Pro-face PS3700A-T41-ASU-E66 User manual

E-1
WARNING
• When inserting the PS-3700A(Eden™ESP6000-667MHz Model) (hereafter referred to as the
"PS-A")'s power cord into the PS-A's AC Connector, check first that the PS-A's power supply is
completely turned OFF, via a breaker, or similar unit.
• Before either plugging in or unplugging a board or interface connector, be sure to turn the PS-A’s
power OFF.
• Whenever changing the Backlight, to prevent electric shocks and burns, be sure to turn OFF the
PS-A's power and wear protective gloves.
• After the PS-A’s backlight burns out, unlike the PS-A’s “Standby Mode”, the touch panel is still
active. If the operator fails to notice that the backlight is burned out and touches the panel, a
potentially dangerous machine operation error can occur.
If your PS-A's backlight suddenly turns OFF, use the following steps to determine if the back-
light is actually burned out.
1) If your PS-A isnot set to "Standby Mode" and the screen has gone blank, your backlight is
burned out.
2) Or, if your PS-A is set to Standby Mode, but touching the screen does not cause the
display to reappear, your backlight is burned out.
• Do not open or remodel the PS-A unit, since it may lead to a fire or electric shock.
• Do not use power beyond the PS-A's specified voltage range. Doing so may cause a fire or an
electric shock.
• Do not use the PS-A in an environment where flammable gases are present, since operating the
PS-A may cause an explosion.
• The PS-A uses a lithium battery for backing up its internal clock data. If the battery is incorrectly
replaced (i.e. its + and - sides are reversed), the battery may explode. When changing the
battery, please contact your local PS-A distributor.
• Do not use the PS-A unit as a warning device for critical alarms that can cause serious operator
injury, machine damage or production stoppage. Critical alarm indicators and their control/acti-
vator units must be designed using stand-alone hardware and/or mechanical interlocks.
• To prevent operator injury or machine damage, be sure to design your machine operation system
so that the machine will not malfunction due to a communication fault between the PS-A and its
host controller.
• Do not use PS-A touch panel switches in life-related or important disaster prevention situations. For
safety related switches, such as an emergency switch, be sure to use a separate mechanical switch.
• The PS-A is not appropriate for use with aircraft control devices, aerospace equipment, central
trunk data transmission (communication) devices, nuclear power control devices, or medical
life support equipment, due to these devices inherent requirements of extremely high levels of
safety and reliability.
• When using the PS-A with transportation vehicles (trains, cars and ships), disaster and crime
prevention devices, various types of safety equipment, non-life support related medical devices,
etc. redundant and/or failsafe system designs should be used to ensure the proper degree of
reliability and safety.
WARNINGS
To prevent this unit from malfunctioning :
• In order to extend the lifetime of the hard disk, Pro-face recommends you set the Windows [Con-
trol panel]-[Power Management option]-[Turn off hard disks] selection to turn the hard disk off
when the unit is not being operated. A setting of 5 minutes is recommended.
• Do not strike the PS-A's touch panel with a hard or heavy object, or press on the touch panel with
excessive force, since it may damage the display.
• Do not install the PS-A where the temperature will exceed its specified range.
• Be sure that water, liquids or metal particles do not enter the PS-A, since it may cause a malfunc-
tion or a short circuit.
• Avoid installing the PS-A where sudden, large changes in temperature may occur. These changes
may cause condensation to form inside the unit, possibly causing a malfunction.
• To prevent excessive heat from building up inside the PS-A, do not install it where its ventilation
holes may be blocked. Also, do not install or store the PS-A near high temperature equipment.
• Do not install or store the PS-A in direct sunlight or where high levels of dust exist.
• Since the PS-A is a precision instrument, do not install or store it where either strong shocks or
excessive vibration may occur.
• Do not install or store the PS-A in an area containing chemicals or chemical fumes.
• Do not use paint thinner or organic solvents to clean the PS-A's case or screen.
• Due to the danger of unforeseeable accidents, back up all PS-A data regularly.
• After turning this unit OFF, be sure to wait a few seconds before turning it ON again. If the unit is
started too soon, it may not start up correctly.

