Pride Mobility Celebirty The Ultimate In Style &... User manual

The Ultimate In Style & Performance
®
Owner’s Manual
www.pridemobility.com
21 Healey Road
Dandenong, 3175
Victoria, Australia

Please read and follow all instructions in this owners manual before attempting to operate your
Scooter for the first time. If there is anything in this manual you do not understand, or if you
require additional assistance for set-up, contact your local authorized Pride provider.
sing your Pride product safely depends upon your diligence in following the warnings, cau-
tions, and instructions in this owners manual. sing your Pride product safely also depends
upon your own good judgement and/or common sense, as well as that of your provider, caregiver,
and/or healthcare professional. Pride is not responsible for injuries and/or damage resulting
from any persons failure to follow the warnings, cautions, and instructions in this owners manual.
Pride is not responsible for injuries and/or damage resulting from any persons failure to exer-
cise good judgement and/or common sense.
The symbols below are used throughout this owners manual to identify warnings and cautions. It
is very important for you to read and understand them completely.
WARNING! Failure to heed the warnings in this owners manual may result in personal injury.
CAU ION! Failure to heed the cautions in this owners manual may result in damage to your
Scooter.
SAFETY GUIDELINES
Copyright © 2002
Pride Mobility Products Australia Pty. Ltd.
INFMANU1467/REV D/OCTOBER 2002

3
Celebrity
CONTENTS
I. INTRODUCTION ......................................................................................................................... 4
II. SAFETY ......................................................................................................................................... 6
III. SPECIFICATIONS .....................................................................................................................
IV. DESCRIPTION .......................................................................................................................... 11
V. BATTERIES AND CHARGING ............................................................................................ 16
VI. OPERATION ............................................................................................................................... 20
VII. COMFORT ADJUSTMENTS ................................................................................................ 22
VIII. DISASSEMBLY AND ASSEMBLY ..................................................................................... 25
IX. OPTIONAL ACCESSORIES ................................................................................................. 28
X. BASIC TROUBLESHOOTING ............................................................................................. 2
XI. CARE AND MAINTENANCE ................................................................................................ 31
XII. WARRANTY ............................................................................................................................... 33

4Celebrity
I. INTRODUCTION
Welcome to Pride Mobility Products, Pty. Ltd. (Pride). Congratulations on the purchase of your new Pride Scooter.
Your Scooter design combines the most advanced state-of-the-art components with modern, attractive styling.
We are certain that the design features and trouble-free operation will add convenience to your daily living and
ensure complete satisfaction.
At Pride, your safety is important to us. Please read and follow all of the instructions in this manual before
you attempt to operate your Scooter for the first time. These instructions were produced for your benefit.
Your understanding of these instructions is essential for the safe operation of your new Pride Scooter.
Pride is not liable for damage to property or personal injury arising out of the unsafe use of a Pride Scooter. Pride
is also not liable for any property damage or personal injury arising out of the failure of any person and or/user to
following the instructions and recommendations set forth in this manual or any other instructions or recommenda-
tions contained in other Scooter related literature issued by Pride or contained on the Pride Scooter itself.
This owners manual is compiled from the latest specifications and product information available at the time of
publication. We reserve the right to make changes as they become necessary. Any changes to our products may
cause slight variations between the illustrations and explanations in this manual and the product you have purchased.
If you experience any problems with your Scooter that you are unable to solve, or if you do not feel capable of safely
following any of the instructions and/or recommendations as contained in this manual, please contact your authorized
Pride provider for assistance.
Once you understand how to operate and take care of your Scooter, we are certain that it will give you years of trouble-
free service and enjoyment.
Information Exchange
We want to hear your questions, comments, and suggestions about this manual. We would also like to hear about the
safety and reliability of your new Pride Scooter and the service you received from your authorized Pride provider.
Please notify us of any change of address so we can keep you apprised of important information about safety, new
products, and new options that can increase your ability to use and enjoy your Pride Scooter. Please feel free to write us
at the address below:
Pride Mobility Products Australia Pty. Ltd.
21 Healey Road
Dandenong, 3175
Victoria, Australia

5
Celebrity
I. INTRODUCTION
My Authorized Pride Provider Is:
Name:_______________________________________________________________________________
Address:_____________________________________________________________________________
Quick Reference Information:
Scooter Model:________________________________________________________________________
Serial Number:__________________________________________________________________________
Purchase Date:________________________________________________________________________
NOTE: If you ever lose or misplace your product registration card or owners manual, write to us and we
will be glad to send you a new one immediately.

