Purmo V10 User manual

Purmo Group, Gateshead, NE11 0PG; Purmo Group Newcastle West, V42 TD39
DSVI-001
Safety Precaution:
Radiators are hot when in use, and as such, present a risk of
burns to users on prolonged contact.
The temperature of a radiator is dependent on the temperature
of the system water, as set by the system installer or end user.
Installers and users should ensure that those who come in to
close proximity to hot radiators are aware of the risks of burns.
Installers and users should take all necessary steps to minimise
the risk of burns. If the risk is significant, consideration should
be given to installing low temperature radiators, or to placing
guards in front of radiators.
For the correct installation of radiators it is essential that the
fixing of the radiator is carried out in such a way that it is
suitable for intended use AND predictable misuse.
A number of elements need to be taken into consideration
including fixing method used to secure the radiator to the wall,
the type and condition of the wall itself, and any additional
potential forces or weights, prior to finalising installation.
IN ALL CASES IT IS STRONGLY RECOMMENDED THAT A
SUITABLY QUALIFIED PROFESSIONAL INSTALLER OR SIMILAR
TRADESPERSON CARRIES OUT THE INSTALLATION.
PLEASE NOTE: The fixing materials provided are only intended
for installation on walls made of solid wood, bricks, concrete
or on timber frame stud walls where the fixing is in to the
timber. All walls being considered should have no more than
a maximum of 3 mm wall finishing. For walls made of other
materials, for example hollow bricks, please consult your installer
or specialist supplier. ONCE AGAIN, IF YOU ARE UNSURE, IT
IS STRONGLY RECOMMENDED THAT A SUITABLY QUALIFIED
PROFESSIONAL INSTALLER OR SIMILAR TRADESPERSON
CARRIES OUT THE INSTALLATION.
PENCIL MARKS
PENCIL MARKS
RADIATOR
LENGTH
RIGHT HAND
LEFT HAND
HEIGHT : 600mm TO 1900mm
88 88
200
200
ALL RADIATOR LENGTHS
HEIGHT : 2000mm TO 3000mm
88 88
200
200 ==
ALL RADIATOR LENGTHS
A
THGIEH
LENGTH
HTGNEL / 2
5
3
A
4
6
27
2
821
1
272
V10: 100mm
DIMENSION A
V20: 88mm
RADIATOR WALL LOCATION
FIG 1.
MOUNTING LUG LOCATIONS
FIG 2.
Vertical Flat Tube Radiator
Models: V10 & V20
Installation Procedure:
1. Decide on the position of the radiator and mark the
mounting bracket positions according to Fig 1.
2. Align the wall brackets according to Fig 3 and mark the
hole fixing hole positions.
3. Drill and plug the bracket fixing holes and fix the brackets
securely to the wall.
4. Mount the radiator on the brackets and connect the
radiator to the heating system.
5. Fit the plugs and vent to the radiator.
6. Fill the system and vent the radiator.
7. Balance the system to ensure correct flow through all
radiators.
MOUNTING BRACKET DETAILS
FIG 3.

Purmo Group, Gateshead, NE11 0PG; Purmo Group Newcastle West, V42 TD39
Vertical Flat Tube Radiator
Models: V10 & V20
BRACKET MOUNTING AND
PIPE CENTRE DETAILS
CONNECTION DETAILS
A
E
F
B
C
D
CONNECTION LADDER
C
A
EF
D
B
BAFFLE LOCATED IN
CENTRE OF HEADER
BETWEEN FLOW AND
RETURN
(INDICATED BY STICKER)
BAFFLE
LOCATION STICKER
69
77
8
BRACKET
LN2 WALL
SIDE VIEW V10
99
78 21
BRACKET
A2 WALL
SIDE VIEW V20
02
38
02
PLAN VIEW V10
02
60
02
PLAN VIEW V20
A
B
C
D
E F
G H
Notes:
Radiator should be connected BOE(BD/DB) or
BBOE (EF/FE)
OR
For TTOE or TOE the radiator must be inverted.
The header containing the baffle (depicted by
the baffle sticker), must always be fitted flow/
return.
Information for the installer:
These radiators are for use on two pipe pumped indirect
domestic and commercial heating installations, with a maximum
working temperature of 100°C.
The system should be designed in accordance with BS EN
12828:2012+A1:2-14 or BS EN 12831-1:2017 as appropriate,
with particular care to avoid air entry or water discharge.
The installation work must be carried out in accordance with
recognised good practice, and precautions taken to avoid
contamination which could lead to corrosion. In accordance
with current Building Regulations a corrosion inhibitor or other
suitable water treatment must be used. The manufacturer’s
instructions must be strictly followed.
Failure to comply with these standards might invalidate the
manufacture’s warranty.
10 Year warranty.
The recommendations of BS 7593, Code of Practice for
treatment of water in domestic hot water central heating
systems, should be followed where appropriate.
Important Notes:
• The header with the flow/return connections contains a
baffle and is identified by a sticker (shown on the right).
• Connections in the opposite header are to be used as vents
or drains depending on the orientation of the radiator.
• Ensure there is no trapped air in the radiator by adequately
bleeding the system during installation.
• Flow rate may need to be adjusted/balanced for optimum
performance.
PLAN VIEW V20
2020
78
SIDE VIEW V20
60
99
100 Min
PLAN VIEW V10
69
2020
SIDE VIEW V10
38
77
100 Min
DSVI-001

Moretti (UK) Ltd , Trade House, Yeovil BA22 8RT
Product Warranty
Thank you for purchasing a Moretti Design Radiator. Your radiator has been designed and tested to
give you many years of trouble-free service. For your additional peace of mind, we give the following
Warranty across the below design radiators. Your statutory rights are not affected by this Warranty.
•Moretti Modena
•Moretti Rovingo
•Moretti Sorrento
•Moretti Tuba
Subject as provided below. Moretti Radiators underwritten by Moretti (UK) Ltd (“Moretti ”) warrants to
the original purchaser at the original installation site that its products will be free from defects in materials
and workmanship for the period of 5 (FIVE) years*.
*12 months on any panel products placed in an area of high humidity
The original purchaser’s remedy for breach of this Warranty is expressly limited to repair or replacement
of any part or parts found to be defective under conditions of normal service and use during the above
Warranty period and does not extend to Moretti being liable for any incidental, special or consequential
damages or losses whatsoever. Such as loss of use of the product, inconvenience or lost profits.
This Warranty does not cover any defect, damage or malfunction in the product which is due to; failure
to comply in any respect with Moretti’s installation, maintenance or operating instructions; faulty storage,
handling, installation or repair; mis-use; neglect; accident; abuse; or general wear and tear.
The system should be designed in accordance with BS EN 12828:2012 and BS EN 12831:2017, and
installed and commissioned in accordance with BS EN 14336:2004. On completion of the installation
the system should be properly flushed and filled in accordance with the British Code of Practice for the
preparation, commissioning and maintenance of domestic central heating and cooling systems. We
strongly recommend the use of corrosion inhibitor for all applications.
Before free service under this Warranty can be provided, the original purchaser will be required to prove
the date of purchase and may be required to provide Moretti with supporting information, as Moretti
may need to conduct its investigation into the alleged defect.
Moretti reserves the right to make reasonable charge for inspection and testing any product which is
subject to a Warranty claim and the rights conferred by the Warranty are conditional upon the payment
of such charge. The charge may be made at Moretti’s discretion, either before or after the inspection
and testing of the product. In the event that it is established to Moretti’s reasonable satisfaction that a
valid Warranty claim has been made in respect of the product, then charge which has been paid will be
refunded in full by Moretti.
