Provision ISR Mini Ultra-Z Z-10AHD-1 (IR) PTZ User manual

[Date]
Tal Hanoch
PROVISION-ISR

1
Package Contents:
Item
Qty.
Z-10AHD-1 (IR) PTZ
1
DC12V/3A power supply
1
Wall Screws
4

2
Table of Contents:
1 General Instructions:...................................................................3
1.1 Safety Instructions: .......................................................................... 3
1.2 Warnings: ......................................................................................... 3
2 Features: ......................................................................................4
2.1 Product Picture: ............................................................................... 4
2.2 Product Features.............................................................................. 4
2.3 Specifications: .................................................................................. 5
3 Installation Site Preparations:.....................................................6
3.1 Tool List: ........................................................................................... 6
3.2 Installation Preparation: .................................................................. 6
3.3 DIP Switch Setting:........................................................................... 6
3.4 Output Mode Setting:...................................................................... 7
4 Setup of the OSD Menu:..............................................................7
4.1 Display Boot-UP Info. ......................................................................... 7
4.2 Enter the OSD Menu: ....................................................................... 8
4.3 SYSTEM Menu: ............................................................................... 10
4.4 LENS................................................................................................ 13
4.5 Advanced Camera Menu:............................................................... 15
4.6 PAN/TILT......................................................................................... 18
4.7 AUTO RUNNING ............................................................................. 19
4.8 IR SET.............................................................................................. 26
APPENDIX I: DIP SWITCH SETTING: ...............................................27
APPENDIX II Shortcuts Key Chart: .................................................32
APPENDIX III Trouble Shooting ....................................................34

3
1 General Instructions:
1.1 Safety Instructions:
Make sure to read the user manual before using the camera.
Always follow national and local safety codes during the installation.
Only qualified and experienced person can carry the installation and
maintenance for this camera.
Use reliable tools.
Make sure that the environmental conditions meets the installation
requirements for this product.
Please check the space and toughness of the installation surface before
installation. It should be able to bear 4 times the weight of the camera
and its accessories.
1.2 Warnings:
Do not install this speed dome in hazardous places where combustible
or explosive materials are stored or used.
Do not install on platform that suffers from constant vibrations.
Make sure no object or fluid substances get inside the unit.
This speed dome runs on DC 12V, do not connect it to different voltage.
Do not turn power on before installation is complete.
Do not disassemble any part of the camera.
Use soft towel to clean the down the lenses when necessary, do not use
caustic detergent.
To protect the image sensor, avoid facing the camera directly into
strong light.
To prevent damage, do not drop the unit or expose to strong shocks or
vibrations.
Make sure no object is blocking the unit’s full range of motion.

4
2 Features:
2.1 Product Picture:
2.2 Product Features
Adaptive PELCO-P/D protocol.
Adjustable IR illumination.
Memory recall.
Real-Time-Control: call any functions at any time.
Support 128 preset positions.
English OSD menu.
Proportional zoom.
Auto flip function.
Advanced step motor for smoother movement.
Support 4 groups cruise scan, 4 patterns, one scan and 360°continuous
scan and 360° intermittent scan.
IR lights automatically adjust the light intensity according to the zoom
ratio to reduce the dark angle and flashlight effect.
The underpart dome adopts full metal class points bin type design for
fast heat dissipation and anti-mist, non-interference light source images
and long life span IR light.

5
2.3 Specifications:
Power Supply
Input：AC100～240V 50/60Hz
Output：DC12V±5%，3A
Max. Power
Consumption
IR off：~7.2W
IR on：~19.8W
Sync system
Internal Sync
Language
English
Signal Output
AHD/CVBS + PAL/NTSC
Pan Speed
0.08°～240°/S (Max. Preset Speed)
Tilt Speed
0.08°～240°/S (Max. Preset Speed)
Pan Range
0°～360°(Continuous)
Tilt Range
0°～90°（180° auto flip）
Presets
128
Preset Accuracy
<±0.1°
Tour
4 Groups
Pattern
4
Zone
1
Protocol
RS485
Communication
PELCO-D/P auto detected
Baud Rate
2400bps、4800bps、9600bps、19200bps
Address
1-255 (By DIP Switch or Software)
IR Light switch
Superpower LED：Default: Zoom x1~5: open the
near-distance IR lights; Zoom x6~10: keep the near
IR on and opens far-distance IR lights.
Work
Temperature
Indoor：0℃～+50℃；
Outdoor ：-20℃～+50℃(with heater)
Work Humidity
<90%