6Celebrity
II. SAFETY
SAFETY PRECAUTIONS
nDo not operate your new Celebrity for the first time without completely reading and understanding this owners
manual.
nDo not carry passengers on your Celebrity.
nDo not leave the key in the key switch when your Celebrity is unattended.
nMake certain that the seat is locked into place and the key is removed from the key switch before mounting or
dismounting your Celebrity. Also make certain that the seat is in a locked position when you operate your
Celebrity.
nReduce your Celebritys speed when driving on uneven terrain and soft surfaces.
nReduce your Celebritys speed when cornering.
nNever drive your Celebrity across the side of a hill or diagonally up or down a hill, and do not stop, if possible,
while driving up or down an incline.
nProceed with extreme caution when driving near raised surfaces, unprotected ledges and drop offs (curbs,
porches, stairs, etc.).
nNever remove your Celebritys anti-tip wheels or modify the Celebrity in any way not authorized by Pride.
nUse extreme caution when operating your Celebrity on busy streets and in parking lots or shopping malls and
never ride your Celebrity where you cannot walk safely and legally. Consult local authorities with regard to
operating your Celebrity on public roadways.
nDo not operate your Celebrity while you are under the influence of alcohol.
nCheck with your physician if you are taking any medications that may affect your ability to operate your
Celebrity safely.
nKeep your hands on the tiller and your feet on the floorboard when you are operating your Celebrity.
nMake certain that the tyres are properly inflated (30 psi).
nNever use your Celebrity as a seat in a moving vehicle.
nMake certain that the Celebritys batteries are properly secured when you transport your Scooter in another
vehicle.
nDisconnect your Celebritys batteries if you will not be using the Scooter for more than 48 hours.
WARNING! Battery posts, terminals, and related accessories contain lead and lead compounds.
Wash hands after handling.
WARNING! Do not expose the electronics to any type of moisture at any time (rain, snow, mist, or
washing the Scooter). Such exposure can damage the electronics. Never attempt to ride a Scooter
that has been exposed to moisture until it has dried.
WARNING! Do not operate or store the Scooter where it may be exposed to inclement weather
conditions such as rain, snow, mist, and below-freezing temperatures (such as storage on an
outside car or van lift). Attempting to operate the Scooter in such conditions can damage the
electronics and potentially result in loss of control.
WARNING! Do not operate a Scooter in icy or slippery conditions or on salted surfaces (i.e.,
pavement or roads). Such use may result in an accident, personal injury, or adversely affect the
performance and/or safety of your Scooter.
WARNING! Always protect batteries from freezing temperatures and never charge a frozen battery.
his damages the battery and may cause personal injury. Attempting to charge a battery in
freezing conditions does not prevent a battery from freezing.

7
Celebrity
II. SAFETY
As you begin using your Celebrity during daily activities, you will probably encounter situations for which you will
need some practice negotiating on your Scooter. Simply take your time as you operate your Celebrity and you will
soon be in full and confident control as you maneuver through doorways, on and off elevators, up and down ramps,
and over moderate terrain.
DOORS
nDetermine if the door opens toward or away from you.
nUse your hand to turn the knob or push the handle or push-bar.
nDrive your Celebrity gently and slowly forward to push the door open. Or drive your Celebrity gently and
slowly backwards to pull the door open.
ELEVATORS
Modern elevators have a door edge safety mechanism that, when pushed, reopens the elevator door(s).
nIf you are in the doorway of an elevator when the door(s) begin to close, push on the rubber door edge or
allow the rubber door edge to contact the Scooter and the door will reopen.
nUse care that pocketbooks, packages, or Celebrity accessories do not become caught in elevator doors.
RAMPS AND OTHER INCLINES
More and more buildings have ramps with specified degrees of inclination. These ramps are designed for easy and
safe Scooter access. Some ramps may have turning switchbacks that require good cornering skills on your Celeb-
rity.
nTake wide swings with your Celebritys front wheel(s) around any tight corners. If you do that, the Celebritys
rear wheels will follow a wide arc, not cut the corner short, and not bump into or get hung up on any railing
corners.
nWhen driving down a ramp, keep the Celebritys speed adjustment dial set to the tortoise (slowest speed
setting) to ensure a safely controlled descent. See IV. Description.
nAvoid sudden stops and starts.
14.1%
68 kg 90 kg 113 kg 136-158 kg
68 kg 90 kg 113 kg 136-158 kg
12.3% 10.5% 8.7%
15.8% 14.1% 12.3% 10.5%
FIGURE 2. MAXIMUM RECOMMENDED INCLINE ANGLE 4 WHEEL
FIGURE 1. MAXIMUM RECOMMENDED INCLINE ANGLE 3 WHEEL

