Pride Mobility Maxima Scooter SC940 User manual

Owner’s Manual
ATTENTION:
Please read the content
of your owner’s manual
before operating your
scooter.
Unit 106, Heyford Park Camp Road
Upper Heyford, Oxfordshire OX25 5HA
www.pridemobility.com
The Ultimate In Style & Performance
®

Thesymbolsbelowareusedthroughoutthisowner'smanualandonthescootertoidentifywarningsandimportant
information.Itisvery importantforyouto readthemandunderstand themcompletely.
WARNING! Indicates a potentially hazardous condition/situation that can cause personal
injury, equipment and/or property damage.
MANDATORY! These actions should be performed as specified. Failure to perform
mandatory actions can cause injury to personnel and/or damage to equipment.
PROHIBITED! These actions are prohibited; do not perform at any time or in any situation.
Performing a prohibited action can cause personal injury and/or equipment damage.
Copyright© 2005
PrideMobilityProducts Ltd.
INFMANU2203/REVB/DECEMBER2005
SAFETY GUIDELINES
NOTE: This owner’s manual is compiled from the latest specifications and product information avail-
able at the time of publication. We reserve the right to make changes as they become necessary. Any
changes to our products may cause slight variations between the illustrations and explanations in this
manual and the product you have purchased.
Pleasefilloutthefollowinginformationforquickreference:
Pride Dealer:______________________________________________________________________
Purchase Date:______________________________________________________________________
Address:___________________________________________________________________________
Phone Number:______________________________________________________________________
Serial Number:_______________________________________________________________________

Maxima 3www.pridemobility.com
I. INTRODUCTION......................................................................................................................... 4
II. SAFETY......................................................................................................................................... 5
III. SPECIFICATIONS ................................................................................................................... 14
IV. YOUR SCOOTER...................................................................................................................... 16
V. BATTERIES AND CHARGING ............................................................................................ 20
VI. OPERATION............................................................................................................................... 24
VII. COMFORT ADJUSTMENTS................................................................................................ 26
VIII.DISASSEMBLY AND ASSEMBLY ..................................................................................... 29
IX. BASIC TROUBLESHOOTING ............................................................................................. 32
X. CARE AND MAINTENANCE ................................................................................................ 34
XI. WARRANTY................................................................................................................................. 37
CONTENTS

4Maxima
www.pridemobility.com
I. INTRODUCTION
SAFETY
Welcome to Pride Mobility Products Ltd.(Pride). The productyou have purchased combines state-of-the-art
componentswithsafety,comfort andstylingin mind.We areconfidentthe designfeatureswillprovide youwith
theconveniences youexpect duringyour dailyactivities. Understandinghow tosafely operateand carefor this
productshouldbring youyears oftrouble freeoperations andservice.
Readandfollowall instructions,warningsandnotes inthismanualand allotheraccompanyingliterature before
attempting to operatethis product for the firsttime. In addition,your safetydepends uponyou, as well asyour
dealer, carerorhealthcareprofessional inusinggood judgement.
Ifthere is anyinformation inthis manualwhich youdo notunderstand orifyou requireadditional assistancefor
setupor operation, please contact your authorised PrideDealer. Failuretofollowtheinstructions,warnings
andnotesinthismanualandthoselocatedonyourPrideproductcanresultinpersonalinjuryorproduct
damageandwillvoidPride’sproductwarranty.
PURCHASER’S AGREEMENT
Byacceptingdeliveryofthisproduct,youpromisethatyouwillnotchange,alterormodifythisproductorremove
orrenderinoperableor unsafeanyguards, shieldsorothersafety featuresofthis product;fail,refuseor neglectto
installany retrofit kitsfrom timeto timeprovided byPride toenhance orpreserve thesafeuse ofthis product.
INFORMATION EXCHANGE
Wewant tohear yourquestions, commentsand suggestionsabout thismanual.Wewould alsolike tohear about
thesafetyandreliabilityofyournewscooterandabouttheserviceyoureceivedfromyourauthorisedPrideDealer.
Pleasenotifyusofanychangeofaddress,sowecankeep youapprisedofimportantinformationaboutsafety,new
productsand newoptions thatcan increaseyour abilityto use andenjoy yourscooter.Please feelfree to contact
usat the addressbelow:
PrideMobilityProducts Ltd.
Unit106, Heyford Park Camp Road
UpperHeyford, OxfordshireOX25 5HA
NOTE: If you ever lose or misplace your product registration card or your copy of this manual, contact
us and we will be glad to send you a new one immediately.

