ENGLISH
Resolute™ Strength Selectorized Line
Rotary Torso RSL 315
Assembly Guide

©2019 Precor Inc. | Rotary Torso RSL 315 | Assembly Guide 2
Assembly Requirements
It takes about 90 minutes to assemble this equipment. If this is your rst time doing this, allow more time.
CAUTION
At least two people are required to assemble the equipment. DO NOT attempt to assemble this by yourself. Precor recommends that all strength equipment be bolted to the
ooring at all anchoring points.
Installation Requirements
● Unpack the boxes and assemble the equipment close to where you plan to use it.
● Locate equipment at least 40 inches (1 meter) away from any walls, furniture, or objects on all sides.
● While tightening the fasteners, be sure to leave room for adjustments. DO NOT fully tighten fasteners until instructed to do so.
● Set up and assemble the equipment on a solid, at surface, so that it remains level and stable.
● DO NOT move the equipment without assistance.
Required Tools
● Torque wrench with torque range to at least 150 ft-lb (206 N-m) and ts the following hex bits: 6, 8, and 10 mm
● Socket wrench sets, metric and standard, plus extensions
● Open-end wrench sets, metric and standard
● Hex wrench sets, metric and standard, plus extensions
●Box cutter
●Rubber mallet
● Retaining ring pliers - large, medium, and small
● Pliers - large, medium, and small
Trademarks
Resolute is a trademark and Precor is a registered trademark of Precor, Incorporated.
All other trademarks belong to their respective owners.

©2019 Precor Inc. | Rotary Torso RSL 315 | Assembly Guide 3
Part # Name Quantity Part # Name Quantity
Main frame 1 Back pads 2
Arm handles 1 Roller pads 3
Upper cross brace 1 Weight plates 10 lb (4.5 kg) 15
Lower cross brace 1 Weight labels 1
Bumpers 4 Washer, rubber, black 1
Roller pad cap rings 3 Washers, domed, silver 2
Roller pad caps 3 Retaining rings 3
Weight stack tower frame 1Button head cap screws (BHCS) 5/16-inch x 1½-inch 4
Top plate assembly 1 Washer, silver, 13.5 mm ID x 35 mm OD 1
Add-on weight 5 lb (2.2 kg) 1Socket head cap screws (SHCS) M12 x 35 mm 8
Add-on weight handle 1Socket head cap screws (SHCS) M12 x 125 mm 2
Kick plate 1 Socket head cap screws (SHCS) M12 x 130 mm 2
Weight stack spacer, 3-inch 1Socket head cap screws (SHCS) M10 x 40 mm 2
Guide rods 2 Socket head cap screws (SHCS) M10 x 65 mm 2
Shroud, crown 1Button head cap screws (BHCS) M10 x 125 mm 2
Guide rod with cap 1Button head cap screw (BHCS) M6 x 15 mm 1
Shroud, rear upper 1Hex head screws 5/16-inch x 1½-inch 3
Shroud, front upper placard 1Nylon lock nuts, M12 2
Shroud, rear lower 1Nylon lock nuts, M10 2
Shroud, front lower 1Washers, 13 mm 12
Shroud, rear middle 1Washers, 11 mm 6
Shroud, front middle (left and right) 2Washers, 9 mm 7
Top tray 1
Shroud, lower pulley cover 1
Seat pad 1
1
10
11
12
13
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
3
30
31
32
33
34
35
36
37
39
4
40
42
43
44
45
46
47
6
7
8
9
2
5
14
Parts List
38
41

©2019 Precor Inc. | Rotary Torso RSL 315 | Assembly Guide 4
Frame Assembly
DO NOT tighten fasteners until instructed to do so.
Have your assistant hold frame parts in place during assembly.
Image Hardware Instructions
12 M12 x 130 mm SHCS
4 washers, 13 mm
2 M12 nylon lock nuts
Tools: Hex wrench, 10 mm
Socket wrench, 19 mm
2 M10 x 125 mm BHCS
2 washers, 11 mm
Connect lower cross brace to weight stack tower and kick
plate .
Align to far right hole under pulley.
Insert both guide rod fasteners from user side to align kick plate.
Hand tighten only. These will be removed temporarily in a later
step.
22 M12 x 35 mm SHCS
2 washers, 13 mm
Tool: Hex wrench, 10 mm
Connect lower cross brace to main frame .
35
43
8
45
37
45
43
12
46
40
4
35
1
45
4
1
12
37
4
40
45
46
8
4
45
8
12
4
1
2
3

©2019 Precor Inc. | Rotary Torso RSL 315 | Assembly Guide 5
32 M12 x 35 mm SHCS
2 washers, domed
Tool: Hex wrench, 10 mm
Connect upper cross brace to weight stack tower .
42 M12 x 125 mm SHCS
2 washers, 13 mm
Tool: Hex wrench, 10 mm
Connect upper cross brace to main frame .
54 M12 x 35 mm SHCS
4 washers, 13 mm
Tool: Hex wrench, 10 mm
Connect arm handle to main frame .
6 Tools: tHex wrench, 10 mm
Socket wrench, 19 mm
Torque wrench
Gently rock the frame to align. Tighten all M12 fasteners to a torque of 55
ft-lb (75 N-m).
Do not tighten the M10 screws installed in step 1 at this time. They will
be removed temporarily in a later step.
1
3
36
1
2
8
31
3
35
35
8
31
3
1
3
36
45
35
45
45
1
2
35
45

