Provision ISR Ultra-Z-18s User manual

Contents
Before installing
Key features
Configure, fix and wire...............
Basic speed dome operation........
Programming the speed dome
Parts and dimensions
Wiring schematic
Specifications
1
2
3
4
7
8
18
19
20
New features..................

Before installing
1
!
·
·
·
·
·
·
Installation should be carried out only by qualified personnel and in accordance with
any wiring regulations in force at the time.
The speed dome is heavy and could cause injury if not correctly mounted in
accordance with these instructions. Use only the fittings supplied with the speed
dome and ensure that all lanyard safety cables are connected correctly during
installation.
Adequate protection against lightning strikes and power surges must be installed to
prevent damage to the speed dome.
Any safety warnings on the product and in these instructions must be adhered to.
If cleaning is necessary, disconnect power to the speed dome first. Do not use
abrasive cleaners, as these will cause damage to the cover and cause poor image
quality. Use a damp cloth to gently clean the dome cover and dry off with a soft
clean cloth.
Do not use any brackets, mounts or other accessories not specifically designed for
use with this speed dome.
Do not attempt to service or repair the speed dome as opening or removing covers
may expose dangerous voltages or other hazards. Refer all servicing to qualified
service personnel.

Key features
2
Presets
Pattern tours
AUTO SCAN between 2presets
Group function
Up to 127 sets of positional and zoom level information can be stored as
presets. These can be called manually by the operator, automatically by an
alarm input, or grouped to form a sequence of actions to run automatically.
Each preset can also be programmed with the following:
Any dome movement can be recorded - and subsequently played back - as
four separate pattern tours. These can be played back individually or
grouped to form a sequence of tours.
AUTO SCAN isausefulfeaturewhen,forexample,theoperatorwishesto‘patrol’a
perimeter fence. If one preset is defined at one end of the fence and a
second preset is defined at the other, the scan function will smoothly and
accurately move from one end to the other and then back again in a
repeating sequence. Speed can be adjusted as necessary and up to 8 scan
functions can be defined.
The group function is a powerful feature which allows the operator to define
a sequence of speed dome actions to form an automatic patrol sequence.
Actions can be a mix of preset positions, pattern tours and scan functions.
Up to 8 groups can be defined and each group can have up to 20 actions
which repeat indefinitely until interrupted by the operator or an alarm input.
Specific parameters such as preset speed, dwell time and action loop can
also be specified
Alarm action - relay outputs can be triggered when particular presets are
called
Title - each preset can be titled with up to 10 characters so that zones can
easily be identified
Privacy zones
Alarm inputs and outputs
On Screen Display (OSD)
Powerful park function
By defining a privacy zone, sensitive scenes such as windows can be
masked off so they cannot be viewed by the operator. Up to 8 privacy
zones can be defined. Privacy zone size adjusts automatically depending
on the speed dome zoom level.
This speed dome has 8 alarm inputs and 4 alarm outputs. Any alarm input
can be set to call a predefined preset, scan function, pattern or group. Any
preset can be configured to activate any or all of the alarm outputs. For
example, a PIR detector connected to alarm input 1 could call preset 7 to
view that particular scene whilst activating an external lamp connected to
relay 1 and an external siren connected to relay 3.
The operator can choose if any or all of the following information is
displayed on screen during normal speed dome operation.
TimeandDate
The speed dome also has a full on screen menu setup allowing quick and
easy configuration of all the speed dome features.
The speed dome can be configured to run a specified VST function, pattern
tour, group or preset after a defined period of inactivity.
Preset status and title
Speed dome position coordinates and zoom level
Alarm I/O status
Speed dome ID

New features
3
1. Special Preset setting
The user could set the parameters of focus Mode, Color, WDR,
Stabilizer, Auto slow shutter, White Balance, AE Mode
according to different scene on each preset, in this case, the
camera can always give the best picture quality.
2. Nest Group
One group could nest another group, one group could only be
nested once.
3. Schedule function
The user could set a schedule to make the speed dome run
different functions(such as preset, pattern, group, auto scan) at
different time. Up to7 schedules can be defined.
4. soft camera ID
The user could adjust the camera ID by keyboard, no need to
process on dip switch.
5. Firmware updating and baut rate adjusting could be processed
in junction box conveniently, no need to open the speed dome
housing.
6. Pelco D/P and AD protocol are available.
7. Full duplex RS422 and semideplex RS485 port are available.
The user could select different communication mode by adjusting
dip switch.
8. Powerful lightning proof design could resist up to 20KV lighting or surge.
9. Powerful power supply design
10?. Password protection
The user could set a password for the speed dome to prevent
unpermitted processing.

4
Configure, fix and wire
1. Remove the foam packing pieces
2. Reassemble the speed dome
Before proceeding with installation, the speed dome foam packing
pieces must be removed. Remove the outer dome cover with the tool
supplied and carefully remove the foam packing pieces. When
handling the dome cover, always wear the gloves supplied to avoid
getting fingerprints on the outer dome cover.
Refit the black inner dome cover and outer dome cover. If the
lanyard safety wire was removed, it must be refitted before the dome
cover is fixed.
Foam
Foam
1. Wearing the gloves and using the supplied
tool, remove the outer dome cover.
2. Remove the foam pieces from the camera
module.
Foam
3. Fix the bracket
1. Fix the supplied mounting template, taking
account of any pipework, cables, overhangs
etc. that may obstruct the bracket once fitted.
3. Remove the junction box cover. Using the
supplied bolts and tool, firmly fix the bracket.
Pendent option
Pendent option
Pendent option
5. Bring the speed dome up to the bracket.
4. Feed the speed dome cable through the
bracket.
2. After making suitable checks for buried
pipes and cables, drill fixing holes suitable for
the bolts supplied with the speed dome.
Lanyard
6. Tighten the three screws to fix the speed
dome and ensure the lanyard safety chain is
properly connected.
Cover
Lanyard
3. Carefully unclip the black inner dome