6
3 Installation Site Preparations:
3.1 Tool List:
(1) Screws* (2) Monkey wrench
(3) Philips screwdriver (4) Straight Screwdriver
(5) Wire stripper (6) Socket head wrench
(7) Electric drill (8) Hammer
(9) BNC connector (10) BNC Clamp
*Included in the kit
3.2 Installation Preparation:
(1) Check the space and toughness of the site and make sure that the
environmental conditions meet the installation requirements for this product.
(2) The installation surface should be able to bear 4 times the weight of the
PTZ and its accessories.
3.3 DIP Switch Setting:
(1)Default Settings: Pelco P/D (auto-detected), baud rate: 2400, address: 1.
Use Philips screwdriver to remove the DIP switch cover (see location below)
(2)Baud Rate Setup
Decoder Switch: 9~10 (1=ON, 0=OFF)
Switch 9-10 setting
Baud Rate
Max transmission
distance(M)
9
10
0
0
2400BPS
1800
1
0
4800BPS
1200
0
1
9600BPS
800

7
1
1
Auto detected 2400、
4800、9600、
19200BPS
600-1800
(3) When the DIP Switch 9th and 10th are ON, the PTZ can automatically
detected the baud rate 2400, 4800,9600,19200
(4) Hardware Address Setup*: Please refer to Appendix I.
*Please note that the address setting can also be configured via the
software using the camera OSD (Page 11).
3.4 Output Mode Setting:
(1) Default Settings: AHD + PAL/NTSC
This output can be changed via the controller (Even if the user cannot gain a
video output from the unit due to output incompatibility)
(2) Set your controller/DVR PTZ Settings to the Camera’s Default
Communication Settings: Protocol: PELCO-D, address: 1 (Unless user
changed it by the DIP switch configuration), baud rate: 2400.
(3) Call the Preferable Preset that matches your required configuration:
Preset 74 for AHD + PAL
Preset 75 for AHD + NTSC
Preset 76 for CVBS + PAL
Preset 77 for CVBS + NTSC
4 Setup of the OSD Menu:
4.1 Display Boot-UP Info.
Before installation please check the protocol, baud rate, address and RS485
data cable. Default Settings: Protocol: PELCO-D, address: 1, baud rate: 2400.

8
When starting, the PTZ will display the following information:
Once done, the above information will disappear and the user will gain
control over the camera.
4.2 Enter the OSD Menu:
While the camera is in standby condition, call preset 95 (“Call” + 95 + “Enter”)
in order to display the main menu. Use the Up/Down direction to select item
or start the configuration. Use the Right key to confirm and left key for exit
the current setting.
The Main menu as follows:
Level self-check: Success
Vertical self-check: Success
Success
PROTOCOL: PELCO P D
BAUD RATE: 2400BPS
CAMERA ID: 001
CAMERA S/N: 0000000001
MODEL: -----------------
VERSION: V1.02
FAN SPEED: 6000RPM
STARTING…….

9
SYSTEM
LENS
PAN/TILT
AUTO RUNNING
IR SET
EXIT

10
4.3 SYSTEM Menu:
<Main Menu> <SYSTEM>
System info includes following settings.
< SITE INFO>: In this menu the user can setup the dome’s name, View
the Hardware address, change the camera software address and choose
the leading command (Hardware or Software).
< DISPLAY SETUP >: In this menu the user can choose which details will
display on the camera Screen. The available options are: Site name,
Preset title, Pattern name, Zoom, Orientation, Temperature, Zone name
and RTC time.
<DISPLAY BOOT-UP INFO>: User can view the boot information.
<SET DEFAULT>: All settings will go back to factory default. Preset
positions will be retained.
<SYSTEM REBOOT>: After change dome ID or adjust deviation between
two preset positions, user this to remotely reboot the system.
SITE INFO
DISPLAY SETUP
BOOTUP SCREEN
SET DEFAULT
SYSTEM REBOOT
BACK
EXIT

