Rain-Flo Irrigation 2600 II Series User manual

MODEL 2600 SERIES II
RAISED BED PLASTIC MULCH LAYER
Rain-Flo Irrigation
929 Reading Road
East Earl, Pa 17519
PH: 717-445-3000
ASSEMBLY
INSTRUCTIONS

1
STEP 1
Standard parts shipped with equipment:
Cover Disk Set
Yellow Arm Set
Press Wheel Set
Dirt Shield Set

STEP 2
2
See Operating Manuel for adjustments.
Yellow Arms & Press wheels
Remove lynch pin
from hole on yel-
low arm and slide
yellow arm through
press wheel and
into hinge. Fasten
in place with lynch
pin. Secure chains
to holes as shown.
Rain-Flo
Irrigation
Rain-Flo
Irrigation
Lynch Pin g
Press Wheel
Yellow Arm

STEP 3
3
See Operating Manuel for adjustments.
Disks AnD Dirt shielDs
Slide disk bracket over end of yellow
bar and tighten in place with yellow lock
handle. Install dirt shield as shown, by slid-
ing end through hole and fastening with tee
lock handle.
Rain-Flo
Irrigation
Rain-Flo
Irrigation
Dirt Shield Cover Disk

STEP 4
4
Chisel teeth
See Operating Manuel for adjustments.
Chisel teeth are upside down for shipping.
Rotate chisel tooth till tip is on bottom.

Plastic: Place plastic rolls on top of rollers(A). Pull end of plastic down
in between rollers and underneath bottom roller(B). Secure plastic and drip
tape at end of row. Only feed from one roll at a time.
Plastic
Roll
Plastic
Roll
Plastic
End ViEw
5
A
B
STEP 5
See Operating Manuel for adjustments.
instAlling DriP tAPe AnD PlAstiC
A
B
C
Drip Tape: Remove plate with locking clamp(A). Slide drip roll onto
rod, press plate(A) tight against roll and tighten tee-handle on clamp. Feed
drip tape through swing arm guide and stationary guide (B) then into down
pipe(C).
Note; Turn drip emitters up toward plastic for less clogging, and to avoid
damaging drip tape with the press pan, adjust down pipe about 1- 2”
below the plastic mulch. Also make sure drip roll is compressed rmly
between plates for positive braking effect.

STEP 6
trACtor hook-UP
6
Hook up to tractor pto. Connect to 12V battery.
Bolt sensor square
with machine.
Note: Small 12V battery mounted on machine will also work.

Rain-Flo Irrigation
[phone]
~2015 Edition~