5
4. Complete the install
Protocol & Baud rate DIP switch table
Speed dome ID DIP switch table
Note: ID 0 should not be used. Where multiple speed domes
are connected, a unique ID must be assigned to each one.
Dip switches 9-10 are reserved and must not be changed.
1 2 3 4 5 6 7 8
ON
Factory default
switch positions
Speed dome ID is set
using standard
binary notation
1 2 3 Protocol/Rate
OFF OFF OFF PelcoD, 00 bps
OFF ON OFF
AD,4800 bps
ON ON OF
C,9600 bps
OFF OFF O
elcoP,9600 bps
ON OFF O
elcoP,4800 bps
OFF ON O
ON ON ON PelcoD, 00 bps
Note: Dip switches 4-6 are reserved
and must not be changed.
1 2 3 4 5 6 7 8 9 10 DIP
1 2 4 8 16 32 64 128 – – VAL/ID
ON OFF OFF OFF OFF OFF OFF OFF
OFF ON OFF OFF OFF OFF OFF OFF – – 2
ON ON OFF OFF OFF OFF OFF OFF – – 3
OFF OFF ON OFF OFF OFF OFF OFF – – 4
ON OFF ON OFF OFF OFF OFF OFF – – 5
OFF ON ON OFF OFF OFF OFF OFF – – 6
ON ON ON OFF OFF OFF OFF OFF – – 7
OFF OFF OFF ON OFF OFF OFF OFF – – 8
– – – – – – – – – – –
ON ON ON ON ON ON ON ON 255
– – 1
Dip4 reserved
Dip5 Rs485/Rs422
Dip6 NTSC/Pal
0
24
F
P
P
V
48
AD,4800 bps
N
N
N

6
If there’s a problem at this stage...
6. Verify basic operation
…work through the logical steps below to determine and rectify the problem
- check the PCB to make sure the red power LED is lit. If not, check that the PSU is
correctly connected and has power. If you have a test meter, verify that the output of the PSU is
approximately 24V AC.
If the power LED is lit, check the BNC crimp connection is correctly made at both the PCB end and
the DVR / monitor / matrix end. A portable test monitor connected directly to the video output of the
speed dome is also a useful test - if a picture is displayed, double check the BNC connections and
the signal cable used.
- check that the control equipment you are using is compatible with the speed
dome and is configured to match the speed dome settings correctly.
If dip switches were changed on the speed dome, check the power on self test screen to ensure
that protocol, ID and baud rate are as expected.
If the settings match, you should check the polarity of the connections, both on the control
equipment and the speed dome. If you suspect there is a polarity issue, swap the A & B wires at the
speed dome to see if this resolves the problem.
Check also that there are no other telemetry devices on the system with the same ID as the speed
dome. If in doubt, connect the speed dome directly to the PTZ controller and isolate all other
equipment.
No picture
No PTZ control
1. After carefully checking the installation,
including all cable connections, apply power to
the dome and check that the startup and self
test screen is displayed.
2. After the self test is complete, the dome
starts normal operation. Verify that there is
basic PTZ control from your control equipment.
HIGH SPEED DOME
------------------------
FIRMWARE VER
COLOUR SYSTEM
PROTOCOL
ADDRESS
BAUD RATE
Comm.Mode
ZOOM MODULE
ALARM I/O
HOME TEACHING.. O:----
I:12345678
: 1.0SY28V
: P A L
: PELCO-D
: 1
: 2 4 0 0
: RS485/422
: O K
: O K
WAIT...
14:46:46
5. Complete the install
1a - wall bracket option. After making all the
connections to the PCB, fit the junction box
cover with the four screws.
Note: when fixing the cover to the junction box, ensure that the seal is also
fitted properly and that none of the cables are trapped
1b - pendent option. After making all the
connections to the PCB, raise the dome
assembly to the junction box, connect the
dome cable to the PCB and fix with the four
screws.
Seal
Seal
Note: when fixing the cover to the junction box, ensure that the seal is also
fitted properly and that none of the cables are trapped
Note: when fixing the cover to the junction box, ensure that the seal is also
fitted properly and that none of the cables are trapped
Note: when fixing the cover to the junction box, ensure that the seal is also
fitted properly and that none of the cables are trapped
C A M 1
325/37/x1
11-07-15