8Celebrity
II. SAFETY
DRIVING SURFACES
Your Celebrity was designed to provide optimum stability under normal driving conditionsdry, level surfaces
composed of concrete or asphalt. However, Pride recognizes that there will be times when you will operate your
Celebrity on surfaces other than concrete or asphalt. For that reason, we also designed your Celebrity to perform
admirably on packed soil, grass, and gravel. Feel free to use your Celebrity safely on grounds and in park areas.
nAvoid tall grass that can become entangled in the running gear.
nPacked soil, gravel, driveways, or roads will not present a problem for your Celebrity.
nAvoid loosely packed gravel and sand.
nIf you feel unsure about a driving surface, avoid that surface.
DRIVING IN REVERSE
Before driving in reverse always check that your path is free of hazards such as curbs such as pedestrians, etc.
Other inclines may be natural or man-made, and not designed specifically for Scooters. Figures 1 and 2 illustrate
your Celebritys stability and its ability to climb grades under various weight loads and under controlled testing
conditions.
These tests were conducted with the Celebritys seat in the highest position and adjusted backward on the seat
base to its farthest rearward position. Use this information as a guideline. Your Celebritys ability to travel up
inclines is affected by your weight, your Scooters speed, your angle of approach to the incline, and your Scooter
setup.
nWhen you approach an incline, it is best to lean forward. See figures 3 and 4. This shifts the center of gravity
of you and your Celebrity toward the front of the Scooter for improved stability.
WARNING! Do not exceed the incline guidelines or any other specifications presented in this
owners manual.
FIGURE 4. INCREASED STABILITY DRIVING POSITION
FIGURE 3. NORMAL DRIVING POSITION

Celebrity
III. SPECIFICATIONS
61 cm
162,5 cm
122 cm
46 cm
41 cm
61 cm- 71 cm
127 cm
127, 5 cm
4 Wheel Turning Radius
4 Wheel Length
3 Wheel Length
3 Wheel Turning Radius
9 cm
90˚;100˚
102˚;105˚
47 cm
Adjustable
20 cm- 30,5 cm
100 cm- 109 cm
43 cm - 52 cm
FIGURE 5. CELEBRITY DIMENSIONS

