Pyle view VIEW PLHR77 User manual

7" Widescreen TFT/LCD Video Monitor
w/Headrest Shroud and Stand
PLHR77
HTTP://WWW.PYLEAUDIO.COM
Instruction Manual
1 x headrest shroud
1 x instruction manual
1 x bracket
1 x remote control
2 x connection wire
1. When connect the electric power wires, you should make clear about the
positive and negative electrode ( the red one is positive and the black
is negative). If you wrongly connected the fuse in the filter box will be
broken protectively. Please replace the fuse in same parameter.
2. Because the LCD screen is the main component It should be paid
attention to be damp-proof.
3. The device must be installed firmly to prevent falling of device that will
possibly cause injury and device-broken.
4. The connecting-point of direct current (12V) should connect on the Main
line of storage battery as possible as it can , for keeping this device in
normal operation and be away from the large voltage drop influence.
5. There is high voltage cluster in this machine, if you are the professional
person, should never to take part the machine if malfunction and
contact the dealer in time.
Attentions:
Accessories
PLHR 77

Thank you for purchasing the TFT LCD color monitor. To enjoy the features
of this device and to ensure years of trouble-free operation, please read
this manual carefully and follow the instructions.
Front Panel
1. AV input
2. Earphone jack
3. Pilot lamp
4. V1/V2 switch
5. Mode
Remote control
1 2 3 4 5 6 7 8 9 10
6. Activation of menu indicator
7. Negative adjustment
8. Positive adjustment
9. Power ON/OFF
10. Remote sensor
Power ON/OFF
Analog variable increase
Menu button
V1/V2 conversion
Analog variable decrease
Switch for mode
PLHR77
Specification
Screen Size:
Resolution:
System:
Power source:
Power consumption:
Video Input:
Operating Temperature:
Storage Temperature:
Headrest bracket
Suitable for any kinds of car
seats. Easy and conveniently
installation without damage
to the seats. Length can be
adjusted(as Picture).
7 inch
480xRGBx234
NTSC/PAL
DC 12V
<9W
Composition video signal
0°C ~ 60°C
-20°C ~ 80°C
Installation Diagram
(Yellow) Video 1 input
(Red) Audio right input
(White) Audio left input
(Black) Grounding
(Red) Battery +12V
(Yellow) Video 2 input
