RADEMACHER DuoFern 9471-1 User manual

VBD 621-5 (12.20)
Item no. 3514 06 62
EN DuoFern Tubular Motor Actuator 9471-1
Instruction manual for the electrical connection and for commissioning
Type: 9471-1

2
EN
i
Dear Customer,
with your purchase of a DuoFern Tubular Motor Actuator
9471-1 you have chosen a quality product manufactured by
RADEMACHER. Thank you for the trust you have placed in us.
RADEMACHER products have been developed with the greatest
possible convenience in mind. Having applied uncompromising
quality standards and thorough testing, we are proud to be able
to present this innovative product to you.
It’s brought to you by all the highly quali-
fied personnel here at RADEMACHER.

3
EN
i
Contents
i Dear Customer, ...................................................................2
1. This manual... ......................................................................4
1.1 How to use this manual .....................................................................4
2. Hazard symbols ..................................................................5
2.1 Levels of danger and signal words.................................................5
2.2 Symbols and depictions used..........................................................6
2.3 Glossary - definition ............................................................................7
3. Included in delivery ...........................................................8
4. Overview and connections...............................................9
4.1 Operating buttons and indicator light ...................................... 10
5. Functional description ................................................... 11
5.1 Functional characteristics............................................................... 12
6. Technical specifications ................................................. 14
7. Safety instructions .......................................................... 16
7.1 Intended use ....................................................................................... 16
7.2 Improper use....................................................................................... 17
7.3 Expert knowledge required by the installer............................ 18
8. Safety instructions for the electrical connection...... 18
8.1 Important information regarding the electrical
connection........................................................................................... 19
8.2 Connecting and installing the DuoFern Tubular
Motor Actuator 9471-1.................................................................... 21
8.3 Connection diagram ........................................................................ 22
9. Logging DuoFern transmitters on / off ....................... 23
9.1 Logging on and off via radio code.............................................. 24
10. Deleting all settings (reset) ........................................... 25
11. Dismantling...................................................................... 25
12. Simplified EU declaration of conformity..................... 26
13. Warranty terms and conditions.................................... 27

4
EN
i
1. This manual...
...describes how to install, connect and commission the DuoFern
Tubular Motor Actuator 9471-1.
1.1 How to use this manual
◆Before you begin, please read this manual through completely
and follow all the safety instructions.
◆Please also read the instruction manual of the respective
connected tubular motor.
◆This manual is part of the product. Please store it in an easily
accessible place.
◆When passing the DuoFern Tubular Motor Actuator 9471-1
on to a third party, this manual must be passed on as well.
◆Damage resulting from non-compliance with these instruc-
tions and safety instructions will void the guarantee. We
assume no liability for any consequential damage.
i

5
EN
i
2. Hazard symbols
The following hazard symbols are used in this manual:
Danger to life resulting from electric shock
Danger area / dangerous situation
2.1 Levels of danger and signal words
DANGER!
This hazard will lead to serious injury or death if not avoided.
WARNING!WARNING!
This hazard may result in serious injury or death if not avoided.
CAUTION!
This hazard may result in minor or moderate injury if not avoided.
ATTENTION!
This hazard may lead to property damage.
i

6
EN
2.2 Symbols and depictions used
Depiction Description
1. Steps to be taken
2.
◆Itemisation
1) or a) Lists
i
Further useful
information
Please read the respective manual
i

7
EN
i
2.3 Glossary - definition
DuoFern
◆RADEMACHER radio technology for controlling compatible
products.
WR ConfigTool
◆RADEMACHER software for programming the DuoFern Manual
Control incl. automatic software updates for the DuoFern
Manual Control.
HomePilot®
◆The HomePilot® is a central controller unit for RADEMACHER
radio products.

8
EN
i
3. Included in delivery
Included in delivery
a) 1 x DuoFern Tubular Motor Actuator 9471-1 incl. antenna
b) 1 x instruction manual (not illustrated)
a)

9
EN
RADEMACHER
STATUS
9471-1
DuoFern Rohrmotor-Aktor
L N
▲
▼
L N
E ▲ ▼
Made in Germany
i
4. Overview and connections
2)
1) 4)
Pos. Symbol Description
1) Control input (up/down)
Connection of an external roller shutter switch
/ button for manual control on site.
2) Rotation direction (up / down)
Connecting cables to the tubular motor.
3) 230 V / 50 Hz
Connection of the supply voltage.
4) 230 V / 50 Hz (internally bypassed) *
The phase [L] can be forwarded to the external
roller shutter switch and the neutral conductor
[N] can be forwarded to the tubular motor.
* Do not use to forward the mains voltage to the
home installation.
3)

