Provision ISR PRO-AHD series User manual

Pro-AHD Series
Hidden Camera

1
Contents
1) CAUTIONS
2 ) Product Introduction
2.1 Camera Introduction
2.2 Product Features
3)
Menu Setup
4) Product Installation
5) Technical Specification
4.1 General Notes
4.2 Installation Tools and Information
4.3 Installation Method
4.4 Connections
4.5OSD Control

2 3
1 CAUTIONS
1. To avoid the risk of electric shock, do not open or
maintain the machine by yourself, please consult a
professional.
2. To prevent fire or shock, use the power after safety
certification. the input voltage, current, voltage polarity
and operating temperatures must meet the require-
ments of this camera.
3. Please note the operating temperature and environ-
mental requirements of the camera, avoid too low
or too high temperatures. General operating tempera-
ture range of -10°C ~ +50°C (Fahrenheit temperature
is 14°F ~ 122°F). Avoid flooding and rain, minimize
dust and moisture erosion; otherwise camera would be
damaged.
4. Cameras in use should avoid direct sunlight, glare,
otherwise the sensor will be damaged.
5. Do not touch the sensor surface. If any foreign
objects are visible, use a cotton swab or lens cleaner
to wipe it, if it is difficult to remove, a neutral detergent
diluted with water would be useful. Do not use
corrosive solution.
6. In order to make the camera work smoothly and
obtain a satisfactory image, the power cord and video
connection can not be too long. Otherwise, the
increase of line loss will lead to inadequate operating
voltage of the camera or inadequate video signal.
7. To prevent camera damage and personal injury, do
not place camera on unstable objects, brackets,or
bases.
8. Do not place camera near a radiator or other heating
devices.

4 5
2 Product Introduction
2.1 Camera Introduction
PROVISION-ISR’s new cameras series has adopted
CMOS image sensor with high performance, which
provides mega pixel resolution and supports HD video.
It supports coaxial transmission that can reach more
than 300M, based on 75-3 coaxial cable. The series
supports both AHD/CVBS 960H output and real-time
video transmission.
2.2 Product Features
● Coaxial cable with BNC connector
● Auto Day/Night (ICR)
● Auto Defog, HBLC, BLC
● Digital WDR, 2D/3D NR
● Motion Detection, Privacy Mask
● AHD/CVBS Signal Selectable from OSD
AHD-960H: Press left 5 seconds;
960H-AHD: Press right 5 seconds;
PAL-NTSC: Press down 5 seconds to switch
between PAL&NTSC
3 Menu Setup
Press "MENU" button to enter the main MENU, press
"UP" and "DOWN" to select menu, press "LEFT" and
"RIGHT" to choose or set the corresponding function.
To enter submenu press "MENU" again. Set up Save
and exit.
4 Product Installation
4.1 General Notes
1. Make sure the unit is powered off before installation.
2. Check if power supply voltage is consistent with
electric voltage to prevent damages to the device.
3. Do not use in environments exceeding temperature
limitations, and maintain good ventilation to prevent
risk of fire or electric shock.
4. The installation and maintenance of this product
should be professional, please do not in any way
remove or modify the equipment; only use the

6 7
required accessories from the manufacturers. Issues
caused by unauthorized repair are your responsibility.
4.2 Installation Tools and Information
Prepare the required engineering data and instructions.
Before installing please prepare the following tools and
instrumentation: A straight or a Phillips-head screwdriver,
multi-meter, scissors, needle nose pliers, tape measure,
pencil.
4.3 Installation Method
1. Check if all equipment is in tact.
2. Mounting bracket or base:
• If you are installing on a cement wall, use the expan
sion screw holes and then mount the bracket or
base.
• If you are installing on a wooden wall, use the
self-tapping screws to mount
3. Mounting the camera
a. Dome Camera
Adjust the lens position to aim at the monitoring points
and present a clear picture. Manually fix lens location
and adjust the hemisphere cover. Re-examine the
screen whether the character meets your requirements.
Tighten the hemisphere cover.
b. Bullet Camera
Adjust the body so the lens aim at the monitoring points
and presents a clear picture. Tighten the screws to
ensure camera will not move.
Installation method above is for reference only.
Note:
The wall needs to bear at least 3
times the weight of bracket and
camera.