7
11-07-15
09:37:15
O:-23-
I:12345678
PRESET003
PRESET3
PARKING BAY 1
RECEPTION
Basic speed dome operation
Programming, calling and deleting presets
Understanding the On Screen Display (OSD)
There are many different PTZ keyboards and DVR systems capable
of controlling this speed dome, and it would be impossible to
describe them all here. Therefore, examples given in the following
pages are based on the more popular control equipment available.
Whilst the principles of operation are the same, regardless of the
control equipment used, reference may need to be made to the
manual supplied with your particular control equipment.
To program a preset position, move the speed
dome to the desired scene and zoom level
and press:
Where is a preset number between 1 &
128 (but note that preset 95 is reserved and
cannot be used). Confirmation is displayed on
the OSD.
SET - XXX - ENTER
XXX
To delete a preset position, press:
Where is a preset number between 1 &
128 (but note that preset 95 is reserved and
cannot be used). The preset position is
cleared from memory.
CLEAR - XXX - ENTER
XXX
To reprogramme a preset position, follow the
steps for programming a preset - it is not
necessary to delete the old preset position first
PRESET LABEL: If defined,
is displayed when a preset
position is called
ALARM I/O: Shows which
alarm inputs and outputs are
active
DATE/CLOCK: Shows
current time and date
PTZ INFORMATION: The current
pan/tilt position in degrees and
the current zoom level
ACTION TITLE: Shows
current speed dome
action
To go to a preset position thats already
been programmed, press:
SHOT - XXX - ENTERXXX - Preset
Where is a preset number between 1 &
128 (but note that preset 95 is reserved and
cannot be used). The speed dome moves to
the preset position. Confirmation and preset
title (if defined) is displayed on the OSD.
XXX
O:----
I:12345678
O:----
I:12345678
11-07-15
12:38:05
11-07-15
12:42:22
CAMERA ID: Shows the
current ID as defined by the
dip switch settings
CAM001 307/46/×003
Preset001
CAM001 325/37/×001 CAM001 325/37/×003

Display setup DATE TIME SETUP
System information
The speed dome setup menu allows the operator to customise and
program all aspects of speed dome operation. All menu settings are
retained in non-volatile memory so if power is lost to the speed dome
for any reason, all settings will be retained.
M A I N M E N U
-----------------------------
<SYSTEM INFORMATION>
<DISPLAY SETUP>
<DOME CAMERA SETUP>
<ALARM SETUP>
<PASSWORD SETUP>
<HELP>
EXIT
<SYSTEM INITIALISE>
DISPLAY SETUP
-----------------------------
CAMERA ID
PTZ INFORMATION
PRESET LABEL
ALARM I/O
DATE/TIME
<DATE TIME SETUP>
<PRIVACY ZONE>
BACK
EXIT
ACTION TITLE
DATE/TIME SETUP
-----------------------------
DATE 07-01-07/SUN
TIME 14:37:15
BACK
EXIT
SYSTEM INFORMATION
-----------------------------
FIRMWARE VER
COLOUR SYSTEM
PROTOCOL
ADDRESS
BAUD RATE
Comm.MODE RS422/RS485
BACK
EXIT
To access the speed dome setup menu, key:
To navigate the main menu, move the joystick
up / down to choose a menu item or change
settings within a menu item.
To enter a menu item or confirm a new setting,
key:
To exit a menu item or cancel a new setting,
key:
Where a menu item is surrounded by
brackets, it indicates that there is a sub menu.
Where a menu screen shows , selecting
this option will exit the menu and the speed
dome will return to normal operation. Where a
menu screen shows , selecting this
option will return to the higher menu level.
The main menu has five options:
- Provides
information such as firmware version, protocol
and ID values as defined by the dip switch
settings.
SHOT - 95 - ENTER
NEAR
FAR
EXIT
BACK
<SYSTEM INFORMATION>
<DISPLAY SETUP>
<DOME CAMERA SETUP>
<PASSWORD SETUP>
<SYSTEM INITIALISE>
- Allows the operator to
specify which On Screen Display information
is shown during normal operation. Also allows
privacy zones to be defined and time/date to
be changed
- Allows all
operating features of the speed dome to be
programmed and managed. Also allows
settings for the camera module to be changed
- Allows a password
to be set to protect the speed dome setup
- Allows various
speed dome settings to be reset to factory
defaults
From the main menu, use the joystick to
highlight and key:
To return to the main menu, highlight
and key:
To exit the setup menu completely, highlight
and key:
SYSTEM INFORMATION
NEAR
BACK
NEAR
EXIT NEAR
From the main menu, use the joystick to
highlight and key:
- shows camera ID
according to the DIP switch settings, eg
CAM 1.
- shows
current speed dome action, eg PRESET3.
-
shows the current pan / tilt position in degrees
and the current zoom level.
- shows
preset title (if defined) when a preset is called.
- shows real time
status of the alarm inputs and outputs.
- sub menu to change
the date and time
- sub menu to setup the
speed dome privacy zones
Highlight the item to modify and key:
Use the joystick to change the setting and key:
to save or: to cancel.
DISPLAY SETUP NEAR
CAMERA ID (ON / OFF)
ACTION TITLE (ON / OFF / AUTO)
PTZ INFORMATION (ON / OFF / AUTO)
PRESET LABEL (ON / OFF / AUTO)
ALARM I/O (ON/OFF)
<DATE TIME SETUP)
<PRIVACY ZONE>
NEAR
NEAR FAR
Note: If the auto option is chosen, the relevant
information is displayed for a few seconds
before disappearing.
From the display setup menu, use the joystick
to highlight and key:
Highlight the item to modify and key:
Move the joystick up and down to change an
individual value and left and right to move to
the previous / next value
DATE/TIME SETUP
NEAR
NEAR
: P A L
: PELCO-D
: 0 0 1
: 2 4 0 0
ON/OFF
ON/OFF
ON/OFF/AUTO
ON/OFF/AUTO
ON/OFF/AUTO
ON/OFF/AUTO
8
Programming the speed dome
1.0SY28V
: 2.5W036V