10 Celebrity
III. SPECIFICATIONS
Model Numbers Three-wheel: SC4000AUSCRED (Candy Apple Red), SC4000AUSVBLU (Viper Blue), SC4000AUSFGRE
(Forest Green), SC4000AUSOBLK (Onyx Black),
Four-wheel: SC4400AUSCRED, SC4400AUSVBLU, SC4400AUSFGRE, SC4400AUSOBLK
Length 127 cm (3 wheel), 130 cm (4 wheel)
Width 61 cm
Tires Type: Pneumatic; Front: 8 cm x 25,5; Rear: 10 cm x 25,5 cm
Weight Capacity 158 kg maximum
Battery Type Two 12-volt, 32 AH, U-1 type, SLA (sealed lead-acid) or two 12 volt, 40 AH, SLA
Horsepower 1.4 hp (peak)
Charger Onboard 3-amp charger
Speed (max) Variable up to 8.4 kmh
Maximum Grade Variable (refer to figures 1 and 2)
Range, Maximum (12V 40 AH batteries) Up to 32-49 km
(12V 32 AH batteries) Up to 32-40 km
Turning Radius 3 wheel: 122 cm; 4 wheel: 162,5 cm
Body Colors Painted: Candy Apple Red, Viper Blue, Forest Green, and Onyx Black
Seating Standard Option Seating Style: Medium-back luxury contoured seat
Standard Seating Features:
•Adjustable armrest height, width, and angle
•Four adjustable seat-back angles
Dimensions: 46 cm width x 41 cm depth (usable) x 47 cm height (usable)
Material: Vinyl: Grey, Beige, Black
Fabric: Grey, Gold
Armrests: Upholstered, matching vinyl or fabric with cosmetic edge guards
Adjustable seatpost height from ground: variable between 58,5 cm to 65 cm
Included Features Full directional lighting package with front “running lights”; deluxe motorcycle-style rearview mirror (can be
installed on left or right side of tiller); lighted touch pad control console; front basket; four position adjustable
seat-back angle; adjustable armrest width, height & angle; dual microprocessor-based motor controller
system; modular controller/charger assembly; infinitely adjustable tiller with auto-leveling console and shock
dampening action; standard front & rear integrated bumpers; easily accessible charger port receptacle,
circuit breaker and freewheel lever; standard non-marring, high density polyurethane bumper(s); battery well
accepts 32 AH or 40 AH batteries; standard battery fixation straps
Brakes Electronic disc, manual freewheel
Rear Wheel Drive Sealed Transaxle - 24V
Wheels Pride Micro-Mag aluminum alloy wheels in red/black/or gold
Tiller Type Infinitely adjustable with auto-leveling console
Freewheel Mechanism Availability Lever at lower right portion of rear shroud
Weight of Scooter TOTAL Weight of Celebrity (with two 12V 40AH batteries) = 96 kg (3 wheel); 103 kg (4 wheel)
TOTAL Weight of Celebrity (with two 12V 32AH batteries) = 90 kg (3 wheel); 97 kg (4 wheel)
Component breakdown:
Front section: 20,5 kg (3 wheel), 28 kg (4 wheel)
Rear section (without batteries or rear shroud): 29 kg
Rear plastic shroud: 1,8 kg
Seat (Med-back: 11 kg
Batteries: (note: two batteries are required per Scooter) 12V, 40 AH 14 kg (each)
12V, 32 AH 11 kg (each)
Basket: ,6 kg
Front-to-Rear Lockup Dual lock pins & camlock levers
Ground Clearance 9 cm
Accessories Rear basket; cup holder; portable canopy; safety flag; solid foam filled tires; cane/crutch holder; walker
holder; dust cover; weather breaker canopy; oxygen tank holder

11
Celebrity
FIGURE 6. CELEBRITY COMPONENTS
BATTERIES
REAR SECTION
FRONT SECTION SEAT
REAR SHROUD
BASKET
IV. DESCRIPTION
CONTROL CONSOLE ASSEMBLY
The control console assembly houses all of the controls you need to drive your Celebrity, including the speed adjustment
dial, throttle control levers, battery condition meter, status LED, running lights button, horn buttons, turn signal buttons,
and the hazard light button. See figure 7.
WARNING! Do not expose the control console assembly to moisture. In the event that the console
does become exposed to moisture, do not attempt to operate your Celebrity until the console has
thorou hly dried.
FIGURE 7. CONTROL CONSOLE ASSEMBLY
BATTERY CONDITION METER
HORN
BUTTON
SPEED ADJUSTMENT DIAL
THROTTLE CONTROL LEVER (REVERSE)
HORN
BUTTON
HAZARD LIGHT BUTTON
LEFT TURN SIGNAL BUTTON
RUNNING LIGHTS BUTTON
RIGHT TURN SIGNAL BUTTON
THROTTLE CONTROL LEVER (FORWARD)
STATUS LED
Your Celebrity is a motorized electric Scooter designed to enhance your personal mobility. Your Celebrity is an indoor/
outdoor Scooter designed to travel primarily on smooth surfaces, such as pavement, roads, parking lots, floors, and
driveways. For easy transportation or storage, you can disassemble your Celebrity into seven components. See figure 6.

