CLIMBER OWNER’S MANUAL
C764

COMMERCIAL PRODUCTS DIVISION
ii
ThankyouforpurchasingthePrecorC764Climber—oneofthemostadvanced
climbers available. Built to the exacting standards of the health club environ-
ment, the C764 climber is intended for commercial use and can withstand the
rigors of daily club use with little maintenance.
The easy-to-use electronic console prompts users to begin their workout. A
Quick Start option allows users to opt past weight and course selections and
begin working out immediately. For those interested in determining correct
calorie loss and specific course modes, the C764 climber provides program-
mability. Throughout the workout, the electronic console displays a variety of
statisticsincluding:elapsedtime,floorsclimbed, steprate,andcalories burned.
To maximize the use of the C764 climber, please read this manual thoroughly.
ABOUT THIS MANUAL
Insidethismanual,youwillfindinstructionsforinstallingandusingtheC764.The
manual uses the following conventions for identifying special information:
“Note:” Contains additional information that applies to the preceding text.
“Important:” Indicates information to which you should pay special attention.
“CAUTION:” Indicates steps or information necessary to prevent harm to
yourself or damage to the equipment.
“WARNING:” Provides instructions to prevent electrical damage to the
equipment and prevent injuries to yourself.
“DANGER:” Indicates steps you must take to prevent electrical shock.
OBTAINING SERVICE
Donot attempt to service theC764 climber yourself except forthe maintenance
tasks described in this manual. The C764 climber does not contain any user-
serviceableparts. For informationabout product operation or service, contact a
Precor Commercial Products Customer Service Representative at 1-800-4-
PRECOR.
Tohelpthe customer servicerepresentativeexpediteyourcall, have yourserial
number readily available. The serial number on the C764 climber is located on
alabelplacedunderneaththerightfootpedalasyoufacethe electronicconsole
display. Write the serial number in the space provided below:
Model number:________________ Serial number: ___________________
Before You Begin

COMMERCIAL PRODUCTS DIVISION
iii
IMPORTANT SAFETY INSTRUCTIONS
SAVE THESE INSTRUCTIONS
IMPORTANT SAFETY INSTRUCTIONS
When using an electrical appliance, basic precautions should always be followed, including
the following:
• Read all instructions before using the C764 Climber. These instructions were written to
ensure your safety and to protect the unit.
• To ensure the proper use and safety of the C764, make sure that all users read this
manual. Please make this manual a part of your training program.
Beforebeginninganyfitnessprogram,you should have a complete physical examination by
your physician.
Il est conseillé de subir un examen médical complet avant d’entre-prendre tout programme
d’exercise. Si vous avez des étourdissements ou des faiblesses, arrêtez les exercices
immédiatement.
DANGER—To reduce the risk of electrical shock, always unplug the C764 from
the electrical outlet immediately after using and before cleaning.
• The C764 should never be left unattended when plugged in. Unplug the unit from the
outlet when it is not in use, and before any maintenance or repair.
• Closesupervisionis necessary when the C764 isusedby,on, or near children, invalids,
or disabled persons.
• UsetheC764onlyforitsintendeduseasdescribedinthismanual.Donotuseaccessory
attachments that are not recommended by the manufacturer—such attachments might
cause injuries.
• Never operate the unit if it has a damaged cord or plug, if it is not working properly, if it
has been dropped or damaged, or dropped in water. Return the unit to a service center
for examination and repair.
• Keep the power cord away from heated surfaces.
• Never drop or insert any object into any opening. Keep hands away from moving parts.
• Donotoperate where aerosol (spray)productsarebeingusedor where oxygen isbeing
administered.
• Do not use outdoors.
• Todisconnect,turnallcontrolstotheOFF(O)position,thenremovethepowerplugfrom
the outlet.
WARNING—
WARNING–To reduce the risk of burns, fire, electric shock, or injury to persons,
take the following precautions:
Connect the C764 to a properly grounded outlet only. See
Grounding Instructions .
ATTENTION–Gardez les enfants et toutes personnes non familières avec
l’escalier d’exercice loin de cet équipment.

