Rain Bird CP Operating manual

1
Troubleshooting
and Maintenance Guide for
Residential Automatic Valves

2
Valves are an essential part of any sprinkler system. They are the link between the "brains" of the
system (the controller) and the sprinkler heads, to turn the water on and off.
Most automatic sprinkler systems are set up with two types of valves. A brass "gate valve" or "ball
valve" is usually located right after the "tee" where the sprinkler system cuts off from the main
source of water to the house. This valve, referred to as the "shutoff valve," is used to shut down the
sprinkler system for repairs or winterizing without shutting off the water to the entire house. It is rec-
ommended that all systems be equipped with a shutoff valve installed in a box for easy access.
Some systems also require the use of a back-flow preventer. Check local building codes.
The second type of valve is the sprinkler "zone valve." Each zone valve is piped to a set of sprin-
klers. When the valve is turned on, either by hand or in response to an electronic signal from the
controller, all the sprinklers piped to that particular valve go on. In most cases, there are several
valves located together (called a manifold). These are often in a valve box if underground.
Why are several valves needed? All systems are limited by a combination of the pressure of the wa-
ter (psi) and the number of gallons per minute (gpm) available. Each sprinkler uses a certain num-
ber of gallons per minute of water. This release of water through the nozzle reduces water pressure
to a certain degree while the system is working. For maximum performance, each zone is controlled
by one valve and is set up with the proper amount of sprinklers so that the psi and gpm capacity of
the system is not exceeded. The purpose of this information is to address questions and problems
related to zone valves.
Controller
Valve Box
Supply Line
Shut o
Valve
Supply Line
Water Flow
Zone
Valve
Zone
Valve
Water Flow
Water Flow
Controller Sprinklers
Sprinklers
BASIC AUTOMATIC
IRRIGATION SYSTEM
COMPONENTS
DIAGRAM

3
Types of Zone Valves
There are two basic types of zone valves commonly available.
Anti-Siphon Valves
Anti-siphon valves have a built-in backflow device to prevent
possibly contaminated water from flowing backward into the
household supply. If approved by your local codes, these types
of valves provide inexpensive backflow protection. Anti-siphon
valves must be installed at least 6" above the highest sprinkler
head on the line in order for the backflow device to work
properly. Both automatic and manual versions are available.
Anti-siphon valves are an inexpensive choice and easy to install and maintain. The built-in anti-
siphon backflow device prevents potential contamination of household water supplies from fertiliz-
ers and other toxic chemicals which may enter the system.
Check your local codes for the types of backflow protection required in your area. Electric models
are simple to hook up to a controller for automatic watering. They are best suited to plans where
there is not more than a slight rise in elevation, and fairly clean source water.
Caution: This valve is designed as a zone valve and as such may not
function properly, resulting in water contamination, if installed where
constant pressure is placed on the outlet (sprinkler) side of the valve. The manual version is not
suitable for use in a continuous open position as a main shutoff valve or as a means of inexpen-
sive backflow prevention for an entire system; nor are the automatic models to be used as a mas-
ter valve where other valves will be installed downstream.
Must be
at least
6” above
the
highest
sprinkler
Installation Notes
 Must be installed upright
 Must be installed at least 6"
(15,2 cm) above the highest
point of water in the pipe
and sprinklers it serves
 No valve can be located
downstream of the anti-
siphon valve
 Must not be subjected to
operating pressure for more
than twelve (12) hours in
any twenty-four (24) hour
period
 Uniform Plumbing Code
Sec. 1003 (2) 602.2 Con-
sult local codes

