  9. Prilux Versa LED User manual

Prilux Versa LED User manual

1/8 julio 2021
ÑE
Versa LED
[GRÁFICOS: Unidades en mm/ GRAPHICS: Units in mm/GRAPHIQUES: Unités en mm/GRÁFICOS: Unidades em mm]
Especicaciones/ Specications
Aislamiento eléctrico/
Electrical isolation
CI
Índice de estanqueidad/
Sealing rating IP66
Protección contra impactos/
Impact resistance IK08
Nº LED/
LED Number 12 LED 24 LED
Peso/
Weight 4kg
Altura Máx. de instalación/
Sealing rating 20m
Máx. sup. proyectada al aire/
Maximum surface wind exposed
0,124m2
540
230112
Manual instrucciones
Instruction manual
2/8
AVISO
ANTES DE COMENZAR LA INSTALACIÓN DE ÉSTE PRODUCTO,
POR FAVOR, LEA ATENTAMENTE LAS INSTRUCCIONES Y
GUÁRDELAS EN UN SITIO SEGURO.
LA INSTALACIÓN DEBE REALIZARLA PERSONAL
CUALIFICADO.
LA INADECUADA MANIPULACIÓN DE LOS COMPONENTES
O DE LA PROPIA LUMINARIA PODRÍA DAÑAR EL CORRECTO
FUNCIONAMIENTO DE ESTE PRODUCTO, QUEDANDO ANULADA
LA GARANTÍA DEL FABRICANTE.
QUEDA ANULADA LA GARANTÍA DEL FABRICANTE: SI LA
INSTALACIÓN NO SE REALIZA SEGÚN LO INDICADO EN EL REBT
2002.
ES DE OBLIGADO CUMPLIMIENTO LA APLICACIÓN DE ITC BT09-
4 DEL REBT (INSTALACIÓN DE PROTECTORES DE SOBRETENSIONES
EN LÍNEAS Y LUMINARIAS) PARA INSTALACIONES INDUSTRIALES
Y DE ALUMBRADO PÚBLICO. LA GARANTÍA NO CUBRE DAÑOS
PRODUCIDOS POR SOBRETENSIONES EN LUMINARIAS SIN
PROTECTORES DE SOBRETENSIONES.
RESPETAR LAS PRECAUCIONES
DE MANIPULACIÓN DE LOS
COMPONENTES SENSIBLES A
DESCARGAS ELECTROSTÁTICAS
(LED).
PRECAUCIONES:
• Mantenga el producto fuera del alcance de los niños.
• No sumerja este producto en agua ni lo manipule con las manos mojadas.
• No golpee el producto.
• No instale el producto donde haya fuentes de calor o concentraciones
de humedad.
• No manipule el producto mientras se encuentre en funcionamiento y
déjelo enfriar antes de tocarlo con las manos.
• El producto no debe ser cubierto por material aislante térmico en ningún
caso.
• Mantenga una distancia mínima de 1m con la supercie u objeto a
iluminar.
• Si el producto se encuentra dañado sustitúyalo inmediatamente por uno
nuevo.
• Desconecte la corriente antes de instalar el producto.
• Este producto contiene componentes sensibles a la electricidad estática y
una descarga sobre ella podría destruir o dañar sus componentes.
• Antes de proceder a cualquier manipulación o mantenimiento hay que
asegurarse de que el aparato esté completamente desconectado del
suministro eléctrico.
• La reposición o mantenimiento de cualquier componente deberá hacerse
con idénticos elementos recomendados y suministrados por el propio
fabricante. De no ser así, cualquier incidencia en una instalación que
no se haya realizado de acuerdo con esta hoja de instrucciones será
responsabilidad del instalador.
• La fuente de luz de esta luminaria debe reemplazarse unicamente por el
fabricante, su servicio técnico o persona cualicada equivalente.
• La luminaria debe colocarse de forma que no se espera una mirada
prolongada a la luminaria a una distancia más cercana a 1m.
PRECAUTIONS:
• Keep the product out of the reach of children.