COMMERCIAL PRODUCTS DIVISION
iv
The C764 climber must be grounded. If it should malfunction or breakdown,
grounding provides a path of least resistance for electric current which reduces
the risk of electrical shock. The climber is equipped with a cord having an
equipment-grounding conductor and a grounding plug. The plug must be
inserted into an appropriate outlet that is properly installed and grounded in
accordance with all local codes and ordinances. If you do not follow these
Grounding Instructions , you could void the Precor limited warranty.
DANGER
Improper connection of the equipment-grounding conductor can result in a risk
of electric shock. Check with a qualified electrician or service person if you are
in doubt as to whether the climber is properly grounded. Do not modify the plug
providedwiththeclimber—ifitwillnotfittheoutlet,haveaproperoutletinstalled
by a qualified technician.
120V UNITS DESIGNATED FOR U.S. MARKETS
Theclimberisforuseonanominal120-voltcircuit andhasagroundingplugthat
looks like the plug illustrated in Diagram A. Make sure that the treadmill is
connected to an outlet having the same configuration as the plug. No adapter
should be used with this product.
Grounding Instructions
240V UNITS DESIGNATED FOR U.S. MARKETS
This product is rated for more than 15 amps and is for use on a circuit having a
nominal rating of 120 volts and is factory-equipped with a specific electric cord
and plug to permit connection to a proper electric circuit. Make sure that the
productis connected to an outlethaving the sameconfiguration as the plug. No
adaptershouldbeusedwiththisproduct.Iftheproductmustbereconnectedfor
use on a different type of electric circuit, the reconnection should be made by
qualified service personnel.
Proper grounding plug and
power outlet for 120v.
Diagram A

COMMERCIAL PRODUCTS DIVISION
v
Information Regarding International Use
FCC Communications Commission, part 15
TheC764climberhasbeentestedandfoundtocomplywiththelimitsforaClass
Bdigitaldevice,pursuanttopart15oftheFCCRules.Theselimitsaredesigned
to provide reasonable protection against harmful interference in a residential
installation.TheC764climbergenerates,uses,andcanradiateradiofrequency
energy and, if not installed and used in accordance with the owner’s manual
instructions, may cause harmful interference to radio communications. How-
ever, there is no guarantee that interference will not occur in a particular
installation. If the C764 climber does cause harmful interference to radio or
televisionreception,which can be determinedbyturningthe C764 climber OFF
andON,youareencouragedtotry tocorrecttheinterferenceusing oneormore
of the following measures:
• Reorient or relocate the receiving antenna for your TV, radio, VCR, etc.
• Increase the separation between the C764 climber and receiver (TV, radio,
etc.).
• ConnecttheC764 climberintoadifferentpoweroutlet—onacircuitdifferent
from the one used by the receiver (TV, radio, etc.).
• Consult your dealer or an experienced radio/TV technician for help.
Canadian Department of Communications
“This digital apparatus does not exceed the Class B limits for radio noise
emissions from digital apparatus set out in the Radio Interference Regulations
of the Canadian Department of Communication and Information.”
“Leprésentappareilnumériquen’émetpasdebruitsradioéélectriquesdépassant
les limites applicables aux appareils numériques de la class B prescrites dans
le Règlement sur le brouillage radioélectrique édicté par le ministére des
Communications du Canada.”
European Applications—240 Volt Units Only
ThisproductconformstotherequirementsoftheEuropeanCouncilDirective89/
336/EEC, Electromagnetic Compatibility and has been tested to the following
standards
EN55022, Limits & Methods of Measurement of Radio Interference,
Information Technology Equipment.
EN50082-1, Generic Immunity Standard for Residential, Commercial and
Light Industrial Products.

