USERʼS MANUAL
Visit our website
www.iconsupport.eu
Model No. : PFIVEL63012.0
Serial No ___________
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Keep this manual
for future reference.
QUESTIONS ?
If you have questions, or if there are
missing parts, please contact us:
UK
Call: 08457 089 009
From Ireland: 053 92 36102
Website: www.iconsupport.eu
E-mail: [email protected]
Write:
ICON Health & Fitness, Ltd.
c/o HI Group PLC
Express Way
Whitwood, West Yorkshire
WF10 5QJ
UK
Write the serial number in the
space above for reference.
Serial number decal

2
TABLE OF CONTENTS
IMPORTANT PRECAUTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
BEFORE YOU BEGIN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
WARNING DECAL PLACEMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
ASSEMBLY. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
HOW TO OPERATE THE ELLIPTICAL. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
FEATURES OF THE CONSOLE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
MAINTENANCEAND TROUBLESHOOTING. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
EXERCISE GUIDELINES. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
NOTES. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
EXPLODED DRAWINGS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
PART LIST . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
ORDERING REPLACEMENT PARTS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Last Page

3
IMPORTANT PRECAUTIONS
WARNING : To reduce the risk of serious injury, read all important precautions and
instructions in this manual and all warnings on your elliptical before using your elliptical. ICON
assumes no responsibility for personal injury or property damage sustained by or through the
use of this product.
1. Before beginning any exercise program, con-
sult your physician. This is especially important
for persons over age 35 or persons with pre-
existing health problems.
2. Use the elliptical only as described in this
manual.
3. It is the responsibility of the owner to ensure
that all users of the elliptical are adequately
informed of all precautions.
4. The elliptical is intended for home use only.
Do not use the elliptical in a commercial, rental,
or institutional setting.
5. Keep the elliptical indoors, away from mois-
ture and dust. Place the elliptical on a level sur-
face, with a mat beneath it to protect the oor
or carpet. Make sure that there is at least 3 ft.
(0.9 m) of clearance in the front and rear of the
elliptical and 2 ft. (0.6 m) on each side.
6. Inspect and properly tighten all parts regu-
larly. Replace any worn parts immediately.
7. Keep children under age 12 and pets away
from the elliptical at all times.
8.The elliptical should not be used by persons
weighing more than 250 lbs. (115 kg).
9. Wear appropriate clothes while exercising;
do not wear loose clothes that could become
caught on the elliptical. Always wear athletic
shoes for foot protection while exercising.
10. Hold the handlebars or the upper body arms
when mounting, dismounting, or using the el-
liptical.
11. The pulse sensor is not a medical device.
Various factors may affect the accuracy of heart
rate readings. The pulse sensor is intended
only as an exercise aid in determining heart
rate trends in general.
12. The elliptical does not have a freewheel; the
pedals will continue to move until the ywheel
stops. Reduce your pedaling speed in a con-
trolled way.
13. Keep your back straight while using the el-
liptical; do not arch your back.
14. Over exercising may result in serious injury
or death. If you feel faint or if you experience
pain while exercising, stop immediately and
cool down.

4
BEFORE YOU BEGIN
Thank you for purchasing the ProForm® Elipse
4.0. The elliptical provides an array of features
designed to make your workouts at home more
effective and enjoyable.
For your benet, read this manual carefully be-
fore you use the elliptical. If you have questions
after reading this manual, please see the front
cover of this manual. To help us assist you, note
the product model
number and serial number before contacting us.
The model number is PFIVEL63012.0 and the lo-
cation of the serial number decal are shown on the
front cover of this manual.
Before reading further, please familiarize yourself
with the parts that are labeled in the drawing be-
low.
115 Kg
115 Kg
115 Kg
ENGLISH
115 Kg
WARNING DECAL PLACEMENT
This drawing shows the location(s) of
the warning decal(s). If a decal is miss-
ing or illegible, call the telephone num-
ber on the front cover of this manual
and request a free replacement decal.
Apply the decal in the location shown.
Note: The decal(s) may not be shown
at actual size.

5
ASSEMBLY
Assembly requires two persons. Place all parts of the exercise cycle in a cleared area and remove
the packing materials. Do not dispose of the packing materials until assembly is completed.
In addition to the included tool(s), assembly requires an adjustable wrench and a Phillips
screwdriver .
Use the part drawings below to identify the small parts used in assembly. The number in parenthe-
ses below each drawing refers to the key number of the part, from the PART LIST near the end of
this manual. The number following the parentheses is the quantity needed for assembly. Note: Some
small parts may have been preassembled. If a part is not in the hardware kit, check to see if it has
been preassembled.