• Do not immerse this product in water or handle it with wet hands.
• Do not hit the product.
• Do not install the product where there are heat sources or moisture
concentrations.
• Do not handle the product while it is in operation and allow it to cool before
touching it with your hands.
• The product must not be covered with thermal insulation material under
any circumstances.
• Maintain a minimum distance of 1m from the surface or object to be
illuminated.
• If the product is damaged, replace it immediately with a new one.
• Disconnect power before installing the product.
• This product contains components sensitive to static electricity and a
discharge to it could destroy or damage its components.
• Before carrying out any work or maintenance, make sure that the device is
completely disconnected from the power supply.
• The replacement or maintenance of any component must be carried
out with the same elements recommended and supplied by the
manufacturer himself. If this is not the case, any incident on an installation
that has not been carried out in accordance with this instruction sheet is
the responsibility of the installer.
• The light source of this luminaire must be replaced only by the manufacturer,
its technical service or equivalent qualied person.
• The luminaire must be positioned so that a prolonged look is not expected
at the luminaire at a distance closer to 1m.
WARNING
BEFORE INSTALLING THIS PRODUCT, PLEASE READ THE
INSTRUCTIONS CAREFULLY AND STORE THEM IN A SAFE PLACE.
THE INSTALLATION SHOULD BE CARRIED OUT BY TRAINED STAFF.
INCORRECT HANDLING OF THE PARTS OR THE LIGHT FIXTURE ITSELF
MAY IMPAIR THE PROPER PERFORMANCE OF THIS PRODUCT. IN
THIS CASE, THE MANUFACTURER GUARANTEE SHALL BE DEEMED
VOID.
THE MANUFACTURER GUARANTEE SHALL BE DEEMED VOID: IF THE
INSTALLATION IS NOT PERFORMED IN ACCORDANCE WITH THE
SPANISH LOW VOLTAGE ELECTROTECHNICAL REGULATION 2002
(REBT 2002).
THE APPLICATION OF IBC BT09-4 OF REBT (INSTALLATION OF
LINE AND LIGHT FIXTURE SURGE PROTECTORS) IS ESSENTIAL
FOR INDUSTRIAL AND PUBLIC LIGHTING INSTALLATIONS. THE
GUARANTEE DOES NOT COVER AGAINST DAMAGES CAUSED
BY SURGES IN LIGHT FIXTURES WITHOUT SURGE PROTECTORS
INSTALLED.
ATTENTION!!!
OBSERVE PRECAUTIONS FOR
HANDLING ELECTROSTATIC
SENSITIVE DEVICES.
3/8
MONTAJE BÁCULO/ POLE MOUNTING
Giro/Turn
10º -10º
4/8
8Nm máx.
Vidrio templado 4mm/
4mm tempered glass
10Nm máx.
Ø60mm máx.
220-240 50-60Hz
5/8
MONTAJE POSTE/ POST MOUNTING
1
2
Giro/Turn
10º
-10º
6/8
8Nm máx.
10Nm máx.
220-240 50-60Hz
Ø60mm máx.
La luminaria puede conectarse a la red eléctrica a través de
bloque de conexión estanco IP68 5p,
Código:239394
The luminaire can be connected to the mains via a water-
tight connection block IP68 5p,
Code:239394
*
NO INCLUIDO
/NOT INCLUDED
*
Ver esquema de electricación/
See electrication diagram
7/8
SALIDA FIJA/
FIXED OUTPUT
AZUL/BLUE N
MARRÓN/BROWN L
NEGRO/BLACK -
GRIS/GRAY -
VERDE/AMARILLO
GREEN/YELLOW
ESQUEMA DE ELECTRIFICACIÓN/ ELECTRIFICATION DIAGRAM
8/8
www.grupoprilux.com
FP
Versa LED