COMMERCIAL PRODUCTS DIVISION
vi
Personal Safety
When using the C764 take the following precautions:
• Assemble and operate the climber on a solid, level surface.
• Wear proper exercise clothing and shoes for your workout—no loose
clothing. Do not wear shoes with heels or leather soles. Check the soles of
your shoes and remove any dirt and embedded stones. Tie long hair back.
• Keep hands away from moving parts.
• Usecare whengettingonoroff theclimber.Keepyourlegs clearofthestair
arms when stepping off the climber because the stair arms could hit your
legs as they return to a stationary position.
• Do not rock the unit. Do not stand on the handrails or casing.
• Do not remove the climber’s casing. Do not attempt to service the climber
yourselfotherthantheassemblyandmaintenanceinstructionsfoundinthis
owner’s manual. For customer service, see Obtaining Service on page ii.
• Do not overexert yourself or work to exhaustion.
• Stop your workout immediately if you feel any pain or abnormal symptoms,
and consult your physician.
• Do not insert fingers or other objects into opening between the stair arm
assemblies and the enclosure housing.
PRECOR HEART RATE OPTION—SAFETY GUIDELINES
ThePrecorHeart Rate Option wascreatedanddesigned exclusively for Precor
products. Before using this option, read and follow the instructions found in the
owner’s manual that accompanies your option kit or chest strap transmitter.
Theequipmentisextremelysensitive—youshouldusetheheartrateoptionwith
this in mind and take time to read the following guidelines:
• HandlethePrecorHeartRateOptionwithcare.Donotdroptheequipment.
It might damage the transmitter and you could void the manufacturer’s
limited warranty.
• Donot placethechest strapnearstrongelectromagneticradiationsources.
Television sets, electric motors, radios, and high voltage power lines can
interfere with the heart rate signal that is being transmitted to the receiver
and might affect the heart rate readings that appear on the electronic
console.
• Use only one chest strap at a time inside the range of the receiver. If the
receiver tries to process several signals simultaneously, an incorrect heart
rate reading could result. Be sure to keep any other transmitters at least 5
feet (1.5 meters) away from the receiver on your C764.
• Keep the equipment dry. Although the chest strap should not be immersed
in water, wetting the electrodes and your chest will improve the initial
performance. Note that perspiration on the chest strap during workouts is
normal and actually enhances the signal being sent from the chest strap’s
transmitter.

COMMERCIAL PRODUCTS DIVISION
vii
• To conduct the electrical impulses from your heart, the chest strap’s
electrodes require a certain percentage of salts and minerals in the water
used to wet them. The electrodes continue to transmit your heart rate
reading as long as they are in contact with your skin and your skin is
providingenoughmoisturethroughyourperspirationtokeeptheelectrodes
wet. However, if the concentration of salts in your perspiration is not high
enough to conduct electrical impulses and send them to the receiver, your
heart rate reading will appear erratic or not appear at all. Some people
cannotuse theheartratefeature becausetheydonot havetheproperbody
chemistry. See Correcting Inconsistent Heart Rate Readings .
• Donotusethecheststrapifyouaretakinganymedicationorhaveacardiac
pacemaker. Inaccurate heart rate readings can occur due to medication or
electrical impulses from the cardiac pacemaker.
• Stretchingor bending theelectrode strips on the chest strap maycause the
strips to lose their conductivity. Handle the chest strap with care.
• After extensive use, the chest strap (transmitter) may wear out, causing
inaccurateheartratereadings.Witheveryuse,checkthestrapforexcessive
wear and replace it if necessary. See Obtaining Service on the inside front
cover.
Precor climbers are designed for the enjoyment of those interested in an
excellent cardiovascular and lower body workout. By following the above
precautions and using good common sense, you and your customers will have
many safe and pleasurable hours of healthful exercise with this Precor climber.
Precor Heart Rate Option—Safety Guidelines

