Pro-Form PFVB09988.0 User manual

Model No. WECCBE10000
Serial No.
Serial Number Decal
USER'S MANUAL
CAUTION
Read all precautions and instruc-
tions in this manual before
using this equipment. Save this
manual for future reference.
www.weiderfitness.com
Visit our website at
QUESTIONS?
As a manufacturer, we are
committed to providing com-
plete customer satisfaction. If
you have questions, or if
there are missing parts, we
will guarantee complete satis-
faction through direct assis-
tance from our factory.
TO AVOID UNNECESSARY
DELAYS, PLEASE CALL
DIRECT TO OUR TOLL-FREE
CUSTOMER HOT LINE. The
trained technicians on our
customer hot line will provide
immediate assistance, free of
charge to you.
CUSTOMER HOT LINE:
1-888-936-4266
Mon.–Fri., 8 a.m.–6:30 p.m.
EST (excluding holidays)

2
TABLE OF CONTENTS
IMPORTANT PRECAUTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
BEFORE YOU BEGIN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
ASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
ADJUSTING THE WEIDER®SLANT BOARD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
EXERCISE FORM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
PART LIST AND EXPLODED DRAWING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
CUSTOMER RECORD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
ORDERING REPLACEMENT PARTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
LIMITED WARRANTY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Back Cover
WEIDER is a registered trademark of ICON Health & Fitness, Inc.

3
IMPORTANT PRECAUTIONS
WARNING: To reduce the risk of serious injury, read the following important precautions
before using the WEIDER®slant board.
1. Read all instructions in this manual before
using the slant board.
2. It is the responsibility of the owner to ensure
that all users of the slant board are adequate-
ly informed of all precautions.
3. Use the slant board only as described in this
manual.
4. Use the slant board only on a level surface.
Cover the floor beneath the slant board to
protect the floor.
5. Inspect and tighten all parts regularly.
Replace any worn parts immediately.
6. Keep children under the age of 12 and pets
away from the slant board at all times.
7. The slant board should not be used by per-
sons weighing more than 250 pounds
(115 kg).
8. Wear appropriate clothing when exercising;
always wear athletic shoes for foot protection.
9. When using the slant board, make sure that
the locking pin is fully inserted and clipped
around the swing arm.
10. If you feel faint, dizzy, or short of breath at
any time while exercising, stop immediately
and begin cooling down.
11. The slant board is intended for home use
only. Do not use the slant board in any com-
mercial, rental, or institutional setting.
WARNING: Before beginning this or any exercise program, consult your physician. This
is especially important for persons over the age of 35 or persons with pre-existing health problems.
Read all instructions before using. ICON assumes no responsibility for personal injury or property
damage sustained by or through the use of this product.

4
BEFORE YOU BEGIN
Thank you for selecting the innovative WEIDER®slant
board. The WEIDER®slant board is designed to help
you develop your upper and lower abdominal muscles
for a firm, flat stomach, in only minutes a day.
For your benefit, read this manual carefully before
using the WEIDER®slant board. If you have ques-
tions, please call our Customer Service Depart-ment
toll-free at 1-888-936-4266, Monday through Friday, 8
a.m. until 6:30 p.m. Eastern Standard Time (excluding
holidays). To help us assist you, please note the prod-
uct model number and serial number before calling.
The model number is WECCBE10000. The serial
number can be found on a decal attached to the slant
board (see the front cover of this manual).
Before reading further, please familiarize yourself with
the parts that are labeled in the drawing below.
Backrest
Swing Arm
Foam Pad
Locking Pin
Handgrip
Adjustment Foot

5
2. Press two 1 3/4” Cover Caps (10) onto the
Adjustment Foot (4).
Press two 3/4” Inner Caps (12) into the Short Pad
Bar (7). Slide the Swing Arm (3) onto the
Adjustment Foot (4) and align the hole in the Swing
Arm with one of the holes in the Adjustment Foot.
Slide the Short Pad Bar into the holes in the Swing
Arm and the Adjustment Foot.
Wet the ends of the Short Pad Bar (17) with soapy
water. Slide a Large Foam Pad (8) onto each end of
the Short Pad Bar.
ASSEMBLY
Before beginning assembly, carefully read the
following information and instructions:
• Place all parts in a cleared area and remove the
packing materials; do not dispose of the packing
materials until assembly is completed.
• Read each assembly step before you begin.
• Tighten all parts as you assemble them, unless
instructed to do otherwise.
• During assembly, make sure that all parts are ori-
ented as shown in the drawings.
The following tools (not included) are required:
• one adjustable wrench
• one Phillips screwdriver
Assembly will be more convenient if you have the
following tools: A socket set, a set of open-end or
closed-end wrenches, or a set of ratchet wrenches.
16
17
12
5
53
1
1. Before beginning assembly, make sure that you
have read the information above.
Press a 1 1/2” Square Inner Cap (16) into the top of
the Swing Arm (3).
Press two 3/4” Inner Caps (12) into the Long Pad
Bar (17). Slide the Long Pad Bar into the indicated
hole in the Swing Arm (3).
Wet the ends of the Long Pad Bar (17) with soapy
water. Slide a Small Foam Pad (5) onto each end of
the Long Pad Bar.
8
12
7
8
3
4
2
10