CAMERA SETUP1
-----------------------------
FOCUS MODE
COLOUR
<WHITE BALANCE>
<AE MODE>
BACK
EXIT
DIGITAL ZOOM
DOME CAMERA SETUP
-----------------------------
<CAMERA SETUP1>
<MOTION SETUP>
<PRESET SETUP>
<SCAN SETUP>
<PATTERN SETUP>
BACK
EXIT
<CAMERA SETUP2>
<GROUP SETUP>
<SCHEDULE SETUP>
From the main menu, use the joystick to
highlight and key:
- setup of specific camera module features.
- setup of the pan / tilt /
zoom operation of the speed dome, park
action configuration, and configuration of the
alarm inputs.
- full management and
programming of individual presets.
- full management and
programming of SCAN functions.
- full management and
programming of pattern tours.
Highlight the setup menu required and key:
DOME CAMERA SETUP
NEAR
<CAMERA SETUP1>,
<MOTION SETUP>
<PRESET SETUP>
<SCAN SETUP>
<PATTERN SETUP>
NEAR
Remember: A menu item surrounded by
brackets shows it has a sub menu.
<CAMERA SETUP2>
<GROUP SETUP>
<SCHEDULE SETUP>
- full management and
programming of group functions.
- full management and
programming of Schedule.
From the dome camera setup menu, use the
joystick to highlight and
key:
MANUAL - the operator must focus the
camera manually using the NEAR and FAR
keys.
SEMIAUTO - the camera automatically
focuses during normal PTZ movement but
preset focus information is stored when a
preset is programmed and recalled each time
the preset is called
AUTO - the module auto focuses continually
- switches the module
between colour and b/w mode
- sub menu to change
the white balance settings
- sub menu to change the auto
exposure settings
CAMERA SETUP1
NEAR
FOCUS MODE
COLOUR (ON/OFF)
<WHITE BALANCE>
<AE MODE>
DIGITAL ZOOM (ON / OFF) - disables or
enables the 10x digital zoom. When disabled,
the maximum zoom level is 36x (optical).
Dome camera setup Camera setup1
9
Privacy zone Edit zone
PRIVACY ZONE
-----------------------------
Z O N E N O .
ZONE DISPLAY
CLEAR ZONE
<EDIT ZONE>
BACK
E D I T Z O N E 1
-----------------------------
MOVE TO TARGET POSITION
[NEAR:SELECT/FAR:CANCEL]
E D I T Z O N E 1
-----------------------------
[L/R:ADJUST ZONE WIDTH]
[U/D:ADJUST ZONE HEIGHT]
[NEAR:SAVE /FAR:CANCEL]
From the display setup menu, use the joystick
to highlight and key:
shows the privacy zone
currently being modified.
- determines whether the privacy
zone is displayed during normal operation.
- allows the operator to define
the privacy zone.
Highlight the item to modify and key:
Use the joystick to change the setting and key:
to save or: to cancel.
PRIVACY ZONE NEAR
ZONE NO. (1-8) -
DISPLAY
<EDIT ZONE>
NEAR
NEAR FAR
From the privacy zone menu, use the joystick
to highlight and key:
Use the joystick to move the speed dome to
the approximate position and zoom level for
the privacy zone and key: to select or
to cancel and return to the privacy zone
menu.
EDIT ZONE NEAR
NEAR
FAR
1
ON/OFF
CANCEL/YES
ON/OFF
AUTO
ON/OFF
Move the joystick left and right to finely adjust
the width of the privacy zone and up and down
to finely adjust the height.
To save the privacy zone, key: or key:
to cancel.
NEAR
FAR
EXIT
<WHITE BALANCE>
<AE MODE>
MIRROR ON/OFF
PIC EFFECT OFF/NEG/B/W
SLOW AE 001-048