COMMERCIAL PRODUCTS DIVISION
viii
Table of Contents
Before You Begin.................................................................................. ii
About this Manual....................................................................... ii
Obtaining Service ....................................................................... ii
Important Safety Instructions...................................................... iii
Grounding Instructions ............................................................... iv
Information Regarding International Use.................................... v
Personal Safety .......................................................................... vi
Precor Heart Rate Option—Safety Guidelines ........................... vi
Unpacking the C764 Climber ............................................................... 1
Setting Up the C764 Climber ............................................................... 3
Installation Requirements........................................................... 3
Assembly Instructions................................................................. 3
Using the C764 Climber ....................................................................... 9
Turning the Climber On and OFF ............................................... 9
Understanding the Electronic Console ....................................... 10
Graphic Display on the C764 Climber ........................................ 11
Right Display on the C764 Climbers........................................... 12
Working Out on the C764 Climber ...................................................... 14
Pausing During Your Workout.................................................... 14
Ending Your Workout ................................................................. 14
Cooling Down After Your Workout.............................................. 14
Understanding Smart Rate......................................................... 14
Utilizing the Heart Rate Capability.............................................. 15
Correcting Inconsistent Heart Rate Readings ............................ 16
Exercising on the C764 Climber ................................................. 17
Using Manual Mode and the Quick Start Key............................. 19
Changing the Interval Course Profile on the C764 Climber........ 20
Using the Random Course on the C764 Climber ....................... 20
Maintaining the C764 Climber ............................................................. 21
Cleaning the Climber.................................................................. 21
Accessing the Software Version Number and Odometer........... 21
Servicing the Climber ................................................................. 21
Power Cord Maintenance........................................................... 22
C764 Long Term Storage........................................................... 22
Special Forms ....................................................................................... 23
Custom Course Grid for the C764 Climber................................. 23
Workout Statistics Log................................................................ 24
Specifications .......................................................................... Back cover

page 1
COMMERCIAL PRODUCTS DIVISION
Your C764 climber is carefully inspected before shipment so it should arrive in
good operating condition. Precor ships the unit in five pieces:
• base frame assembly
• upper column support
• electronic console display
• handrails (For the vertical handlebar installation, refer to
the C764 Addendum .)
• hardware kit, Owner’s Manual, and limited warranty card
(The hardware kit is shown in Diagram 1.)
Toremovetheclimberfromthewoodpallet,locatethelagboltonthepalletunder
the right foot pedal (close to the casing) and remove it.
CAUTION: This unit weighs over 180 pounds. To avoid back strain and
ensure the safety of the unit and yourself, we suggest that you get
assistance before removing the base frame assembly from its container.
Unpacking the C764 Climber

page 2
COMMERCIAL PRODUCTS DIVISION
Diagram 1
Hardware kit
HJ
Carefully unpack the parts from the shipping container. Open the hardware kit
and make sure that you have the following items:
(A) four hex head screws—for installing the upper column support
(B) six split lock washers—attach to screws on upper column support and
to the handrail clamp screws
(C) three screws—for installing electronic console display
(D) three split lock washers—attach to bolts on electronic console display
(E) three washers—attach to bolts on electronic console display
(F) two button-head socket bolts—for installing handrails to base frame
(G) two locknuts (nylon end)—attach to lower handrail screws
(H) two button-head screws—for installing handrails to handrail clamp
(J) two handrail rubber boots—for covering lower handrail screws at base
If any items are missing, contact your Precor Commercial Products Service
Representative at 1-800-4-PRECOR.
Note: If you have the C764 vertical handlebars, refer to the addendum for
assembly instructions.
AC
BD
E
G
F
(B)