4
In-Line Valves
The second type of zone valve is an "in-line" valve. It is installed
below ground, preferably in a valve box for ease of maintenance.
A separate backflow preventer is required for backflow protec-
tion. In-line valves are automatic valves.
In-line valves are suitable for sites with all types of elevation
changes. Because of their protected location, in-line valves are
less likely to be tampered with by children or vandals, and less
likely to incur freeze damage than above ground models. An in-
line valve is also suitable for use as a master valve.
In situations where the water is pumped from a lake, well, ditch, or other "dirty" water source, sand
and other debris should be filtered from the line through a filter with a 100 mesh screen. If water sup-
ply is also used as a drinking water source, a separate backflow prevention device is required to pre-
vent potential contamination should fertilizers or toxic chemicals in the water be siphoned backwards
through the lines.
If your water is supplied by a municipal water system, check with your local Rain Bird dealer or
plumbing supplier for the type of backflow prevention device required in your area. For specific infor-
mation about backflow and the types of backflow prevention devices available, please call our toll-
free number. 1-800-RAIN-BIRD, and request a "Backflow Prevention Handbook."
Controller
To Sprinklers
Shuto
Service
Line from
Street
PVB Valve
Valves

5
Tips On New Installations
Tapping Into Your Water Source
Turn off the water at the meter. Cut into your household service line and install a system appropriate
tee, after the meter. The tee selected will depend on the type of service line piping. The cut can be
done anywhere on the line, depending on the layout of your system and the location of your first
manifold. Unless unregulated static pressure is over 80 psi, tap into the line before the household
pressure regulator. In freezing climates, you will probably be tapping into your source inside a base-
ment.
Next, install a gate or ball valve to act as your system shutoff valve. House the valve in a valve box
for easy access in below ground situations. Once this valve is installed and tested, the valve at the
meter may be left open for water usage inside the house. In freezing climates, your next step will be
to install a manual drain valve so that the water can be drained from the pipes between the zone
valves and the shut-off valve.
Install Schedule 40 PVC, thick-walled pipe up to the valves. In basement installations, you will need
to drill a hole through the wall to direct the pipe out to the valves. For convenience in "blowing out"
the system for winter, access to the line by means of a tee with a capped 1" riser may be installed at
this point.
If a backflow preventer is to be used, install it outside at the proper height.
Important: Remember to flush the line. Turn on the water at the shutoff valve and flush the pipes
free of dirt.
Meter in House
Meter in Yard
Service to
house
Compression
Tee
Shuto
Valve
Slope Downward
for Drainage
Shuto
Valve
Shuto
Valve
Water
Meter
Drain
Cap Service
Line
from
Street
To
Control
Valves
Service
Line to
House
To
Control
Valves
Shuto
Valve
Compression
Tee Water
Meter
Service
Line
from
Street
Water
Shuto

6
Installing the Valves
If you are installing a new in-line valve manifold, or grouping anti-siphon valves together, keep in
mind that the location should be easily accessible for maintenance. Locate the manifold where you
are not likely to be sprayed by the sprinklers when turning the system on manually. On larger sys-
tems, separate valve groups may be required for the front and back yards. It is a good idea to keep
a plan showing where all in-ground valves and pipes have been installed.
Important: Be sure to flush the line coming up to the valves, before installing the valves.
Tip: If using a manifold for underground valves partially assembling the manifold ahead of time will
make the job easier. Be sure that the valve is installed horizontally according to the arrows printed
on the body for the direction of flow. Valve operation may be erratic and valve warranty is void if in-
stalled backward or in a vertical position. Do not over-tighten or use any kind of pipe dope. Call our
toll-free Technical Services Hotline for any questions on system installation: 1-800-RAIN-BIRD.
WATER
FLOW
ARROW

7
Installing the Valves (Continued)
Most valves have a flush mode which allows a little extra water through the valve to clean it out. To
flush valve to clear debris: Turn the bleed screw counter-clockwise ONLY 1 turn. Flush one minute
and turn clockwise to close. Test and flush each line before sprinklers are attached.
How to Operate
Several models of Rain Bird 24 Volt valves are available for home use. Minimum current require-
ments for opening the smaller valves is .30 amps and for holding the valve open is .19 amps. Larger
valve models have slightly higher requirements. All Rain Bird valves are designed to work with Rain
Bird controllers and other controllers that have a power output sufficient to activate the valve. Your
Rain Bird valve offers some simple features you should be familiar with. Note: Some valves have
only part of these features.
See the diagram above for information on flushing the valves.
a. Flow control - Regulates the amount of water passing through the valve. Does not turn on or off
the valve. (Not available on all models.)
b. Flush Valve / Manual bleed - Turns the valve on manually by "bleeding" water off of the dia-
phragm. External bleed valve models have a knob or screw to turn and the water sprays out of the
top of the valve.
c. Manual On/Off - Turn solenoid 1/4 turn counterclockwise to turn valve on manually. Do not turn
past 1/4 turn or the Solenoid may come loose and release pressurized water.