Maxima 5www.pridemobility.com
II. SAFETY
GENERAL
Your scooterisastate-of-the-art life-enhancementdevicedesignedto increasemobility.Prideprovides anexten-
sivevarietyof productsto bestfitthe individualneeds of thescooter user. Pleasebeaware thatthe finalselection
andpurchasing decision regardingthe type of scooterto be usedis the responsibility ofthe scooter user whois
capableof making such adecision and his/herhealthcare professional (i.e., medicaldoctor,physical therapist,
etc.).
The contents of this manual are based on the expectation that a mobility device expert has properly fitted
thescooterto theuserand hasassistedthe prescribinghealthcareprofessional and/ortheauthorised PrideDealer
inthe instructionprocess for theuse ofthe product.
There are certain situations, including some medical conditions, where the scooter user will need to prac-
tice operating the scooter in the presence of a trained attendant. A trained attendant can be defined as a
family member or care professional specially trained in assisting a scooter user in various daily living
activities.
As you begin using your scooter during daily activities, you will probably encounter situations in which
you will need some practice. Simply take your time and you will soon be in full and confident control as
youmaneuverthrough doorways,on andoff lifts,up anddown rampsand over moderateterrain.
Belowaresome precautions,tipsand othersafety considerationsthatwill helpyou becomeaccustomedto oper-
atingthescootersafely.
MODIFICATIONS
Pridehasdesignedand engineeredyourscooter toprovidemaximummobility andutility.Awiderange ofacces-
soriesis availablefrom your authorisedPride Dealer tofurther customiseyour scooter tobetter suit yourneeds
and/orpreferences.However,undernocircumstancesshouldyoumodify,add,remove ordisableanyfeature,part
orfunctionof yourscooter.
WARNING! Do not modify your scooter in any way not authorised by Pride. Unauthorised
modifications may result in personal injury and/or damage to your scooter.
MANDATORY! Do not operate your new scooter for the first time without completely reading
and understanding this owner’s manual.
REMOVABLE PARTS
WARNING! Do not attempt to lift or move your scooter by any of its removable parts.
Personal injury and damage to the scooter may result.

6Maxima
www.pridemobility.com
II. SAFETY
PRE-RIDE SAFETY CHECK
Gettoknowthefeelofyourscooter anditscapabilities.Priderecommendsthatyouperform a safetycheckbefore
eachuse tomake sureyour scooteroperates smoothlyand safely.Fordetails onhow toperform thesenecessary
inspections,seeX. “Careand Maintenance.”
Performthefollowinginspectionspriortousingyourscooter:
!Check for proper tyre inflation. Maintain 2-2.4 bar (30-35 psi) in each tyre (if equipped with pneu-
matic tyres).
!Check all electrical connections. Make sure they are tight and not corroded.
!Checkall harnessconnections tothe electronicmodule. Makesure theyare securedproperly.
!Check the brakes.
!Check battery charge.
INCLINE INFORMATION
More and more buildings have ramps with specified degrees of inclination, designed for easy and safe
access.Some ramps may have turningswitchbacks (180-degree turns)that require youto have goodcornering
skillsonyour scooter.
!Proceedwith extremecaution asyou approachthe downgrade ofa rampor otherincline.
!Take wide swings with your scooter’s front wheel(s) around any tight corners. If you do that, the scooter’s rear
wheelswillfollowawidearc,notcutthecornershortandnotbumpintoorgethunguponanyrailingcorners.
!When driving down a ramp, keep the scooter’s speed adjustment set to the slowest speed setting to
ensurea safelycontrolled descent.See IV.“Your Scooter.”
!Avoid sudden stops and starts.
Ifyou discovera problem,contact yourauthorised PrideDealer forassistance.
WEIGHT LIMITATIONS
Your scooterisratedfor amaximumweightcapacity.Refertothespecifications tableforinformation.
TYRE INFLATION
If your scooter is equipped with pneumatic tyres, you should check or have the air pressure checked at least
once a week. Proper inflation pressures will prolong the life of your tyres and help ensure the smooth
operation of your scooter.
WARNING! It is critically important that 2-2.4 bar (30-35 psi) tyre pressure be maintained
in pneumatic tyres at all times. Failure to maintain 2-2.4 bar (30-35 psi) tyre pressure in
pneumatic tyres at all times may result in catastrophic tyre and/or wheel failure, causing
serious personal injury and/or damage to your scooter.
WARNING! Inflate your scooter drive tyres from a regulated air source with an available
pressure gauge. Maximum air pressure for scooter drive tyres is 2-2.4 bar (30-35 psi). Inflating
your tyres from an unregulated air source could overinflate them, resulting in a burst tyre
and/or personal injury.
WARNING! Exceeding the weight capacity voids your warranty and may result in personal
injury and damage to your scooter. Pride will not be held responsible for injuries and/or
property damage resulting from failure to observe weight limitations.
WARNING! Do not carry passengers on your scooter. Carrying passengers may result in
personal injury and/or property damage.

