protech prox KS-M220 User manual

USER
MANUAL
KS-M220 & KS-M221 M2
KS-M220 / KS-M221
21.5”Multi-Functional
ModularKioskSystem

KS-M220 / KS-M221
21.5” Multi-Functional Modular
Kiosk System
COPYRIGHT NOTICE & TRADEMARK
All trademarks and registered trademarks mentioned herein are the
property of their respective owners.
This manual is copyrighted in Mar. 2021. You may not reproduce or
transmit in any form or by any means, electronic, or mechanical,
including photocopying and recording.
DISCLAIMER
This user’smanual is meant to assist users in installing and setting up
the system. The information contained in this document is subject to
change without any notice.
CE NOTICE
This is a class A product. In a domestic environment this product may
cause radio interference inwhich case the user may be required totake
adequate measures.

FCC NOTICE
This equipment has been tested and found to comply with the limits for
a Class A digital device, pursuant to part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential area is
likely to cause harmful interference in which case the user will be
required to correct the interference at his own expense.
You are cautioned that any change or modifications to the equipment
not expressly approve by the party responsible for compliance could
void your authority to operate such equipment.
CAUTION: Danger of explosion may occur when the battery
is incorrectly replaced. Replace the battery
only with the
same or equivalent type recommended by the manuf
acturer.
Dispose of used batteries according to the manufacturer’s
instructions.
WARNING: Some internal parts of the system may have high
electrical voltage. We strongly recommend that only qualified
engineers are allowed to service and disassemble the
system. If any damages should occur on the system and are
caused by unauthorized servicing, it will not be covered by
the product warranty.

i
Contents
1Introduction.........................................................................................1-1
1.1 About This Manual ....................................................................1-2
2Getting Started ....................................................................................2-1
2.1 Packing List...............................................................................2-2
2.2 System Overview ......................................................................2-3
2.2.1 KDS Type ..........................................................................2-3
2.2.2 M-Type...............................................................................2-4
2.2.3 Cash Pay Type ..................................................................2-8
2.3 Specifications ..........................................................................2-12
2.4 Safety Precautions..................................................................2-13
3System Configuration.........................................................................3-1
3.1 System Rear I/O Ports Diagrams..............................................3-2
3.1.1 KDS Type ..........................................................................3-2
3.1.2 M-Type...............................................................................3-3
3.1.3 Cash Pay Type ..................................................................3-3
3.2 KS-M220 High-End Level System Jumper & Connector Quick
Reference Table........................................................................3-4
3.3 KS-M220 High-End Level System Component Locations........3-6
3.3.1 Top View of BE-0996RA-**N .............................................3-6
3.3.2 Jumper Setting of BE-0996RA-**N....................................3-7
3.3.3 Bottom View of BE-0996RA-**N........................................3-8
3.3.4 I/O View of BE-0996RA-**N ..............................................3-9
3.4 How To Set Jumpers...............................................................3-10
3.5 Setting KS-M220 High-End Level Connectors and Jumpers...3-12

ii
3.5.1 COM2 Connector Pin9 Definition Selection Guide
(JP_COM2).......................................................................3-12
3.5.2 COM Connectors (COM1, COM2) ...................................3-13
3.5.3 Internal USB 2.0Connector (JUSB1)...............................3-14
3.5.4 ATX Power Input Connector (ATX1).................................3-15
3.5.5 HD Audio Connector (AUDIO1)........................................3-15
3.5.6 Speaker Connectors (SPK_L_OUT1, SPK_R_OUT1).....3-16
3.5.7 Digital Input / Output Connector (JDIO1) .........................3-17
3.5.8 CPU Fan Connector (CPU_FAN1)...................................3-18
3.5.9 Front Panel Connector (JFP1) .........................................3-18
3.5.10 Battery Wafer (JBAT1)......................................................3-19
3.5.11 SPI Override Protection Selection (JP1)..........................3-19
3.5.12 SATA 3.0 Connector (SATA1)..........................................3-20
3.5.13 SATA Power Connector (JHDD_PWR1) .........................3-21
3.5.14 I2C Wafer (JI2C1)............................................................3-21
3.5.15 LVDS Connector (JLVDS1) .............................................3-22
3.5.16 Panel Inverter Connector (JINV1) ...................................3-23
3.5.17 Mini PCI Express Slot (M_PCIE1)...................................3-24
3.5.18 mSATA Connector (M_SATA1)........................................3-25
3.5.19 Slide Switch For LVDS Resolution Selection (SW1).......3-26
3.5.20 LVDS VCC Selection (JP5) .............................................3-29
3.5.21 Backlight PWM Level Selection (JP6).............................3-30
3.5.22 V3P3 MPCIE Selection (JP9)..........................................3-31
3.5.23 Clear CMOS Data Selection (JCMOS1)..........................3-32
3.6 KS-M221 Entry Level System Jumper & Connector Quick
Reference Table......................................................................3-33
3.7 KS-M221 Entry Level System Component Locations.............3-34
3.7.1 Top View of BE-0986RB..................................................3-34

