Pro-face FP5000 Series User manual

FP5000 Series
User Manual
FP5000-MM01-EN-PDF_02

2
The information provided in this documentation contains general descriptions and/or technical
characteristics of the performance of the products contained herein. This documentation is not
intended as a substitute for and is not to be used for determining suitability or reliability of these
products for specific user applications. It is the duty of any such user or integrator to perform the
appropriate and complete risk analysis, evaluation and testing of the products with respect to the
relevant specific application or use thereof. Neither Schneider Electric nor any of its affiliates or
subsidiaries (hereinafter, referred to as Schneider Electric) shall be responsible or liable for misuse
of the information that is contained herein. If you have any suggestions for improvements or
amendments or have found errors in this publication, please notify us.
You agree not to reproduce, other than for your own personal, noncommercial use, all or part of
this document on any medium whatsoever without permission of Schneider Electric, given in
writing. You also agree not to establish any hypertext links to this document or its content.
Schneider Electric does not grant any right or license for the personal and noncommercial use of
the document or its content, except for a non-exclusive license to consult it on an "as is" basis, at
your own risk. All other rights are reserved.
All pertinent state, regional, and local safety regulations must be observed when installing and
using this product. For reasons of safety and to help ensure compliance with documented system
data, only the manufacturer should perform repairs to components.
When devices are used for applications with technical safety requirements, the relevant
instructions must be followed.
Failure to use Schneider Electric software or approved software with our hardware products may
result in injury, harm, or improper operating results.
Failure to observe this information can result in injury or equipment damage.
Copyright © 2017 Schneider Electric Japan Holdings Ltd. All Rights Reserved.

3
FP5000 Series User Manual
Table of Contents
Safety Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
About the Book. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Chapter 1 Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Model Number Configuration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Model Numbers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Package Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Revision. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Certifications and Standards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Federal Communication Commission Radio Frequency Interference
Statement - For U.S.A. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Hazardous Location Installation - For USA and Canada. . . . . . . . . . . 19
European (CE) Compliance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
KC Markings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Chapter 2 Device Connectivity . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
System Design . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Chapter 3 Parts Identification and Functions . . . . . . . . . . . . . . . . 27
FP-5600TPD/5700TPD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
LED Indications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Chapter 4 Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
4.1 General Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Electrical Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Environmental Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Structural Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
4.2 Functional Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Display Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Touch Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
4.3 Interface Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Interface Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Interface Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
DVI-D Input Interface. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Chapter 5 Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
FP-5600TPD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
FP-5700TPD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Chapter 6 Installation and Wiring. . . . . . . . . . . . . . . . . . . . . . . . . . 53
6.1 Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
Installation Procedures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
6.2 Wiring Principles . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
Connecting the DC Power Cord . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
Connecting the Power Supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
Grounding . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
6.3 USB Cable Clamp . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
USB Clamp (Type B) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67

4
6.4 Front USB Cover . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
Opening the Front USB Cover. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
Chapter 7 System Specifications and Launcher. . . . . . . . . . . . . . 73
7.1 System Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
Operating System, Drivers, Utilities. . . . . . . . . . . . . . . . . . . . . . . . . . . 75
Settings Workflow . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76
Installing the Drivers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
Installing the Utilities . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79
7.2 Launcher . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80
About the Launcher . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81
Display Settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83
PC Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87
Chapter 8 Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89
Regular Cleaning. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90
Periodic Check Points . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91
Replacing the Installation Gasket . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92
Replacing the Backlight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93
Troubleshooting Checklist . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 94
After-sales Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95

5
FP5000 Series User Manual
Safety Information
Important Information
NOTICE
Read these instructions carefully, and look at the equipment to become familiar with the device
before trying to install, operate, or maintain it. The following special messages may appear
throughout this documentation or on the equipment to warn of potential hazards or to call attention
to information that clarifies or simplifies a procedure.
PLEASE NOTE
Electrical equipment should be installed, operated, serviced, and maintained only by qualified
personnel. No responsibility is assumed by Schneider Electric for any consequences arising out of
the use of this material.
A qualified person is one who has skills and knowledge related to the construction and operation
of electrical equipment and its installation, and has received safety training to recognize and avoid
the hazards involved.