12 Celebrity
IV. DESCRIPTION
Key Switch
nFully insert the key into the key switch and turn it clockwise to power up (turn on) your Celebrity.
nTurn the key counterclockwise to power down (turn off) your Celebrity.
Speed Adjustment Dial
This control dial allows you to preselect and limit your scooters top speed.
nThe image of the tortoise represents the slowest speed setting.
nThe image of the hare represents the fastest speed setting.
Th ottle Cont ol Leve
This lever allows you to control the forward speed and the reverse speed of your Celebrity up to the maximum
speed you preset with the speed adjustment dial.
nPlace your right hand on the right handgrip and your left hand on the left handgrip.
nUse your right thumb to push the right side of the lever to disengage your Celebritys brakes and move
forward.
nRelease the lever and allow your Celebrity to come to a complete stop before pushing the other side of the
lever to move in reverse.
nWhen the throttle is completely released, it automatically returns to the center stop position and engages your
Celebritys brakes.
Batte y Condition Mete
This meter gives an approximate reading of your scooters battery voltage when the key is fully inserted into the
key switch.
nGreen indicates the Celebritys batteries are fully charged.
nYellow indicates that the Celebritys battery voltage level is getting low and will require a charge soon.
nRed indicates that your Celebritys battery voltage level is very low, and the batteries should be recharged as
soon as possible.
Running Lights Button
This button controls your Celebritys running lights.
nPress the button once to turn on your Celebritys running lights.
nPress the button again to turn off your Celebritys running lights.
Ho n Button
The key must be inserted and turned to the on position for the horn to be operational.
nThis button activates a warning horn.
nDo not hesitate to use the warning horn when its use could prevent accident or injury.
Haza d Light Button
This button activates the 4-way flashers on your Scooter.
nPress the button once to turn on the flashers.
nPress the button again to turn off the flashers.
WARNING! If the key is moved to the off position while your Celebrity is in motion, the electronic
brakes en a e and your Celebrity comes to an abrupt stop!

13
Celebrity
IV. DESCRIPTION
Tu n Signal Buttons
nPress the appropriate turn signal button once to activate it.
nYour Celebritys turn signals are timed to shut off automatically.
Status LED
The Status LED will alert you to electrical problems that may occur with the Celebrity. The LED remains constantly lit
while your scooter is on. If the Celebrity develops an electrical problem, the status LED will flash a code. See XI. Basic
Troubleshooting), If the status LED flashes a code other than a code listed in Basic Troubleshooting, contact your
authorised Pride Provider.

14 Celebrity
IV. DESCRIPTION
LIGHT COVER
FIGURE 8. REAR SECTION (LEFT LIGHT COVER REMOVED FOR CLARITY)
AMMETER MAIN CIRCUIT BREAKER (RESET BUTTON)
CHARGER POWER LEAD STORAGE COMPARTMENT
CHARGER POWER LEAD RECEPTACLE
TURN SIGNAL
LIGHT BULB
ANTI-TIP WHEEL
MANUAL FREEWHEEL LEVER
RUNNING LIGHT FUSE
RUNNING LIGHT LIGHT BULB
ELECTRONICS
MODULE
FUSES
TURN SIGNAL FUSE
Batteries
The batteries store the electrical energy that powers your Celebrity. See V. Batteries and Charging.
Main Circuit Breaker
When the voltage in your Celebritys batteries becomes low or your Celebrity is heavily strained because of
excessive loads or steep inclines, the main circuit breaker may trip to protect your Celebritys motor and electron-
ics from damage.
nThe main circuit breaker reset button pops out when the breaker trips. See figure 8.
nWhen the breaker trips, the entire electrical system of your Celebrity shuts down.
nAllow a minute or two for your Celebritys electronics to rest.
nPush in the reset button to reset the breaker.
nIf the breaker trips frequently, you may need to charge your batteries more often. You may also need to have
your authorized Pride provider perform a load test on your Celebritys batteries.
nIf the main circuit breaker trips repeatedly, see your authorized Pride provider for service.
REAR SECTION
The onboard battery charger (not shown), the charger power lead receptacle, the batteries (not shown), the
electronics module, the main circuit breaker (reset button), the ammeter, the manual freewheel lever, the anti-tip
wheels, and the motor/transaxle assembly (not shown) are located on the rear section of your Celebrity. See figure
8. Refer to VIII. Disassembly and Assembly for instructions on removing the rear shroud, which covers the rear
section.