E-2
ThePS3700A-T41-ASU-E66 is a UL/CSA listedproduct (UL File No. E220851).Please pay special
attentiontothefollowinginstructionswhenapplyingforUL/CSAapprovalformachinerywhichincludes
thisPS-Aunit.
The PS-A conforms as a component to the following standards:


UL508 IndustrialControlEquipment


CAN Std C22.2 No.14-1995 CAN/CSA 22.2 No.60950
PS3700A-T41-ASU-E66 (UL Registration Model No.:3280015-01)
-EquipmentwithaPS-Aunitmountedinit requiresUL/CSAevaluationforthecombinationofthePS-A
andequipment.
- The PS-A must be used as a built-in component of an end-use product.
- Use the PS-Aindoors only.
- When connecting the PS-A’s power cord, be sure to use a cord that is appropriate for the current and
voltage used and that has conductive wires that areAWG18 or larger.
- Danger of explosion if backup battery is incorrectly replaced. Should be replaced only with same or
equivalent type recommended by the manufacturer. Dispose of used batteries according to the
manufacturer’sinstructions.
- Be sure the unit the PS-A is built into uses a UL508 compatible structure.
The PS3700A-T41-ASU-E66 is CE marked, EMC compliant products.
<ComplieswiththefollowingStandards>
• Safety
EN60950
• EMI
EN61000-6-4, EN55011(Group 1, Class A)
• EMS (EN61000-6-2/EN61131-2)
EN61000-4-2, EN61000-4-3, EN61000-4-4, EN61000-4-5, EN61000-4-6,
EN61000-4-8, EN61000-4-11, EN61000-4-12
• FCC
47 CFR Part15 Class A
Ifthefollowingrequirementsarenotmet,thePS-AmayfailtomeetEN60950standardrequirements.
• The PS-A must be used as a built-in component of an end-use product.
• Use the PS-Aindoors only.
• When connecting the PS-A’s power cord, be sure to use a cord that is appropriate for the current and
voltage used and that has conductive wires that areAWG18 or larger.
• There is a danger of explosion if the backup battery is incorrectly replaced. This battery should be
replacedonly withsameorequivalenttyperecommendedbythe manufacturer.Disposeofusedbatter-
iesaccordingtothemanufacturer’sinstructions.
• BesurethePS-A unit's enclosure is anEN60950approvedsheetsteel structure.
CE Marking Notes
UL/CSA Application Notes

E-3
Thefollowingitemsareincluded in the PS-A's package. Before using the PS-A, pleaseconfirmthatall
itemslistedherearepresent.
Thisunithasbeencarefullypacked,withspecialattentiontoquality. However,shouldyoufindanything
damagedormissing,pleasecontactyourlocalPS-Adistributorimmediately.
Package Contents


PS-A Unit (1)
(PS3700A-T41-ASU-E66)


Installation Fasteners (4/set ×2 )


Installation Gasket (1)
•Be careful when installing the PS-A not to damage the built-in HDD.
•The Power Cord included in the FP unit’s package is designed only for
AC100V or AC115V use. Any other voltage will require a different cord.
AC Power Cord Clamp (1)
USB Cable Clamp (1)
CD-ROM (1)
• The CD-ROM included in this package contains a User Manual, RAS-API Ref-
erence Manual, and PS-A Series Utility and Driver files. Please refer to PDF
manuals.
• When you order a PS-A unit built to your specifications, that PS-A package
should include each optional item's Installation Guide. Please use that guide
to check the contents of each optional item's package.
Installation Guide (1)
<This Guide>
Installation
Guide
AC Power Cord (1)

E-4
ThePS-Aunit'sCD-ROM containsthefollowingPDFmanualfiles.
- PS-3700A (EdenTM ESP6000-667MHz Model) User Manual (psae6e.pdf)
- PS Series Type A (EdenTM ESP6000-667MHz Model) API Reference Manual (psae6ape.pdf)
ReadingaPDFfile requires installation of the Adobe Corporation's Acrobat®Reader.
Acrobat®ReaderInstallation:
ToinstalltheAcrobat®Readersoftware,followthe steps given below.
1)Thissoftware, in theformofaself-extracting file, islocatedinthisCD-ROM in thefoldertitled
[reader].Usethe Explorer software tofindthefile [Reader\Eng\ar505enu.exe], and double-click
onthefileicontobegintheReaderinstallation.
2)Afterinstallationbegins,followtheinstructionsgiven.
ViewingthePDFmanual:
ToviewthePDFmanual contained in this CD-ROM, follow the steps given below.
1)Use the Explorer software tolocate the file [Manual\Eng\psae6e.pdf or psae6ape.pdf]in the
foldertitled[Manual].
2)Double-clickonthePDFfile'sicon.Acrobat®Readerwill automatically start and the first page of
thePDFmanualwill appear.
About The Manual

