Prince Castle Sicom Chef EHB Series User guide

Sicom Chef® Set-
up Manual
Extend Holding Bin
EHB Series
355 EAST KEHOE BLVD. ~ CAROL STREAM, IL, 60188, USA
PHONE: [phone] ~ TOLL FREE: 1-800-PCASTLE
540-554revA-EN 1Printed in USA 07/17 © 2017
TABLE OF CONTENTS
Configuring PHU in Digital Menu Board (DMB) Portal . . . . . . . . . . . . ... . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . . . . . . . . 2
Connecting EHB to Chef. . . . . . . . . . . . ... . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . . . . . . . . ............................................. 14
Troubleshooting. . . . . . . . . . . . ... . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . . . . . . . . ........................................................... 21

Printed in USA 07/17 © 2017 2540-554revA-EN
Extended Hold Bin
EHB Series
Configuring PHU in Digital Menu Board (DMB) Portal
Visit the DMB portal site that corresponds with your parent brand (e.g. yourbranddmb.sicomasp.com)
1
2
2On the DMB Set Up Menus, click Setup Equipment.
Enter the registered E-mail Address and Password into the fields. Click

540-554revA-EN 3Printed in USA 07/17 © 2017
Extended Hold Bin
EHB Series
Configuring PHU in Digital Menu Board (DMB) Portal
Click your Store Number followed by
3
4Under Create New Equipment, select PHU from the drop-down menu.

Printed in USA 07/17 © 2017 4540-554revA-EN
Extended Hold Bin
EHB Series
Configuring PHU in Digital Menu Board (DMB) Portal
Fill out the required fields, beginning with Name. This is the title that will be given to the PHU in the DMB portal.
5
6For Manufacturer, select Prince Castle.

540-554revA-EN 5Printed in USA 07/17 © 2017
Extended Hold Bin
EHB Series
Configuring PHU in Digital Menu Board (DMB) Portal
For Model, select 2nd Generation.
7
8For Size, select your PHU configuration (Rows x Columns). E.g. 2x4

Printed in USA 07/17 © 2017 6540-554revA-EN
Extended Hold Bin
EHB Series
Configuring PHU in Digital Menu Board (DMB) Portal
Enter the MAC address that is located on top of the unit above the display panel.
9
MUST MATCH.
DASHES “—” ON TAG
BECOME COLONS “:”
WHEN ENTERED IN
PORTAL.

540-554revA-EN 7Printed in USA 07/17 © 2017
Extended Hold Bin
EHB Series
Configuring PHU in Digital Menu Board (DMB) Portal
Click then return to Set Up Menus.
10
11 On the DMB Set Up Menus, click Setup Dayparts.


Printed in USA 07/17 © 2017 8540-554revA-EN
Extended Hold Bin
EHB Series
Configuring PHU in Digital Menu Board (DMB) Portal
Click your Store Number followed by
Click Then fill in the required fields according to your store’s operational preferences.
12
13

540-554revA-EN 9Printed in USA 07/17 © 2017
Extended Hold Bin
EHB Series
Configuring PHU in Digital Menu Board (DMB) Portal
If all days have the same times, click Click to finish.
14
15

Return to Set Up Menus then click Setup Pan Assignments.

Printed in USA 07/17 © 2017 10 540-554revA-EN
Extended Hold Bin
EHB Series
Configuring PHU in Digital Menu Board (DMB) Portal
16
17 Click on each heater zone of the PHU configuration and select your desired products.
Click your Store Number. From the Select Holding Unit drop-down, select your PHU.

540-554revA-EN 11 Printed in USA 07/17 © 2017
Extended Hold Bin
EHB Series
Configuring PHU in Digital Menu Board (DMB) Portal
18
Repeat for all times of day - Breakfast, Lunch, and Dinner - for all days of the week. To apply the same
menu to all days, click
Under the “From” heading, click “Breakfast” under “Sunday”.
Hold the Ctrl key on the keyboard, and under the “To” heading, click “Breakfast” for the
remaining days of the week.

Printed in USA 07/17 © 2017 12 540-554revA-EN
Extended Hold Bin
EHB Series
Configuring PHU in Digital Menu Board (DMB) Portal
18
Click
Repeat for Lunch and Dinner. Click to finish.


540-554revA-EN 13 Printed in USA 07/17 © 2017
Extended Hold Bin
EHB Series
Configuring PHU in Digital Menu Board (DMB) Portal
IMPORTANT: Click Sync changes to restaurants. DMB portal configuration will not
transmit to Chef if this step is neglected.19
Click the box next to your store to sync the changes to.
Click to finish.


Printed in USA 07/17 © 2017 14 540-554revA-EN
Extended Hold Bin
EHB Series
Connecting EHB to Chef®
On the underside of the Sicom Chef module, press the power button on the far right-hand side.
Then locate the orange NETWORK port on the far left-hand side. Connect Chef to an available LAN router
port.
1
POWER ON
NETWORK
PORT
CONNECT TO OPEN
LAN PORT
On the back of the EHB, locate the Ethernet port directly below the power cord. Connect the EHB to the next
available LAN router port.2
CONNECT TO OPEN
LAN PORT

540-554revA-EN 15 Printed in USA 07/17 © 2017
Extended Hold Bin
EHB Series
Connecting EHB to Chef®
On the front side of the router, LAN ports 1 and 2 should be illuminated.
2

Flip the green power button ON “—” on the EHB. The red display should read “EnSP.” Verify that it switches
to “En” within 20 seconds. This means the EHB has successfully connected to the internet.3
POWER EHB ON “—”
20 SECONDS

Printed in USA 07/17 © 2017 16 540-554revA-EN
Extended Hold Bin
EHB Series
Connecting EHB to Chef®
Within 1 minute, notice .EnSP => .En now has a dot on the left-hand side. This means the menu is being
downloaded to the EHB from the Portal.
4
Notice the timer bar displays dim and “WAIT” appears across all windows.
5
1 MINUTE
DOT MEANS
MENU IS BEING
DOWNLOADED

To monitor the PHU on the Chef screen, touch the gear icon in the lower right-hand corner.
Then tap “Configuration”.
6

540-554revA-EN 17 Printed in USA 07/17 © 2017
Extended Hold Bin
EHB Series
Connecting EHB to Chef®
Enter the password: “1”, “2”, “3”. Hit the green checkmark
7
PASSWORD IS
“1 2 3”
In the tab, tap the drop down arrow on last row entitled Select the
PHU to be monitored, (e.g. “Main 2x4”).
8

Printed in USA 07/17 © 2017 18 540-554revA-EN
Extended Hold Bin
EHB Series
Connecting EHB to Chef®
Tap “Save” on the lower left side.
9
To return to the home screen, hit the gear icon followed by “Overview”.
10

The configuration in the Chef portal for PHU “Main 2x4” should now be displayed on the home screen.
11


540-554revA-EN 19 Printed in USA 07/17 © 2017
Extended Hold Bin
EHB Series
Connecting EHB to Chef®
To test communication between Chef and the EHB, start all timers from left to right, starting with the top left
product “HAMC”.
12
The first timer activated for duplicate products will be green, while the second timer will be orange.
Verify that the timers on the EHB have started and match the green and yellow on the Chef screen.


Printed in USA 07/17 © 2017 20 540-554revA-EN
Extended Hold Bin
EHB Series
Connecting EHB to Chef®
From the EHB timer bar, press all the and buttons to cancel the timers.
12
Verify that the timers on the Chef screen have stopped and the screen returns to only the product names.