page 3
COMMERCIAL PRODUCTS DIVISION
Youdo notneedanyspecial knowledgeorexperienceto setupaC764 climber,
however you will need assistance. Ask for one or more assistants to help you
assemble the climber. You will also need to obtain a socket wrench and a set of
Allen wrenches.
INSTALLATION REQUIREMENTS
Followthe installation requirementsbelow when installingthe climber. Ifyou do
not install the climber according to the following guidelines, you could void the
Precor limited warranty.
•Set up the C764 climber on a solid, flat surface. Aflat surface is required
for your safety and proper use of the climber.
•Fill out and mail the limited warranty card. The serial number is located
onalabelunderneaththerightfootpedalasyoufacetheelectronicconsole.
•Use the appropriate voltage, dedicated circuit, and grounding as
specifiedontheclimber.TheC764climberisavailablein a120-voltmodel
in the U.S.A. and Canada. A 240-volt model is available for the European
and international markets. Refer to the climber’s identification label to
determine the voltage that your climber requires. The C764 climber’s 120-
voltand 240-volt models require a dedicated 15amp circuit. Failureto use
a dedicated circuit might damage the unit and void the manufacturer’s
limited warranty.
CAUTION: Do not use a non-grounded outlet. Do not remove or otherwise
bypass the plug with an adapter. Electrical damage can occur if the C764
climber is connected to an improper power source.
ASSEMBLY INSTRUCTIONS
Toassistyouintheassemblyoftheclimber,theitemsinthehardwarekit,shown
in Diagram 1, correspond to a particular letter in the alphabet. These letters
appearthroughouttheassemblyinstructions.RefertoDiagram1,whileperform-
ing the following steps:
Note: Before assembling the climber ask for assistance from other adults and
acquire a socket wrench and a set of Allen wrenches. Refer to the C764
Addendum for assembly instructions regarding the vertical handlebars.
1. Unpack the climber and remove the packing materials from the handrails,
upper column support, electronic console display, and base frame
assembly.
Setting Up the C764 Climber

page 4
COMMERCIAL PRODUCTS DIVISION
2. Removetheclimberfromtheshipping pallet. Be sure to remove the lag bolt
thatholdstheclimberonthepallet.Thelagboltislocatedundertherightfoot
pedalnexttothecasing.Askforassistancetolifttheclimberofftheshipping
pallet.
CAUTION: To avoid injury and ensure your safety, you need assis-
tance to lift the climber off the pallet and place it on the floor. Do not
drop the unit.
3. Make sure that the climber is unplugged and turned OFF. Do not assemble
the C764 climber if it is plugged into a power outlet.
4. Take the following steps to secure the upper column to the base frame
assembly:
a. Place four split washers (B) found in the hardware kit onto the hex head
screws (A).
b. Position the upper column above the base frame mounts so that the
handrail clamp (on the upper column) faces the foot plates. Slide the
rubber boot up the column to expose the mounting holes.
c. Align the mounting holes and insert the screws (A) through the column
support mount and into the base frame mount. See Diagram 2. Finger-
tighten each screw. Use an appropriate socket wrench and alternately
tighten each screw until all four screws are secure and tight against the
upper column. Do not overtighten.
Note:Referto the C764Addendumforassemblyinstructionsregarding
the vertical handlebars.
Diagram 2 Install upper column onto
base frame assembly
Base frame assembly
Column support mount
Upper column
Screw
Split washers
Boot
Base frame mount

page 5
COMMERCIAL PRODUCTS DIVISION
d. Hold the electronic console display above the upper column support
whileyourassistantunwrapstheribboncableandthreadsitthroughthe
uppercolumnsupport.Grabtheconnectoratthebaseofthecolumnand
gently pull it out. See Diagram 3. Do not connect the cables at this time.
CAUTION: Be sure not to crimp or pinch the ribbon cable as you
placetheelectronic consoledisplayinto position.Cablespinched
orotherwisedamagedbyimproperinstallationwillnotbecovered
by the limited warranty.
Diagram 3
Thread ribbon cable
connector
Base frame assembly
Diagram 4
Attach electronic console
display to upper column
support
Electronic console
e. Takethethreescrews(C),threelockwashers(D)andthreewashers(E)
from the hardware kit. Place the lock washers and then the washers on
the screws. Align the mounting holes on the electronic console display
withtheuppercolumnsupportandinsertthescrewssothatthewashers
are against the upper column support. See Diagram 4. Be sure that the
bottomofthe display is parallel with thetopofthe upper handrail clamp.
Alternately tighten each screw using the appropriate Allen wrench until
all three screws are secure and tight against the mounting plate. Do not
overtighten.
Boot
Upper column support
Ribbon cable receptacle
Ribbon cable connector
Upper column support
Mounting plate
Screw
Washer
Lockwasher
Upper handrail clamp

