Pro-Lift T-2501 User manual

Hydraulic Transmission Jack, Telescopic
Model Capacity
T-2501 700 lb.
T-2501-M0 _092018
Read this manual and follow all the Safety Rules and Operating Instructions before using this product.
This is the safety alert symbol. It is used to alert you to potential personal injury hazards.
Obey all safety messages that follow this symbol to avoid possible injury or death.
!
To avoid crushing and related injuries:
NEVER work on, under or around a
load supported only by a hydraulic
jack. Immediately transfer the load to
an appropriate work station.
WARNING: Cancer and Reproductive Harm.
AVERTISSEMENT: Cancer et dommages au système reproducteu
r.
ADVERTENCIA: Cáncer y daño reproductivo.
www.P65Warnings.ca.gov
WARNING
!

2
SAFETY and GENERAL INFORMATION
Save these instructions. For your safety, read, understand, and follow the information provided with and on this jack
before using. The owner and operator of this equipment shall have an understanding of this jack and safe operating
procedures before attempting to use. The owner and operator shall be aware that use and repair of this product
may require special skills and knowledge. Instructions and safety information shall be conveyed in the operator's
native language before use of this jack is authorized. If any doubt exists as to the safe and proper use of this jack,
remove from service immediately.
Inspect before each use. Do not use if broken, bent, cracked or damaged parts are noted. Any jack that appears
damaged in any way, or operates abnormally shall be removed from service immediately. If the jack has been or
suspected to have been subjected to a shock load (a load dropped suddenly, unexpectedly upon it), immediately
discontinue use until jack has been checked by a factory authorized service center (contact distributor or manufacturer
for list of authorized service centers). It is recommended that an annual inspection be done by qualied personnel.
Labels and Operator's Manuals are available from manufacturer.
PRODUCT DESCRIPTION
Hydraulic Transmission Jack is designed to be used as an aid in the removal and installation of automotive and
light truck transmissions, transfer cases and transaxles. This telescopic style transmission jack is for use under an
overhead lift or in a garage pit.
NEVER use for any purpose other than those uses outlined above!
!
SPECIFICATIONS
Model Capacity Min.
Height
Max.
Height Saddle Base Extended Saddle Area Jack Size Volume of Hyd. Oil
T-2501 700 lb. 57 1/4" 76 3/8" 9 7/8" x 9 7/8" 18 7/8" x 18 7/8" 36 1/8" x 32 5/8" 695 mL

3
PREPARATION
Assembly (refer to Figure 1)
Tools required: M16 & M18 wrench.
1. Four major parts should be included in the package:
(a) Hydraulic unit; (b) Upright Post; (c) Saddle Assembly; (d) 2 pieces of base half with hardware.
2. Attach the base halves to the upright post, then secure using threaded pins, washers and M12 nuts.
3. Attach the casters onto the base halves using M12 nuts and washers.
4. Place hydraulic unit on top of the upright post and secure with M10x25 bolts and washers.
5. Attach saddle assembly above the ram of hydraulic unit and secure using pin and spring pin provided.
6. Attach all four bracket supports onto saddle plate with bolts and wing nuts.
7. Attach saddle brackets to bracket support with provided nuts.
8. Finally, attach chains with bolts, washers, and nuts to saddle bracket.
Before Use
1. Verify that the product and application are compatible, if in doubt call Technical Service [phone].
2. Before using this product, read the operator's manual completely and familiarize yourself thoroughly with the
product, its components and recognize the hazards associated with its use.
3. With ram plunger fully retracted, remove the oil ller plug. Insert the handle into the handle sleeve, then pump 6
to 8 strokes. This will help release any pressurized air, which may be trapped within the reservoir. Ensure the oil
level is just below the oil ller hole. Reinstall the oil ller plug.
4. To familiarize yourself with basic operation, turn the release valve lever:
a. Clockwise until rm resistance is felt to further turning. This is the ‘CLOSED’ release valve position used to
raise the ram/saddle.
b. Counter-clockwise, but no more than 2 turns from the closed position. This is the ‘OPEN’ release valve position
used to lower the ram/saddle.
5. Ensure that jack rolls freely. Raise and lower the unloaded jack throughout the lifting range before putting into
service to ensure the pump operates smoothly. Replace worn or damaged parts and assemblies with authorized
replacement parts only.
Saddle Assembly
Pump Handle
Saddle Bracket
Hydraulic Unit
Figure 1- Transmission Jack Components
Tilt Adjustments
Knobs
Bracket Support
Caster
Upright Post
Chain
Oil Filler
Plug
Release Valve
Lever
Ram
Plunger
Handle
Sleeve
Hydraulic Unit/ Ram