6
STEP 1
Fix the Front bottom tube (7) and the Rear bottom
tube (8) onto the Main frame (1) with the Allen pan
head screw (11), Curved washer (12) and acorn
nut(13) as shown.
STEP 2
While another person holds the Upright (2) near
the Frame (1), connect the Extension Wire (30) to
the sensor Wire (31).
Next, connect the Resistance Cable (17) to the
Lower Cable (32) in the following way:
• See drawing A. Pull upward on the metal bracket
on the Lower Cable (32), and insert the tip of the
Resistance Cable (17) into the wire clip inside the
metal bracket as shown.
• See drawing B. Firmly pull the Resistance Cable
(17) upward and slide it into the top of the metal
bracket as shown.
• See drawing C. Using pliers, squeeze the prongs
on the upper end of the metal bracket together.
Push the Wires (30, 31) and the Cables (17, 32)
downward into the Frame (1).
Tip: Do not pinch the wires and cables. Insert the
Upright (4) into the Frame (1). Attach the Upright
with four Screws (15) and four Curved washer (12).
ABC
9
6
6
9
32 11
16 Metallic
support
Metallic
support
17

7
STEP 3
Attach the Swing tube (4L/R) to the Axle of Handle-
bar post (2) with Hex bolt (21) and Flat washer (20).
But don’t tighten them rstly.
STEP 4
Attach the Pedal tube (3L/R) to the Cross bar (78) with Flat washer (27)and Nylon nut(28), then tighten the
Hex bolt (21) and Nylon nut (28). Finally cover the End cap (29)&(35) respectively.

8
STEP 5
Fix the Fixed handlebar (6) to the Handlebar post (2)
with the Bolts (14), Arc washers (12) and Acorn nuts
(13).
STEP 6
Fix Handlebar (5L/R) to the Swing tubes (4L/R) with
Bolts (16), Arc washers (12) and Acorn nuts (13).
Connect the Extension wire (30) well with the wire of
Computer(
10).Then x the computer(10) on the handlebar post (2)
with Screws (33) . Finally insert the Pulse sensor wire
(36) into the hole bottom of computer (10).

9
HOW TO EXERCISE ON THE ELLIPTICAL
EXERCISER
To mount the elliptical exerciser, hold the upper body
arms and step onto the pedal that is in the lowest
position. Then, step onto the other pedal. Push the
pedals until they begin to move with a continuous
motion.
Note: The pedal discs can turn in either direction. It is
recommended that you move the pedal discs in the
direction shown by the arrow;
however, for variety, you may turn the pedal discs
in the opposite direction.
The upper body arms are designed to add upper-
body exercise to your workouts. As you exercise,
push and pull the upper body arms to work your
arms, shoulders, and back. To focus on lower-body
exercise, hold the upper body arms but do not push
or pull them as you exercise.
To dismount the elliptical exerciser, wait until the
pedals come to a complete stop. Note: The elliptical
exerciser does not have a free wheel; the pedals
will continue to move until the ywheel stops.
When the pedals are stationary, step off the highest
pedal rst. Then, step off the lower pedal.
MEASURE YOUR HEART RATE IF DESIRED
You can measure you heart rate using either the
handgrip pulse sensor or the optional chest pulse
sensor.
Note: If you hold the handgrip pulse sensor and
wear the chest pulse sensor at the same time, the
console will not display your heart rate accurately.
If there are sheets of clear plastic on the metal
contacts on the handgrip pulse sensor, remove
the plastic. In addition, make sure that your hands
are clean. To measure your heart rate, hold the
handgrip pulse sensor with your palms resting
against the metal contacts. Avoid moving your
hands or gripping the contacts tightly.
When you are nished exercising
If the pedals do not move for several minutes and
the buttons are not pressed, the console will turn
off and the display will be reset.
HOW TO USE THE ELLIPTICAL
Contacts

10
IInspect and tighten all parts of the exercise cycle
regularly.
Replace any worn parts immediately.
To clean the exercise cycle, use a damp cloth and a
small amount of mild detergent.
Important: To avoid damaging the console, keep
liquids away from the console and keep the console
out of direct sunlight.
BATTERY REPLACEMENT
If the console display becomes dim, the batteries
should be replaced; most console problems are the
result of low batteries.
The console requires two 1,5V AA batteries; alkaline
batteries are recommended. Remove the battery
cover from the console. Insert two batteries into the
console.
Make sure that the batteries are oriented as shown
by the diagram inside the console. Then, reattach
the battery cover.
MAINTENANCE AND TROUBLESHOOTING