3.7.2 Jumper Setting of BE-0986RB........................................3-35
3.7.3 Bottom View of BE-0986RB ............................................3-36
3.7.4 I/O View ofBE-0986RB...................................................3-36
3.8 Setting KS-M221 Entry Level Connectors and Jumpers ...............
................................................................................................3-37
3.8.1 COM3 and COM4 PIN9 Definition Selection Guide
(JP_COM3, JP_COM4)...................................................3-37
3.8.2 COM Port (COM1, COM2, COM3, COM4) .....................3-38
3.8.3 VGA Port (VGA1).............................................................3-40
3.8.4 HDMI Port (HDMI1).........................................................3-40
3.8.5 LAN Port (LAN1, LAN2) ..................................................3-41
3.8.6 Dual USB 3.0 Port (USB1) ..............................................3-42
3.8.7 USB 3.0 Port (USB2).......................................................3-42
3.8.8 USB 2.0 Port (USB3).......................................................3-43
3.8.9 ProgrammableGPIO PIN HEADER (JDIO1)..................3-43
3.8.10 I2C Wafer (JI2C1)............................................................3-43
3.8.11 MCU FWRewrite Connector (JMCU1) ...........................3-44
3.8.12 System Fan Connector (FAN1) .......................................3-44
3.8.13 DC Power Input Connector (PWR2)................................3-44
3.8.14 Mini PCI Express Slot (M_PCIE1)...................................3-45
3.8.15 mSATA Connector (M_SATA1)........................................3-46
3.8.16 LVDS Connector (LVDS1) ...............................................3-47
3.8.17 Slide Switch for LVDS Resolution Selection (SW1).........3-48
3.8.18 Front Panel Connector (JFP1) .........................................3-51
3.8.19 HD Audio Connector (AUDIO1)........................................3-51
3.8.20 Panel Inverter Connector (JINV1) ....................................3-52
3.8.21 SATA 3.0 Connector (SATA1)...........................................3-52
3.8.22 SATA Power Connector (SATA_PWR1)...........................3-52
3.8.23 BIOS Reset Connector (JP9) ...........................................3-53
3.8.24 LVDS Backlight Control Selection (JP7) ..........................3-53
iii

iv
3.8.25 LVDS VCC Voltage Selection (JP_VDD1).......................3-54
3.8.26 Clear CMOS Data Selection (JP4)..................................3-55
4Software Utilities.................................................................................4-1
4.1 Driver and OS Support For High-End Level System.................4-2
4.1.1 Installing Intel®Chipset Software Installation Utility ..........4-3
4.1.2 Installing Graphics Driver Utility ........................................4-4
4.1.3 Installing LAN Driver Utility................................................4-5
4.1.4 Installing Sound Driver Utility ............................................4-6
4.1.5 Intel®Management Engine Components Installer Installation
...........................................................................................4-7
4.1.6 Installing Intel®Serial I/O Driver Utility..............................4-8
4.2 Driver and OS Support For Entry Level System.......................4-9
4.2.1 Installing Intel®Chipset Software Installation Utility ........4-10
4.2.2 Installing Graphics Driver Utility ......................................4-11
4.2.3 Installing LAN Driver Utility..............................................4-12
4.2.4 Installing Sound Driver Utility ..........................................4-13
4.2.5 Microsoft Hotfix kb3211320 and kb3213986 Driver
installation........................................................................4-14
4.2.6 Installing Intel®Serial I/O Driver Utility............................4-15
5BIOS SETUP ........................................................................................5-1
5.1 Introduction................................................................................5-2
5.2 Accessing Setup Utility for KS-M220 High-End Level System .5-4
5.2.1 Main...................................................................................5-7
5.2.2 Advanced...........................................................................5-9
5.3.3.1 Advanced – CPU Configuration..........................5-10
5.3.3.2 Advanced – SATA Configuration ........................5-11