Maxima 7www.pridemobility.com
II. SAFETY
When climbing an incline, try to keep your scooter moving. If you must stop, start up again slowly and then
accelerate cautiously. When driving down an incline, do so by setting the speed adjustment dial to the
slowest setting and driving in the forward direction only. If your scooter starts to move down the incline
faster than you anticipated or desired, allow it to come to a complete stop by releasing the throttle control
lever. Then push the throttle control lever forward slightly to ensure a safely controlled descent.
Otherinclines may be natural or, ifman-made, not designed specificallyfor scooters. Figure 1 illustratesyour
scooter’sstabilityanditsabilitytoclimbgradesundervariousweightloadsandundercontrolledtestingconditions.
These tests were conducted with the scooter’s seat in the highest position and adjusted rearward on the seat
base to its farthest rearward position. Use this information as a guideline.Your scooter’s ability to travel up
inclines is affected by your weight, your scooter’s speed, your angle of approach to the incline and your
scooter setup.
WARNING! When climbing an incline, do not zigzag or drive at an angle up the face of the
incline. Drive your scooter straight up the incline. This greatly reduces the possibility of a
tip or a fall. Always exercise extreme caution when negotiating an incline.
WARNING! Do not drive your scooter across the side of an incline or diagonally up or down
an incline; do not stop, if possible, while driving up or down an incline.
WARNING! You should not travel up or down a potentially hazardous incline (i.e., areas
covered with snow, ice, cut grass or wet leaves).
WARNING! When on any sort of an incline or decline, never place the scooter in freewheel
mode while seated on it or standing next to it.
WARNING! Even though your scooter is capable of climbing slopes greater than those
illustrated in figure 1, do not, under any circumstances, exceed the incline guidelines or
any other specifications presented in this manual. Doing so could cause instability in your
scooter, resulting in personal injury and/or damage to your scooter.
Figure 1. Maximum Recommended Incline Angles
181-227 kg/
28-36 stone
(400-500 lbs.)
7.5% (4.5°)
68 kg/
11 stone
(150 lbs.)
12.3% (7°)
90 kg-113 kg/
11-18 stone
(150-250 lbs.)
10.5% (6°)
136-158 kg/
21-25 stone
(300-350 lbs.)
8.7% (5°)
WARNING! Any attempt to climb or descend a slope steeper than what is shown in figure
1 may put your scooter in an unstable position and cause it to tip, resulting in personal
injury.
WARNING! Never carry an oxygen tank weighing more than 7 kg (15 lbs.). Never fill the
rear basket with contents exceeding 7 kg (15 lbs.).

8Maxima
www.pridemobility.com
II. SAFETY
CORNERING INFORMATION
Excessively high cornering speeds can create the possibility of tipping. Factors which affect the possibility
of tipping include, but are not limited to, cornering speed, steering angle (how sharply you are turning),
uneven road surfaces, inclined road surfaces, riding from an area of low traction to an area of high traction
(suchaspassingfromagrassyarea toapavedarea–especiallyat highspeedwhileturning)andabruptdirectional
changes.High corneringspeeds arenot recommended. Ifyou feelthat youmay tipover ina corner, reduceyour
speedand steeringangle(i.e., lessenthe sharpnessof theturn) toprevent yourscooter fromtipping.
WARNING! When cornering sharply, reduce your speed. When using your scooter at higher
speeds, do not corner sharply. This greatly reduces the possibility of a tip or fall. To avoid
personal injury or property damage, always exercise common sense when cornering.
Figure 2A. Increased Stability Driving Position
Figure 2. Normal Driving Position
BRAKING INFORMATION
Your scooter is equipped with two powerful brake systems:
!Regenerative:Useselectricityto rapidlyslowthe vehiclewhenthethrottle controlleverreturnsto thecentre/
stopposition.
!DiscPark Brake:Activatesmechanically after regenerativebraking slows thevehicle to nearstop or when
poweris removedfrom thesystem forany reason.
Whenyouapproach anincline,it isbestto leanforward. See figures2 and2A.This shiftsthecentre ofgravityof
youand yourscooter towardthe frontof thescooter forimproved stability.
NOTE: When negotiating ramps, if the throttle control lever is released while moving forward, the
powered scooter may "rollback" approximately 30.5 cm (1 foot) before the brake engages. If the throttle
control lever is released while moving in reverse, the powered scooter may "rollback" approximately
one meter (3 feet) before the brake engages.

Maxima 9www.pridemobility.com
II. SAFETY
OUTDOOR DRIVING SURFACES
Your scooterisdesignedtoprovide optimumstabilityundernormaldriving conditions—dry,levelsurfacescom-
posedofconcrete,blacktoportarmac.However,Priderecognizesthattherewillbetimeswhenyouwillencounter
other surface types. For this reason, your scooter is designed to perform admirably on packed soil, grass and
gravel.Feel free touse yourscooter safely onlawns and inpark areas.
!Reduceyourscooter’sspeed whendrivingon uneventerrain and/orsoft surfaces.
!Avoid tall grass that can become tangled in the running gear.
!Avoid loosely packed gravel and sand.
!Ifyoufeelunsure aboutadriving surface,avoidthat surface.
STREETS AND ROADWAYS
WARNING! Exercise extreme caution when operating the scooter on footpaths, pavements,
bridleways, pedestrian areas and roads. Obey the Code of Practice for Class 3 vehicle
users. Failure to heed could result in serious injury and/or damage to your scooter.
NOTE: Acopy of the Department of Transportation, Code of Practice for Class 3 vehicle users, may be
obtained by contacting your authorised Pride Dealer.
STATIONARY OBSTACLES (STEPS, KERBS, ETC.)
WARNING! Do not drive near raised surfaces, unprotected ledges and/or drop-offs (kerbs,
porches, stairs, etc.).
WARNING! Do not attempt to have your scooter climb or descend an obstacle that is
inordinately high. Serious personal injury and/or damage may result.
WARNING! Do not attempt to have your scooter proceed rearward down any step, kerb or
other obstacle. This may cause the scooter to tip and cause personal injury.
WARNING! Be sure your scooter is traveling perpendicular to any kerb you may be required
to ascend or descend. See figures 3 and 3A.
WARNING! Do not attempt to negotiate a kerb that has a height greater than 5 cm (2 in.).
Figure 3. Correct Kerb Approach Figure 3A. Incorrect Kerb Approach
KERB
KERB