E-5
1Part Names 1 : Display / Touch Panel
2 : Power Lamp LED (POWER)
10
1
12
15
14
18
16 21
20
19
22
3
4
7
11
13
17 2324
2526
27
28 29
Top
Bottom
Side
Rear
Front
2
5
6
LED PS-A Status
Green Normal Operation
(PowerOn)
Orange System MonitorError
Touch Panel SelfTestErro
r
Orange/Red Backlightisnotfunctioning
3 : IDE Access Lamp
LED PS-A Status
Green CurrentlyusingIDEI/F
4 : Front Packing
5 : Hardware Reset Switch (RESET)
6 : USB Connector (1 port)
7 : Arm Attachment Screw Holes
(VESA 75mm)
8 : Power Switch
9 : Expansion Board Support
10 : FD Drive
11 : CD-ROM Drive
12 : PCMCIA Connectors (PCMCIA)(2 ports)
13 : Rear Cover
14 : Mouse Connector (MOUSE)
15 : Keyboard Connector (KEYBOARD)
16 : Expansion Slot
17 : LAN Connector (LAN)
(10 BASE-T /100 BASE-TX)
18 : USB Connectors (2 ports)
19 : RS-232C Connector (COM1)
[+5V/RI Changeover]
20 : RS-232C Connector (COM2)
[+5V/RI Changeover]
21 : RS-232C Connector (COM3)
[RS-422/RS-485 Changeover]
22 : RS-232C Connector (COM4)
23 : Line Input Connector (LINE IN)
24 : Speaker Output Connector
(SPEAKER)
25 : Mike Input Connector (MIC IN)
26 : Printer Connector (LPT1)
27 : Cooling FAN
28 : CF Card Slot
29 : AC Inlet Connector
9
8

E-6
Unit:mm [in]
2Dimensions
Front
Top
100 [3.94]
282 [11.10]
5 [0.20]
395 [15.55]
294 [11.57]
383 [15.08]
Side
• Prior to attaching peripheral units to the PS-A, be sure the PS-A’s power cord
is disconnected from the main power supply.
• To prevent an electrical shock, be sure to disconnect the PS-A’s power cord
from the power supply before connecting the cord or any peripheral devices
to the PS-A.


PS-A Unit
External Dimensions (with Installation Fasteners installed)
100 [3.94]
160 [6.30]
5 [0.20]
394.8 [15.54]
404.8 [15.94]
Bottom 165 [6.50]
Front
293.8 [11.57]
303.8 [11.96]
Left Side
Top
Unit:mm [in]
160 [6.30]
160 [6.30]
Right Side

E-7


Electrical


Environment
3General Specifications
• When using any of the PS-A’s optional devices, be sure to check
that device’s specifications for any special conditions or cautions
that may apply to its use.
• Be aware that not only does the Hard Disk have a fixed lifetime,
but that accidents can always occur. Therefore, be sure to back up
your Hard Disk’s data regularly, or prepare another Hard Disk unit
that can be used for backup.
Rated Voltage AC100V/AC240V
VoltageSupplyRange AC85Vto AC265V
Rated Frequency 50/60Hz
AllowableVoltageDrop 1cycle orless
(pauseoccurrencesmustbe morethan1secondapart)
PowerConsumption 120VAorless
VoltageEndurance AC1500V20mAfor1minute
(between charging andFG terminals)
Insulation Resistance 10MΩorhigheratDC500V
(between charging andFG terminals)
AmbientOperating Temperature
Storage Temperature
AmbientHumidity
StorageHumidity
Air Purity (Dust)
Pollution Degree
Corrosive Gases When using
HDD 4.9m/s
2
at10Hzto 25Hzin X,Y,Z direction
s
for 30 minutes
When NOT
usingHDD 9.8m/s
2
at10Hzto 25Hzin X,Y,Z direction
s
for 30 minutes
NoiseImmunity
(ImpulseNoise)
NoiseImmunity
(Firsttransientburstnoise)
Electrostatic Discharge Immunity
Freeofdust
Pollution Degree2
Freeofcorrosivegases
+5
o
C to +50
o
C (WhenUsingHDD)
0oC to +50 oC (WhenNOT Using HDD)
-10 oC to + 60 oC
10%RH to 85%RH
(Noncondensing,wetbulbtemperature:29oC or less)
10%RH to 85%RH
(Noncondensing,wetbulbtemperature:29oC or less)
Noise Voltage:1500V(via noisesimulator)
PulseDuration:50ns,500ns,1µs
Rise Time :1ns
PowerLine :2kV IEC61000-4-4
COM Port:1kV IEC61000-4-4
4kV IEC61000-4-2
Vibration Resistance