v
5.3.3.3 Advanced – PCH-FW Configuration...................5-12
5.3.3.4 Advanced – Trusted Computing.........................5-13
5.3.3.5 Advanced – ACPI Settings .................................5-15
5.3.3.6 Advanced – F81866 Super IO Configuration .....5-16
5.3.3.7 Advanced – Hardware Monitor...........................5-19
5.3.3.8 Advanced – F81866 Watchdog ..........................5-21
5.3.3.9 Advanced – S5 RTC Wake Settings...................5-22
5.3.3.10 Advanced – USB Configuration..........................5-25
5.3.3.11 Advanced – Network Stack Configuration..........5-26
5.2.3 Chipset.............................................................................5-28
5.2.3.1 Chipset – System Agent (SA) Configuration ......5-29
5.2.3.2 Chipset – PCH IO Configuratioin........................5-31
5.2.4 Security............................................................................5-33
5.2.5 Boot .................................................................................5-35
5.2.6 Save & Exit......................................................................5-36
5.3 Accessing Setup Utility for KS-M221 Entry Level System.............
................................................................................................5-38
5.3.1 Main.................................................................................5-41
5.3.2 Advanced.........................................................................5-43
5.3.2.1 Advanced - ACPI Settings ..................................5-45
5.3.2.2 Advanced - Onboard Device Configuration........5-46
5.3.2.3 Advanced - Hardware Monitor............................5-47
5.3.2.4 Advanced - F81964 Watchdog...........................5-51
5.3.2.5 Advanced - S5 RTC Wake Settings....................5-52
5.3.2.6 Advanced - CPU Configuration ..........................5-55
5.3.2.7 Advanced - F81964 Super IO Configuration ......5-58
5.3.2.8 Advanced - USB Configuration...........................5-63
5.3.2.9 Advanced - Platform Trust Technology...............5-64
5.3.3 Chipset.............................................................................5-65
5.3.3.1 Chipset - North Bridge........................................5-66

vi
5.3.3.2 Chipset - South Bridge........................................5-67
5.3.4 Security............................................................................5-76
5.3.5 Boot .................................................................................5-77
5.3.6 Save & Exit......................................................................5-78
Appendix A System Diagrams....................................................A-1
Easy Maintenance....................................................................................A-2
KS-M220 / KS-M221 KDS Body Exploded Diagrams ............................A-12
KS-M220 / KS-M221 KDS Control Box Exploded Diagrams..................A-31
KS-M220 / KS-M221 Cash Pay Lower Parts Exploded Diagrams.........A-38
KS-M220 / KS-M221 M-Type Lower Parts Exploded Diagrams.............A-55
Appendix B Technical Summary................................................B-1
Technical Summary for KS-M220 High-End Level System..........B-2
BE-0996 M/B Block Diagram....................................................................B-2
Interrupt Map ............................................................................................B-3
I/O MAP..................................................................................................B-14
Memory Map...........................................................................................B-16
Configuring WatchDog Timer .................................................................B-19
Flash BIOS Update.................................................................................B-21
Technical Summary for KS-M221 Entry Level System ..............B-25
BE-0986 M/B Block Diagram..................................................................B-25
Interrupt Map ..........................................................................................B-26
I/O MAP..................................................................................................B-39
Memory Map...........................................................................................B-41
Configuring WatchDog Timer .................................................................B-43
Flash BIOS Update.................................................................................B-45

vii
Revision History
The revision history of KS-M220 / KS-M221 User Manual is described below:
Version No.
Revision History
Date
M2

In Section 2.4 Safety Precautions, added the caution
message: “The equipment power supply cord
shall be connected to a socket-outlet with
earthing connection.” on Page 2-13.
The name of the power input port for KDS type has
been corrected to “DC In (Power)” in Section 3.1
System Rear I/O Ports Diagrams on Page 3-2.
2021/03/31
M1
Initial Release
2020/08/05