page 6
COMMERCIAL PRODUCTS DIVISION
Diagram 5
5. Take the ribbon cable connector that you threaded through the upper
columnsupportinstep4d.andopenthetabsontheribboncablereceptacle.
Plug the connector into the receptacle. See Diagram 5. Make sure that all
pins are aligned and the tabs are fully engaged. The connector is designed
to engage in one direction only. Do not force the connector into the
receptacle. Gently push the excess ribbon cable and connectors back up
into the upper column support.
Connect ribbon cables
correctly
Correct alignment Incorrect alignment
Ribbon cable receptacle
Ribbon cable connector
Tab
6. Lower the rubber boot over the base frame casing and column support
mounts.Pushdownontheboottosecureitontothebaseframecasing.See
Diagram6.Makesurethatthebootseatscorrectlyoverthecoverextrusion.
Diagram 6
Slide boot into position
Upper column support
Base frame casing
Boot
Cover extrusion

page 7
COMMERCIAL PRODUCTS DIVISION
Diagram 7
Install lower handrails
Handrail boot
Wide portion of boot
Lower handrail
Locknut
Base mount
7. Take the following steps to secure the handrails onto the climber:
a. Take a handrail boot (J) from the hardware kit and slide it onto the base
of each handrail. Refer to Diagram 7. Be sure to mount the bell-shaped
boot properly. The wide portion of the “bell” should be facing toward the
base.
b. Place the lower portion of the handrails onto the base mounts.
c. Insert the upper-portion of the handrails into the handrail clamp on the
upper column support. Refer to Diagram 8. Push the handrails together
so that the handrails meet in the center of the clamp. The foam wrap on
both handrails should be snug up against the handrail clamp.
d. Return to the lower handrail mounts and insert the bolts (F) and attach
the locknuts (G), but do not tighten until the upper handrails have been
fully secured inside the upper handrail clamp.

page 8
COMMERCIAL PRODUCTS DIVISION
Install upper handrails
Diagram 8
Foam wrap on handrails
Upper column support
Handrail clamp
Bolts
Lockwasher
e. At the upper handrail clamp, place a lock washer (B) on each screw (H)
and insert the screws into the handrail clamp. Tighten the screws
securely using the proper Allen wrench. See Diagram 8.
f. Check the lower handrail bolts and tighten the locknuts and bolts
securely.HoldtheboltwithyourAllen wrenchwhileyouturnthelocknut
with a socket wrench. Refer to Diagram 7 on page 7.
g. Slide the handrail boot down and secure it over the bolt and locknut.
CAUTION: A fully-assembled C764 climber is very heavy. To avoid
possible injury, Precor recommends that more than one person move
the climber to its final location.
8. Ifyouneedtomovetheclimber,askforassistance.Theclimberweighsover
180 pounds. It is recommended that you and your assistants place a hand
truck under the rear crossbar to move the climber.
CAUTION: Do not remove or otherwise bypass the 3-prong plug with
an adapter in order to use a non-grounded outlet. Do not plug the
climber into a power transformer in an attempt to adjust the voltage
requirements. Failure to follow these instruction might damage the
unit and void the manufacturer’s limited warranty.
9. Plug the climber into a grounded outlet. Be sure to use the appropriate
voltage requirements. Refer to Installation Requirements on page 3.
You have completed assembling the C764 climber. To become familiar with
using the climber, please continue on to the following section.

page 9
COMMERCIAL PRODUCTS DIVISION
TheC764Climberisdesigned so users can work out withminimalinstructionor
training.Thedirectionson the console andthepromptsonthedisplaywillguide
auserthrough the entire workout session. Beforetheclimberis used, however,
we recommend that you familiarize yourself with it so it will be used safely and
effectively. This section covers the following information:
• instructions for turning the climber ON and OFF
• an overview of the features provided on the electronic console
• instructions for exercising on the climber
• an explanation about using manual mode and the QUICK START key
• an explanation about using the interval and random courses
TURNING THE CLIMBER ON AND OFF
Use the ON/OFF power switch to turn the climber ON and OFF. This switch is
located near the power cable.
Using the C764 Climber