E-8
• The Hard Disk lifetime given here may be reduced due to unfore-
seen environmental factors, however, generally speaking, the disk
should last for 20,000 hours (of operation) or approximately 5
years, whichever comes first at an operating temperature of 20oC
and 333 hours of operation per month. (HDD access frequency of
20% or less)
• Using the Hard Disk in an environment that is excessively hot
and/or humid will shorten the disk’s usage lifetime. A wet bulb
temperature of 29oC or less is recommended. This is equivalent to
the following data.
*1 The front face of the PS-A unit, installed in a solid panel, has been tested using condi-
tions equivalent to the standard shown in the specification . Even though the PS-A unit’s
level of resistance is equivalent to this standard, oils that should have no effect on the
PS-A can possibly harm the unit. This can occur in areas where either vaporized oils are
present, or where low viscosity cutting oils are allowed to adhere to the unit for long
periods of time. If the PS-A’s front face protection sheet becomes peeled off, these condi-
tions can lead to the ingress of oil into the PS-A and separate protection measures are
suggested. Also, if non-approved oils are present, it may cause deformation or corrosion
of the front panel’s plastic cover. Therefore, prior to installing the PS-A, be sure to
confirm the type of conditions that will be present in the PS-A’s operating environment.
If the installation gasket is used for a long period of time, or if the unit and its gasket are
removed from the panel, the original level of the protection cannot be guaranteed. To
maintain the original protection level, Pro-face recommends that you replace the instal-
lation gasket regularly.


Structural
Grounding 100Ωor less, or your country’s applicable standard
Ratings*1
Equivalent to IP65f (JEM 1030)
(When Not Using front-face USB Port unit)
Design Type: Modular
Installation method: Panel / VESA Arm
Cooling Method Via Cooling Fans (for Unit/ for CPU)
Weight Approx. 8.0kg (17.6Ib)
Dimensions(WxHxD) 395 mm [15.55 in] x 294 mm [11.57 in.] x 100 mm [3.94 in.]
• In order to extend the lifetime of the hard disk, Pro-face recom-
mends you set the Windows [Control panel]-[Power Management
option]-[Turn off hard disks] selection to turn the hard disk off when
the unit is not being operated. A setting of 5 minutes is recom-
mended.
• When using CD-ROM Drive, be sure to use the PS-A unit where
no excessive vibration. It causes data read error.
Temperature Humidity
at 35oC no higher than 64%RH
at 40oC no higher than 44%RH

E-9


Serial Interface (COM1,COM2,COM3,COM4)


RS-232C Interface (COM1, COM2, COM3, COM4)
15
69
4Interfaces
Pin Arrangement PIN# Signal Condition Direction
1 CD Carrier Detect Input
2 RXD Receive Data Input
3 TXD Send Data Output
4 DTR Data Terminal Ready Output
5 GND SignalGround -
6 DSR Data SetReady Input
7 RTS RequestSend Output
8 CTS ClearSend Input
9 RI /5V Ring Indicate In/Output
FG FG FrameGround -


RS-422 Interface (COM3)
Pin# Signal Condition Direction
1 RXA NoConnection -
2 RXB Send Data In/Output
3 TXA Receive Data In/Output
4 NC No Connection -
5 GND Signal Ground -
6 NC No Connection -
7 TXB NoConnection -
8 NC No Connection -
9 NC No Connection -
FG FG FrameGround -