6

7
FP5000 Series User Manual
About the Book
At a Glance
Document Scope
This manual describes how to use this product.
Validity Note
This documentation is valid for this product.
The technical characteristics of the device(s) described in this manual also appear online at
http://www.pro-face.com.
The characteristics presented in this manual should be the same as those that appear online. In
line with our policy of constant improvement we may revise content over time to improve clarity and
accuracy. In the event that you see a difference between the manual and online information, use
the online information as your reference.
Registered Trademarks
Microsoft and Windows are registered trademarks of Microsoft Corporation in the United States
and/or other countries.
Product names used in this manual may be the registered trademarks owned by the respective
proprietors.
Related Documents
You can download the manuals related to this product, such as the software manual, from our
support site at http://www.pro-face.com/trans/en/manual/1001.html.
Product Related Information
Critical alarm indicators and system functions require independent an redundant protection
hardware and/or mechanical interlocks.
When you cycle power, wait at least 10 seconds after it has been turned off. If this product is
restarted too quickly, it may not operate correctly.
DANGER
HAZARD OF ELECTRIC SHOCK, EXPLOSION, OR ARC FLASH
Remove all power from the device before removing any covers or elements of the system, and
prior to installing or removing any accessories, hardware, or cables.
Unplug the power cable form both this product and the power supply.
Always use a properly rated voltage sensing device to confirm power is off.
Replace and secure all covers or elements of the system before applying power to this
product.
This product uses 12 to 24 Vdc power. Using any other level of power can damage both the
power supply and this product.
Failure to follow these instructions will result in death or serious injury.

8
In the event the screen cannot be properly read, for example, if the backlight is not functioning, it
may be difficult or impossible to identify a function. Functions that may present a hazard if not
immediately executed, such as a fuel shut-off, must be provided independently of this product. The
machine’s control system design must take into account the possibility of the backlight no longer
functioning and the operator being unable to control the machine or making mistakes in the control
of the machine.
For additional information, refer to NEMA ICS 1.1 (latest edition), "Safety Guidelines for the
Application, Installation, and Maintenance of Solid State Control" and to NEMA ICS 7.1 (latest
edition), "Safety Standards for Construction and Guide for Selection, Installation and Operation of
Adjustable-Speed Drive Systems" or their equivalent governing your particular location.
WARNING
LOSS OF CONTROL
The designer of any control scheme must consider the potential failure modes of control paths
and, for certain critical control functions, provide a means to achieve a safe state during and
after a path failure. Examples of critical control functions are emergency stop and overtravel
stop, power outage and restart.
Separate or redundant control paths must be provided for critical control functions.
System control paths may include communication links. Consideration must be given to the
implications of unanticipated transmission delays or failures of the link.
Observe all accident prevention regulations and local safety guidelines.
Each implementation of this product must be individually and thoroughly tested for proper
operation before being placed into service.
The machine control system design must take into account the possibility of the backlight no
longer functioning and the operator being unable to control the machine, or making errors in
the control of the machine.
Failure to follow these instructions can result in death, serious injury, or equipment
damage.
WARNING
UNINTENDED EQUIPMENT OPERATION
The application of this product requires expertise in the design and programming of control
systems. Only persons with such expertise should be allowed to program, install, alter, and apply
this product.
Follow all local and national safety standards.
Failure to follow these instructions can result in death, serious injury, or equipment
damage.

FP5000 Series User Manual
9
The following characteristics are specific to the LCD panel and are considered normal behavior:
LCD screen may show unevenness in the brightness of certain images or may appear different
when seen from outside the specified viewing angle. Extended shadows, or crosstalk may also
appear on the sides of screen images.
LCD screen pixels may contain black and white colored spots and color display may seem to
have changed.
When the same image is displayed on the screen for a long period, an afterimage may appear
when the image is changed.
The panel brightness may decrease when used for a long time in an environment continuously
filled with inert gas. To prevent deterioration of panel brightness, regularly ventilate the panel.
For more information, please contact customer support.
http://www.pro-face.com/trans/en/manual/1015.html

NOTE: Change the screen image periodically and try not to display the same image for a long
period of time.
WARNING
UNINTENDED EQUIPMENT OPERATION
Do not use this product as the only means of control for critical system functions such as motor
start/stop or power control.
Do not use this equipment as the only notification device for critical alarms, such as device
overheating or overcurrent.
Use only the software provided with this product. If you use another software, please confirm
the operation and safety before use.
Failure to follow these instructions can result in death, serious injury, or equipment
damage.
CAUTION
SERIOUS EYE AND SKIN INJURY
The liquid in the LCD panel contains an irritant:
Avoid direct skin contact with the liquid.
Wear gloves when you handle a broken or leaking unit.
Do not use sharp objects or tools in the vicinity of the LCD panel.
Handle the LCD panel carefully to prevent puncture, bursting, or cracking of the panel material.
If the panel is damaged and any liquid comes in contact with your skin, immediately rinse the
area with running water for at least 15 minutes. If the liquid gets in your eyes, immediately rinse
your eyes with running water for at least 15 minutes and consult a doctor.
Failure to follow these instructions can result in injury or equipment damage.