OPERATION
Follow the instruction for removal and installation of transmission, transfer case or transaxle according to the vehicle
manufacturer's service manual.
Raise saddle assembly:
1. Close release valve by turning the release valve level clockwise until rm. Pump handle until saddle reaches
desired height.
2. Secure the load using the provided chains.
Ensure center gravity of load is centered on the saddle and load is stable before moving jack. An o-center
transmission could cause the jack to tip or ip over .
Lower saddle assembly:
Be sure all tools and personnel are clear before lowering load. Slowly engage release valve!
Maintain control of the rate of speed at which the load lowers at all times!
Open release valve by turning lever counter-clockwise, but never more than 2 full turns. Control the rate of descent
at all times. The more you open the release valve, the faster the load descends.
Never use this jack as a work station!
!
!
4
!
•Read, understand, and follow all printed material provided with and on this product before use.
• Do not exceed rated capacity.
• Use only on hard, level surfaces capable of supporting the load.
•Adequately support the vehicle before starting repairs.
• If loaded jack must be moved, make certain that load is secured by appropriate means, is stable, is in
the lowest possible position, is moved over a smooth, hard level surface and that the lifting platform
is level.
• Use of this product is limited to removal, installation, and transportation of automotive and light
truck transmissions, transfer cases and transaxles.
• Use only adapters / accessories provided by the manufacturer of this transmission jack.
• Use only adapters / accessories whose rated capacity is greater than the rated capacity of this jack.
• Ensure the center of gravity is center loaded on the saddle.
• Never use this device as a work/repair station. Transfer the load immediately to a suitable work station.
• No alteration shall be made to this product.
• Failure to heed these markings may result in personal injury and/or property damage.
To avoid crushing and related injuries:
• Never work on, under or around a load supported only by hydraulic jack.
• Be alert and sober when using this product. Do not operate under the
inuence of drugs or alcohol.
WARNING
!
WARNING
!

TROUBLESHOOTING
MAINTENANCE
Important: Use only good grade hydraulic jack oil. Avoid mixing di󰀨erent types of uid and NEVER use brake uid,
turbine oil, transmission uid, motor oil or glycerin. Improper uid can cause premature failure of the jack and the
potential for sudden and immediate loss of load.
Adding oil
1. With saddle fully lowered, set jack in its upright, level position. Remove oil ller plug.
2. Fill until oil is level with the oil ller hole, reinstall oil ller plug.
Changing oil
For best performance and longest life, replace the complete uid supply at least once per year.
1. With saddle fully lowered, remove oil ller plug.
2. Lay the jack on its side and drain the uid into a suitable container.
Note. Dispose of hydraulic uid in accordance with local regulations.
3. Set jack in its level position. Fill until oil is level with the oil ller hole, reinstall oil ller plug.
Lubrication
A periodic coating of light lubricating oil to pivot points, axles and hinges will help to prevent rust and assure that
casters and pump assemblies move freely.
Cleaning
Periodically check the pump piston and ram for signs of rust or corrosion. Clean as needed and wipe with an oily
cloth.
Note: Never use sandpaper or abrasive material on these surfaces!
Storage
When not in use, store the jack with saddle fully lowered.
5
Symptom Possible Causes Corrective Action
Jack will not lift load • Release valve not tightly closed
• Load is too heavy
• Ensure release valve tightly closed
•Consider higher capacity jack
Jack will lift, but not maintain
pressure
•Release valve not tightly closed
•Hydraulic unit malfunction
•Ensure release valve tightly closed
•Discontinue use, Contact Tech.
Service
Jack will not lower after unloading • Reservoir overlled
• Linkage binding
• Ensure load is removed, then
drain uid to proper level
• Clean and lubricate moving parts
Poor lift performance • Fluid level low
•Air trapped in system
• Ensure proper uid level
•With ram fully retracted, remove
oil ller plug to let pressurized air
escape, then reinstall oil ller plug
Jack will not lift to full extension • Fluid level low • Ensure proper uid level