WB mode setup Auto exposure setup
W B M O D E S E T U P
-----------------------------
W B M O D E
RED ADJUST
BLUE ADJUST
BACK
EXIT
A E S E T U P
-----------------------------
BLC
DAY/NIGHT
A E M O D E
IRIS LEVEL
GAIN LEVEL
SHUTTER SPD
BRIGHTNESS
BACK
EXIT
From the zoom camera setup menu, use the
joystick to highlight
and key:
AUTO - the speed dome determines the
optimum white balance settings for a given
scene
MANUAL - the operator can adjust white
balance settings manually
iNDOOR-
OUTDOOR-
ATW-
- in manual mode, the red
colour content can be adjusted
- in manual mode, the blue
colour content can be adjusted
WHITE BALANCE SETUP
NEAR
WB MODE
(AUTO/ INDOOR/OUTDOOR/ATW)
RED ADJUST
BLUE ADJUST
MANUAL
From the zoom camera setup menu, use the
joystick to highlight
and key:
- The operator can select
BLC(Back Light Compensation) mode,
selecting will disable this feature.
- the
operator can choose to fix the camera in to
DAY (colour) or NIGHT (B&W with IR cut filter
mode). In AUTO mode, the camera switches
between DAY and NIGHT depending on the
surrounding light level
- in AUTO mode, the speed dome
determines optimum camera exposure
settings for a given scene. In modes other
than AUTO, the operator can adjust specific
exposure characteristics to suit a particular
scene
Highlight the item to modify and key:
Use the joystick to change the setting and key:
AUTO EXPOSURE
SETUP NEAR
BLC (OFF/ ON)
DAY/NIGHT (AUTO/DAY/NIGHT)
AE MODE
NEAR
OFF
AUTO
---
---
O N
AUTO
AUTO
---
---
---
---
CAMERA SETUP2
-----------------------------
PIC FREEZE
P I C F L I P
ZOOM SPEED
FLICKERNESS
WDR
AUTO SLOW SHUTTER
STABALIZER
BACK
EXIT
O F F
O N
7
OFF
OFF/ON/AUTO/ON-R/ON-D
OFF
ON/OFF/HOLD
From the dome camera setup menu, use the
joystick to highlight and key:
- when set to ON, there’s no
image flash.
- when set to ON, the image will be
turned 180 degrees.
- Operator can select zoom
speed.
- Should be set to ON when
used in certain lighting conditions (EG
Fluorescent lighting) to prevent picture flicker.
- Used to select
shutter speed
Highlight the item to modify and key:
Use the joystick to change the setting and key:
to save or: to cancel.
MOTION SETUP
NEAR
PIC FREEZE
PIC FLIP
ZOOM SPEED
FLICKERNESS
AUTO SLOW SHUTTER
NEAR
NEAR FAR
Camera setup2
10
Motion setup
MOTION SETUP
-----------------------------
AUTO FLIP
JOG SPEED
JOG DIRECTION
P W R U P A C T I O N
ZOOM PROPORTIONAL
PRESET LOCK
<PARK ACTION>
BACK
EXIT
O N
SLOW
NOR
O N
O N
OFF
From the dome camera setup menu, use the
joystick to highlight and key:
- when set to ON, the
speed dome will resume its last operation
when power is restored after a power failure
Highlight the item to modify and key:
Use the joystick to change the setting and key:
to save or: to cancel.
MOTION SETUP
NEAR
PWR UP ACTION
NEAR
NEAR FAR
AUTO FLIP (ON / OFF)
JOG SPEED
JOG DIRECTION (INVERSE / NORMAL)
<ZOOM PROPORTIONAL> -
<PARK ACTION>
PRESET LOCK
- when set to ON, the
dome will flip 180 degrees when the tilt
position reaches 90 degrees.
- determines the maximum
speed in degrees / second the dome will move
during manual operation
-
when set to normal, the pan direction is
opposite to the joystick movement.
used to select
zoom proportion.
- Configure actions that run
automatically after a defined period of
inactivity
- when set to ON, preset
programming directly from the keyboard is
disabled to prevent tampering
3DNR ON/OFF STABLE ZOOM ON/OFF

PRESET SETUP
-----------------------------
PRESET NO.
<EDIT SCENE>
<PRESET DEFAULTS>
<EDIT LABEL>
BACK
EXIT
C L EAR P R E S E T
0 0 1
CANCEL
From the dome camera setup menu, use the
joystick to highlight and key:
- The preset
number currently being modified. If the preset
number is already defined, the speed dome
will move to that preset position, otherwise
UNDEFINED is displayed under the preset
number
- use this option to program
the preset position
- use to edit the preset label.
Highlight the item to modify and key:
Use the joystick to change the setting and key:
to save or: to cancel.
PRESET SETUP
NEAR
PRESET NUMBER (1 - 128)
<EDIT SCENE>
<EDIT LABEL>
NEAR
NEAR FAR
This option is only available when the
selected preset position is already
programmed
<CAM ADJUST>
CLR PRESET
- use to program camera
status for each preset.
- use this option to delete the
current preset position
From the preset setup menu, use the joystick
to highlight and key:
Using the joystick, move the speed dome to
the desired position and zoom level and key:
to save or: to cancel.
EDIT SCENE NEAR
NEAR FAR
Preset setup
11
Park action setup
P A R K A C T I O N S E T U P
-----------------------------
PARK ENABLE
WAIT TIME
PARK ACTION
BACK
EXIT
N O T E : P A R K T I M E U N I T S I S S E C O N D S
OFF
00:10:00
HOME
From the motion setup menu, use the joystick
to highlight and key:
- when set to ON, the speed
dome will run the specified park action after
the wait time has elapsed
- can be set between one minute
and 4 hours. If no manual control occurs
during this time, the park action will run
- choose the action to run after
the wait time has elapsed. This can be return
to home position, go to a preset or run a
SCAN, GROUP or PATTERN TOUR
Highlight the item to modify and key:
Use the joystick to change the setting and key:
to save or: to cancel.
PARK ACTION SETUP
NEAR
PARK ENABLE
WAIT TIME
PARK ACTION
NEAR
NEAR FAR
From the motion setup menu, use the joystick
to highlight and key:
- YES/CANCEL
for each preset, specifies the camera setting.
f
Focus mode - AUTO/SEMIAUTO/MANUAL
Highlight the item to modify and key:
Use the joystick to change the setting and key:
to save or: to cancel.
PRESET DEFAULTS
NEAR
Preset defaults
NEAR
NEAR FAR
ollowing items are available only when
YYY YYY YYYYYY YYYUyes is selected.
MANUAL - the operator must focus the
camera manually by joystick movement using
the ZOOM IN and ZOOM OUT keys.
SEMIAUTO - the camera automatically
focuses during normal PTZ movement but
preset focus information is stored when a
preset is programmed and recalled each time
the preset is called.
AUTO - the module auto focuses continually
MOTION DETECTION OFF/ <ON>
Motion position setup
Motion position setup
-----------------------------
USE U/D/L/R ADJUST THE POSITION
USE NEAR TO SELECT
Motion position setup
-----------------------------
USE U/D/L/R ADJUST WEIGHT AND HEIGHT
USE NEAR TO SELECT
Motion position setup
Move to position setup
Move to positon setup
-----------------------------
USE U/D/L/R ADJUST
USE NEAR TO SELECT
MOVE TO POSITION
077/05 X005