RS-485 Interface (COM3)
Pin# Signal Condition Direction
1 DATA+ Send Data In/Output
2 DATA- Receive Data In/Output
3 NC No Connection -
4 NC No Connection -
5 GND Signal Ground -
6 NC No Connection -
7 NC No Connection -
8 NC No Connection -
9 NC No Connection -
FG FG FrameGround -

E-10


Switches
The following switch settings corresponding to each Serial Interface need to be
signified. To set the switches, remove the PS-A’s Rear Cover and locate the fol-
lowing switches, next to the PS-A’s circuit board. For information about attaching/
removing the Rear Cover, 5. Installation
 Removing and Installing
the Rear Cover The switches are located as follows;
COM1
PCI
A
B
COM3
BAT
• COM3 and COM4 cannot be used for +5V Output.
• Do not connect any pins to COM3 [NC].
• No. 5 pin (GND) for RS-232C (COM1,COM2,COM3, COM4) is the
signal ground. Be sure to connect the GND terminal to the other
unit’s SG (signal ground) terminal.
• Be sure to confirm what settings will be used by the other device
when setting the switches. Failure to do so can result in a unit
malfunction or damage.
• Whenever changing any PS-A switch settings, be sure to first turn
the PS-A’s power supply OFF. Failure to do so can cause a PS-A
malfunction.
• Connect the FG terminal line to the connector cover's PS-A con-
nector attachment screw.
• FG and SG terminals are internally connected in the PS-A. When
connecting to another device, be sure to create an SG shorting
loop in your system.
Use inch type (#4-40UNC) threads to hold the cable's set (attachment) screws
in place.
Switch
Location Switch Name Description
A DIPSW1
8-pointdipswitch. Changesthe TouchPanel communicationmethod.
(Serial <---> USB) For details aboutDIPSW1, see Table (1). (If"Serial" is
selected,COM4 cannotbe used.) Factorysettingissameassettingsof
"Whenusing USB"described in Table(1).
B DIPSW2 10-pointdipswitch. Designatesthecommunicationmethodsettings. For detailsaboutDIPSW2,seeTable(2).
FactorysettingsareallOFF. (RS-232C)

E-11
T
XD
R
TS SW4
SW5
SW7
SW6
SW8
TXA
TXB
RXA
COM3
RXB
Table (1) DIPSW1
("Whenusing USB"aretheDIPSW1factory settings.)
DIPSW2 (SW4 to SW8) in the above table 2 operate as shown in the circuit
diagram below.
Fig. 1 DIPSW2 (SW4 to SW8) circuit diagram
DIPSW1
No. Description ON OFF When using
USB Whenusing COM4
1 Usedbythesystem Reserved Reserved OFF OFF
2ChangesTouchPanel'scommunciationmethod COM4 USB OFF ON
3SwitchestheCOM4Touch PanelReceiveData
CommunicationONorOFF Available NOT Available OFF ON
4SwitchestheCOM4Touch PanelSendData
CommunicationONorOFF Available NOT Available OFF ON
5SwitchestheExternal Device'susageofCOM4
ONorOFF Available NOT Available OFF ON
6 SwitchestheUSBReference VoltageONorOFF Available NOT Available ON OFF
7SwitchestheUSBTouchPanelPossitive (+)Data
CommunicationONorOFF Available NOT Available ON OFF
8SwitchestheUSBTouchPanelNegative (-)Data
CommunicationONorOFF Available NOT Available ON OFF
Table (2) DIPSW2
(Factory settings are all OFF.)
*1 If you use termination resistance, base your setiings on your connection specifica-
tions.
DIPSW2
No. Description ON OFF RS-232C RS-422 RS-485
1ChangesCOM1(RS-232C)
#9pin(RI<->+5V) +5V500mAexternaloutput possible RI ON/OFF ON/OFF ON/OF
F
2ChangesCOM3's
communciationmethod
RS-422/RS-485 RS-232C OFF ON ON
3ChangesCOM2(RS-232C)
#9pin(RI<->+5V) +5V500mAexternaloutput possible RI ON/OFF ON/OFF ON/OF
F
4ChangesTXdata'soutput
mode TXdataoutputiscontrolled via theRTSsignal TXdataoutputis NOTcontrolledvia theRTS
signal.(normallyoutput) OFF ON/OFF ON
5Switchesthe TXtermination
resistance ON/OFF Insertsterminationresistance of 220Ωbetween TXAandTXB. Notermination OFF ON
ON/OFF
*1
6Switchesthe RXtermination
resistance ON/OFF Insertsterminationresistance of 220Ωbetween RXAandRXB. Notermination OFF ON
ON/OFF
*1
7Switchesthe shortingofTXA
andRXAONorOFF
ShortsTXAandRXA
(RS-485mode)
Noshorting
(RS-422mode)
OFF OFF ON
8Switchesthe shortingofTXB
andRXBONorOFF
ShortsTXBand RXB
(RS-485mode)
Noshorting
(RS-422mode)
OFF OFF ON
9ChangesCOM3's
communciationmethod
RS-422/RS-485 RS-232C OFF ON ON
10 Usedbythesystem Reserved Reserved OFF OFF OFF