10 Maxima
www.pridemobility.com
WARNING! Do not use your scooter to negotiate steps or escalators. You may cause injury
to yourself and to others and damage your scooter.
DOORS
!Determineif thedoor openstoward oraway fromyou.
!Useyour hand to turn the knob orpush the handle orpush-bar.
!Driveyourscooter gentlyandslowlyforward topushthe dooropen.Or driveyourscooter gentlyandslowly
rearwardsto pull the dooropen.
STAIRS AND ESCALATORS
Scootersare not designedto travel upor down stairsor escalators.Alwaysuse alift.
II. SAFETY
FREEWHEEL MODE
Your scooterisequippedwitha manualfreewheellever that, whenengaged,allowsthescooter tobe pushed.For
moreinformationabouthowtoplaceyourscooterintoandout offreewheelmode,seeIV.“YourScooter.”
WARNING! When your scooter is in freewheel mode, the braking system is disengaged.
! Disengage the drive motors only on a level surface.
! Ensure the key is removed from the key switch.
! Stand behind the scooter to engage or disengage freewheel mode. Never sit on a
scooter to do this.
! After you have finished pushing your scooter, always return it to the drive mode to lock
the brakes.
Failure to heed the above could result in personal injury and/or damage to your scooter.
Anaddedfeaturebuiltintothescooter is“push-too-fast”protectionwhichsafeguards thescooteragainstgaining
excessivespeedwhileinfreewheel mode.
“Push-too-fast” operates differently depending on which of two conditions exists:
!Ifthe keyis switched“off”whenin freewheelmode, thescooter’s controlleractivates regenerativebraking
whenthescooterispushedfasterthan amaximumthresholdwhichhasbeenpreprogrammed. Inthiscase,the
controlleris actingas aspeed governor.
!Ifthekeyis switched“on”whileinfreewheel mode,youwillencounter considerableresistanceatany speed.
Thispreventsthescooterfromgainingunwantedmomentumshouldthemanualfreewheelleverinadvertently
bereleasedwhile drivingthescooter.
INCLEMENT WEATHER PRECAUTIONS
Exposure of your scooter to inclement weather conditions should be avoided whenever possible. If suddenly
caughtup inrain, snow,severecold orheat whileoperating yourscooter proceedto shelterat theearliest oppor-
tunity.Thoroughlydryyour scooterbeforestoring,chargingoroperatingyour scooter.
WARNING! Operating in rain, snow, salt, mist/spray conditions and on icy/slippery surfaces
can cause personal injury and/or damage to the scooter and electrical system. Maintain
and store your scooter in a dry and clean condition.

Maxima 11www.pridemobility.com
LIFTS
Modernliftshave adoor edgesafety mechanismthat, whenpushed, reopensthe lift door(s).
!Ifyou arein thedoorway of alift whenthe door(s)begin to close,push onthe rubberdoor edge orallow the
rubberdoor edge to contact the scooterand the door will reopen.
!Usecare that handbags ,packages or scooter accessories donot become caught inlift doors.
NOTE: If your scooter’s turning radius is greater than 1500 mm, it may be difficult to maneuver in lifts
and building entrances. Use caution when attempting to turn or maneuver your scooter in small spaces,
and avoid areas that might pose a problem.
LIFT/ELEVATION PRODUCTS
Ifyouwillbetravelingwithyourscooter,youmayfinditnecessarytousealift/elevationproducttoaidintranspor-
tation.Priderecommendsthatyoucloselyreviewtheinstructions,specificationsandsafetyinformationsetforthby
themanufacturerofthelift/elevationproduct beforeusingthatproduct.
BATTERIES
In addition to following the warnings below, be sure to comply with all other battery handling information.
Formore informationabout yourscooter’sbatteries, seeV.“ Batteriesand Charging.”
WARNING! Scooter batteries are heavy (refer to specifications table). Lifting weight beyond
your capacity could result in personal injury. If necessary, get someone physically able to
lift the batteries for you.
WARNING! Battery posts, terminals and related accessories contain lead and lead
compounds. Wash hands after handling.
WARNING! Always protect the batteries from freezing and never charge a frozen battery.
Charging a frozen battery may result in personal injury and/or damage to the battery.
WARNING! RED (+) cables must be connected to positive (+) battery terminals/posts. BLACK
(-) cables must be connected to negative (-) battery terminals/posts. Failure to connect
your battery harnesses in the proper manner may result in personal injury and/or damage
to your scooter. REPLACE cables immediately if damaged.
BATTERY DISPOSAL AND RECYCLING
Ifyou encounter adamaged or crackedbattery, immediatelyenclose it ina plastic bagand call your authorised
PrideDealerforinstructionsondisposal.YourauthorisedPrideDealerwillalsohavethenecessaryinformationon
batteryrecycling,whichis ourrecommendedcourse ofaction.
PREVENTING UNINTENDED MOVEMENT
WARNING! If you anticipate being seated in a stationary position for an extended period
of time, turn off the power. This will prevent unexpected motion from inadvertent throttle
control lever contact. Failure to do so may result in personal injury.
II. SAFETY