10
EN
RADEMACHER
STATUS
9471-1
DuoFern Rohrmotor-Aktor
L N
▲
▼
L N
E ▲ ▼
Made in Germany
i
4.1 Operating buttons and indicator light
Pos. Symbol Description
5) Connect button
Logging on to the DuoFern radio network or a
DuoFern transmitter.
6) STATUS Indicator light - status display
green flashing
constantly
lit up
brief
flashing
Connection is active
Connection or disconnection
was successful
Control command received
red flashing
constantly
lit up
Disconnection is active
Connection or disconnection
was not successful
7) Disconnect button
◆Logging off from the DuoFern radio net-
work or a DuoFern transmitter.
◆Reset to the default factory settings
5)
6)
7)

11
EN
i
5. Functional description
Tubular motor controller in a DuoFern network
The DuoFern Tubular Motor Actuator 9471-1 can be used to in-
tegrate conventional tubular motors into a DuoFern network, for
example, to use a wide range of the functions of DuoFern sensors
and DuoFern transmitters, such as the HomePilot®.
Manual operation on site
An additional external locking roller shutter switch or button can
be connected to enable manual operation on site.
Installation and electrical connection
The DuoFern Tubular Motor Actuator 9471-1 is designed for flush
mounting. The electrical connection is carried out by means of
clamping the connecting cable in the existing spring clip.

12
EN
i
5.1 Functional characteristics
DuoFern HomePilot®
DuoFern Environmental Sensor
DuoFern Manual Control
* WR ConfigTool with DuoFern Manual Control
RolloTron Comfort DuoFern / Troll Comfort DuoFern
DuoFern Manual Transmitter Standard
DuoFern Wall Controller
Function Value
range
Factory
setting A B C D E F G
1. Manual operation Up/ stop / down -● ● ● ● ●
2. Direct drive to a desired
%-position 0% - 100% - ●
3. Manual mode on / off on / off off ● ● ● ●
4. Automatic timer on / off on / off on ● ● ● ●
5. Random function - - ● ● ●
6. Dawn function - - ● ● ● ●
7. Automatic dawn function
on / off on / off off ● ● ● ●
8. Automatic dusk function - - ● ● ● ●
9. Automatic dusk function
on / off on / off off ● ● ● ●
10. Sun function - - ● ●
11. Automatic sun function on / off on / off off ● ● ● ●
12. Sunshine position 0% - 100% 50 % ● ● ●
13. Wind function - - ●
14. Automatic wind function on / off on / off off ● ● ●
15. Wind rotation direction Up / down Up ● ● ●
16. Rain function - - ●
17. Automatic rain function on / off on / off off ● ● ●
18. Rain rotation direction Up / down Up ● ● ●
* The "WR ConfigTool" software can be downloaded from our website at
www.rademacher.de.

13
EN
i
5.1 Functional characteristics
DuoFern HomePilot®
DuoFern Environmental Sensor
DuoFern Manual Control
* WR ConfigTool with DuoFern Manual Control
RolloTron Comfort DuoFern / Troll Comfort DuoFern
DuoFern Manual Transmitter Standard
DuoFern Wall Controller
Function Value
range
Factory
setting A B C D E F G
19. Running time 2 s - 150 s 150 s ● ● ●
20. Ventilation position on / off off ● ● ●
21. Ventilation position 1 % - 99 % 80 % ● ● ●
22. Reversal of rotation direction on / off off ● ● ● ● ●
23. Connectivity test - - ● ●
24. Connect with radio code - - ● ● ●
25. End point setting for
RADEMACHER tubular motors via radio - - ● ●
26. Reset via radio (3-stage) - - ● ●
27. Single-button operation - -
28. Jog mode - - ● ●
29. Venetian blind mode on / off off ● ● ●
30. Standard slat position ** 0% - 100% 0% ● ●
31. Automatic tilt after manual stop
direction “Down”** on / off on ● ●
32. Automatic tilt to sunshine position ** on / off off ● ●
33. Automatic tilt to ventilation position ** on / off off ● ●
34. Automatic tilt after moving to a
%-position ** on / off on ● ●
35. Slat run time ** 100 - 5000 ms 900 ms ● ●
36. Motor dead time 0/160/480 ms 0 ms (off) ● ●
* See page 12 / ** Only available if “Venetian blind mode” is activated.

14
EN
6. Technical specifications
i
Mains connection [ L / N ]
Mains supply
voltage:
230 V / 50 Hz
Consumption: Standby: < 0.5 W
Control input [ sE t ]
for an external roller shutter switch / button on site
Input voltage: 230 V / 50 Hz (Ri = 200 kW)
Rotation direction [ s/ t]
Output voltage: 230 V / 50 Hz
Maximum switching
capacity:
M2.5 A / 550 W
Improper use can lead to serious injuries or property
damage.
◆Small contact distance (µ), not suitable for disconnecting
the device.
◆Do not use the DuoFern Tubular Motor Actuator 9471-1 to
disconnect the connected appliance.