E D I T S C E N E - P R E S E T 0 0 1
-----------------------------
MOVE TO START POSITION
[NEAR:SAVE /FAR:CANCEL]
C A M 0 0 1 O : - - - -
0 0 6 / 0 2 X 0 0 1 I : - - - -
From the preset setup menu, use the joystick
to highlight and key:
Using the joystick, move the speed dome to
the desired position and zoom level and key:
to save or: to cancel.
EDIT SCENE NEAR
NEAR FAR
Edit scene
E D I T S C E N E - P R E S E T 0 0 1
-----------------------------
MOVE TO START POSITION
[NEAR:SAVE /FAR:CANCEL]
C A M 0 0 1 O : - - - -
0 0 6 / 0 2 X 0 0 1 I : - - - -
From the preset setup menu, use the joystick
to highlight and key:
Using the joystick, move the speed dome to
the desired position and zoom level and key:
to save or: to cancel.
EDIT SCENE NEAR
NEAR FAR
12
Preset defaults
PRESET DEFAULTS P R E - 0 0 1
-----------------------------
CLEAR DEFAULTS CANCEL
BACK
EXIT
F O C U S M O D E A U T O
C O L O U R O N
W D R ON/OFF/AUTO/ON-R/ON-D
S T A B A L I Z E R ON/OFF/HOLD
AE-SLOW SHUTTER OFF
<WHITE BALANCE>
<AE MODE>
From the motion setup menu, use the joystick
to highlight and key:
- YES/CANCEL
for each preset, specifies the camera setting.
f
Focus mode - AUTO/SEMIAUTO/MANUAL
Highlight the item to modify and key:
Use the joystick to change the setting and key:
to save or: to cancel.
PRESET DEFAULTS
NEAR
Preset defaults
NEAR
NEAR FAR
ollowing items are available only when
YYY YYY YYYYYY YYYUyes is selected.
MANUAL - the operator must focus the
camera manually by joystick movement using
the ZOOM IN and ZOOM OUT keys.
SEMIAUTO - the camera automatically
focuses during normal PTZ movement but
preset focus information is stored when a
preset is programmed and recalled each time
the preset is called.
AUTO - the module auto focuses continually

13
Edit label
PRESET LABEL SETUP
-----------------------------
L A B F O R P R E [ ]
----------
1234567890
ABCDEFGHIJ
KLMNOPQRST
UVWXYZ -
S A V E C A N C E L
C L E A R C A N C E L
BACK
EXIT
From the preset setup menu, use the joystick
to highlight and key:
The solid white square shows the current
cursor position.
The flashing white square shows the currently
selected character.
Move the joystick up / down / left / right to
choose the required character and key:
to insert it in the preset label. The solid white
square moves to the next cursor position.
Repeat until the preset label is complete.
If a mistake is made, use the joystick to select
the backspace ( ) and key: . The cursor
moves back one square.
Select to save the preset label or
to lose changes, and key: to
exit
EDIT LABEL NEAR
NEAR
NEAR
OK
CANCEL NEAR
From the dome camera setup menu, use the
joystick to highlight and key:
shows the SCAN number
currently being modified.
- any defined preset between 1 &
127.
- any defined preset between 1
&127.
- determines the speed of
movement in degrees per second between
each preset position.
- deletes the currently selected
SCAN function.
- runs the currently selected
SCAN function for testing purposes
Highlight the item to modify and key:
Use the joystick to change the setting and key:
to save or: to cancel.
SCAN SETUP
NEAR
SCAN NO. (1-8) -
1ST POS.
2ND POS.
SCAN SPEED
CLEAR SCAN
RUN SCAN
NEAR
NEAR FAR
Note:AV VSCAN always moves anti-clockwise to
the 1st position and then clockwise to the 2nd
position.
AUTO SCAN Setup
vVST S E T U P
-----------------------------
SCAN NO.
1 S T P O S .
2 N D P O S .
SCAN SPEED
DIRECTION
CLEAR SCAN
RUN SCAN
BACK
EXIT
1 / 8
NONE
NONE
30/SEC
NORMAL
CANCEL
WB mode setup Auto exposure setup
W B M O D E S E T U P
-----------------------------
W B M O D E
RED ADJUST
BLUE ADJUST
BACK
EXIT
A E S E T U P
-----------------------------
BLC
DAY/NIGHT
A E M O D E
IRIS LEVEL
GAIN LEVEL
SHUTTER SPD
BRIGHTNESS
BACK
EXIT
From the zoom camera setup menu, use the
joystick to highlight
and key:
WHITE BALANCE SETUP
NEAR
From the zoom camera setup menu, use the
joystick to highlight
and key:
-The operator can select
BLC(Back Light Compensation) mode,
selecting will disable this feature.
- the
operator can choose to fix the camera in to
DAY (colour) or NIGHT (B&W with IR cut filter
mode). In AUTO mode, the camera switches
between DAY and NIGHT depending on the
surrounding light level
- in AUTO mode, the speed dome
determines optimum camera exposure
settings for a given scene. In modes other
than AUTO, the operator can adjust specific
exposure characteristics to suit a particular
scene
Highlight the item to modify and key:
Use the joystick to change the setting and key:
AUTO EXPOSURE
SETUP NEAR
BLC (OFF/ ON)
DAY/NIGHT (AUTO/DAY/NIGHT)
AE MODE
NEAR
OFF
AUTO
---
---
O N
AUTO
AUTO
---
---
---
---
Preset-001 Preset-001
AWC- the speed dome determines the
optimum white balance settings for a given
scene
MANUAL - the operator can adjust white
balance settings manually
iNDOOR- indoor mode
OUTDOOR-outdoor mode
ATW-auto trace white balance mode
- in manual mode, the red
colour content can be adjusted
- in manual mode, the blue
colour content can be adjusted
WB MODE
RED ADJUST
BLUE ADJUST
3DNR ON/OFF