8
Troubleshooting
How the Valve Works
It is easier to troubleshoot valves if you know a little about how the valve works. When an electrical
impulse is transmitted to the solenoid (black cylinder with wires), an electromagnetic field causes a
small metal plunger in the solenoid to move upward. When the plunger moves upward, a small hole
(port) in the valve is uncovered. Water in the chamber above the closing mechanism (either dia-
phragm or piston) flows through the port and out of the valve, relieving water pressure needed to
hold the valve closed. At this point, the pressure of the incoming flow of water is now greater than
the pressure in the chamber above the diaphragm, and the force of the water pushing up under-
neath the diaphragm opens the valve.
When the solenoid is de-energized, the plunger moves down, closing the small port. Water flowing
through a small hole in the closing mechanism refills the chamber above the diaphragm and builds
up pressure. The increased pressure forces the diaphragm downward, thus closing the valve. All
valves have a range of pressure and water flow that must be maintained in order to work properly.
Now that you have an idea of the way the valves work you can see why sufficient pressure and flow
are important. If a problem does occur, it is also very important to ensure that the small internal ports
are not blocked by debris. Adequate flushing is the key to success in a new installation.
Valve Cutaway Diagram
Diaphragm moves
up to open valve,
and moves down to
close valve.

9
TROUBLESHOOTING GUIDE
1. For any problem,
check the basics
first.
A. Is controller plugged in and properly programmed?
B. Is master shut off valve open?
C. Is flow control on valve in an "open" or "flow" position? Not all models have this fea-
ture. Check the instructions that came with your valve, or see "How to Operate" section
of this packet.
D. Are water pressure and flow rate adequate for your particular valve model? (Check
the instructions that came with the valve or call us toll free at 1-800-RAIN-BIRD for the
requirements of your particular Rain Bird valve model.) If your pressure is too low, in-
vestigate these causes:
 Pressure drain from washing machines, showers, etc. or broken pipe
 Master shutoff valve not fully open
 Blockage in main supply line; to repair, cut main line, flush line, and repair cut
 Too many heads on line; redesign system layout to reduce the number of heads op-
erating at once
 Inadequate pressure at the point of connection
E. Is valve in "Manual Off" position? See "How to Operate" section of this packet.
F. If your system is supplied by a pump, is it working?
SYMPTOM CAUSE DIAPHRAGM VALVE REMEDY
A. Check the Basics
as in No. 1 above
If all basics check out, see if the valve will work manually. On some
models you will need to turn the solenoid 1/4 turn counterclockwise. On
other models, turn the screw in the center of the bonnet (water should
spray out of the top of the valve temporarily). Check your valve operat-
ing instructions or refer to section entitled "How to Operate," in this
packet of information. If the valve works manually, go on to step 2-B. If
the valve doesn't work, go on to step 2-D.
2. Valve won't turn on
with controller
B. No power between
controller and valves
Check by pressing the "Manual Start" button of the controller and ad-
vance to the desired station. Attach a circuit tester (voltmeter) to the
common terminal and the station terminal of the controller. If you do not
get a 24-30 volt reading, the problem is in the controller.
Check for shorted or broken wiring. Follow directions as above, except
attach voltmeter to common wire and station wire nearest valve. If you
do not receive a 24-30 volt reading, replace or repair wiring.
C. Solenoid burned
out or clogged
The solenoid should make a distinct "click" when activated. If controller
and wiring check out, try unscrewing the solenoid and swapping it with
a nearby valve of the same model. Using the "Manual Start" on your
controller, check the station again to see if the borrowed solenoid acti-
vates the valve. If so. replace solenoid. If not check 2-D.