page 10
COMMERCIAL PRODUCTS DIVISION
UNDERSTANDING THE ELECTRONIC CONSOLE
Once the C764 climber is set up, it is ready to use. There are no complex
instructions to follow or mandatory programming steps required to operate the
climber. Choose either the quick start feature which lets you immediately start
the manual program, or the setup mode which prompts you for more specific
information.Theeasy-to-understandpromptsletyouspecifyhowlongyouwant
to work out, select one of 15 workout programs and then specify how hard you
want to work.
As you exercise, the electronic console provides motivation and presents
constant feedback about your progress. An explanation of each feature on the
C764 console follows Diagram 11.
The electronic console keypad has two sets of keys. The upper set (CHANGE)
affect the electronic console displays, the lower set (RESET, WORK LEVEL/
SPEED, DOWN/UP, ENTER, and QUICK START) affect the function and
features of the climber.
Note: Before beginning a workout, the or keys provide a way to answer the
prompts being displayed on the electronic console.
CHANGE keys: Each of three “change” keys appear below their respective
column of functions. Display a particular function by pressing the appropriate
CHANGEkeyuntilthefunction’sindicatorlights.Forexample,iftheCALORIES
indicator is lit, you can change the display to show the distance (feet or meters)
thatyouhavetravelledsinceyoustartedyourworkoutbypressingtheCHANGE
key until the HORIZONTAL DISTANCE indicator is lit.
Diagram 11
1 2 3 4 5 6 7 8 9 01
WORK LEVEL TIME FLOORS CLIMBED FLOORS PER MINUTE
CAUTION
Do not allow children and people unfamiliar with climber operation
on or near the climber. Before beginning any fitness program, you
should have a complete physical examination by your physician.
If you feel faint or dizzy, stop exercising immediately.
ATTENTION
Gardez les enfants et toutes personnes non familie`res avec l'escalier
d'exercice loin de cet e´quipement. Il est conseille´ de subir un
examen me´dical complet avant d'entreprendre tout programme
d'exercice. Si vous avez des e´tourdissements ou des faiblesses,
arreˆtez les exercices imme´diatement.
TM
CHANGE CHANGE CHANGE
SEGMENTTIME LEFT
WATTS
METS
OFF
CALORIES
CALORIES PER MINUTE
HORIZONTAL DISTANCE
OFF
STEPS PER MINUTE
FEET PER MINUTE
METERS PER MINUTE
HEART RATE
For information about Precor products, call 1-800-786-8404.
DOWN
UP
WORK LEVEL / SPEED QUICK START
RATE PER MINUTE
ENTER
RESET
225
210
195
180
165
150
135
120
105
98
90
83
75
68
60
53
45
38
30
Steps
150
140
130
120
110
100
90
80
70
65
60
55
50
45
40
35
30
25
20
46
43
40
37
34
30
27
24
21
20
18
17
15
14
12
11
9
8
6
FeetMeters
1 Step = 8 inches
1 Floor = 10 Feet (3 meters) Horizontal Distance = the energy equivalent in miles / kilometers
To ensure accurate heart rate
readings, you must wear a
Precor heart rate chest strap.
WEIGHT LOSS CARDIOVASCULAR Above Zone
55% 85%
Below Zone
When you wear a Precor heart rate chest strap, SMART RATE displays
the heart rate training zone in which you are exercising.
SMART RATETM
USA
R