[GRÁFICOS: Unidades en mm/ GRAPHICS: Units in mm/GRAPHIQUES: Unités en mm/GRÁFICOS: Unidades em mm]
1/8 julio 2021
540
230112
Manuel d’instructions
Manual de instruções
Spécications/ Especicações
Isolation électrique/
Isolamento elétrico
CI
Indice d’étanchéité/
Índice de estanquicidade IP66
Protection contre les chocs/
Proteção contra impactos IK08
Nb LED/
Nº LED 12 LED 24 LED
Poids/
Peso 4kg
Hauteur d’installation max./
Altura máx. de instalação
20m
Surface max. exposée au vent/
Máx. sup. projetada ao ar
0,124m2
2/8
PRÉCAUTIONS :
• Tenir le produit hors de portée des enfants.
• Ne pas immerger ce produit dans l’eau ou le manipuler avec les mains
mouillées.
• Ne pas cogner le produit.
• Ne pas installer le produit dans un endroit où il y a des sources de chaleur
ou des concentrations d’humidité.
• Ne pas manipuler le produit pendant son fonctionnement et le laisser
refroidir avant de le toucher avec vos mains.
• Le produit ne doit en aucun cas être recouvert d’un matériau d’isolation
thermique.
• Garder une distance minimale d’1m avec la surface ou l’objet à éclairer.
• Si le produit est endommagé, le remplacer immédiatement par un
nouveau.
• Couper l’alimentation avant d’installer le produit.
• Ce produit contient des composants sensibles à l’électricité statique et une
décharge électrique pourrait détruire ou endommager les composants.
• Avant d’effectuer toute manipulation ou entretien, s’assurer que l’appareil
est complètement débranché de l’alimentation électrique.
• Le remplacement ou l’entretien de tout composant devra être effectué
avec des éléments identiques recommandés et fournis par le fabricant.
Dans le cas contraire, tout incident sur une installation qui n’a pas
été réalisée conformément à cette che d’instructions relève de la
responsabilité de l’installateur.
• La source lumineuse de ce luminaire doit être remplacée uniquement par
le fabricant, son service technique ou une personne qualiée équivalente.
• Le luminaire doit être positionné de sorte à éviter toute xation du regard
prolongée sur le luminaire à une distance inférieure à 1 mètre.
PRECAUÇÕES:
• Manter o produto fora do alcance das crianças.
• Não mergulhar este produto em água, nem o manipular com as mãos
molhadas.
• Não golpear o produto.
• Não instalar o produto onde houver fontes de calor ou concentrações de
humidade.
• Não manipular o produto enquanto este se encontrar em funcionamento
e deixar arrefecer antes de tocar com as mãos.
• O produto nunca deverá ser coberto por material isolador térmico.
• Manter uma distância mínima de 1m em relação à superfície ou objeto
a iluminar.
• Se o produto se encontrar danicado, substituir imediatamente por um
novo.
• Desligar a corrente antes de instalar o produto.
• Este produto contém componentes sensíveis à eletricidade estática e
uma descarga sobre o mesmo poderia destruir ou danicar os seus
componentes.
• Antes de proceder a qualquer manipulação ou manutenção, há que
certicar-se de que o aparelho está completamente desligado da
corrente elétrica.