15
Celebrity
WARNING! Before placin your Celebrity into or takin it out of freewheel mode, make certain that
the key is removed from the key switch. Even thou h the motor of your Celebrity is disen a ed
from the drive system when your Scooter is put in manual freewheel mode, the motor can still run
if the throttle lever is pushed. Never sit on a Scooter when it is in freewheel mode. Never put a
Scooter in freewheel mode on any incline.
FIGURE 9. WORKING FUSE FIGURE 0. BLOWN FUSE (REPLACE)
WARNING! Failure to use properly rated fuses may cause dama e to the Celebritys electrical
system, and may result in personal injury.
IV. DESCRIPTION
Manual F eewheel Leve
Whenever you need or want to push your Celebrity for short distances, you can put it in manual freewheel mode.
nThe manual freewheel lever is located on the end of the motor/transaxle assembly at the right rear of the
Celebrity. See figure 8.
nPull up on the manual freewheel lever to disable the drive and brake systems.
nYou may now push your Celebrity.
nPush down on the manual freewheel lever to reengage the drive and brake systems, and take your Celebrity
out of freewheel mode.
Moto /T ansaxle Assembly
The motor/transaxle assembly is an electromechanical unit that converts electrical energy from your Celebritys
batteries into the controlled mechanical energy that drives the Celebritys wheels.
Anti-Tip Wheels
The anti-tip wheels are an integral and important safety feature of your Celebrity. Do not, under any circumstances,
remove the anti-tip wheels from your Celebrity. See figure 8.
Cha ge Powe Lead Receptacle
The charger power lead plugs into your Celebritys battery charger by means of the charger power lead recep-
tacle.
Fuses
The fuses help protect your Celebritys lighting, control console assembly, and charging systems from receiving an
overload of electrical current. The fuses used in the Celebrity are the same type automobiles use. See figure 8.
If a fuse must be replaced, use only the specified amp fuse. See XI. Care and Maintenance.

16 Celebrity
V. BATTERIES AND CHARGING
Your Celebrity uses two long-lasting, 12-volt, deep-cycle batteries that are sealed and maintenance free. They are
recharged by an onboard 3-amp charging system designed for ease of use and convenience.
nCharge your Celebritys batteries prior to using it for the first time.
nKeep your batteries fully charged to keep your Celebrity running trouble-free.
Follow these easy steps to charge your batteries safely:
1. Position your Scooter close to a standard wall outlet.
2. Remove the key from the control console assembly.
3. Make certain that the freewheel lever is in the drive (down) position.
4. Plug the charger power lead into the charger power lead receptacle on the Scooter.
5. Extend the charger power lead and plug it into the wall outlet.
NOTE: There is a charger inhibit function on your Scooter. The Scooter will not run and the battery
Condition meter will not operate while the batteries are charging.
It is recommended that you charge your batteries for 8 to 14 hours. You can check this periodically by the battery
condition meter on the control console assembly. However, you must first unplug the battery charger and then
insert the key. The battery condition meter on the control console assembly indicates the approximate strength of
your batteries. See figure 11.
nGreen indicates the Celebritys batteries are fully charged.
nYellow indicates that the Celebritys battery voltage level is getting low and will require a charge soon.
nRed indicates that your Celebritys battery voltage level is very low, and the batteries should be recharged as
soon as possible.
You can also check the charge by the ammeter which is visible on the rear electronics module. The battery charger
must be plugged into a wall outlet to obtain a reading. When the amperage reading is at or near zero (0) amps, the
battery charging is complete. See figure 12.
6. When the batteries are fully charged, unplug the charger power lead from the wall outlet and then from the
charger power lead receptacle.
7. Place the charger power lead in the rear storage compartment for safekeeping.
FIGURE 2. AMMETER INDICATES BATTERY IS
FULLY CHARGED
FIGURE . BATTERY CONDITION METER
WARNING! Never use an extension lead to plu in your battery char er. Plu the char er directly
into a properly wired standard wall outlet.