6
15
14
13
16
2
Holes
10
2
3
3
4
3. Press a 1 1/2” Square Inner Cap (16) into the open
end of the Backrest Frame (2).
Align the indicated holes in the Backrest Frame (2)
with the holes in the Swing Arm (3). Attach the
Backrest Frame to the Swing Arm with the 5/16” x
2 1/2” Bolt (14), the 5/16” Nylon Locknut (13), and
the Locking Pin (15). Make sure that the Locking
Pin is fully inserted and clipped around the
Swing Arm. Be careful not to overtighten the
Nylon Locknut; the Swing Arm must be able to
pivot for storage.
4. Press two 1 3/4” Cover Caps (10) onto the Backrest
Frame (2).
5. Attach the Backrest (1) to the Backrest Frame (2)
with the two 1/4” x 3/4” Screws (6), the 1/4” x 2 1/4”
Screw (9), and the 1/4” Flat Washer (11). 1
2
9
11
6
5

7
ADJUSTING THE LEVEL OF THE BACKREST
To change the level of the Backrest (1), first remove
one of the Large Foam Pads (8) from the Short Pad Bar
(7). Remove the Short Pad Bar from the Swing Arm (3)
and the Adjustment Foot (4). Align the hole in the Swing
Arm with a different hole in the Adjustment Foot and re-
insert the Short Pad Bar. Then, re-attach the Large
Foam Pad.
FOLDING THE SLANT BOARD FOR STORAGE
The slant board can be folded for compact storage. To
fold the slant board, first remove the Locking Pin (15)
from the Swing Arm (3) and the Backrest Frame (2).
Fold the Swing Arm under the Backrest Frame. Re-
insert the Locking Pin into the Swing Arm for safekeep-
ing.
ADJUSTING THE WEIDER®SLANT BOARD
The steps below explain how the WEIDER®slant board can be adjusted. Refer to page 8 for exercise informa-
tion.
Inspect and tighten all parts each time you use the slant board. Replace any worn parts immediately. The slant
board can be cleaned with a damp cloth and mild, non-abrasive detergent; do not use solvents.
1
3
8
7
4
15
3
2
1

8
EXERCISE FORM
LEG RAISES
Lie on the bench, grasp the handgrips, and extend your legs as shown. Lift your legs with a slow, steady
motion—avoid rapid or jerky movements. Return to the starting position. Repeat.
CRUNCHES
Lie on the bench and tuck your feet under the foam pads as shown. Bend forward at the waist, keeping your
back straight, and sit up as shown. Return to the starting position. Repeat.
The WEIDER®slant board is a versatile exercise
bench that will help you shape your upper and lower
abdominal muscles. Be careful not to overdo it during
the first few weeks of your exercise program.
To get the most from your exercise, proper form is
important. As you perform each repetition, use your
abdominal muscles to pull yourself up, moving with a
smooth, continuous motion.
Always begin and end each workout with a few min-
utes of stretching. Remember to keep plenty of water
nearby as you exercise, and drink periodically to avoid
dehydration. If you feel faint, dizzy, or short of
breath at any time while exercising, stop immedi-
ately and begin cooling down.
WARNING: Before beginning this
or any exercise program, consult your physi-
cian. This is especially important for persons
over the age of 35 or persons with pre-exist-
ing health problems.

9
Key No. Qty. Description
1 1 Backrest
2 1 Backrest Frame
3 1 Swing Arm
4 1 Adjustment Foot
5 2 Small Foam Pad
6 2 1/4” x 3/4” Screw
7 2 Short Pad Bar
8 2 Large Foam Pad
9 1 1/4” x 2 1/4” Screw
Key No. Qty. Description
10 4 1 3/4” Cover Cap
11 1 1/4” Flat Washer
12 4 3/4” Inner Cap
13 1 5/16” Nylon Locknut
14 1 5/16” x 2 1/2” Bolt
15 1 Locking Pin
16 2 1 1/2” Square Inner Cap
17 1 Long Pad Bar
# 1 User’s Manual
PART LIST and R0601A
EXPLODED DRAWING—Model No. WECCBE10000
15
14
5
16
3
13
5
8
12
12
7
8
1
2
6
10
10
4
10
10
9
11
12
12
17
16
Note: # indicates a non-illustrated part. Specifications are subject to change without notice.

10
Model No.: __________________________________ Serial No.: ____________________________________
Retailer Name: ________________________________________ Purchase Date: _______________________
Retailer Address: ____________________________________________________________________________
CUSTOMER RECORD
