Protech Systems BS-E098 User manual

Ver. Q1
All Rights Reserved. Copyright 2017
Packing Checklist
BS-E098
BS-E098 BS-E098
Specifications System View
Front View
Rear View
Side View
Bottom View
45.98
4
6
6
BS-E098
Quick
Reference
Guide
If you discover any item below damaged or lost,
please contact your vendor.
BS-E098 x1
This Quick Reference Guide x1
Driver/ Manual DVD x1
Mini Jumper (2.0 mm) x6
Top View
217.5
VESA 75
VESA 75
140.6
System
CPU BS-E098RA-N1B: Pentium®N4200 4C/6W/2.5GHz
BS-E098RA-N0B: Celeron®N3350 2C/6W/2.4GHz
BS-E098RA-U1B: Pentium®N4200 4C/6W/2.5GHz
BS-E098RA-U0B: Celeron®N3350 2C/6W/2.4GHz
Memory Support 1x SO-DIMM socket,supporting 1600/1867 DDR3L DRAM
up to 8G (non-ECC)
Drive Bay 1 x 2.5” 7mm SATAIII HDD / SSD
Power Supply DC 12V power input (3 pins lockable terminal block)
O.S. Support Windows®10 64bit, Ubuntu14.04 64bit (kernel 4.4)
Dimension (WxHxD) 217.5mm x 45mm x 148mm
Weight 2 kg
Certificate FCC/CE
I/O Ports
USB BS-E098RA-N1B/N0B: 4 x USB 3.0 (rear), 2 x USB 2.0 (front)
BS-E098RA-U1B/U0B: 4 x USB 3.0 (rear), 4 x USB 2.0 (front)
Serial Ports COM1~COM3 on front I/O, COM4 on rear I/O
COM2 RS-232/422/485 selectable by BIOS (default: RS-232)
RS-485 supports auto flow control (selected by BIOS)
COM3/4 RI/5V/12V selectable by jumper (default:RI)
Antenna Hole 2 x antenna holes for reservation
LAN 2 x GbE LAN, supports Wake-On-LAN
Expansion Slots/ BS-E098RA-N1B/N0B:1 full-sized mPCIe,
mSATA 1 full-sized mSATA (with USB signals)
BS-E098RA-U1B/U0B:1 full-sized mSATA (with USB signals)
Audio 1 x Line-out (on rear I/O panel)
Display
Display 1 x DP1.2 resolution: up to 4096x2160@60Hz (rear I/O)
1 x VGA resolution: up to 1920x1200@60Hz (rear I/O)
Others
Software Support Hardware Monitor API (for Temp) and WatchDog API
Optional Item 60W Power adapter with lockable 3-pin terminal block
Environment
Operating Temp. SSD: 0°C ~ 60°C (32°F~140°F)
HDD: 0°C ~ 40°C (32°F~104°F)
Storage Temp. -40°C ~ 86°C (-40°F~185°F)
Humidity 20% ~ 95%
COM4
DC Power
Input
LAN2 LAN1
4 x
USB 3.0
DP
Line-out
VGA
COM1 COM2 COM3
Optional
USB 2.0
USB 2.0
Power
Button
Optional
Antenna
Power LED
Optional
Antenna
HDD LED

Jumper Setting
BS-E098
All Rights Reserved. Copyright 2017
Safety Precaution
Fanless Embedded PC with Intel®Apollo Lake PentiumTM / Celeron®SoC
The following messages are safety reminders on how to protect your system
from damages, and thus help you extend the life cycle of the system.
1. Check the Line Voltage
The operating voltage for the power supply should cover the range of
9V~36V DC; otherwise, the system may be damaged.
2. Environmental Conditions
Place your BS-E098 on a sturdy, level surface. Be sure to allow
enough room on each side to have easy access.
Avoid moving the system rapidly from a hot place to a cold place or
vice versa because condensation may come from inside of the system.
Place BS-E098 against strong vibrations, which may cause hard disk
failure.
3. Handling
Do not turn the system upside down. This may cause the hard drive
to mal-function.
Do not allow foreign objects to fall into this product.
If water or other liquid spills into this product, unplug the power cord
immediately.
4. Good Care
When the outside of the case is stained, remove the stain with neutral
washing agent with a dry cloth.
If dust has been accumulated on the outside, remove it by using a
special made vacuum cleaner for computer.
CAUTION!
Danger of explosion if battery is incorrectly replaced. Replace only with the same or
equivalent type recommended by the manufacturer. Dispose of used batteries
accordingto the manufacturer’s instructions.
WARNING!
Some internal parts of the system may have high electrical voltage. Therefore we
strongly recommend qualified engineers open and disassemble the system.
1
COM3 Pin9 RI/5V/12V
12V
1
2
5
65
1
6
2
5V
RI
(default)
21
2
5
6
COM4 Pin9 RI/5V/12V
12V
1
2
5
6
RI
(default)
21
2
5
6
(default)
Normal
Clear CMOS Data
Clear
CMOS
1
5
1
6
2
5V
LAN2 LAN1
VGA1
DP1 USB2 USB1
SATA_PWR1
JI2C1
JP9
USB3
JP3
SATA1
JP_VDD1
SW1
LVDS1
JINV1
JP7 JP4
JBAT1
FAN1
PWR2
JDIO1
JFP1
COM1
COM2
COM3
COM4
M_PCIE1
SLOT1
AUDIO1
JLPC1
SO_DIMM1
JP_COM4
JP_COM3
Mini PCI-E
mSATA
CAUTION! Danger of explosion may occur if the battery is replaced incorrectly. Replace batteries only with the same or equivalent
type recommended by the manufacturer. Dispose the used batteries according to the manufacturer’s instructions.