11
4.3.1 SITE INFO
<Main Menu> <SYSTEM> <SITE INFO >
<DOME ID OPT>: Setting the address method that controls the dome,
user can choose from SOFT (Software –As defined below in the OSD
menu) and HARD (Hardware –As defined by the DIP switch prior to the
installation).
[SOFT]: when choose this, the SOFTWARE ID is effective while the
HARDWARE ID is ineffective.
[HARD]: when choose this, the HARDWARE ID is effective while the
SOFTWARE ID is ineffective.
<SOFTWARE ID>: shows the current software ID, user can modify and
choose address in the range of 001~254
<HARDWARE ID>: shows the current physical ID, it is decided by the DIP
Switch only: user cannot modify via the OSD.
<BROADCAST ID>: shows the current ID, The ID functions the same as
dome’s <SORTWARE/ HARDWARE ID>, The dome works when receives
any of those ID. The dome’s broadcast ID is 255 and cannot be
modified.
DOME ID OPT: HARD
SOFTWARE ID: 001
HARDWARE ID: 001
BROADCAST ID: 255
BACK
EXIT

12
<BACK>: return to upper menu.
<EXIT>: exit the menu
4.3.2 DISPLAY SET UP
< Main Menu><SYSTEM><DISPLAY SETUP>
<PRESET TITLE>：Choose to display preset position or not.
<PATTERN NAME>：Choose to display pattern name or not
<ORIENTATION>：Choose to display the current lens direction or not.
<TEMPRETURE>：Choose to display the current temperature or not.
4.3.3 DISPLAY BOOT-UP INFO
PRESET TITLE: OFF
PATTERN NAME: OFF
ORIENATATION: OFF
TEMPRETURE: OFF
BACK
EXIT
PROTOCOL: PELCO P D
BAUD RATE: 2400BPS
CAMERA ID: 001
CAMERA S/N: 0000000001
MODEL: -----------------
VERSION: V3.06*
CALL PRESET 1 TO BACK

13
<Main Menu><SYSTEM><DISPLAY BOOT-UP INFO>
Enter into Boot-up info displays to check current setup, call preset 1 to return
to upper menu
4.3.5 SET DEFAULT
<Main Menu><SYSTEM><SET DEFAULT>
Select <SET DEFAULT> to restore factory default setting.
Please note: there is no confirmation prompt! Once entering the camera
will immediately restore itself.
4.3.6 SYSTEM REBOOT
<Main Menu><SYSTEM><SYSTEM REBOOT>
Select <SYSTEM REBOOT> to reboot the dome.
4.4 LENS
<Main Menu><LENS>
<ZOOM SPEED>: Set the zoom speed level to HIGH or LOW
<DIGITAL ZOOM>: Turn On/Off the Digital Zoom.
<AF/AI SET>: Set up Auto Focus (AF), Auto Iris (AI) or Both
ZOOM SPEED: HIGH
DIGITAL ZOOM: OFF
AF/AI SET: BOTH
AF RESUME TIME: 005
AI RESUME TIME: 005
DAY/NIGHT: IR-CTR
BACK
EXIT

14
<BOTH>: Joystick movement triggers both auto focus and auto iris
<FOCUS>：Joystick movement triggers auto focus only
<IRIS>: Joystick movement triggers auto iris only.
<NONE>: Joystick movement triggers none of the functions.。
<AF RESUME TIME>: This item sets the time to restore auto focus after
focus is manually changed. The default setting is 005, options are:
[OFF] Never restore auto focus after switch to manual.
[001-255]The dome will start auto focus that number of seconds after user
manually adjusts focus.
<AI RESUME TIME>: This item sets the time to restore auto iris after iris
is manually changed. The default setting is 005 seconds, options are:
[OFF]: Never restore auto iris after switch to manual.
[001-255]: The dome will start auto iris that number of seconds after user
manually adjust iris.
<DAY/NIGHT>: Set the dome color/ black & white mode. Color mode is
suitable to work in daytime because it needs higher illumination. Light
sensitivity of black & white mode is much higher. It is suitable to work
at night without illumination but the video is black and white.
There are 4 options:
[AUTO]: The dome will automatically change modes according to the
environment illumination.
[COLOR]: The dome is always in color mode.
[NIGHT]: The dome is always in Black and White mode.
[IR-CTL]: The dome is controlled by the IR lights sensor, when the IR lights
opened, the mode auto change to Black and White.