KS-M220 SERIES USER MANUAL
Page: 1-1
1 Introduction
This chapter provides the introduction for KS-M220 /
KS-M221 system as well as the framework of the user
manual.
The following topic is included:
•About This Manual

Chapter 1 Introduction
KS-M220/KS-M221 SERIES USER MANUAL
Page: 1-2
1.1 About This Manual
Thank you for purchasing our KS-M220 / KS-M221 system. The KS-M220 /
KS-M221 provides faster processing speed, greater expandability and can handle
more tasks than before. This manual is designed to assist you how to install and set up
the whole system. It contains 5 chapters and 2 appendixes. Users can configure the
system according to their own needs. This user manual is intended for service
personnel with strong hardware background. It is not intended for general users.
The following section outlines the structure of this user manual.
Chapter 1 Introduction
This chapter provides the introduction for the KS-M220 / KS-M221 system as well as
the framework of the user manual.
Chapter 2 Getting Started
This chapter describes the package contents and outlines the system specifications.
Read the safety reminders carefully on how to take care of your system properly.
Chapter 3 System Configuration
This chapter describes the external I/O ports, outlines the locations of the
motherboard components and their respective functions. You will learn how to set the
jumpers and configure the system to meet your own needs.
Chapter 4 Software Utilities
This chapter contains helpful information for proper installations of the Intel Chipset
Software Installation Utility, Intel®Management Engine Components Installer,
Graphics Driver Utility, LAN Driver Utility, Sound Driver Utility, Microsoft Hotfix
kb3211320 and kb3213986 Driver and Intel®Serial I/O Driver Utility.
Chapter 5 AMI BIOS Setup
This chapter indicates you how to change the BIOS configurations.
Appendix A System Diagrams
This appendix provides easy maintenance diagrams, exploded diagrams and part
numbers of KS-M220 / KS-M221 system.
Appendix B Technical Summary
This appendix provides the information about the allocation maps for the system
resources, Watchdog Timer Configuration and Flash BIOS Update.

KS-M220/KS-M221 SERIES USER MANUAL
Page: 2-1
2 Getting Started
This chapter provides the information for the KS-M220 /
KS-M221 system. It describes the package contents and
outlines the system specifications.
The following topics are included:
•Package List
•System Overview
•System Diagrams
•System Specification
•Safety Precautions
Experienced users can go to Chapter 3 System
Configuration on page 3-1 for a quick start.

Chapter 2 Getting Started
KS-M220/KS-M221 SERIES USER MANUAL
Page: 2-2
2.1 Packing List
If you discover any of the items listed above are damaged or lost,
please contact your local distributor immediately.
Item
Q’ty
KS-M220 / KS-M221 system
1
Quick Reference Guide
1
Manual / Driver DVD
1
AC Power Adaptor
1
Door Key
2

Chapter 2 Getting Started
KS-M220/KS-M221 SERIES USER MANUAL
Page: 2-3
2.2 System Overview
2.2.1 KDS Type
Front View Rear View
21.5” Touch Panel
Face Camera
Left Side View
Right Side View
Top View Bottom View

Chapter 2 Getting Started
KS-M220/KS-M221 SERIES USER MANUAL
Page: 2-4
2.2.2 M-Type
Front View
21.5” Touch Panel
Face Camera
Credit Card Reader
(Customer Assigned)
Barcode Scanner
Thermal Printer
IC Card Reader

Chapter 2 Getting Started
KS-M220/KS-M221 SERIES USER MANUAL
Page: 2-5
Rear View
Rear I/O Ports

Chapter 2 Getting Started
KS-M220/KS-M221 SERIES USER MANUAL
Page: 2-6
Side View

Chapter 2 Getting Started
KS-M220/KS-M221 SERIES USER MANUAL
Page: 2-7
Top View

Chapter 2 Getting Started
KS-M220/KS-M221 SERIES USER MANUAL
Page: 2-8
2.2.3 Cash Pay Type
Front View
21.5” Touch Panel
Face Camera
Credit Card Reader
(Customer Assigned)
Barcode Scanner
Thermal Printer
IC Card Reader