E-12


Keyboard / Mouse Interface
PS/2 compatible Keyboard / Mouse Interface


Ethernet Interface (10BASE-T / 100BASE-TX)
This interface complies with the IEEE802.3 Ethernet communication standard
(10BASE-T / 100BASE-TX) and uses an RJ-45 type modular jack connector (8
points).


CF Card Interface
This interface accepts a CF Card, and connects to IDE.
ElectricalSpecifications
O.D :Open Drain
T.S : 3 state I/O
TTL :TTLInput
D-sub 25 pin (Female)
Screw Size: (4-40): Inch Type
13 1
25 14
Pin
No.
SPP/ECP
Mode
Signal
Name
EPP
Mode
Signal
Name
Direction Electrical
Specif. Pin No.
SPP/ECP
Mode
Signal
Name
EPP
Mode
Signal
Name
Direction Electrical
Specif.
1STRBWRITE
In/Output O.D/T.S *1 14 AUTOFD DSTRB In/Output O.D/T.S*1
2 DATA0 DATA0 In/Output O.D 15 ERROR ERROR Input TTL
3 DATA1 DATA1 In/Output O.D 16 INIT INIT In/Output O.D/T.S*1
4 DATA2 DATA2 In/Output O.D 17 SLCTIN ADSTRB In/Output O.D/T.S*1
5 DATA3 DATA3 In/Output O.D 18 GND GND
6 DATA4 DATA4 In/Output O.D 19 GND GND
7 DATA5 DATA5 In/Output O.D 20 GND GND
8 DATA6 DATA6 In/Output O.D 21 GND GND
9 DATA7 DATA7 In/Output O.D 22 GND GND
10 ACKNLG ACKNLG Input TTL 23 GND GND
11 BUSY WAIT Input TTL 24 GND GND
12 PE PE Input TTL 25 GND GND
13 SLCT SLCT Input TTL
*1 Pins 1, 14, 16 and 17 will become O.D when the SPP mode specification is used. If the mode
changes to ECP or EPP, these pins will become T.S


Printer Interface (LPT1)
This interface conforms to Centronics standards.

E-13


USBInterface
This interface is for connecting USB compatible devices.
The USB port on the unit's Front face is USB Ver. 1.1 compatible.
The USB ports (2 ports) on the unit's Bottom face are USB Ver. 2.0 compatible.


PCMCIAInterface(PCMCIA)
These interfaces (2) are used to attach a PCMCIA Type II units.


SoundInterface
This interface uses 3 mini-pin jack connectors.


Expansion Unit Interface
This interface is used to attach a PCI unit.
5Installation
• Before installing the PS-A into a cabinet or panel, check that the installa-
tion gasket is securely attached to the unit.
• Agasketwhichhasbeenusedforalongperiodoftimemayhavescratches
or dirt on it, and could have lost much of its water resistance. Be sure to
change the gasket at least once a year, or when scratches or dirt be-
come visible.
• The corresponding gasket is CA3-WPG15-01.
• Be sure the gasket's seam is not inserted into any of the unit's corners,
only in the straight sections of the groove. Inserting it into a corner may
lead to its eventually tearing.
• To ensure the installation gasket's maximum level of moisture resis-
tance, be sure the gasket's seam is inserted as shown into the panel's
bottom face.