©2019 Precor Inc. | Rotary Torso RSL 315 | Assembly Guide 6
Seat Assembly
Image Hardware Instructions
1 3 roller pad cap rings
3 roller pads
Prepare pads for arm handle and main frame by snapping the roller pad cap
rings onto roller pads.
2 3 retaining rings
Tool: Retaining ring pliers
Slide roller pads onto pad rods on arm frame and onto knee rod on main
frame . Secure pads with retaining rings.
3 3 roller pad caps Snap roller pad caps onto roller pads.
44 BHCS 5/16-inch x 1½-inch
4 washers, 9 mm
Tool: Hex wrench, 1/2-inch
Attach back pads (wide sides towards middle) to main frame .
53 hex head screw 5/16-inch x 1½-inch
3 washers, 9 mm
Tool: Socket wrench, 1/2-inch
Attach seat pad to main frame .
6
27
1
2
32
7
1
27
6
7
2
33
26
47
25
26
42
47
1
1
47
42
47
25
32
33

©2019 Precor Inc. | Rotary Torso RSL 315 | Assembly Guide 7
Route the Cable
Image Hardware Instructions
1Tools: Socket wrench, 8 mm
Socket wrench, 4 mm
To route the cable around the lower pulley on the weight stack tower,
remove the cable retainer. Route the cable around the pulley and then
replace the cable retainer.
2Tools: Hex wrench, 10 mm
Open-end wrench, 19 mm
Torque wrench
To route the cable to the upper pulleys of weight stack tower, remove the
cable retainers, route the cables, and replace the retainers. Tighten to 50
ft-lb (67 N-m) of torque.

©2019 Precor Inc. | Rotary Torso RSL 315 | Assembly Guide 8
Finish the Weight Stack Tower
Image Hardware Instructions
12 M10 x 125 mm BHCS
2 washers, 11 washers
Tool: Hex wrench, 6 mm
Remove the guide rod fasteners installed in step 1 of the Frame Assembly.
2 2 guide rods
1 weight stack spacer, 3-inch
Align the weight stack spacer over the holes on the base of the tower. Insert two
weight guide rods and lean outwards about 6 inches (15 cm), enough clearance
for the weights. Flat side of weight stack spacer should face user side.
3 2 bumpers
15 10 lb (4.5 kg) weight plates
1 top plate assembly
Slide one bumper on to each rod. Place the weight plates on the rods. Ensure the
side with three holes face the user side and single hole to the back. Place the top
plate over the weight plates. The plates and top plate should align ush on the
user side.
13
40
14
8
46
40
13
14
28
9
5
28
46
9
5

©2019 Precor Inc. | Rotary Torso RSL 315 | Assembly Guide 9
4Straighten the guide rods to a vertical position. Have your assistant lift the guide
rods into the upper part of the frame.
5Tools: Hex wrench, 6 mm
Torque wrench
While the assistant is holding the rods into the upper frame, replace the two
guide rod bolts, removed in step 1, underneath the guide rods in the bottom
frame. Secure them to the kick plate. Let the guide rods drop onto the bolts and
fully tighten the bolts. Tighten M10 screws to 32 ft-lb (43 N-m) of torque.
6 1 M10 x 65 mm SHCS
2 washers, 11 mm
1 M10 nylon lock nut
Tools: Hex wrench, 8 mm
Socket wrench, 17 mm
1 guide rod with cap
Prepare the lower base for the add-on weight assembly. Place the retaining
screw through the bracket on the weight stack spacer.
Remove the cap from the guide rod and place the rod into bracket opening se-
cured by the screw.
7 2 bumpers
1 add-on weight
1 add-on weight handle
Place one bumper onto the third guide rod, followed by another bumper (wide
sides together), the add-on weight, and the add-on weight handle.
8 1 M10 x 65 mm SHCS
2 washers, 11 mm
1 M10 nylon lock nut
Tools: Hex wrench, 8 mm
Socket wrench, 17 mm
Replace the cap to the top of the rod and secure top of rod to weight stack tower
frame.
44
44
11
16
44
16
39
46
5
11
10
46
39 44
10
39
46
5
39
46
8
46
40

©2019 Precor Inc. | Rotary Torso RSL 315 | Assembly Guide 10
91 washer, rubber
1 washer, silver 13.5 mm ID x 35 mm OD
Place the washers into the top of the cable connector in the add-on weight han-
dle.
10 Tool: Torque wrench Attach the cable to the weight stack. Thread the bolt into the top plate assembly
until the cable meets ALL of the following requirements.
The top weight begins to separate from the second weight.
The selector pin can be easily inserted into each of the weight plates.
The add-on weight is engaged when the latch is in the down position.
At least six turns of the threads on the cable bolt extend into the add-on
weight selector stem.
The distance from the underside of the jam nut to the top of the washer should
be no more than 1.61 inch (41mm).
Tighten the locking bolt against the select stem to 50 ft-lb (81 N-m) of
torque.
11 1 weight labels Remove back of labels. Align top holes on labels and top weight and place pin
into hole. Remove pin and place into a lower hole on labels. Re-align labels as
necessary and then press rmly onto weights. Rub vigorously and thoroughly to
adhere. Peel the extra label away and rub remaining labels again.
12 Lubricate the guide rods with a Teon-based lubricant, such as Tri-Flow Superior
Lubricant. Remove any excess with a clean cloth or tissue.
30
34
29
30
34
41 mm