10
TROUBLESHOOTING GUIDE
SYMPTOM CAUSE DIAPHRAGM VALVE REMEDY
2. Valve won't turn on
with controller
(continued)
D. Valve opening
mechanism damaged
or clogged with debris.
See if you can flush debris from the valve by using the flush mode. If
not, turn off the water, disassemble, inspect and clean the valve (See
Diaphragm Valve Disassembly Procedure). Pay particular attention to
cleaning the small bleed ports underneath the solenoid and on the sur-
face of the diaphragm. Check to see that the diaphragm is not torn or
damaged. Replace diaphragm if damaged. If water is particularly dirty,
install a 100 mesh or finer filter before the valve to prevent future grit
build-up.
E. Valve installed
backwards
Reinstall valve so that water flow is the same direction as arrows em-
bossed on valve.
A. When the valve
won't turn off with the
controller, the fore-
most goal is to stop
the flow of water.
 Put controller in auto/off mode. If watering continues. . .
 Unplug controller. If this stops the watering, the problem is probably
in the controller. If watering continues. . .
 Turn flow control knob (if there is one) to lowest flow position. If this
does not shut off the flow completely. . .
 Turn off manual main shut off valve to sprinkler system
 When water flow is stopped, check steps B through D for trouble-
shooting procedure
3. Valve won't turn off
with controller
B. Solenoid burned
out or plunger clogged
Check solenoid as in 2-C. Check for dirt impeding the movement of the
plunger. To do this, turn off the water and remove power to the so-
lenoid. Unscrew the solenoid. Sometimes the plunger inside the sole-
noid can become stuck in the upward position due to dirt in the sole-
noid. Run water into the solenoid to dislodge dirt. Push a piece of wire
into the small hole in the retainer at the bottom of the solenoid to see if
the plunger inside will move up and down freely. If not. replace the so-
lenoid.
C. Valve closing
mechanism stuck in
open position due to
debris or damage
See Valve Disassembling Procedure A. Check small ports for blockage
by debris; rinse and inspect diaphragm and diaphragm seat for dirt or
damage. Replace diaphragm if damaged.
D. Damaged or misa-
ligned parts allow wa-
ter to leak from valve
Check valve body and bonnet for cracks. Check integrity of seal be-
tween body and bonnet and solenoid and bonnet. Repair or replace
parts as necessary to stop leak.
E. Valve set in
"Manual On" mode
Depending on the model, you will need to be sure the solenoid is tight-
ened into the full clockwise position ("Manual Off") or turn the bleed
screw or knob on top of the valve clockwise to tighten. See section enti-
tled "How to Operate."

11
TROUBLESHOOTING GUIDE
SYMPTOM CAUSE DIAPHRAGM VALVE REMEDY
4. Water leaks out at
sprinkler heads when
station is off.
A. Closing mechanism
dirty or damaged and
does not seat properly
See Diaphragm Valve Disassembly Procedure. Check small ports for
blockage by debris; rinse and inspect diaphragm and diaphragm seat
for dirt or damage. Replace diaphragm or valve body if damaged.
B. Valve not fully in
"Manual Off" mode
See 3-E above.
C. Solenoid burned
out or obstructed
Turn off water. Remove solenoid. Check for twisting or damage to sole-
noid O-ring. Check solenoid plunger as in 3-B above. Rinse bottom of
solenoid and seating surface inside valve. Replace solenoid if dam-
aged.
D. Low head drainage It is normal for water to temporarily continue to drain from the piping
through the lowest head on the line. The longer the piping, and the low-
er the slope of the pipe, the longer this will take.
Stop watering on the soggy zone for two days. Check the lowest head
on the line.
If area is very wet or a small amount of water drips from sprinkler, see 4
-A and 4-B above. If area around sprinkler has dried out somewhat, the
problem is probably due to drainage from the piping. This line drainage
can be stopped by using a Rain Bird Sprinkler or Rotor with a SAM
Check Valve. Different models are available through professional in-
stallers, retailers, or the Rain Bird Online Store.
5. Valve won't turn off
manually
A. Valve in "Manual
On" mode
See 3-E above
B. Valve closing
mechanism stuck in
open position
See 3-C above
C. Solenoid energized Stop power to valve
6. Valve won't turn on
manually
A. Flow control in
closed position
See 1-C above
B. Valve opening
mechanism blocked by
debris.
See 2-D above
C. Valve in "Manual
Off" mode.
See 2-A above