15
EN
6. Technical specifications
i
DuoFern radio technology
Transmission frequency: 434.5 MHz
Transmission power: Max. 10 mW
Range: Indoors: approx. 30 m *
Outdoors:approx. 100 m
* Depending on the building structure
Max. number of DuoFern
devices:
20
General information
Permissible ambient
temperature range:
-20 °C to + 55 °C
Dimensions (W x H x D): 48.7 x 45.7 x 19.8 mm
Connecting terminals: Spring resistance connecting
terminals (0.1 mm2- 1.5 mm2 )

16
EN
i
7. Safety instructions
The use of defective devices can lead to personal injury and
damage to property (electric shock / short circuit).
◆Never use defective or damaged devices.
◆Check that the DuoFern Tubular Motor Actuator 9471-1 is
intact.
◆Consult our customer service department in the event that
you discover damage, see page 28.
7.1 Intended use
Only use the DuoFern Tubular Motor Actuator 9471-1 for con-
necting and controlling tubular motors for roller shutters and
Venetian blinds.
Operating conditions
◆Only use the DuoFern Tubular Motor Actuator 9471-1 in dry
rooms.
◆A 230 V / 50 Hz power supply, together with a site-provided
disconnecting device (fuse), must be available at the instal-
lation location.
◆The installation and operation of the radio systems is only
permitted for systems and devices where a malfunction in the
transmitter or receiver would not cause a danger to persons
or property or where this risk is already covered by other
safety equipment.
iRadio systems which transmit on the same frequen-
cy can cause interference.
i

17
EN
i
7.2 Improper use
Improper use can lead to serious injuries or property
damage.
◆Do not use the DuoFern Tubular Motor Actuator 9471-1 to
disconnect the connected appliance.
◆Never use the radio system (e.g. DuoFern radio system)
and its components for the remote control of devices and
systems with increased safety-relevant requirements or
where there is an accident risk. Applications of this kind
require additional safety equipment. Observe the respec-
tive statutory regulations for the installation of systems
of this kind.
Using the DuoFern Tubular Motor Actuator 9471-1 for any other
purpose than previously mentioned is not permissible.
There is a risk to life caused through short circuiting and
electric shocks if the DuoFernTubular Motor Actuator 9471-1
is used outside.
◆Do not install and use the DuoFern Tubular Motor Actuator
9471-1 in a roller shutter box / outside or in damp rooms.

18
EN
i
7.3 Expert knowledge required by the installer
The electrical connection, installation and commissioning of the
DuoFern Tubular Motor Actuator 9471- 1 must only be carried
out by a qualified electrician in accordance with the instructions
in this manual.
8. Safety instructions for the electrical connection
DANGER!
There is a risk of fatal electric shock when touching electri-
cal components.
◆All connection and installation work must only be carried
out in a de-energised state.
◆Disconnect all phases of the mains power lead and secure it
to prevent any reconnection.
◆Check that the system is de-energised.
Prior to the electrical connection, check that the voltage / frequen-
cy on the type plate corresponds to that of the local mains supply.
i

19
EN
i
8. Safety instructions for the electrical
connection
WARNING!WARNING!
Short-circuiting, caused when the DuoFern Tubular Motor
Actuator 9471-1 is overloaded, poses a danger to life.
◆The maximum switching capacity must not be exceeded.
Please observe the details in the “Technical Specifications”,
see page 15.
ATTENTION!
A defective antenna can lead to malfunctions or failure of
the DuoFern Tubular Motor Actuator 9471- 1.
◆The antenna lead must not be shortened and damaged.
8.1 Important information regarding the electrical
connection
Connection instructions for operating with
an external roller shutter switch / button on site
◆It is imperative that a locking roller shutter switch / button
is used in order to avoid increased current consumption and
excessive heat build-up.
◆When using the control input [ sE t], you must connect the
external roller shutter switch / button and the DuoFern Tubular
Motor Actuator 9471-1 to the same phase [ L ].
◆The maximum length of lead to connect an external roller
shutter switch / button must not exceed 10 m.
i

20
EN
i
Minimum length of insulation stripped:
9 mm
All leads must be stripped to 9 mm.
Further installation instructions
◆In order to ensure optimal operation, the DuoFern Tubular
Motor Actuator 9471-1 should not be installed on a metallic
base or near metal objects.
◆The DuoFern Tubular Motor Actuator 9471-1 is intended for
flush mounting.We recommend installation in a deep 58 mm
flush-mounted box or in an electronic socket.
Please read the specifications relating to the electri-
cal connection detailed in the instruction manual for
the tubular motor.
8.1 Important information regarding the
electrical connection