12 Maxima
www.pridemobility.com
MOTOR VEHICLE TRANSPORT
Currently, there are no standards approved for tie-down systems in a moving vehicle of any type to trans-
porta person while seated ina scooter.
Although your scooter may be equipped with a positioning belt, this belt is not designed to provide proper
restraint during motor vehicle transport.Anyone traveling in a motor vehicle should be properly secured in
the motor vehicle seat with safety belts fastened securely.
GETTING ONTO AND OFF OFYOUR SCOOTER
Getting onto and off of your scooter requires a good sense of balance. Please observe the following safety
tips when getting onto and off of your scooter:
!Ensurethat yourscooter isnot infreewheel mode. SeeIV.“YourScooter.”
!Make certain that the seat is locked into place and the key is removed from the key switch.
!Flipup theseat armrests tomake getting onand offthe scootereasier.
WARNING! Position yourself as far back as possible in the scooter seat to prevent the
scooter from tipping and causing injury.
WARNING! Avoid using your armrests for weight bearing purposes. Such use may cause
the scooter to tip and cause personal injury.
WARNING! Avoid putting all of your weight on the floorboard. Such use may cause the
scooter to tip and cause personal injury.
REACHING AND BENDING
Avoid reaching or bending while driving yourscooter.Bending forward creates the risk of accidental throttle
controllevercontact.Bendingtothesidewhileseatedcreatestheriskoftipping.Itisimportanttomaintainastable
centreof gravity and keep the scooterfrom tipping. Pride recommends that thescooter user determine his/her
personallimitationsandpracticebending andreachinginthe presenceofaqualifiedattendant.
WARNING! Do not bend, lean, or reach for objects if you have to pick them up from the
scooter deck or from either side of the scooter. Movements such as these may change
your centre of gravity and the weight distribution of the scooter and cause your scooter to
tip, possibly resulting in personal injury.
WARNING! Prevent personal injury! Keep your hands away from the tyres when driving. Be
aware that loose fitting clothing can become caught in drive tyres.
WARNING! Do not sit on your scooter while it is in a moving vehicle. Personal injury and/or
property damage may result.
WARNING! Always be sure your scooter and its batteries are properly secured when it is
being transported. Failure to do so may result in personal injury and/or damage to your
scooter.
II. SAFETY

Maxima 13www.pridemobility.com
II. SAFETY
POSITIONING BELTS
Your authorisedPrideDealer,therapist(s)andotherhealthcare professionalsareresponsiblefordeterminingyour
requirementfora positioningbelt inorder tooperateyour scootersafely.
WARNING! If you require a positioning belt to safely operate your scooter, make sure it is
fastened securely. Serious personal injury may result if you fall from the scooter.
PRESCRIPTION DRUGS/PHYSICAL LIMITATIONS
Thescooterusermustexercisecareandcommonsensewhenoperatinghis/her scooter.Thisincludesawarenessof
safetyissueswhentakingprescribedorover-the-counterdrugsorwhen theuserhasspecificphysicallimitations.
WARNING! Consult your physician if you are taking prescribed or over-the-counter
medication or if you have certain physical limitations. Some medications and limitations
may impair your ability to operate your scooter in a safe manner.
ALCOHOL
Thescooteruser mustexercise careandcommon sensewhenoperating his/herscooter.This includesawareness
ofsafetyissueswhileundertheinfluenceofalcohol.
WARNING! Do not operate your scooter while you are under the influence of alcohol, as
this may impair your ability to drive safely.
ELECTROMAGNETIC AND RADIO FREQUENCY INTERFERENCE (EMI/RFI)
WARNING! Laboratory tests have shown that electromagnetic and radio frequency waves
can have an adverse affect on the performance of electrically-powered mobility vehicles.
ElectromagneticandRadio FrequencyInterferencecancome fromsourcessuch ascellularphones, mobiletwo-
way radios (such as walkie-talkies), radio stations, TV stations, amateur radio (HAM) transmitters, wireless
computerlinks,microwavesignals,pagingtransmittersandmedium-rangemobiletransceiversusedbyemergency
vehicles.In some cases, thesewaves can cause unintendedmovement or damage tothe control system. Every
electrically-poweredmobilityvehiclehasanimmunity(or resistance)toEMI.Thehighertheimmunity level,the
greatertheprotection againstEMI.This producthas beentestedand haspassedat animmunity levelof20 V/M.
WARNING! Be aware that cell phones, two-way radios, laptops and other types of radio
transmitters may cause unintended movement of your electrically-powered mobility vehicle
due to EMI. Exercise caution when using any of these items while operating your mobility
vehicle and avoid coming into close proximity of radio and TV stations.
WARNING! The addition of accessories or components to the electrically-powered mobility
vehicle can increase the susceptibility of the vehicle to EMI. Do not modify your scooter
in any way not authorised by Pride.
WARNING! The electrically-powered mobility vehicle itself can disturb the performance
of other electrical devices located nearby, such as alarm systems.
NOTE: For further information on EMI/RFI, visit the Resource Center on www.pridemobility.com. If
unintended motion or brake release occurs, turn your scooter off as soon as it is safe to do so. Contact
your authorised Pride Dealer to report the incident.

