INSTALLATION GUIDE
FOR RGN8617WS and RGN8617C
CARE AND MAINTENANCE
SAFETY INFORMATION Released Date: 2021-10-28
• Wipe clean using soft, dry cloth or static duster. Always avoid using harsh chemicals and abrasives to clean fixture as they may damage
the finish.
If you need further assistance call Quoizel Customer Care at 1-800-645-3184 (9:00am - 5:00pm EST), or visit us on-line at
www.quoizel.com.
Please read and understand this entire manual before attempting to assemble, install or operate the product.
WARNING
• RISK OF ELECTRIC SHOCK - Before beginning installation, turn off electricity at the circuit breaker box or the main fuse box.
• RISK OF FIRE - Use bulbs specified by the markings and/or labels on the fixture.
CAUTION
• For your safety, read instructions completely before beginning installation.
• If in doubt about electrical installation, consult a licensed electrician.
• Turn off electricity to fixture before replacing the bulb(s).
TOOLS REQUIRED
PACKAGE CONTENTS
Crossbar Assembly
x1
AA Wire Connector
x3
CC Outlet Box Screw
x2
DD
MOUNTING HARDWARE
Alternate
Mounting Screw
x2
BB
AFixture Body
x 1
Glass Shade
x2
B
Lock Screw
[preassembled on
Fixture Body ]
x6
C

- of 2 -2
INSTALLATION
1
Install Crossbar Assembly
(2) Alternative Screws
*Alternative screws are provided to
replace pre-assembled mounting screws
if necessary.
Your installation is now complete! Restore electricity and save this sheet for future reference.
5
Install Bulbs
BULB BASE TYPE
Medium (E26)
BULB TYPE
TYPE A
100W
MAX
Install correct bulbs referringtwo
to fixture markings and/or labels
for maximum wattage.
Recommended Bulb Type (not
included):
4
Install Shades
3
Install Fixture Body
2
Wiring
White wire from supply White from fixture
Black (or red) wire from supply Black from fixture
Ground wire from supply
Ground wire
from fixture
Green ground screw
