USER’S MANUAL
Model No. PFBE19618.0
Serial No.
Write the serial number in the space
above for reference.
Serial Number
Decal
CAUTION
Read all precautions and
instructions in this manual before
using this equipment. Keep this
manual for future reference.
proform.com
To register your product and
activate your warranty today,
go to my.proform.com.
For service at any time, go to
proformservice.com.
Or call 1-888-533-1333
Mon.–Fri. 6 a.m.–6 p.m. MT
Sat. 8 a.m.–12 p.m. MT
Please do not contact the store.
ACTIVATE YOUR
WARRANTY
CUSTOMER CARE

2
WARNING DECAL PLACEMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
IMPORTANT PRECAUTIONS..................................................................3
SETUP AND ADJUSTMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
EXERCISE GUIDELINES .....................................................................7
ORDERING REPLACEMENT PARTS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Back Cover
LIMITED WARRANTY. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Back Cover
TABLE OF CONTENTS
PROFORM is a registered trademark of ICON Health & Fitness, Inc.
WARNING DECAL PLACEMENT
362388
This drawing shows the location(s) of the warning decal(s). If
a decal is missing or illegible, see the front cover of this
manual and request a free replacement decal. Apply the
decal in the location shown. Note: The decal(s) may not be
shown at actual size.
(two on each side)
(one on each handle)
(one on each handle)

3
1. It is the responsibility of the owner to
ensure that all users of the pilates chair are
adequately informed of all precautions.
2. Before beginning any exercise program,
consult your physician. This is especially
important for persons over age 35 or persons
with pre-existing health problems.
3. The pilates chair is not intended for use by
persons with reduced physical, sensory, or
mental capabilities or lack of experience and
knowledge, unless they are given supervi-
sion or instruction about use of the pilates
chair by someone responsible for their
safety.
4. Use the pilates chair only as described in
this manual and in the included instructional
materials.
5. The pilates chair is intended for home
use only. Do not use the pilates chair in a
commercial, rental, or institutional setting.
6. Keep the pilates chair indoors, away from
moisture and dust. Do not put the pilates
chair in a garage or covered patio, or near
water.
7. Use the pilates chair only on a level surface.
Place a mat beneath the pilates chair to
protect the floor. Make sure that there is
enough clearance around the pilates chair to
mount, dismount, and use the pilates chair.
8. Make sure that all parts are properly
tightened each time the pilates chair is used.
Replace any worn parts immediately.
9. Keep children under age 13 and pets away
from the pilates chair at all times.
10. The pilates chair is designed to support a
maximum user weight of 250 lbs. (114 kg).
11. Keep hands and feet away from moving
parts.
12. Always tie loose hair up and out of the way
while using the pilates chair.
13. Always wear eye protection while using the
pilates chair.
14. Always wear athletic shoes for foot
protection while using the pilates chair.
15. Use the hand cords only when seated on the
pilates chair. Do not use the hand cords while
standing.
16. Move the pedals upward and downward in a
controlled manner. Maintain tension on the
pedals so that they do not move quickly and
strike your body or other objects.
17. Over exercising may result in serious injury
or death. If you feel faint, if you become short
of breath, or if you experience pain while
exercising, stop immediately and cool down.
IMPORTANT PRECAUTIONS
WARNING: To reduce the risk of serious injury, read all important precautions and
instructions in this manual and all warnings on your pilates chair before using your pilates chair.
ICON assumes no responsibility for personal injury or property damage sustained by or through the
use of this product.

4
STANDARD SERVICE PLANS

5
SETUP AND ADJUSTMENT
HOW TO UNFOLD THE PILATES CHAIR
To unfold the pilates
chair for use, first
raise it to the position
shown.
Then, firmly hold the
front and rear edges
of the seat (1), and
rotate the seat in the
direction shown by
the arrows until the
seat is level. As you
do this, the front and
rear legs (2, 3) will
unfold.
HOW TO USE THE HAND CORDS
To use the hand cords (4), attach them to any of the
hooks (5) on the frame.
HOW TO ADJUST THE PEDALS
The pedals can be used in either of two positions.
When the pedals are in the low position, you can
exercise by pulling the pedals upward. When the
pedals are in the high position, you can exercise by
pushing the pedals downward.
To adjust the pedals (6), pull the adjustment knob (7)
outward, move the pedals to the low or high position,
and then release the adjustment knob. Move the ped-
als upward or downward slightly to make sure that
the adjustment knob is engaged in one of the two
adjustment holes (not shown).
When the pedals
(6) are in the high
position, you can
add resistance with
the pedal cords (8)
beneath the seat.
Attach the pedal
cords to the hooks
(9) on the pedals.
For maximum resis-
tance, attach the
pedal cords to the
hooks closest to the pedal pads (10).
1
2
3
95% compared to other
drawings on this page
55
5
5
4
4
95% compared to other
drawings on this page
7
6
8
9
6
10
The information below explains how the pilates chair can be unfolded and adjusted for use and folded for storage.
See the accompanying instructional materials to see the correct form for several exercises.
Make sure that all parts are properly tightened each time you use the pilates chair. Replace any worn parts
immediately. The pilates chair can be cleaned with a damp cloth and mild, non-abrasive detergent; never use
solvents to clean the pilates chair.