From the dome camera setup menu, use the
joystick to highlight and key:
shows the group number
currently being modified.
- the currently selected group
can be deleted
- runs the currently selected
group for testing purposes
- allows the operator to
program the group functions. operator can edit
new nesting group action in each group
Highlight the item to modify and key:
Use the joystick to change the setting and key:
to save or: to cancel.
GROUP SETUP
NEAR
GROUP NO. (1-8) -
CLEAR GROUP
RUN GROUP
<EDIT GROUP>
NEAR
NEAR FAR
From the group setup menu, use the joystick
to highlight and key:
To edit the group, key: again
Header explanation:
- the item number (between 1 & 20)
- the specific action for this item
- the action number (eg if ACTION is set
to PRESET, this value can be between 1 &128
- the amount of time before the next
action in the list is called
- for PRESET actions, this value is the
speed at which the dome moves to the preset.
For SCAN and PATTERN, this value is the
number of times the action is repeated before
the next action is called
Move the joystick up and down to choose the
group item to modify and key: The
ACTION is highlighted in white
Move the joystick up and down to change the
action type between NONE, PRESET, SCAN
and PATTERN.
Move the joystick left and right to select and
edit values for AAA, DWELL & OPT.
EDIT GROUP NEAR
NEAR
NO
ACTION
AAA
DWELL
OPT
NEAR.
Key to save this item and continue
adding more items as necessary, or key
to exit.
NEAR
FAR
Group setup Edit group Edit group
GROUP SETUP
-----------------------------
GROUP NO.
SAVE GROUP
CLEAR GROUP
RUN GROUP
<EDIT GROUP>
BACK
EXIT
E D I T G R O U P 1
-----------------------------
-----------------------------
1 P R E S E T 0 0 1 0 0 : 0 3 3 6 0
2 N O N E
3 N O N E
4 N O N E
5 N O N E
-----------------------------
BACK
CANCEL
NO ACTION AAA DWELL OPT
E D I T G R O U P 1
-----------------------------
-----------------------------
1 PATTERN
2 P R E S E T
3 S C A N
4 P R E S E T
5 P R E S E T
-----------------------------
BACK
C A N C E L [ N E A R : E D I T ]
NO ACTION AAA DWELL OPT
1/8
CANCEL
CANCEL
14
1
5
3
10
4
1
360
8
110
5 5
00:03
00:08
00:03
00:15
01:30
PATTERN SETUP
-----------------------------
PATTERN NO.
CLEAR PATTERN
RUN PATTERN
<EDIT PATTERN>
BACK
EXIT
1 / 4
CANCEL
From the dome camera setup menu, use the
joystick to highlight and
key:
- The pattern number
currently being modified.
- the currently selected
pattern can be deleted
- runs the currently selected
pattern for testing purposes
- allows the operator to
program a patten tour
Highlight the item to modify and key:
Use the joystick to change the setting and key:
to save or: to cancel.
PATTERN SETUP
NEAR
PATTERN NO. (1 - 4)
CLEAR PATTERN
RUN PATTERN
<EDIT PATTERN>
NEAR
NEAR FAR
Pattern setup

15
E D I T P A T T E R N 4
-----------------------------
MOVE TO START POSITION
[NEAR:START /FAR:CANCEL
C A M 0 0 1 O : - - -
009/06 X001 I:---
EDIT PATTERN 4
[NEAR:SAVE /FAR:DELETE]
From the pattern setup menu, use the joystick
to highlight and key:
Position the speed dome to the desired
starting point and key:
EDIT PATTERN NEAR
NEAR
Move the dome to the various positions and
zoom levels required for the pattern. The white
squares at the top of the display show
remaining storage and disappear as the
pattern is recorded.
To save the pattern, key:
To abandon pattern programming, key:
NEAR
FAR
Note: Pattern tour memory is only used when
movements are recorded. Pauses between
movements, regardless of time, do not use
pattern tour memory
Edit pattern Schedule Setup
SCHEDULE SETUP
-----------------------------
MASTER ENABLE
D A Y T I M E A C T N O .
1 M O N 0 0 : 0 0 P A T 0 0 1
2 UNDEFINED
3 UNDEFINED
4
5
6
7
UNDEFINED
UNDEFINED
UNDEFINED
UNDEFINED
BACK
From the main menu, use the joystick to
highlight and key:
- selecting this option to set date
and time
-
Highlight the item to modify and key:
Use the joystick to change the setting to ON
and key: to run or: to cancel.
SYSTEM INITIALISE NEAR
DAY TIME
ACT
NEAR
NEAR FAR
selecting this option to set dome motion
OFF
OFF