10

11
FP5000 Series User Manual
FP5000 Series User Manual
Overview
iDisplay_PF 12/2017
Overview
Chapter 1
Overview
Introduction
This chapter describes the panels of this product and general topics such as package contents and
standards.
What Is in This Chapter?
This chapter contains the following topics:
Topic Page
Model Number Configuration 12
Model Numbers 13
Package Contents 14
Revision 15
Certifications and Standards 16
Federal Communication Commission Radio Frequency Interference Statement - For U.S.A. 18
Hazardous Location Installation - For USA and Canada 19
European (CE) Compliance 21
KC Markings 22

Overview
12
Model Number Configuration
The following describes the configuration of model numbers.
Digit position 1 2 3 4 5 6 7 8 9 10 11 12
P F X (model) (series) (size) (type) (LCD) (touch
panel)
(power
supply)
FP 5 6: 12.1-inch
7: 15-inch
00: Standard T: TFT P: Multi D: DC

FP5000 Series User Manual
13
Model Numbers
Global Code
A global code is assigned to every Pro-face product as a universal model number. For more
information on product models and their matching global codes, please refer to the following URL.
http://www.pro-face.com/trans/en/manual/1003.html
Series Display size Model names Model numbers
FP5000 Series 12.1-inch FP-5600TPD PFXFP5600TPD
15-inch FP-5700TPD PFXFP5700TPD

Overview
14
Package Contents
NOTE: This product has been carefully packed with special attention to quality. However, should
you find anything damaged or missing, please contact customer support immediately.
Verify all items listed here are present in your package:
1 FP5000 Series: 1
2 Installation gasket: 1 (attached to this product)
3 DC power supply connector (right angle): 1
4 USB clamp (Type B): 1 set (1 clip and 1 tie)
5 USB masking sticker (mini-B)*1: 1
6 FP5000 Series Installation Guide: 1
7 Warning/Caution Information: 1
*1 See Parts Identification and Functions (see page 27).

FP5000 Series User Manual
15
Revision
You can identify the product version (PV), revision level (RL), and the software version (SV) from
the product label.

Overview
16
Certifications and Standards
NOTE: Some products are not subject to certification and standards. And some products have not
received their certification and standards but are scheduled for assessment.
For information on certifications and standards, such as certified models and certificates, see the
product markings or the following URL:
http://www.pro-face.com/trans/en/manual/1002.html
Agency Certifications
Schneider Electric submitted this product for independent testing and qualification by third-party
listing agencies. These agencies have certified this product as meeting the following standards.
Underwriters Laboratories Inc., UL 508 and CSA C22.2 No142, Industrial Control Equipment
Underwriters Laboratories Inc., ANSI/ISA 12.12.01 and CSA C22.2 No213, Electrical
Equipment for Use in Class I, Division 2 Hazardous (Classified) Locations
IECEx/ATEX for use in zones 2/22
GOST-R or EAC certification (Russia, Belarus, Kazakhstan)
Germanischer Lloyd (GL)
Compliance Standards
Europe:
CE
Directive 2014/35/EU (Low Voltage)
Directive 2014/30/EU (EMC)
Programmable Controllers: EN 61131-2
EN61000-6-4
EN61000-6-2
Directive 94/9/EC (ATEX)
EN60079-0
EN60079-15
EN60079-31
Australia
RCM Mark
EN61000-6-4
Korea
KC Markings
KN11
KN61000-6-2
Qualifications Standards
Schneider Electric voluntarily tested this product to additional standards. The additional tests
performed, and the standards under which the tests were conducted, are specifically identified in
Structural Specifications (see page 35).

FP5000 Series User Manual
17
Hazardous Substances
This product is a device for use in factory systems. When using this product in a system, the system
should comply with the following standards in regards to the installation environment and handling:
WEEE, Directive 2012/19/EU
RoHS, Directive 2011/65/EU
RoHS China, Standard GB/T 26572
REACH regulation EC 1907/2006

Overview
18
Federal Communication Commission Radio Frequency Interference Statement -
For U.S.A.
FCC Radio Interference Information
This product has been tested and found to comply with the Federal Communications Commission
(FCC) limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a commercial, industrial
or business environment. This product generates, uses, and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may cause or be subject to
interference with radio communications. To minimize the possibility of electromagnetic interference
in your application, observe the following two rules:
Install and operate this product in such a manner that it does not radiate sufficient
electromagnetic energy to cause interference in nearby devices.
Install and test this product to ensure that the electromagnetic energy generated by nearby
devices does not interfere with the operation of this product.
WARNING
ELECTROMAGNETIC / RADIO INTERFERENCE
Electromagnetic radiation may disrupt the operation of this product leading to unintended
equipment operation. If electromagnetic interference is detected:
Increase the distance between this product and the interfering equipment.
Reorient this product and the interfering equipment.
Reroute power and communication lines to this product and the interfering equipment.
Connect this product and the interfering equipment to different power supplies.
Always use shielded cables when connecting this product to a peripheral device or another
computer.
Changes or modifications not expressly approved by the party responsible for compliance
could void the user’s authority to operate this product.
Failure to follow these instructions can result in death, serious injury, or equipment
damage.