14 Maxima
www.pridemobility.com
III. SPECIFICATIONS
Figure 4A.Tyre Dimensions
(10")
25 cm
7.5 cm
(3")
FRONT
(10")
25 cm
10 cm
(4")
REAR
11.43 (4.5")
(16"-18")
40.5 - 46 cm
66 cm
(26")
(22")
56 cm
46 cm (18")
(24"-28")
61-71 cm
3-Wheel 119 cm (47")
4-Wheel 120.5 cm (47.5")
3-WheelTurning Radius
132 cm (52")
4-WheelTurning Radius
165 cm (65")
(18.5")
47 cm
103 - 108 cm
(40.5"-42.5")
Figure 4. Scooter Dimensions
Figure 4B.Tyre Dimensions

Maxima 15www.pridemobility.com
III. SPECIFICATIONS
Model Numbers 3-wheel: SC900, 4-wheel: SC940
Available Colours Painted: Candy Apple Red, Forest Green, Viper Blue, Black Onyx
Overall Length23-wheel: 119 cm (47 in.), 4-wheel: 120.5 cm(47.5 in.)
Overall Width266 cm(26 in.)
Total Weight Without Batteries 3-wheel: 77.5 kg(171 lbs.), 4-wheel: 80 kg (176 lbs.)
Heaviest Piece When Disassembled Rear frame: 32 kg (70 lbs.)
Turning Radius23-wheel: 132 cm (52 in.), 4-wheel: 165 cm(65 in.)
Speed (maximum) Variable up to 8.44 km/h (5.25 mph)
Range Per Charge1(With 32 AHbatteries) Up to 32 km(20 miles)
(With 55 AHbatteries) Up to 48 km(30 miles)
Ground Clearance211.43 cm (4.5 in.)
Weight Capacity 227 kg, 36 stone (500 lbs.)
Standard Seating Type: DX contour mediumback
Dimensions: 56 cm(22 in.) width x 46 cm(18 in.) depth x 47 cm(18.5 in.) height
Material: Gray, Beige, or Black vinyl or Gray fabric
Standard Seat Weight 20 kg (45 lbs.)
Drive System Rear-wheel drive, sealed transaxle with a 24-volt DCmotor
Dual Braking System Electronic, regenerative, and electromechanical
Tyres Type: solid; front: 7.5 cm x 25 cm(3 in. x 10 in.), rear: 10 cm x 25 cm(4 in. x 10 in.
)
Battery Requirements Type: Two 12-volt deep-cycle (AGMor Gel-Cell type recommended)
Size: (U-1) 32 AH, (NF-22) 55 AH
Battery Weight Approximately: (32 AH) 11 kg (25 lbs.) each, (55AH) 17 kg (37 lbs.) each
Battery Charger Off-boardcharger
(1) Varies with user weight, terrain type, battery amp hour (AH), battery charge, battery condition, and tyre condition.
(2) Due to manufacturing tolerances and continual product improvement, this specification can be subject to a variance of (+ or – ) 3 %.
NOTE: All specifications subject to change without notice.

