Prevue Pet Products F075 User manual

L
B
FR
C2
C1
T
G
G
D
C5
C4
C1 C3
C2
L
F
C6
B
R
{ 1 } basic allen wrench
{ 18 } long hex screws
{ 2 } roof corner braces
{ 4 } wood perches
{ 4 } food/water cups
{ 8 } corner cap covers
{ 4 } plastic connectors
(optional — for use when
stacking cage units)
KEY:
B = Back
R = Right Side
C = Center Core pieces
F = Front
L = Left Side
G = Grille
T = Tray
D = Divider
cageassemblyinstructions
Ha pton Deluxe
Divided Flight Breeding Cage
Model: # F075
cage: 37½"L ×18"W × 20½"H
interior (each side): 18½"L × 17½"W × 17¼"H
wire gauge: 12 & 15
wire spacing: ½"
getting started!
READ THESE NOTES FIRST:
• Review All Parts: If parts have been damaged, please
contact revue Customer Service.
•Tools: A simple allen wrench is included. You may use your
own hand tool with an allen wrench bit. You may also want to
have a pair of needle nose pliers to straighten or adjust any bent
wires or to remove slugs from holes. For seriously damaged
pieces, please contact revue Customer Service.
Review these instructions thoroughly before attempting to
assemble cage. If you still require assistance, please contact
revue Customer Service at 800.243.3624 or through links
online at prevuepet.com
parts
steps
1a Assemble the cage body: For the next four
steps, the cage body will be assembled in an
upside-down orientation.
With the front panel (F) and right side panel (R)
upside down, align the extended wires on the side
panel mesh with holes along the inner vertical
frame of the front panel. Secure the side panel to
the front panel in two places with long hex screws.
With the back panel (B) and left side panel
(L) upside down, continue to assemble the
cage body; aligning the extended wires on
side panels mesh with holes along the inner
vertical frames of the front and back panels.
Secure side panels to front and back panels
with long hex screws.
Locate the two matching tray channel rails
(C1 & C2). These rails have channels that will
hold the tray & grille. Make sure the channel
is flush with the top surface, and the channel
faces the channel built into its respective side
panel (see detail).
Secure the tray channel rails with long hex
screws through the front and back panels.
NOTE: Cage elements are assembled UPSIDE DOWN for ease
of assembly.
instUS_Ca eAssembly-F075_5:Layout 1 8/3/13 4:57 PM Pa e 1

Ú
C6
D
G
T
Made in China f r Prevue Pet Products, Inc., Chicag IL USA prevuepet.c m 800 243-3624 cust merservice@prevuepet.c mF075 — 05/13 — US
2Install the four perches (two to a side).
Install the four food/water cups.
Rotate the tray/grille lock out of the
way and insert the two trays (T)
and two grilles (G).
Locate one of the plain, square center rails (C3-
C4-C5 are all the same/are all interchangeable).
Secure the center rail with long hex screws
through the front and back panels.
1b FLI THE CAGE BODY U RIGHT
Locate the remaining square center rails
(C4 & C5), and install with long hex screws
though the front and back panels.
R
R
C3
C5
C4
Insert the divider grille (D), if using.
3Attach the roof: Lay the roof panel (C6)
in place. Remove the top left back corner
screw, and reinstall with a corner roof brace
(see detail). Follow the same directions for
the top front right corner.
Insert the cap covers into the open frame corners
on top. If this is NOT stacking onto another cage
unit (eg. on an #F070, or on another #F075), also
insert cap covers at the bottom corners, as footers
for the unit.
✩Your cage is now fully assembled!
*IF YOU ARE ADDING THIS AS AN ADDITIONAL
CAGE UNIT ONTO #F070 or ANOTHER #F075:
Remove the cap covers (refer to the previous step).
One corner at a time, remove long hex screw;
insert plastic connectors (included with #F075
parts) into each corner and align the bottom hole
on the connector with the hole in frame rails;
replace long hex screw. Insert this cage unit over
and onto the plastic connectors.
Maximum stack: three cage units.