FP5000 Series User Manual
19
Hazardous Location Installation - For USA and Canada
General
This product has been designed with the intention of meeting the requirements of Class I, Division
2 hazardous location application. Division 2 locations are those locations where ignitable
concentrations of flammable substances are normally confined, prevented by ventilation, or
present in an adjacent Class I, Division 1 location, but where an abnormal situation might result in
intermittent exposure to such ignitable concentrations.
While this product is a non-incendive device under ANSI/ISA 12.12.01 and CSA C22.2 N213, it is
not designed for, and should never be used within a Division 1 (normally hazardous) location.
This product is suitable for use in Class I, Division 2, Groups A, B, C, and D hazardous locations
or in non-hazardous locations. Before installing or using this product, confirm that the ANSI/ISA
12.12.01 or CSA22.2 N213 certification appears on the product labeling.
NOTE: Some products are not yet rated as suitable for use in hazardous locations. Always use
your product in conformance with the product labeling and this manual.
DANGER
POTENTIAL FOR EXPLOSION
Do not use this product in hazardous environments or locations other than Class I, Division2,
Group A, B, C, and D.
Substitution of any component may impair suitability for Class I, Division 2.
Do not connect or disconnect this product unless power has been switched off or the area is
known to be non-hazardous.
Always confirm that this product is suitable for use in hazardous locations by checking the
ANSI/ISA 12.12.01 or CSA C22.2 N213 certification appears on the product labeling.
Do not install any Pro-face or OEM components, equipment, or accessories unless these have
also been qualified as suitable for use in Class I, Division 2, Groups A, B, C, and D locations.
Do not attempt to install, operate, modify, maintain, service, or otherwise alter this product
except as permitted in this manual. Unpermitted actions may impair the suitability of this
product for Class I, Division 2 operation.
Failure to follow these instructions will result in death or serious injury.
DANGER
POTENTIAL FOR EXPLOSION
Always confirm the ANSI/ISA 12.12.01 or CSA C22.2 N213 hazardous location rating of your
device before installing or using it in a hazardous location.
To apply or remove the supply power from this product installed in a Class I, Division 2
hazardous location, you must either:
Use a switch located outside the hazardous environment, or;
Use a switch certified for Class I, Division 1 operation inside the hazardous area.
Do not connect or disconnect equipment unless power has been switched off or the area is
known to be non-hazardous. This applies to all connections including power, ground, serial,
parallel, and network connections.
Never use unshielded / ungrounded cables in hazardous locations.
Use only non-incendiary USB devices.
When enclosed, keep enclosure doors and openings closed at all times to avoid the
accumulation of foreign matter inside the workstation.
Failure to follow these instructions will result in death or serious injury.

Overview
20
Make sure that this product is properly rated for the location. If the intended location does not
presently have a Class, Division and Group rating, then users should consult the appropriate
authorities having jurisdiction in order to determine the correct rating for that hazardous location.
Operation and Maintenance
The systems have been designed for compliance with relevant spark ignition tests.
NOTE: IP65F, IP66F and IP67F are not part of UL certification.
DANGER
HAZARD OF ELECTRIC SHOCK, EXPLOSION, OR ARC FLASH
Remove all power from the device before removing any covers or elements of the system, and
prior to installing or removing any accessories, hardware, or cables.
Unplug the power cable form both this product and the power supply.
Always use a properly rated voltage sensing device to confirm power is off.
Replace and secure all covers or elements of the system before applying power to this
product.
Use only the specified voltage when operating this product. The DC unit is designed to use 12
to 24 Vdc. Always check whether your device is AC or DC powered before applying power.
Failure to follow these instructions will result in death or serious injury.
DANGER
POTENTIAL FOR EXPLOSION
In addition to the other instructions in this manual, observe the following rules when installing this
product in a hazardous location:
Wire the equipment in accordance with the National Electrical Code article 501.10 (B) for
Class I, Division 2 hazardous locations.
Install this product in an enclosure suitable for the specific application. IP65F, IP66F, IP67F,
Type 1, Type 4X [Indoor Use Only], or Type 13 enclosures are recommended even when not
required by regulations.
Failure to follow these instructions will result in death or serious injury.