16 Maxima
www.pridemobility.com
Key Switch
!Fullyinsert thekey intothe keyswitch andturn itclockwise topower up(turn on)your scooter.
!Turnthekey anticlockwiseto powerdown (turnoff)yourscooter.
WARNING! If the key is moved to the off position while your scooter is in motion, the
electronic brakes engage and your scooter comes to an abrupt stop!
Speed Adjustment Dial
Thisadjustmentdialenablesyoutopreselectandlimityourscooter’stopspeed.
!The image of the tortoise represents the slowest speed setting.
!Theimage ofthe harerepresents thefastest speed setting.
Status LED
The StatusLEDalertsyoutoelectricalproblemsthatmayoccurwiththescooter.TheLEDremainsconstantlylitwhile
your scooter is on. If the scooter develops an electrical problem, the status LED will flash a code. See IX. “Basic
Troubleshooting” fortroubleshootingflashcodes.
IV. YOUR SCOOTER
CONTROL CONSOLE ASSEMBLY
Thecontrolconsole assemblyhousesall ofthe controls youneed todriveyour scooter, includingthekey switch,
speedadjustmentdial, status LED,throttlecontrol lever, batteryconditionmeter, hornbuttons,lightswitch, turn
indicatorbuttons,off-board chargerport andthe hazardlightsswitch. Seefigure 5.
WARNING! Do not expose the control console assembly to moisture. In the event that the
control console assembly does become exposed to moisture, do not attempt to operate
your scooter until the control console assembly has dried thoroughly.
Figure 5. Control Console Assembly
BATTERY CONDITION METER
KEY SWITCH
HORN BUTTON
SPEED ADJUSTMENT DIAL
THROTTLE CONTROL LEVER (REVERSE)
HORN BUTTON
KEY
HAZARD
LIGHTS
SWITCH
LEFT TURN INDICATOR
BUTTON
LIGHT
SWITCH
RIGHT TURN INDICATOR BUTTON
THROTTLE CONTROL LEVER (FORWARD)
STATUS LED
OFF-BOARD CHARGER PORT

Maxima 17www.pridemobility.com
IV. YOUR SCOOTER
Throttle Control Lever
Thisleverallowsyoutocontroltheforwardspeedandthereversespeedofyourscooteruptothemaximumspeedyou
presetwiththespeedadjustmentdial.
!Placeyourrighthand ontherighthandgrip andyourlefthand ontheleft handgrip.
!Useyourrightthumbtopushtherightsideofthelevertodisengageyourscooter’sbrakesandmoveforward.
!Releasetheleverand allowyourscooter tocometoa completestopbefore pushingtheother sideofthelever
tomovein reverse.
!Whenthethrottlecontrolleveriscompletelyreleased,itautomaticallyreturnstothecentre“stop”positionand
engagesyour scooter’s brakes.
Battery Condition Meter
Thebatterycondition meteronthe control consoleassemblyindicates theapproximatestrength ofyourbatteries
usinga colour code. Green indicates fully chargedbatteries, yellow a drainingcharge and red indicatesthat an
immediaterechargeisnecessary.
Horn Buttons
Thesebuttonsactivea warninghorn.
!Thekeymustbeinsertedandturnedclockwiseforthehorntobeoperational.
!Donothesitate touse thewarning hornwhenits usecould preventaccident orinjury.
Light Switch
Thisswitchcontrolsyourscooter’slightingsystem. Togglethis switchto turnonandturnoffthe lights.
WARNING! Scooter users are required to use their lights when visibility is restricted—day
or night. Failure to use the lighting system in periods of poor visibility may result in personal
injury.
Turn Indicator Buttons
Usethesebuttonstoturnontheleftandrightturnindicatorlights.
!Pressthe appropriateturn indicatorbutton onceto activateit.
!Your scooter’sturnindicators are timedtoshut offautomatically.
Hazard Lights Switch
Thisswitchactivates the4-wayflashersonyourscooter.Togglethis switchto turnon andturnoffthelights.
Off-Board Charger Port
Thescooter’soff-boardchargerplugsinto thisport.

18 Maxima
www.pridemobility.com
MAIN CIRCUIT BREAKER
(RESET BUTTON)
STORAGE COMPARTMENT
ANTI-TIPWHEEL
MANUAL FREEWHEEL
LEVER
FUSES
LIGHT COVER
RIGHTTURN
INDICATOR
FUSE
RIGHTTURN
INDICATOR
LIGHT BULB
RIGHT RUNNING
LIGHT FUSE
RIGHT RUN-
NING LIGHT
BULB
AMMETER
ELECTRONICS MODULE
(REMOVE REAR SHROUD
TOVIEW ENTIRE MODULE)
IV. YOUR SCOOTER
REARSECTION
The manual freewheel lever, the anti-tip wheels, the motor/transaxle assembly (not shown), the electronics
module,thebatteries(notshown),themaincircuitbreaker (reset button),thefusesandtheammeterarelocatedon
the rear section of your scooter. See figure 6. Refer to VIII. “Disassembly andAssembly” for instructions on
removingtherearshroud.
Figure 6. Rear Section
Manual Freewheel Lever
Wheneveryou needor want to push yourscooter forshort distances, youcan putit in freewheelmode.
!Pullupfirmlyon themanualfreewheellever todisablethe drivesystemandthe brakesystem.
!You maypushyour scooter.
!Pushdownfirmly onthemanual freewheelleverto reengagethe drivesystemand thebrakesystem andtake
yourscooter outof freewheelmode.
WARNING! When your scooter is in freewheel mode, the braking system is disengaged.
! Disengage the drive motors only on a level surface.
! Ensure the key is removed from the key switch.
! Stand to the side of the scooter to engage or disengage freewheel mode. Never sit on
a scooter to do this.
! After you have finished pushing your scooter, always return it to the drive mode to lock
the brakes.
Failure to heed the above could result in personal injury and/or damage to your scooter.