• A reposição ou manutenção de qualquer componente deverá ser
realizada com idênticos elementos recomendados e fornecidos pelo
próprio fabricante. Caso contrário, qualquer incidência numa instalação
que não tenha sido realizada de acordo com esta folha de instruções
será da responsabilidade do instalador.
• A fonte de luz desta luminária deve ser substituída apenas pelo fabricante,
pelo seu serviço técnico ou por uma pessoa qualicada equivalente.
• A luminária deve ser colocada de forma que não se espere uma visão
prolongada para a luminária a uma distância mais próxima a 1m.
AVERTISSEMENT
AVANT DE COMMENCER L’INSTALLATION DE CE PRODUIT,
VEUILLEZ LIRE ATTENTIVEMENT LES INSTRUCTIONS ET LES
CONSERVER DANS UN ENDROIT SÛR.
L’INSTALLATION DOIT ÊTRE EFFECTUÉE PAR DU PERSONNEL
QUALIFIÉ.
UNE MANIPULATION INAPPROPRIÉE DES COMPOSANTS OU
DU LUMINAIRE POURRAIT NUIRE AU BON FONCTIONNEMENT
DE CE PRODUIT, ANNULANT AINSI LA GARANTIE DU
FABRICANT.
LA GARANTIE DU FABRICANT EST ANNULÉE : SI
L’INSTALLATION N’EST PAS EFFECTUÉE CONFORMÉMENT AU
RÈGLEMENT ÉLECTROTECTHNIQUE POUR BASSE TENSION
ESPAGNOL (REBT 2002).
L’APPLICATION DE L’ITC BT09-4 DU REBT EST OBLIGATOIRE
(INSTALLATION DE DISPOSITIFS DE PROTECTION CONTRE LES
SURTENSIONS SUR LES LIGNES ET LES LUMINAIRES) POUR LES
INSTALLATIONS INDUSTRIELLES ET D’ÉCLAIRAGE PUBLIC. LA
RESPECTER LES PRÉCAUTIONS DE
MANIPULATION DES COMPOSANTS
SENSIBLES AUX DÉCHARGES
ÉLECTROSTATIQUES (LED).
AVISO
ANTES DE COMEÇAR A INSTALAÇÃO DESTE PRODUTO, POR
FAVOR LEIA ATENTAMENTE AS INSTRUÇÕES E GUARDE-AS NUM
LUGAR SEGURO.
A INSTALAÇÃO DEVE SER REALIZADA POR PESSOAL QUALIFICADO.
A MANIPULAÇÃO IMPRÓPRIA DOS COMPONENTES OU DA
PRÓPRIA LUMINÁRIA PODERÁ PREJUDICAR O FUNCIONAMENTO
CORRETO DESTE PRODUTO, FICANDO ANULADA A GARANTIA
DO FABRICANTE.
FICA ANULADA A GARANTIA DO FABRICANTE: SE A INSTALAÇÃO
NÃO SE REALIZAR CONFORME INDICADO NO REBT 2002.
É DE CUMPRIMENTO OBRIGATÓRIO A APLICAÇÃO DE ITC BT09-
4 DO REBT (INSTALAÇÃO DE PROTETORES DE SOBRETENSÕES
EM LINHAS E LUMINÁRIAS) PARA INSTALAÇÕES INDUSTRIAIS E
DE ILUMINAÇÃO PÚBLICA. A GARANTIA NÃO COBRE DANOS
PRODUZIDOS POR SOBRETENSÕES EM LUMINÁRIAS SEM
PROTETORES DE SOBRETENSÃO.
ATENÇÃO!!!
RESPEITAR AS PRECAUÇÕES
DE MANIPULAÇÃO DOS
COMPONENTES SENSÍVEIS A
DESCARGAS ELETROSTÁTICAS
(LED).
ATTENTION !!!
3/8
MONTAGE SUR BRAS/ MONTAGEM EM BRAÇO
Rotation/Rotação
10º -10º
4/8
8Nm máx.
Vidrio templado 4mm/
4mm tempered glass
10Nm máx.
Ø60mm máx.
220-240 50-60Hz
5/8
MONTAGE SUR POTEAU/ MONTAGEM EM POSTE
1
2
Rotation/Rotação
10º
-10º
6/8
8Nm máx.
10Nm máx.
220-240 50-60Hz
Ø60mm máx.
Le luminaire peut être raccordé au réseau électrique via un
bloc de raccordement étanche IP68 5p,
Código:239394
A luminária pode ser ligada à rede elétrica través de bloco
de ligação estanque IP68 5p,
Code:239394
*
NON INCLUS
/NÃO INCLUÍDO
*
Ver esquema de electricación/
See electrication diagram
7/8
ESQUEMA DE ELECTRIFICACIÓN/ ELECTRIFICATION DIAGRAM
SORTIE FIXE/
SAÍDA FIXA
BLEU/AZUL N
MARRON/
CASTANHO L
NOIR/PRETO -
GRIS/CINZA -
VERT/JAUNE
VERDE/AMARELO
8/8
www.grupoprilux.com