Confirm the Installation Gasket's Positioning
It is strongly recommended that you use the installation gasket.
Place the PS-A on a level surface with the display panel facing downward.
Check that the PS-A’s installation gasket is seated securely into the gasket’s groove,
which runs around the perimeter of the panel’s frame.
Gasket
Rear of PS-A unit


About Fan Cover
When installing the PS-A unit, or when attaching an optional item to the
PS-A unit, do not hold the PS-A unit by its rear-face fan cover while
performing the work. Doing so may damage the fan cover or cause the
cover to fall off.

E-14
• Do not tighten the screws with too much force, since it can damage
the PS-A unit.
• The torque necessary to create a drip-resistant seal is 0.5 N•m.
• Depending on the installation panel's thickness, etc., the number of installa-
tion fasteners used may need to be increased to provide the desired level of
moisture resistance.
• Be sure to use installation fastener model CA3-ATFALL-01.


Attach the Installation Fasteners from Inside the Panel
The following figures show the eight (8) insertion slot locations of the PS-A
installation fasteners. Insert the hook section into the slot and tighten the fas-
tener with a screwdriver, as shown.
Insertion Slots
Top View Bottom View
Right Side Left Side


Create a Panel Cut
Insert the PS-A into the panel from the front.
under 4-R3[0.12]
Unit: mm [in.]
Panel Panel thickness
1.6mm[0.06in] to
10mm[0.39in]
PS-A
383.5
[15.10 ]
+1
0
PS-A
Panel +0.04
0
282.5+1
0
+0.04 0
[11.12 ]
Installation
Fastener
Panel
PS-A

E-15
• To enhance the PS-A's maintainability, operability and ventilation, allow
at least 50 mm clearance between the PS-A and other objects. (The
clearance must be large enough to allow you to install or uninstall op-
tion units and to attach connectors.)
• Standard installation for the PS-A unit is in a vertical panel. If the PS-A
unit is to be installed in a slanted panel, the panel should not incline
more than 30° from the vertical.
• If the PS-A panel is to be installed in a slanted panel that inclines more
than 30°, use forced-air cooling to ensure the ambient operation tem-
perature does not exceed 50° C.
• Horizontal installation (that is, rotating the panel so that one of its sides
is the base) is not supported.


InstallationRequirements
(unit:mm[in.])
50
[1.97]
50
[1.97]


Attaching the PS-Ato a VESAArm or to the Wall
To attach the unit to an Arm or to a wall, use the attachment screws to attach a
commercial-type arm or wall mount adaptor to the PS-A's rear face. (Screw hole to
screw hole width: VESA 75mm)
Please refer to each device's installation guide for installation instructions.
The VESA Arm attachment screw hole dimensions are as follows;
(unit:mm[in.])
Rear Face
Insert and tighten the four (4) M4 screws. (6mm or shorter.) The torque required for
these screws is only 0.7 to 0.8 N.m.
75[2.95]
75[2.95]
50
[1.97]
50
[1.97]
50
[1.97]
50
[1.97]
50
[1.97]

E-16


Removing and Installing the Rear Cover
• Use a screwdriver to loosen or tighten the screws. Be sure not to
tighten screws too tightly, since it may damage the equipment.
• Be careful when removing or installing any screws that they do not
fall inside the PS-A.
Lay the PS-A unit on its side and remove the five (5) cover attachment screws. Slide
the rear cover up to remove it in the direction shown. (When reattaching the screws,
use a torque of 0.5 to 0.6N•m.)


USB Cable Clamp Installation
ThisholderpreventstheUSB cable from becoming disconnected due tovibration,etc.
1) Place the PS-Aunit face-down on a flat surface as shown below.Your PS-Aunit has two
USBconnectors.
• When using only one of the USB ports, be sure to use the lower USB connector.
This allows you to securely clamp the USB cable in the cable clamp.
Upper USB Connecto
r
Lower USB Connecto
r

E-17


Attachment
As shown below, insert the USB Cable Clamp’s band through the Bridge. Pass the USB cables
throughtheCableClamp’sbandand securely tighten the clamp band around the cables.
• Be sure the clamp is securely holding the USB cable’s plug and collar.
• Be sure the clamp is positioned as shown below, with the clamp pointing
upwards - not to the side. This is to keep the clamp from interfering with
nearby connectors and their cables.
Clamp
Bridge
USB Cables
Cable Collars


Removal
To remove the clamp from the USB cables, push down on the clamp strap’s clip to release it while
pullingupontheclamp.
Clamp
Strap Clip

E-18


Installing theAC Power Cord Clamp
• Be sure to connect the power cord only after confirming that the
PS-A unit rear face power switch is turned OFF.