12
TROUBLESHOOTING GUIDE
SYMPTOM CAUSE DIAPHRAGM VALVE REMEDY
7. Water leaks out at
valve
A. Leaking round pipe
connections
Tighten connections (use PTFE thread tape only).
B. Leaking between
bonnet and body
Check that diaphragm washer is properly in place. Tighten bonnet
screws. If still leaking evaluate for replacement with model number ap-
propriate for your valve. Refer to the last page for replacement parts or
call our Technical Service hotline for assistance in identifying valve or
part numbers. 1-800-RAIN-BIRD
8. Valve slams on/off
(water hammer)
A. Excessive water
pressure
Install pressure regulator on line before valves to reduce pressure.
B. Valve closing/
opening mechanism
worn
Replace diaphragm with model number appropriate for your valve. Re-
fer to the last page for replacement parts or call our Technical Service
hotline for assistance in identifying valve or part numbers. 1-800-RAIN-
BIRD
C. Air bubble in line Shut off water at main shut off valve and drain the line to release air
bubble. Slowly refill the line.
D. Valve too small for
amount of flow
Replace with larger valve.
E. Pipe is too small for
the flow
Use larger pipe which will slow the velocity of water leading up to the
valve and reduce water hammer.
9. Water runs continu-
ously when valve is
not activated; shuts
off when valve is acti-
vated.
A. Valve installed
backwards
Reinstall valve according to arrows on valve depicting direction of flow.

13
Diaphragm Valve Disassembly Procedure
To inspect the inside of the valve for cleaning or replacement of the diaphragm:
1. Shut off the water at the master shut off valve.
2. Unscrew all bonnet screws if present or unscrew jar-top lid. On some models, the bleed screw
and/or flow control knob will also need to be removed.
3. Remove bonnet assembly to expose the spring, diaphragm, and rubber gasket (if any) and filter (if
any). Remove and inspect the spring, diaphragm, and rubber gasket for wear or damage. Inspect
the diaphragm for clog or a tear in the small hole on its surface.
4. Inspect the valve body for dirt on the diaphragm seat.
5. Inspect the bonnet for dirt clogging the small bleed port near the solenoid.
6. Rinse dirt off if necessary, or use a wire to gently dislodge dirt from the bleed port.
7. Install new diaphragm if necessary. Do not forget to replace the spring. Some new replacement
diaphragms are an all-in-one design and do not have a separate rubber gasket to install. Be sure
that the holes line up.
8. Press the bonnet firmly back in place. Replace the screws and tighten or screw jar top lid back on.
Pressure test the valve to assure that all of the screws are tight enough to prevent any water leak-
age between the valve body and bonnet.
To replace the solenoid:
1. Ensure valve is off with no power going to solenoid.
2. Remove controller wires.
3. Unscrew the solenoid.
2. Check for debris clogging the small port where the solenoid
seats.
3. Rinse off the solenoid to remove debris.
4. Check condition of solenoid O-ring.
5. Replace solenoid if necessary with part number applicable to
your particular model.

14
Valve Model Solenoid P/N Diaphragm P/N Images
CP, CPF, DASASVF B60599 B60488
JTV, JTVF B60599 B36330
DV, DVF, ASVF 20858801 21074603
HV, HVF 236307 231900
Replacement Parts
Rain Bird Corporation
6991 East Southpoint Rd. Bldg #1
Tucson, AZ 85756
Questions?
In the USA or Canada, call Rain Bird
toll free Technical Support at
1-800-RAINBIRD (800-724-6247)
www.rainbird.com
© Copyright 2016 Rain Bird Corporation ® Registered trademark of Rain Bird Corporation