Maxima 19www.pridemobility.com
Anti-TipWheels
Thefront(notshown)and rearanti-tipwheelsarean integral andimportantsafetyfeatureof yourscooter.Donot,
underanycircumstances, removetheanti-tipwheels fromyourscooter.
PROHIBITED! Do not remove the anti-tip wheels or modify your scooter in any way that is
not authorized by Pride.
Motor/Transaxle Assembly (Not Shown)
Themotor/transaxle assemblyis theelectromechanical unitthat convertsthe electricalenergyof yourscooter’s
batteriesintothe controlledmechanicalenergythat drivesthescooter’swheels.
Electronics Module
The electronics module houses all of the scooter’s harness mating plugs and electronic components for
charging the batteries.
Batteries (Not Shown)
Thebatteries storethe electricalenergy that powers yourscooter.SeeV. “Batteriesand Charging.”
Main Circuit Breaker (Reset Button)
Whenthevoltageinyourscooter’sbatteriesbecomesloworyour scooterisheavilystrainedbecauseof excessive
loads or steep inclines, the main circuit breaker may trip to protect your scooter’s motor and electronics from
damage.
!The main circuit breaker reset button pops out when the breaker trips.
!Whenthe breakertrips, theentire electricalsystem ofyour scootershuts down.
!Allowa minuteortwo foryour scooter’selectronics to“rest.”
!Push in the reset button to reset the breaker.
!If the breaker trips frequently, you may need to charge your batteries more often. You may also need to
haveyour authorisedPride Dealer performa loadtest on yourscooter’sbatteries.
!Ifthemain circuitbreaker tripsrepeatedly,see yourauthorised PrideDealer forservice.
Fuses
Thefuseshelpprotectyourscooter’slighting,controlconsoleassemblyandchargingsystemsfromreceivinganoverloadof
electricalcurrent.Thefusesusedinthescooterarethesametypeautomobilesuse.
IV. YOUR SCOOTER
If a fuse must be replaced, use only the specified amp fuse.
SeeX. “Careand Maintenance.”
HERCULES DOCKING DEVICE
Yourscooter is equipped with a Hercules 3000 dockingde-
vice.See figure 7.In order toutilize the dockingdevice, it is
necessary to purchase an insert (T-bar or Bullnose and C-
arm) that, when used with the Hercules 3000, will lift your
scooter.
Contactyour authorised Pride Dealer for more information
aboutthe Hercules3000 dockingdevice. Figure 7. Hercules 3000 Docking Device
DOCKING DEVICE

20 Maxima
www.pridemobility.com
V. BATTERIES AND CHARGING
Your scooterrequires twolong-lasting, 12-volt,deep-cycle batteriesthat aresealed andmaintenance free.They
arerechargedby anoff-board chargingsystem.
!Chargeyour scooter’sbatteries priorto using itfor thefirst time.
!Keepthebatteries fullychargedto keepyour scooterrunningsmoothly.
READING YOUR BATTERY VOLTAGE
Thebatteryconditionmeteronthetillerconsoleindicatestheapproximatestrengthofyourbatteriesusingacolour
code.Fromrightto left,greenindicates fullychargedbatteries,yellow adrainingcharge andredindicatesthat an
immediaterechargeisnecessary. Seefigure8.Toensurethehighest accuracy,thebatterycondition metershould
bechecked whileoperating yourscooter atfull speedon a dry,levelsurface.
You can also check the charging status of the batteries by the ammeter, located at the rear of the scooter. The
charger power lead must be plugged into a standard electrical outlet in order to obtain a reading. When the
amperagereading isat ornear zeroamps, chargingis complete.See figure9.
CHARGING YOUR BATTERIES
PROHIBITED! Never use an extension lead to plug in your
battery charger. Plug the charger directly into a properly
wired standard electrical outlet.
PROHIBITED! Removal of the grounding prong can create
an electrical hazard. If necessary properly install an
approved 3-pronged adaptor to an electrical outlet having
2-pronged plug access. Failure to heed could result in
personal injury and or property damage.
WARNING! Ensure that both ends of the charger power
lead are clean and dry before plugging the charger power
lead into the off-board battery charger port or the electrical
outlet.
Follow these easy steps to charge your batteries safely:
1. Positionyour scooterclose toa standardelectrical outlet.
2. Removethe keyfromthe keyswitch.
3. Makecertain thatthe manualfreewheel leveris inthe drive(down) posi-
tion.
4. Plugthe 3-pincharger power leadinto theoff-board charger port.
5. Extendthe chargerpowerlead andplugit intothe electricaloutlet.
6. Turnthe chargeron.
7. Whenthe batteries arefully charged, turnthe charger off and unplug the
chargerpower leadfrom theelectrical outletand then fromthe off-board
chargerport.
NOTE: There is a charger inhibit function on your scooter. The scooter
will not run and the battery condition meter will not operate while the
batteries are charging.
Figure 8. Battery Condition Meter
Figure 9. Ammeter Indicates
Batteries Are Fully Charged