page 11
COMMERCIAL PRODUCTS DIVISION
RESET: While you are answering the setup prompts, you can cancel the
program, clear the display, and return to the initial start-up prompt, by pressing
RESET. The initial start-up prompt, “PRESS ENTER FOR PROGRAMS OR
PRESS QUICK START” appears on the display. You can then begin another
exerciseprogram.DuringaworkoutontheC764climber,pressingRESETexits
the course or program, erases the workout statistics, and displays the start-up
prompt after the climber performs a systems diagnostic test. The foot pedals
return to a very slow fall rate during this time and do not change until you return
to a program or choose a new course.
WORK LEVEL/SPEED: The or keys change the “work level” by changing
thesteprate whichincreases/decreasesthedegreeof effort.Youdecreasethe
steprate (causing the foot pedalsto travel slower) and increase the resistance
when you press the key. The opposite occurs when you press the key.
ENTER: When you turn ON the climber, several prompts appear before you
startyourworkout. Each prompt needstobeaddressedandthen “entered” into
the climber’s memory by pressing the ENTER key.
QUICK START: If you wish to use the manual program, you can bypass the
setuppromptsbypressingtheQUICKSTARTkey.Whenyoubeginworkingout,
the amount of time you have been on the climber and the number of floors
climbed appears on the electronic console display.
Note: The weight setting defaults to 150 pounds (70 kg) so all calorie calcula-
tions and their associated displays are based on a body weight of 150 pounds.
The time selection defaults to the club limit set in memory. You cannot change
the weight or time setting if you use the QUICK START option.
GRAPHIC DISPLAY ON THE C764 CLIMBER
The left window display on the C764 electronic console provides graphic
information about your workout session. The course profile that appears in the
left window display corresponds to the program you selected. As you proceed
through your workout, your position is indicated by a blinking cell.
WORK LEVEL: Shows the selected effort level, from 1 to 10. The higher the
number, the faster your step rate becomes. You can change the work level
anytime during a workout by using the WORK LEVEL/SPEED and keys to
increase or decrease the degree of effort in your workout.
Note: A WORK LEVEL indicator does not appear when you use the manual or
interval programs.

page 12
COMMERCIAL PRODUCTS DIVISION
RATE PER MINUTE: Provides a comparison chart to help you determine the
number of meters, feet, or step rate at which you are travelling. This chart
corresponds to the bar graph on the C764. You can also use the comparison
chart to convert a highlighted numerical display (STEPS PER MINUTE, FEET
PERMINUTE,or METERS PER MINUTE)foundonthefarright of the console.
SMARTRATE:TM (C764only) WhenthePrecoroptionalheartrate receiver has
been properly installed and you wear the Precor Heart Rate Option’s chest
strap, a blinking segment in the bar graph appears at the bottom of the display.
Ifyouhaveenteredyouraccurateage(completedduringthesetupprompts),the
blinking segment shows you the zone that your heart rate is in: either Weight
Loss or Cardiovascular. Refer to Understanding Smart Rate .
Important: The Smart Rate blinking indicator light and the heart rate display
only appear when the Precor heart rate receiver is installed in the electronic
display and the chest strap transmitter is used. The Smart Rate indicator lights
donotappearwhenyouusetheQuickStartkey.IftheSmartRatelightsappear,
but do not blink, it means that a receiver is installed, but the user is not wearing
the chest strap transmitter or it is not working properly. To correct transmitter
problems, refer to your Precor Heart Rate Option Owner’s Manual . To obtain
service, refer to the inside front cover.
RIGHT DISPLAY ON THE C764 CLIMBER
Priortoyourworkout,promptsappearinthe top rightdisplaywindow.Theaction
you need to take appears in the lower window. Once you begin a workout, the
topwindowindicatestheTIME,DISTANCE(floorsclimbed),andSPEED(floors
perminute).Youcandeterminewhatinformationwillappearinthelowerwindow
by pressing the CHANGE keys and highlighting a particular feature.
TIME: Displays the time that has elapsed since beginning a specified program
or workout. Use this display to pace yourself during a workout.
FLOORS CLIMBED: Shows the equivalent vertical distance that you have
travelled during your workout. A floor is equivalent to 10 feet or 3 meters.
Note: During a workout on the C764 climber, pressing RESET exits your
program and displays the start-up prompt after the climber performs a systems
diagnostictest.Thefootpedalsreturntoaveryslowfallrateduringthistimeand
do not change until you return to a new course or program.
FLOORSPER MINUTE:Onceyoubeginaworkout,theverticalspeedatwhich
you are travelling appears in this display.
