Pyle view PLHR97W User manual

PYLI:
view
PLHR97W
Operating
Instructions
9" TFT LCD Headrest Monitor wI Stand
HTTP://WWW.PYLEAUDIO.COM

Appearance and function
1.Down
2.UP
1 2 3 4 5
3.Remote control and IRwindow
4.Menu
5.Power
on/off
Function
Screen size: 9 inches
Displayformat: 16:9
Resolution:1440X234Dots
System: NTSC/PAL
Wireless Remote Control
Dual Video Input
Reverse Imaging Left/Right Up/Down
Brightness/Contrast/Color/TintAdjustments
Headrest Shroud and Universal Stand Mount
On Screen Display
Brightness, Contrast,
Color
Powersupply: DC 12V
Disaster box
•
R•
.,2V
~ P
~~-
D
00 ,:~~======~I~~ V2vldeolnpul(yellow)
. _____ ~ V1 video Input(yallow)
~ LeftChannal(white)
Right channal (red)
OPERATIONS OF REMOTE CONTROL
~,+ --- Power on/off
Menu--~
~'------- ShiftbelweerlAvl1 Av2 VKIeo
Analog decrea.e ---I-"
~;----- Analog increase
Mode sell lee! ------11
Basic operation
1.Connectthe attached cable to the power source and signal cable.
One tip
ofthe cable is connected to the lemale socket olthe monitor,
anothertip is to the video
outline olVCD or DVD.The blackcable is
connected to ground,red cable is to positive pole.Please mind to
connectthe black and red cable correctlY,orthe safetyfuse
in the
disaster boxwill melt protectively.Connect the left(whiteland right(redl
channel linewith the respective channel audio output
olVCD and DVD.
2.When
poweron,the monitorshows VCDor DVD signal.ll no signal,the
blue screen appears.
3.Brightness,contrast,color,tintcan be adjusted from the function menu.
Just press the "Analog decrease" and" Analong increase" ,adjust to
the bestquality olthe images.
4.There is audio signal output when the monitoris
on V1.There is not
audio signal outputwhen the monitor is onV2.