17
Celebrity
BATTERIES AND CHARGING - FREQUENTLY ASKED QUESTIONS (FAQS)
How does the charger work?
When your Celebritys battery voltage is low, the charger works harder sending more electrical current to the
batteries to bring up their charge. As the batteries approach full charge, the charger sends less and less electrical
current. When the batteries are fully charged, the current sent from the charger is at nearly zero amperage. There-
fore, when the charger is plugged in, it maintains the charge on your Celebritys batteries, but does not overcharge
them. We do not recommend that you charge your Celebritys batteries for more than 24 consecutive hours.
What if the Celebritys batteries wont charge?
nEnsure that the battery cables are connected properly.
nEnsure that both ends of the charger lead are inserted fully.
nExamine the 5-amp charger fuse. If the fuse is blown, the batteries will not charge. See figures and 10.
Can I use a different charger?
For the safest, most efficient and balanced charging of your Celebritys batteries, we prefer and highly recommend
the simultaneous charging of both batteries with the onboard battery charger.
How often must I charge the batteries?
Two major factors must be considered when deciding how often to charge your Celebritys batteries:
nAll day Scooter use on a daily basis.
nInfrequent or sporadic Scooter use.
With these considerations in mind, you can determine just how often and for how long you should charge your
Celebritys batteries. We designed the onboard charger so that it will not overcharge your Scooters batteries (do
not charge them for more than 24 consecutive hours). However, you may encounter some problems if you do not
charge your batteries often enough and if you do not charge them on a regular basis. Following the five guidelines
below will provide safe and reliable battery operation and charging.
nIf you use your Celebrity daily, charge its batteries as soon as you finish using it for the day. Your Celebrity will be
ready each morning to give you a full day of service. We recommend that you charge your Celebritys batteries for 8
to 14 hours after daily use.
nIf you use your Celebrity once a week or less, charge its batteries at least once a week for 12 to 14 hours at a time.
nKeep your Celebritys batteries fully charged.
nAvoid deeply discharging your Celebritys batteries.
nDo not charge your Celebritys batteries for more than 24 consecutive hours.
V. BATTERIES AND CHARGING

18 Celebrity
How can I get maximum range or distance per charge?
Rarely will you have ideal driving conditionssmooth, flat, hard driving surfaces with no wind or curves. Often, you
will face hills, pavement cracks, uneven and loosely packed surfaces, curves, and wind. All of these driving conditions
affect the distance or running time per battery charge. Below are a few suggestions for obtaining the maximum range
per battery charge.
nAlways fully charge your elebritys batteries prior to your daily use.
nMaintain 30 psi (pounds per square inch) in all of your elebritys tyres.
nPlan your route to avoid as many hills, cracked, broken, or soft surfaces as possible.
nLimit your baggage weight to essential items.
nTry to maintain an even speed while your elebrity is in motion.
nAvoid stop-and-go driving.
What type and size of battery should I use?
We recommend deep-cycle batteries that are sealed and maintenance free. Both sealed lead-acid and gel cell are
deep-cycle batteries that are similar in performance. Do not use wet-cell batteries, which have removable caps.
CAUTION! Do not remove the caps from sealed batteries. Water cannot be added to sealed batter-
ies. Cap removal voids the battery warranty and may cause dama e to the batteries and to your
Celebrity.
Use these specifications to reorder deep-cycle batteries:
Type: Deep-cycle (sealed lead-acid or gel cell)
Size: U-1 (32 AH only), 40 AH
Voltage: 12-volts each
Amperage: 32 AH or 40 AH (amp hours)
To replace a battery in your elebrity:
1. Remove the seat and the rear shroud. See VIII. Disassembly and Assembly.
2. Disconnect the battery tie-down straps (if equipped).
3. Disconnect the battery cables from the rear electronics module.
4. Disconnect the battery cables from the battery terminals.
5. Remove the old battery.
6. Place a new battery in the battery well.
7. onnect the red battery cable to the positive (+) battery terminal.
8. onnect the black battery cable to the negative (-) battery terminal.
9. Reconnect the battery cables to the rear electronics module.
10. Reconnect the battery tie-down straps (if equipped).
11. Refit the rear shroud and the seat.
Why do my new batteries seem weak?
Deep-cycle batteries employ a different chemical technology than that used in car batteries, nickel-cadmium batteries
(nicads), or in other common battery types. Deep-cycle batteries are specifically designed to provide power, drain
down their charge, and then accept a relatively quick recharge.
V. BATTERIES AND CHARGING
WARNING! Battery posts, terminals, and related accessories contain lead and lead compounds.
Wash hands after handlin .

