parts from the shipping container. Open the Hardware Kit
and make sure that you have the following items as shown in Diagram 2:
❑(A) 3/16-inch hex key — secure handrails in handrail clamp
❑(B) 5/32-inch hex key — secure front covers
❑(C) End cap
❑(D) Four Phillips-head 1/2-inch screws — attach display console
❑(E) Four buttonhead 3/4-inch screws — secure front cover
❑(F) Twenty hex head 1-inch bolts — attach upright, handrails and stabilizers
❑(G) Twenty 3/8-inch bolts — attach upright and stabilizers to base
❑(H) Height adjustor
If any items are missing, contact your dealer. If you need Customer Support,
refer to Obtaining Service on page 7.
Note: After assembling the EFX, be sure to store the hex keys in a secure place.
The tools are used for maintenance procedures that are described in this manual.
B
A
C
DE
FH
G

page 11
COMMERCIAL PRODUCTS DIVISION
You do not need any special knowledge or experience to set up the EFX. However,
because of the size and weight of the EFX, you will need to obtain appropriate
assistance during assembly.
INSTALLATION REQUIREMENTS
Follow these installation requirements when installing the EFX.
Important: If you do not install the EFX according to the following guidelines, you
could void the Precor Limited Warranty.
•Set up the EFX on a solid, flat surface. Unpack and assemble the EFX close to
where you’ll use it. Make sure that the flat surface under the unit is smooth and
level. A level unit is required for the user’s safety and for proper operation.
Important: If you plan to move the EFX, do so before you install the hand-
rails. Ask for assistance to move the unit. Once the handrails are in place,
the unit is too wide to fit through a standard (32-inch) door frame.
•Provide ample space around the unit. Open space around the unit makes
for a safer mount and dismount.
•Fill out and mail the limited warranty card.The serial number is located on
a label at the rear of the unit near the optional battery recharger receptacle.
Write the serial number onto the Precor Limited Warranty card found on the
back cover of this manual. Refer to
Obtaining Service on page 7 and write the
number there as well.
ASSEMBLY INSTRUCTIONS
To assist you in the assembly, the items in the Hardware kit, shown in Diagram 2,
correspond to a particular letter in the alphabet. These letters appear throughout the
assembly instructions. Refer to Diagram 2 on page 10.
1. Obtain assistance. Place the shipping carton close to the location where you
plan to use the unit. Break down the side walls so that they lie flat.You may
need to cut the tie wraps that hold the base frame and roller arms to the pallet.
2. Unpack the EFX. Remove the packing materials and loose contents. Refer to
the list on page 9.
3. Move the unit to the location where you plan to use it. Once you attach
the handrails and base stabilizers, the EFX is difficult to move through a
standard door frame. Make sure to assemble the unit where it will not have to
be moved through any doorways.
CAUTION: Do not assemble the EFX if it is connected to the optional
battery recharger. Remove the battery recharger from the EFX, prior to
assembly.
Setting Up the EFX®

page 12
COMMERCIAL PRODUCTS DIVISION
2
Diagram 3
4. Cut the tie wrap securing the front base tube to the pallet. Discard the tie wrap.
CAUTION: Grease on the lift screw can stain clothing.
5. Thread the height adjustor to its lowest position. Diagram 3, #1 and #2.
Remove the height adjustor from the Hardware kit. Ask an assistant to lift the
front base tube while you insert the height adjustor.Turn the height adjustor so
that the threads appear inside the base tube.Tighten the nut (with a crescent
wrench) when the height adjustor is fully threaded into the front base tube.
6. Cut the tie wrap holding the plastic grommet. Diagram 3, #3. Use a wire
cutter (or scissors) to remove the plastic grommet from the cable.
Front base assembly.
Cut the tie wrap that
secures the grommet
to the cable.
Height adjustor
Front base tube
3
Tighten the height
adjustor so that the
nut is secure against
the front tube.
Diagram 4
Insert grommet and
route lift motor cable.
Plastic grommet
Front base tube
1
7. Insert the plastic grommet. Diagram 4. Press down on the grommet so that
it snaps into place.Thread the lift motor cable through the grommet.
Plastic grommet
Note that illustrations
1 and 2 do not show the
lift motor that is atop the
front base tube.
Plastic grommet
Lift motor cable
Lift motor cable