6
Replacement Parts Illustration for Models T-2501:
Figure 2 - Replacement Parts Illustration for Models T-2501
REPLACEMENT PARTS (page 6 & 7)
Not all components of the jack are replacement items, but are illustrated as a convenient reference of location and
position in the assembly sequence. When ordering parts, please give the Model number and parts description. Call
or write for current pricing: SFA Companies 10939 N. Pomona Ave. Kansas City, MO 64153, U.S.A.
Tel: [phone] Fax: [phone] Website: www.ProLiftProducts.com; Email: [email protected]

Replacement Parts List for Models T-2501:
7
Item Part Number Description Qty
1 T250-01000-000 Leg ass'y 2
2 T250-00005-000 Fastness haulm 2
35202-00012-100 Nut M12 8
45303-00012-100 Look washer 12 8
5T250-05000-000 3" Frame ass'y 4
65303-00010-000 Look washer 10 3
75102-10025-000 Hcs M10x30 3
8 T250-02000-000 Post ass'y 1
9 BL80-20000-000 Handle ass'y 1
10 BL80-10000-000 Power unit 1
11 T250-00001-000 Pin 1
12 T474-00007-000 Pin 1
13 T250-08000-000 Screw ass‘y 2
14 T250-00002-000 Snail cover 2
15 5304-00025-000 Washer 8
16 T250-00003-000 Snail cover 2
17 5402-02018-000 Spring pin 2
18 5307-00010-000 Washer 8
19 5205-00010-000 Nut 2
20 T250-06000-000 Connect board 1
21 T250-00004-000 Axes 2
22 5304-00018-000 Washer 4
23 T250-07000-000 Adjust board 1
24 T250-03000-000 Bed frame ass'y 1
25 5202-00010-000 Nut M10 4
26 T250-00006-000 Fastness board 4
27 T250-04000-000 Fastness angle iron 4
28 5107-12040-000 Bolt 4
29 5208-00012-000 Nut M12 4
30 L100-05000-000 Chain strip ass‘y 2
31 5103-06060-000 Bolt 4
32 5202-00006-000 Nut M6 4
33 T250-00007-000 Bushing 2
34 5301-00012-000 Washer 12 4
35 5308-00006-003 Washer 6 4
36 G390-40001-000 Bushing 2
T250-90009-K01 Hardware kit -
- BL800S-034 Seal kit for hydraulic unit -
(*) Items included in Hardware Kit

ONE YEAR LIMITED WARRANTY
For a period of one (1) year from date of purchase, SFA Companies will repair or replace, at its option,
without charge, any of its products which fails due to a defect in material or workmanship under normal usage. This
limited warranty is a consumer's exclusive remedy.
Performance of any obligation under this warranty may be obtained by returning the warranted product, freight
prepaid, to SFA Companies Warranty Service Department, 10939 N. Pomona Ave., Kansas City, MO 64153.
Except where such limitations and exclusions are specically prohibited by applicable law, (1) THE
CONSUMER'S SOLE AND EXCLUSIVE REMEDY SHALL BE THE REPAIR OR REPLACEMENT OF DEFECTIVE
PRODUCTS AS DESCRIBED ABOVE. (2) SFA Companies SHALL NOT BE LIABLE FOR ANY CONSEQUENTIAL
OR INCIDENTAL DAMAGE OR LOSS WHATSOEVER. (3) ANY IMPLIED WARRANTIES, INCLUDING WITHOUT
LIMITATION THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR
PURPOSE, SHALL BE LIMITED TO ONE YEAR, OTHERWISE THE REPAIR, REPLACEMENT OR REFUND AS
PROVIDED UNDER THIS EXPRESS LIMITED WARRANTY IS THE EXCLUSIVE REMEDY OF THE CONSUMER,
AND IS PROVIDED IN LIEU OF ALL OTHER WARRANTIES, EXPRESS OR IMPLIED. (4) ANY MODIFICATION,
ALTERATION, ABUSE, UNAUTHORIZED SERVICE OR ORNAMENTAL DESIGN VOIDS THIS WARRANTY AND
IS NOT COVERED BY THIS WARRANTY.
Some states do not allow limitations on how long an implied warranty lasts, so the above limitation may not
apply to you. Some states do not allow the exclusion or limitation of incidental or consequential damages, so the
above limitation or exclusion may not apply to you. This warranty gives you specic legal rights, and you may also
have other rights, which vary from state to state.
8
SFA Companies, Inc.
10939 N. Pomona Ave.
Kansas City, MO 64153
Phone [phone], Fax [phone]