1
Celebrity
We work closely with our battery manufacturer to provide batteries that best suit your elebritys specific electrical
demands. Fresh batteries arrive daily at Pride and are shipped fully charged to our customers. During shipping, the
batteries may encounter temperature extremes that can influence their initial performance. Heat diminishes the
charge on the battery; cold slows the available power and extends the time needed to recharge the battery.
It may take a few days for the temperature of your elebritys batteries to stabilize and adjust to their new room or
ambient temperature.
More importantly, it takes a few charging cycles ( partial draining followed by a full recharging) to establish the critical
chemical balance that is essential to a deep-cycle batterys peak performance and long life.
Please follow these steps to properly break-in your elebritys new batteries for maximum efficiency and service life.
1. Fully recharge any new battery prior to its initial use. This charging cycle brings the battery up to about 88% of
its peak performance level.
2. Fully recharge the batteries. They should be at over 0% of their peak performance level.
3. Operate your Celebrity again.
4. Fully recharge the batteries again.
5. After four or five charging cycles, the batteries are able to receive a charge of 100% of their peak performance
level and are able to last for an extended period of time.
How can I ensure maximum battery life?
Fully charged deep-cycle batteries provide reliable performance and extended battery life. Keep your elebritys
batteries fully charged whenever possible. Batteries that are regularly and deeply discharged, infrequently charged,
or stored without a full charge may be permanently damaged, causing unreliable performance and limited service life.
How should I store my Celebrity and its batteries?
If you plan on not using your elebrity for an extended period of time, it is best to:
nFully charge its batteries prior to storage.
nDisconnect the battery harnesses from the rear electronics module.
nStore your elebrity in a warm dry environment.
nAvoid storing your elebrity where it will be exposed to temperature extremes.
V. BATTERIES AND CHARGING
WARNING! If your Celebritys batteries do become frozen, do not attempt to char e them. Cold or
frozen batteries should be allowed to warm up for several days prior to rechar in .
For prolonged storage, you may wish to place several boards under the frame of your elebrity to raise the Scooter
off of the ground. This takes the weight off the tyres and reduces the possibility of flat spots developing on the areas
of the tyres contacting the ground.
What about public transportation?
If you intend to use public transportation with your Scooter, you must contact in advance the transportation provider
in advance to determine their specific requirements.

20 Celebrity
VI. OPERATION
BEFORE GETTING ON YOUR CELEBRITY
nHave you fully charged the batteries? See V. Batteries and Charging.
nIs the manual freewheel lever in the drive (down) position? Never leave the manual freewheel lever pulled up
unless you are manually pushing your Celebrity.
GETTING ON YOUR CELEBRITY
1. Make certain that the key is removed from the key switch.
2. Stand at the side of your Celebrity.
3. Push down on the seat lock lever and rotate the seat until it is facing you.
4. Make certain that the seat is locked securely in position.
5. Position yourself comfortably and securely in the seat.
6. Fasten the lap belt, if your Celebrity is so equipped.
7. Push down on the seat lock lever and rotate the seat until you are facing forward.
8. Make certain that the seat is locked securely in position.
. Make certain that your feet are safely on the floorboard.
PRE-RIDE ADJUSTMENTS AND CHECKS
nAre you positioned comfortably in the seat? See Getting On Your Celebrity, above.
nIs the seat at the proper height? See VII.  Comfort Adjustments.
nIs the seat locked securely in place? See VII. Comfort Adjustments.
nIs the tiller handle at a comfortable setting and locked securely in place? See VII. Comfort Adjustments.
nIs the key fully inserted into the key switch and in the on position? See IV. Description.
nIs the speed adjustment set to a slow setting? See IV. Description.
nAre you grasping the handgrips with a thumb resting on each side of the throttle control lever? See IV.
Description.
nDoes your Celebritys horn work properly?
nIs your proposed path clear of people, pets, and obstacles?
nHave you planned your route to avoid adverse terrain and as many inclines as possible?
OPERATING YOUR CELEBRITY
After planning your route:
nAdjust the speed adjustment dial on the control console assembly to preset your desired maximum speed.
nPress your thumb against the appropriate throttle lever.
nThe electric brake automatically disengages and the Celebrity accelerates smoothly to the speed you preselected
with the speed adjustment dial.
NOTE: The rear wheel drive transaxle gives your Celebrity maximum traction with minimal steering
effort on your part.