page 13
COMMERCIAL PRODUCTS DIVISION
8. Prepare for the attachment of the upright support to the base assembly.
Diagram 5. Remove the four phillips-head screws (D), two bolts (F), and two
washers (G) from the Hardware kit. Place one washer (G) on each of the two
bolts (F). Keep the fasteners together.
CAUTION: Do not stretch, crimp, or damage the cable. Excess cable may
be gently pushed into the base assembly. Cables damaged by improper
installation will not be covered by the Precor limited warranty.
9. Route the display console cable through the upright support. Diagram 5, #1
Remove any tape or wire ties attached to the cable. Have an assistant hold the
upright support securely while you grasp the display console in one hand and
route the cable through the upright support with the other.
10. Attach the display console. Diagram 5, #2. Use the four phillips-head
screws (D) to attach the display console to the upright support. Have your
assistant hold the upright support securely while you align the mounting holes
and tighten the screws.
Diagram 5
Route the cable and
attach the display
console to the
upright support.
Display console
Upright support
Cable
2
1
Upright support
bracket

page 14
COMMERCIAL PRODUCTS DIVISION
11. Position the upright support over the base. Diagram 6. Have your assistant
move the upright support close to the front of the base assembly while you
thread the cable through the grommet hole and out the front of the base tube
(see inset in Diagram 6, #1). Make sure that the display console (on the
upright support) faces the rear of the unit (see Diagram 6, #2).
CAUTION: As you assemble the unit,do not fully tighten the fasteners until
instructed to do so. Finger tighten the fasteners so that the unit is stable,
but the fasteners still allow room for adjustments.
12. Route the lift motor cable through the cutout in the upright support.
Diagram 6, #1.While your assistant holds the upright support, thread the lift
motor cable through the cutout. Once the cable is routed, rest the upright
support on the base tube.
13. Secure the upright support to the base assembly. Diagram 6, #2. Align the
mounting holes and thread the two bolts (F) with washers (G) through opposite
sides of the upright support and into the base assembly. Finger tighten each
bolt. Do not fully tighten the fasteners until the entire unit has been assembled.
14. Connect the cable into its black receptacle. Refer to the opposite page,
Diagram 7, #1. Just like a telephone connection, a definite "click" is heard
when a good connection is made. If you do not hear a "click," try reinserting
the cable connection again.
Diagram 6
Route the cable
through the grommet
hole and attach the
upright support to the
base.
Have your assistant
hold the upright
support while you
secure it to the base.
2
1
Two bolts (F) with
washers (G)
Upright
support
Cable receptacle
Route the cable
through the grommet.
Lift motor cable

page 15
COMMERCIAL PRODUCTS DIVISION
17. Rotate the rear pads. Diagram 8, inset. Ask your assistant to stabilize the
unit while you rotate the adjustable rear pad to lift the base assembly off the
floor and provide better access to the fasteners.
18. Rest the base assembly on a block. Diagram 8. Have an assistant grasp
the handrails and lift the base up so that you can slide a supportive block of
packing material under the front of the unit.
Diagram 8 Place the base
on supportive
blocks.
Adjustable rear pad
Supportive block
Base assembly
Diagram 7 Connect the
cables.
Cable connector
Cable receptacle
Place excess cable
into the base tube.
Height adjustor
threads
Base tube
15. Connect the lift motor cable. Diagram 7, #2.
16. Push excess cable inside base tube. Diagram 7, #3.Carefully, push any excess
cable behind the height adjustor threads that protrude from inside the base tube.
Lift motor cable
connector
2
1
3

page 16
COMMERCIAL PRODUCTS DIVISION
19. Attach the left and right frame stabilizers. Diagram 9. Proceed with one
side at a time.
a. Remove four bolts (F) and four washers (G) from the Hardware kit. Place
a washer on each bolt and set the fasteners within easy reach of the unit.
b. Grasp one of the frame stabilizers and align it with the upright support bracket.
Have your assistant hold it in place.
c. Insert the four bolts (F) with washers (G) through the frame stabilizer and
upright support bracket. See Diagram 9.
d. Thread all four bolts and washers until the frame stabilizer is secure. Do
not fully tighten the bolts until after the lower section is attached.
e. Perform steps a. through d. on the opposite side.
Diagram 9 Attach the frame
stabilizers to the
upright support
bracket and base
tube.
Bolts (F) and
washers (G)
Frame stabilizer
Diagram 10
Attach the lower
frame stabilizers
to the base
assembly.
f. Carefully, align the mounting holes on the right and left frame stabilizer with the
base frame holes. Insert four bolts (F) and washers (G) on both sides. Gently
move the stabilizers up and down to get the mounting holes on both sides
properly aligned and then thread the bolts through the unit. See Diagram 10.
g. Alternately tighten the eight bolts with a 9/16" wrench. This helps pull the
rest of the parts into alignment.
Upper section
Lower section
Upright support
bracket
Bolts (F) with
washers (G)