6
You can also lock the pedals (6) together or use them
independently. To lock the pedals together, pull the
pedal knob (11) upward, slide it to the position shown
in drawing a, and then lower it. To use the pedals
independently, pull the pedal knob upward, slide it to
the position shown in drawing b, and then lower it.
HOW TO FOLD THE PILATES CHAIR
When the pilates chair is not in use, you can fold it to a
compact storage position. First, adjust the pedals (6) to
the high position (see HOW TO ADJUST THE PEDALS
on page 5).
Then, lift the seat (1) in the indicated location, and
push one of the front legs (2) toward the rear legs (3)
until the pilates chair is folded.
95% compared to other
drawings on this page
95% compared to other
drawings on this page
11 11
ab
66
1
6
2
3

7
EXERCISE GUIDELINES
WORKOUT GUIDELINES
Familiarize yourself with the equipment and learn the
proper form for each exercise. Use your own judgment
to determine the appropriate length of time for each
workout and the numbers of repetitions and sets to
complete. Progress at your own pace and be sensitive
to your body’s signals. Follow each strength workout
with at least one day of rest.
Note: A “repetition” is one complete cycle of an exer-
cise, such as one push-up. A “set” is a series of
repetitions.
Warming Up—Start with 5 to 10 minutes of light
exercise. A warm-up increases your body temperature,
heart rate, and circulation in preparation for exercise.
Working Out—Include 5 to 10 different exercises in
each workout. Select exercises for every major muscle
group, emphasizing areas that you want to develop.
To give balance and variety to your workouts, vary the
exercises from workout to workout.
Cooling Down—Finish with 5 to 10 minutes of stretch-
ing. Stretching increases the flexibility of your muscles
and helps to prevent post-exercise problems.
Cross Training—Combine strength training and
aerobic exercise by following this type of program:
• Strength workouts on Monday, Wednesday, and
Friday
• 20 to 30 minutes of aerobic exercise on Tuesday and
Thursday
• One full day of rest each week to give your body time
to regenerate
EXERCISE FORM
Move through the full range of motion for each exer-
cise, and move only the appropriate parts of the body.
Perform the repetitions in each set smoothly and
without pausing. The exertion stage of each repeti-
tion should last about half as long as the return stage.
Exhale during the exertion stage of each repetition and
inhale during the return stroke. Never hold your breath.
Rest for a short period of time after each set:
• Muscle Building—Rest for three minutes after each
set.
• Toning—Rest for one minute after each set.
• Weight Loss—Rest for 30 seconds after each set.
STAYING MOTIVATED
For motivation, keep a record of each workout. Write
the date, the exercises performed, the resistance used,
and the numbers of sets and repetitions completed.
Record your weight and key body measurements once
a month.
To achieve good results, make exercise a regular and
enjoyable part of your life.

Part No. 401107 R0518A Printed in China © 2018 ICON Health & Fitness, Inc.
ORDERING REPLACEMENT PARTS
ICON Health & Fitness, Inc. (ICON) warrants this product to be free from defects in workmanship and
material, under normal use and service conditions. The frame is warranted for one (1) year from the date
of purchase. Parts and labor are warranted for ninety (90) days from the date of purchase.
This warranty extends only to the original purchaser (customer) and is not transferrable. ICON’s obliga-
tion under this warranty is limited to repairing or replacing, at ICON’s option, the product through one of
its authorized service providers. All repairs for which warranty claims are made must be preauthorized by
ICON. If replacement parts are shipped while the product is under warranty, the customer will be respon-
sible for a minimal handling charge. For in-home service, the customer may be responsible for a minimal
trip charge. This warranty does not extend to freight damage to the product. This warranty will automati-
cally be voided by the following conditions: (1) if the product is used as a store display model, (2) if the
product is purchased or transported outside the USA, (3) if all instructions and warnings in this manual are
not followed, (4) if the product is abused or improperly or abnormally used, or (5) if the product is used for
commercial or rental purposes. No other warranty beyond that specically set forth above is authorized
by ICON.
ICON is not responsible or liable for the following damages: (1) indirect, special, or consequential dam-
ages arising out of or in connection with the use or performance of the product; (2) damages with respect
to any economic loss, loss of property, loss of revenues or prots, loss of enjoyment or use, or costs of
removal or installation; or (3) other consequential damages of any kind. Some states do not allow the
exclusion or limitation of incidental or consequential damages. Accordingly, the above limitation may not
apply to the customer.
The warranty extended hereunder is in lieu of any and all other warranties, and any implied warranties of
merchantability or tness for a particular purpose are limited in their scope and duration to the terms set
forth herein. Some states do not allow limitations on how long an implied warranty lasts. Accordingly, the
above limitation may not apply to the customer. This warranty provides specic legal rights; the customer
may have other rights that vary from state to state.
For warranty service, please call the telephone number on the front cover of this manual. Please be pre-
pared to provide the model number and serial number of the product (see the front cover of this manual).
ICON Health & Fitness, Inc., 1500 S. 1000 W., Logan, UT 84321-9813
LIMITED WARRANTY
IMPORTANT: To protect your fitness equipment with an extended service plan, see page 4.
For information about available replacement parts, see the front cover of this manual. To help us assist you, be
prepared to provide the following information when contacting us:
• the model number and serial number of the product (see the front cover of this manual)
• the name of the product (see the front cover of this manual)
• the key number and description of the replacement part(s) (see SETUP AND ADJUSTMENT on page 5)