89
4.4 Connections
Connection as show in the figure below
4.5 OSD Control
For 1080P Cameras (AHD2.0), The preffered control
method is CoC (Control over Coax). If your AHD DVR
supports this function*, Use the DVR’s PTZ interface to
call Preset 95 or press on “Iris+” to open the OSD
menu. Navigate through the OSD menu by the PTZ
direction arrows. “Iris+” performs as “Enter”.
*All of Provision-ISR’s DVRs support CoC Starting from version 3.4.4

10 11

12 13
PRO-AHD camera (720P)
MC-382AHD37/ DL-382AHD37/ DS-382AHD37/ IV-380AHD37
5 Specifications:
Model
Image Sensor
Effective Pixels
Scanning System
Resolution
Min. Illumination
Day & Night
IR LED
OSD Menu
Backlight Compensation
S/N Ratio
White Balance
Noise Reduce
Video Output
Defog
Privacy Mask
Motion Detection
D-Effect
Lens
Power
Operation temp.
Dimension
Net Weight
1/3" 1.3MP Sony Sensor
1280(H)×960(V)
Progressive
Digital:1280×960P, Analog:960H
0.01Lux / (0Lux IR On)
EXT, Color, B&W, AUTO
Available (11 Languages, AHD/CVBS Output selectable)
OFF/BLC/HSBLC
≥60dB (AGC Off)
AWB, ATW, AWC (Push), Indoor, Outdoor, Manual
3D-DNR (For AHD), 2D-DNR (For Analog)
AHD / CVBS (Signal Selectable from OSD)
Off/On
Off/On (4 Areas)
Off/On (4 Areas)
Freeze, Mirror, Negative Image
DC12V±10%, ~72mA DC12V±10%, ~212mA
-10°C~+50°C (14°F~122°F)
3.7mm Pinhole
MC-382AHD37
N/A
35*35*10mm
90g
DL-382AHD37
N/A
Ø90*55mm
210g
DS-382AHD37
N/A
Ø125x50mm
85g
IV-380AHD37
0Lux (IR On)
18pcs(10m)
104*60*66mm
94g

14 15
PRO-AHD camera (1080P)
MC-392AHD37/ DL-392AHD37/ DS-392AHD37/ IV-390AHD37
Specifications:
Model
Image Sensor
Effective Pixels
Scanning System
Resolution
Min. Illumination
Day & Night
IR LED
OSD Menu
Backlight Compensation
S/N Ratio
White Balance
Noise Reduce
Video Output
Defog
Privacy Mask
Motion Detection
D-Effect
Lens
Power
Operation temp.
Dimension
Net Weight
MC-392AHD37
N/A
35*35*10mm
90g
DL-392AHD37
N/A
Ø90*55mm
210g
DS-392AHD37
N/A
Ø125x50mm
85g
1/3" 2.0MP Sony Sensor
1920(H)×1080(V)
Progressive
Digital:1920×1080P, Analog:960H
0.01Lux
EXT, Color, B&W, AUTO
Available (11 Languages, AHD/CVBS Output selectable)
OFF/BLC/HSBLC
≥60dB (AGC Off)
AWB, ATW, AWC (Push), Indoor, Outdoor, Manual
3D-DNR (For AHD), 2D-DNR (For Analog)
AHD / CVBS (Signal Selectable from OSD)
Off/On
Off/On (4 Areas)
Off/On (4 Areas)
Freeze, Mirror, Negative Image
DC12V±10%, ~72mA DC12V±10%, ~212mA
-10°C~+50°C (14°F~122°F)
IV-390AHD37
0Lux (IR On)
18pcs(10m)
104*60*66mm
94g
3.7mm Pinhole