page 17
COMMERCIAL PRODUCTS DIVISION
20. Tighten all mounting screws with a 9/16" wrench. Once you have tight-
ened the eight bolts that attach the frame stabilizers to the base frame (refer
to Diagram 10), proceed with tightening the four bolts installed in each of the
two upright support brackets. See Diagram 11. Once the stabilizers are se-
cured, tighten the two bolts that secure the upright support to the base frame
(refer to Diagram 6, #2).
Diagram 11 Tighten the
mounting bolts.
Upright support
bracket
Frame stabilizer
Bolts (F) and
washers (G)
Diagram 12
Remove the cover
fasteners.
Upright support
bracket
Remove a screw
from each side.
2
1
21. Remove the cover fasteners from the EFX. Diagram 12. Use a Phillips-
head screwdriver to remove:
• two screws, one on each side of the upright bracket support. Set the
screws aside for use in step 27, c.
• four screws, two on each side of the base tube near the lift motor. Set the
screws aside for use in step 23, d.
• two screws from the base of the upright bracket support. Note the size of the
screw closest to the ramp. It is 3/4-inches in length. Refer to Diagram 13.
Remove two screws
from each side of the
base tube.
Remove two screws
from the base of the
bracket.

page 18
COMMERCIAL PRODUCTS DIVISION
22. Install the lift cover. Diagram 13. The center holes (see inset) on the lift
cover are used for mounting it to the base of the upright bracket support.
(The two side holes are used for a different product.)
a. Position the lift cover as shown in Diagram 13.
b. Insert the 3/4-inch screw into the mounting hole closest to the ramp and
finger tighten.
c. Insert the 1/2-inch screw closest to the upright support.
d. Tighten both screws with a phillips head screwdriver. Do not overtighten
or you may crack the plastic lift cover.
Diagram 14
Install the side
covers.
Ramp cutout
Side cover
Diagram 13
Install the lift cover.
Center holes in
cover
Lift cover
3/4-inch screw
23. Install the side covers. Diagram 14. Proceed with one side at a time.
a. Remove the two 3/4-inch buttonhead screws (E) and 5/32-inch hex key (B)
from the Hardware kit.
b. Grasp one side cover and rotate it so that it slips inside the ramp cutout.
Have your assistant hold it in place.
2
1
Replace screws
from step 21.
1/2-inch screw
Upright support
bracket
3/4-inch buttonhead
screw (E)

page 19
COMMERCIAL PRODUCTS DIVISION
CAUTION: Do not overtighten the screws or you may inadvertently
cause stress cracks in the plastic.
c. Insert the two 3/4-inch buttonhead screws (E) and replace the two screws
removed from the base tube in step 21. Alternately tighten the screws
using the hex key (B) and a phillips head screwdriver to secure the side
cover.
d. Perform steps a. through c. on the opposite side.
24. Insert the left and right handrails into the upper clamp. Diagram 15.
Attach one handrail at a time. Using one hand, apply pressure on the portion
of the handrail being inserted into the clamp while, with the other hand, lift
and lower the base of the handrail. This rotating motion helps move the
handrail into the upper clamp. Repeat this step for the opposite handrail.
25. Check the gap in the upper clamp. Diagram 15, inset. Look underneath the
handrail clamp to see that a minimum 1/4-inch gap exists between the two
ends of the handrails.The gap should be not greater than 1/2-inch. Adjust the
handrails accordingly.
Diagram 15
Insert the handrails
into the handrail
clamp.
Handrail clamp
Handrail
Upright support
bracket
Gap between
handrail ends inside
clamp should be
about 1/4-inch.

page 20
COMMERCIAL PRODUCTS DIVISION
Diagram 16 Secure the handrails.
Display console
Handrail
Tighten bolts in
handrail clamp.
Screws (F) and
washers (G)
26. Secure the handrails. Diagram 16. Align the handrail base mounts with the
handrail bracket. Insert two bolts (F) and washers (G) and finger tighten.
Repeat this step for the opposite handrail.
a. Check the gap in the handrail clamp. Refer to Diagram 15, inset.
b. While maintaining the gap between 1/4-inch and 1/2-inch, tighten the bolts
in the handrail clamp using the hex key provided.
c. Return to the bolts (F) in the base of the handrails and tighten each securely
using a 9/16-inch socket extension and wrench.
Diagram 17
Attach bracket
cover.
Bracket cover
Protrusions inside
cover
Tighten the
bracket cover
screws.
27. Attach the bracket cover by taking the following steps. Diagram 17. Note
that protrusions inside the front of the bracket cover help secure the cover to
the upright support. See inset in Diagram 17.
a. Position the bracket cover so that the protrusions inside the cover “latch”
onto the front of the upright support bracket.
b. Lower the bracket cover and align the mounting holes.
c. Reinsert the two screws, removed in step 21 and tighten securely. Do not
overtighten or you may inadvertently crack the plastic mounts.