Other Prilux Outdoor Light manuals

Prilux Gaudium User manual

Prilux

Prilux Gaudium User manual

Prilux ecTUBE T8 GLASS N User manual

Prilux

Prilux ecTUBE T8 GLASS N User manual

Prilux Egea XL ROAD User manual

Prilux

Prilux Egea XL ROAD User manual

Prilux Zereus User manual

Prilux

Prilux Zereus User manual

Prilux flexiLIGHT 146432 User manual

Prilux

Prilux flexiLIGHT 146432 User manual

Prilux ACTIVA ENERGY AVANT 4 RGB User manual

Prilux

Prilux ACTIVA ENERGY AVANT 4 RGB User manual

Prilux Niza User manual

Prilux

Prilux Niza User manual

Prilux decorativo flexiLIGHT LED DUAL 191821 User manual

Prilux

Prilux decorativo flexiLIGHT LED DUAL 191821 User manual

Prilux Hexagon ARENA-PLAY User manual

Prilux

Prilux Hexagon ARENA-PLAY User manual

Prilux Avatar User manual

Prilux

Prilux Avatar User manual

Prilux flexiLIGHTLED decorativo User manual

Prilux

Prilux flexiLIGHTLED decorativo User manual

Prilux Catt User manual

Prilux

Prilux Catt User manual

Prilux KENIA 20W User manual

Prilux

Prilux KENIA 20W User manual

Prilux Anzio LED User manual

Prilux

Prilux Anzio LED User manual

Prilux Arisa TOP4 User manual

Prilux

Prilux Arisa TOP4 User manual

Prilux Ircana LED User manual

Prilux

Prilux Ircana LED User manual

Prilux Greco User manual

Prilux

Prilux Greco User manual

Prilux Pincho Jardin I User manual

Prilux

Prilux Pincho Jardin I User manual

Prilux Icon PAR56 User manual

Prilux

Prilux Icon PAR56 User manual

Prilux Hexagon PLAY User manual

Prilux

Prilux Hexagon PLAY User manual

Prilux Merk User manual

Prilux

Prilux Merk User manual

Prilux Ebro LED User manual

Prilux

Prilux Ebro LED User manual

Prilux Versa L User manual

Prilux

Prilux Versa L User manual

Prilux ICE GIFT 240895 User manual

Prilux

Prilux ICE GIFT 240895 User manual

Popular Outdoor Light manuals by other brands

ALLSOP Solar Gem Light Guide

ALLSOP

ALLSOP Solar Gem Light Guide

IKEA ISNALEN manual

IKEA

IKEA ISNALEN manual

HEPER ZEROX S Hybrid Installation & maintenance instructions

HEPER

HEPER ZEROX S Hybrid Installation & maintenance instructions

LIGMAN LA-60014 installation manual

LIGMAN

LIGMAN LA-60014 installation manual

Heitronic Juna 35201 Installation and operating instructions

Heitronic

Heitronic Juna 35201 Installation and operating instructions

Maxim Lighting Triumph VX manual

Maxim Lighting

Maxim Lighting Triumph VX manual

Elation PLATINUM HFX user manual

Elation

Elation PLATINUM HFX user manual

GINGKO Smart Baton Light Quick user manual

GINGKO

GINGKO Smart Baton Light Quick user manual

Monzana Lilac GHWLLc70S instructions

Monzana

Monzana Lilac GHWLLc70S instructions

Thorn Voyager Twinspot installation instructions

Thorn

Thorn Voyager Twinspot installation instructions

LIGMAN GI-31581 installation manual

LIGMAN

LIGMAN GI-31581 installation manual

BePureHome CHARGE quick start guide

BePureHome

BePureHome CHARGE quick start guide

Gardco PUREFORM GEN. 2 P26 installation instructions

Gardco

Gardco PUREFORM GEN. 2 P26 installation instructions

KMART SLR-16062 quick start guide

KMART

KMART SLR-16062 quick start guide

Heitronic GU 10 Installation and operating instructions

Heitronic

Heitronic GU 10 Installation and operating instructions

emaux E-Fusion operating manual

emaux

emaux E-Fusion operating manual

ENIM LIGHTING SPL-G Mounting instruction

ENIM LIGHTING

ENIM LIGHTING SPL-G Mounting instruction

RAB LUMINATOR LightAlert! LU300 instructions

RAB

RAB LUMINATOR LightAlert! LU300 instructions

manuals.online logo
manuals.online logoBrands
  • About & Mission
  • Contact us
  • Privacy Policy
  • Terms and Conditions

Copyright 2025 Manuals.Online. All Rights Reserved.