15
4.5 Advanced Camera Menu:
For advanced Menu, Call preset #69.
PLEASE NOTE: Scrolling and changing values in the advanced menu is done
with different controls:
1) The controller joystick has effect.
2) Scrolling up and down is done by pressing IRIS+/IRIS-
3) Changing Values of the selected feature is done by pressing
ZOOM+/ZOOM-
IMPORTANT!!! Changing any values the advanced menu might result in the
camera malfunctioning
LANG EN
OSD-DISP ON
ADDR-DISP OFF
D&N COL
D&N-LV 30
N&D-LV 12
MIRROR OFF
AGC 15
BRIGHT 15
CONTRAST 15
SHARPNESS 19
SAT 20
WDR OFF
2D-NR 00
3D-NR 02
BLC OFF

16
<LANG>: Language of the menu (Only English Available)
<OSD-DISP >: Do Not Change
<ADDR-DISP>: Do Not Change
<D&N>: Do Not Change
<D&N-LV>: Do Not Change
<N&D-LV>: Do Not Change
<MIRROR>: Turning Mirror effect ON/OFF
<AGC>: changing the value of AGC
<BRIGHT>: Changing the brightness value.
<CONTRAST>: Changing the contrast value.
<SHARPNESS>: Changing the sharpness value.
<SAT>: Changing the saturation value.
<WDR>: Turning Digital WDR effect ON/OFF
<2D-NR>: Adjusting the level of 2D-NR noise reduction
<3D-NR>: Adjusting the level of 3D-NR noise reduction
<BLC>: switching between OFF/ON.
WB AUTO
RGAIN 00
BGAIN 00
DE-FOG 00
OUTPUT AHD
FORMAT 720/25
ZOOM 20
FOCUS AF
Z-SAVE ON
F-RANGE 1.3M
ZDISP-POS RD
RESET
SAVE-EXIT

17
<WB>: White Balance is normally compensated for by the automatic
white balance gain control. In some lighting conditions, user may want
to manually adjust the red and blue settings for optimal viewing. There
are 6 options:
[AUTO]: Auto White Balance (default setting).
[ATW]: Auto track White Balance.
[PUSH]: Once touch White Balance
[OUTDOOR]: Suitable for outdoor use.
[INDOOR]: Suitable for indoor use.
[MANUAL]: Manually set the red and blue values
<BGAIN>: Set the blue value (Only effective if WB is set to Manual)
<RGAIN>: Set the red and value (Only effective if WB is set to Manual)
<DE-FOG>: Change level of defog effect.
<OUTPUT>: Manually set the output between AHD & CVBS
<FORMAT>: Manually set the output between 25&30 (PAL/NTSC)
<ZOOM>: Do Not Change.
<FOCUS>: Do Not Change
<Z-SAVE>: Do Not Change
<F-RANGE >: Do Not Change
<ZDISP-POS >: Set the location of the zoom display (RD –Right Down,
RU –Right Up, LD –Left Down, LU –Left Up)
<RESET >: Reset All settings to factory Default

18
4.6 PAN/TILT
<Main Menu><PAN/TILT>
<AUTO STOP TIME>:
For some particular protocols, the dome will not stop moving even there is
no operation by the controller. This menu sets the time duration before
stopping after which the dome receives last control command.
[Off]: Disable this function
[001~255]: The time (second) that dome will stop moving without receiving
any commands.
<SPEED AMPLIFY>:
Some protocols’ controlling speed is much lower, set <SPEED AMPLIFY> to
accelerate domes movement. Options are as below:
[Off]: Disable this function
[01×~ 32×]: Speed amplify from 01~32x
Notice: The above two functions is not available at present
<PROPORTIONAL P/T>:
The dome moves at a certain speed (degree per second). While zoomed in,
the default movement speed may become too fast. This function decreases
the dome movement speed while zoomed in for easier control on the dome.
AUTO STOP TIME: OFF
SPEED AMPLIFY: OFF
RATIO PAN/TILT: ON
SET NORTH
BACK
EXIT

19
<SET NORTH>:
User can set orientation by using joystick to position north.
When select <SET NORTH>, following menu will pop-up.
Adjust the lens to desired position and call preset 1 to confirm and return.
4.7 AUTO RUNNING
<Main Menu><AUTO RUNNING>
4.7.1 PRESET
<Main Menu><AUTO RUNNING><PRESET>
CALL PRESET 1 TO RETURN
CONFIRM. . . . . .
PRESET
TOUR
PATTERN
360 SCAN
ZONE
PARK TIME: 0S
PARK ACTION: OFF
BACK
EXIT