From the main menu, use the joystick to
highlight and key:
- when set to
ON, the correct password must be entered to
access the speed dome setup menus
- allows the current
password to be changed
PASSWORD SETUP NEAR
CHECK PASSWORD (ON/OFF)
<EDIT PASSWORD>
SAVE - to save current password.
Password setupPassword setup
PASSWORD SETUP
-----------------------------
BACK
EXIT
C H E C K P A S S W O R D O F F
<EDIT PASSWORD>
PASSWORD SETUP
-----------------------------
C H E C K P A S S W O R D O F F
<EDIT PASSWORD>
S A V E C A N C E L
16
Edit Password
Password setup
-----------------------------
From the password setup menu, use the
joystick to highlight and
key:
Default password is 11111111
The solid white square shows the current
cursor position.
This flashing white square shows the currently
selected character.
Move the joystick up / down / left / right to
choose the required character and key:
to insert it in the password. The solid white
square moves to the next cursor position.
Repeat until password entry is complete.
If a mistake is made, use the joystick to select
the backspace ( ) and key: . The cursor
moves back one square.
Select to save the password or
to lose changes and key: to exit
EDIT PASSWORD
NEAR
NEAR
NEAR
OK CANCEL
NEAR
Remember: When CHECK PASSWORD is set
to ON, each time the operator attempts to
enter the speed dome setup menu, the above
screen will be displayed. The correct
password must be entered to continue with
menu setup
INPUT CURRENT PASSWORD:
11111111
ALARM SETUP
-----------------------------
A L A R M I N C H A N E L 1 / 8
A L A R M E N A B L E O F F
RELATE PRESET
R E L A T E R E L A Y O U T - - - -
INPUT SETUP
RELAY ACTIVE TIME
S A V E C A N C E L
BACK
EXIT
From the main menu, use the joystick to
highlight and key:
- selecting alarm chanel
- this option will enable
alarm function
- selecting related preset
- selecting related relay
out
- set up alarm input
- set relay active time.
Highlight the item to modify and key:
Use the joystick to change the setting to ON
and key: to run or: to cancel.
ALARM SETUP NEAR
ALARM IN CHANEL
ALARM ENABLE
RELATE PRESET
RELATE RELAY OUT
I
INPUT SETUP
RELAY ACTIVE TIME
NEAR
NEAR FAR
System Initialise
SYSTEM INITIALISE
-----------------------------
C L E A R A L L D A T A
CLR DISPLAY SET
C L R C A M E R A S E T
C L R M O T I O N S E T
C L R E D I T D A T A
REBOOT CAMERA
REBOOT SYSTEM
BACK
EXIT
From the main menu, use the joystick to
highlight and key:
- this option will erase all
presets, VST functions, patterns and groups
Highlight the item to modify and key:
Use the joystick to change the setting to ON
and key: to run or: to cancel.
SYSTEM INITIALISE NEAR
CLR EDIT DATA
NEAR
NEAR FAR
CLEAR ALL DATA
CLR DISPLAY SET
CLR CAMERA SET
CLR MOTION SET
- selecting this option will
perform a full factory reset on the speed
dome. All presets, scan functions, patterns,
groups and privacy zones will be erased
- this option will reset the
on screen display settings to factory default
and erase all privacy zones
- this option will reset the
camera module settings to factory default
- this option will reset the
motion menu settings to factory default
Alarm Setup

17
System Help
SYSTEM HELP
-----------------------------
I N C O M M O N U S E ,
FOLLOW KEY TO CONTROL MENU:
JOG U/D/L/R TO SELECT
FOCUS NEAR TO CONFIRM
FOCUS FAR TO CANCEL
BACK
EXIT
From the main menu, use the joystick to
highlight and key:
Highlight the item to modify and key:
Use the joystick to change the setting to ON
and key: to run or: to cancel.
SYSTEM HELP NEAR
NEAR
NEAR FAR
Calling the actions
Once the pattern tours,
and groups have been
programmed in the speed dome
setup menu, they can all be
accessed directly from the PTZ
control equipment by using the
following sequences.
scan
functions
1. To start a pattern tour press:
Where is a pattern tour number between
1 & 4
The selected pattern tour will run
indefinitely until a manual movement is
made by the operator or an alarm input is
received.
SHOT - 13X - ENTER
X
2. To start a scan function, press:
Where is a scan function number
between 1 & 8
The selected scan function will run
indefinitely until a manual movement is
made by the operator or an alarm input is
received.
3. To start a group, press:
Where is a group number between 1 & 8
The selected group will run indefinitely
until a manual movement is made by the
operator or an alarm input is received.
SHOT - 14X - ENTER
X
SHOT - 15X - ENTER
X
Shortcut Menu
SHOT - NO.-ENTER FUNCTION
0 (TWICE) ENTER MAIN MENU
33 RESERVED
34 RESERVED
62 RESERVED
63 RESERVED
92 RESERVED
93 RESERVED
94 REMOTE RESET
95 ENTER MAIN MENU
131-134 CALL PATTERN
141-148 CALL SCAN
151-158 CALL GROUP
161-165 RESERVED WORD
170 WDR OFF
171 WDR ON
172 AE AUTO
173 SET SHUTTER SPEED TO 1/120 SEC

Heater
Thermostat
Fan
Thermostat
Shield Mount
Tilt Motor
Inner dome cover
Zoom Module
Dome Cover
Pan Motor
Sunshield
Dome Housing
Bracket Mount
Base
Bracket Upper
Cover
Seal
Housing Upper Cover
Bracket Joint
PCB
Parts and dimensions
42
59
138
300
248
91
230
33
33
53
140
19
156
325
201
18