Attaching the AC Power Cord
1) Open theAC Power Cord Clamp and insert theAC Power Cord as shown in fig. 1. Then,
close the Cord Clamp until it clicks into place and locks around theAC Power Cord Collar.
• The Cord Clamp has four teeth for locking. These are to adjust the amount of
grip used to hold the AC Power Cord Collar.
Figure 1
AC Plug Collar
AC Plug
Cord Clamp
6Wiring
• To avoid an electric shock, check that the PS-A's power supply is
turned OFF, via a breaker, or similar unit before connecting the
PS-A's power cord to the AC connector.
• To avoid the dangers of fire, electric hazards and equipment dam-
age, be sure to use only the specified voltage when operating the
PS-A.
WARNINGS
*1 L : AC Input Terminal-live line
N : AC Input Terminal-neutral line
FG : Ground Terminal connected to the PS-A chassis
Insert the power cord (AC inlet plug) into the PS-A's bottom face AC connector.
N
L
FG
AC Connector*1
• The Power Cord included in the PS-A unit’s package is designed only for
AC100V or AC115V use. Any other voltage will require a different cord.

E-19
•If the power supply voltage exceeds the PS-A unit's range, connect a
voltage transformer.
•Between the line and the ground, be sure to use a low noise power supply.
If there is still an excessive amount of noise, connect a noise reducing
transformer.
Be sure any constant or insulating transformer used has a capacity of
200VA or more.
7Power Supply Cautions
Please pay special attention to the following instructions when connecting
the AC Connector to the PS-A unit.
3) Insert the Cord Clamp Lock Pin into the PS-A’s Lock Pin Hole.
4)Adjustthe Lock Pin’s LockTablengthuntilit is securely held.
 
 
 Removing the AC Power Cord
1) While lifting up on the Lock Pin’s Lock Tab Release, pull theAC Plug, Plug Collar and Cord
Clamp backwards to disconnect it from the PS-A.
2) Open the Cord Clamp and remove theAC Power Cord from the Cord Clamp.
Figure 2
2)
3)
4)
Cord Clamp Lock Pin
Lock Pin Hole
Lock Tab Release
CordClamp
ACPlug
ACPlugCollar
2) Connect theAC plug to the PS-A’sAC connector, as shown in fig. 2.
ACConnector

E-20
10 Replacing the Backlight
9Input/Output Signal Line Cautions
•Input and Output signal lines must be separated from the power control cables
for operational circuits.
•If this is not possible, use a shielded cable and the shield should be grounded.
• To improve noise immunity, it is recommended to attach a ferrite core to the
power cord.
Using any backlight other than the model written above may
cause an accident or PS-A unit malfunction.
© 2003 Digital Electronics Corporation. All rights reserved
8Grounding Cautions
•When attaching a wire to the PS-A's bottom face FG terminal, (on the AC
Connector), be sure to create an exclusive ground.*1
•FG and SG terminals are internally connected in the PS-A. When connecting to
another device, be sure to create an SG shorting loop in your system.
*1 Use a grounding resistance of 100 Ω , a wire of 2mm2or thicker, or your country's
applicable standard.
•Input and Output signal lines must be separated from the power control cables
for operational circuits.
•To increase the noise resistance, be sure to twist the ends of the power cord
before connecting it to the PS-A unit.
•The PS-A unit's power cord should not be bundled with or kept close to main
circuit lines (high voltage, high current), or input/output signal lines.
•Connect a surge absorber to handle power surges.
• Ground the lightning surge absorber and the PS-A separately.
• Select a lightning surge absorber which will not exceed the allow-
able circuit voltage, even when the voltage rises to the maximum.
•To reduce noise, make the power cord as short as possible.
Note
Be aware that the Digital Electronics Corporation shall not be held liable for any real or
estimated damages or losses, or third party claims resulting from the use of this product.
The PS-A unit's backlight is user replacable. For an explanation of how to replace
the PS-A's backlight, please refer to the Installation Guide which comes with the
replacement backlights (sold separately). The corresponding backlight is CA3-
BLU15-01.
