Raymarine ST70 Instrument User manual

ST70+
UserReference
Manual
Documentreference: 85024-1
Date: January2009
85024_1.book Page 1 Tuesday, January 27, 2009 11:31 AM

Autohelm, HSB, RayTech Navigator, Sail Pilot, SeaTalk and Sportpilot are UK registered trademarks of Raymarine UK Limited.
Pathfinder and Raymarine are UK registered trademarks of Raymarine Holdings Limited. 45STV, 60STV, AST, Autoadapt,
Auto GST, AutoSeastate, AutoTrim, Bidata, G Series, HDFI, LifeTag, Marine Intelligence, Maxiview, On Board,Raychart,
Raynav, Raypilot, RayTalk, Raystar, ST40, ST60+, Seaclutter, Smart Route, Tridata, UniControl and Waypoint Navigation are
trademarks of Raymarine UK Limited.
All other product names are trademarks or registered trademarks of their respective owners.
Copyright ©2008 Raymarine UK Ltd. All rights reserved.
85024_1.book Page 2 Tuesday, January 27, 2009 11:31 AM

i
Contents
Preface ....................................................................................................................v
Safetynotices ..................................................................................................v
EMCconformance ...........................................................................................v
Pressurewashing ............................................................................................v
Certified installation ......................................................................................... vi
Productdocuments ......................................................................................... vi
Technicalaccuracy................................................................................vi
Productdisposal ............................................................................................. vi
Chapter 1:General information ...................................................................... 1
1.1 Introduction ........................................................................................... 1
1.2 Productbasics ...................................................................................... 1
Concept................................................................................................. 1
Keypadcontrols& control functions....................................................... 1
Sail boat Pilot Controller keypad......................................................... 2
Power boat Pilot Controller keypad .................................................... 2
Instrument keypad.............................................................................. 3
Keypad shortcuts................................................................................ 3
Maximum, minimum & averageindicators............................................. 4
Commonly used control functions.......................................................... 4
Scrolling.............................................................................................. 4
OK function......................................................................................... 4
1.3 Setup principles .................................................................................... 5
Firstuseafterinstallation....................................................................... 5
Display types & grouping.................................................................... 6
1.4 Normaloperation .................................................................................. 7
PilotControllers..................................................................................... 7
Sail boat functions .............................................................................. 7
WindVanemode. .................................................................................7
AutoTackoperation ..............................................................................7
Power boat functions.......................................................................... 9
Fishing patterns ....................................................................................9
Instruments ........................................................................................... 9
1.5 Systeminformation ..............................................................................11
Powerprotocol .....................................................................................11
1.6 Commissioningrequirement ............................................................... 12
Autopilotcalibration............................................................................. 12
Chapter 2:Commissioning Procedures ...................................................... 13
2.1 Requirement ....................................................................................... 13
Autopilotcalibration............................................................................. 13
Controlinformation.............................................................................. 13
2.2 Initial setup ......................................................................................... 13
Switchon............................................................................................. 14
Selectinglanguage.............................................................................. 14
SettingVesselType............................................................................. 15
Select type........................................................................................ 15
Settingdisplay types and groups......................................................... 15
85024_1.book Page i Tuesday, January 27, 2009 11:31 AM

ii ST70+ User Reference Manual
Date & Time......................................................................................... 17
Setting date format ........................................................................... 17
Setting time format............................................................................ 18
Setting local time .............................................................................. 18
Leaving date & time setup................................................................ 18
Dataunits ............................................................................................ 19
Changing units.................................................................................. 19
Leaving units setup........................................................................... 20
Initial setupend routine........................................................................ 20
Next actions......................................................................................... 20
2.3 Dockside setup ................................................................................... 20
Autopilotsystem.................................................................................. 20
Dockside wizard................................................................................ 21
Startingthe wizard ..............................................................................21
Setdrive type ......................................................................................21
Rudderandmotor checksfor systemswith aRudder Reference
transducer ..........................................................................................22
Rudderandmotor checksforsystemswithoutaRudderReference
transducer ..........................................................................................23
Hard over time.................................................................................. 25
End of autopilot dockside setup........................................................ 25
Transducersetup................................................................................. 25
Introduction to transducer setup.......................................................25
Depthoffsets.......................................................................................26
Accessing transducer setup.............................................................. 26
Calibrating conventional transducers................................................ 28
SettingDepth offset ............................................................................28
Settingwater temperature ..................................................................29
Calibrating smart transducers........................................................... 29
Calibrating trim tabs.......................................................................... 30
End of transducer setup.................................................................... 30
Miscellaneous setup............................................................................ 30
Setting ground wind.......................................................................... 30
Setting magnetic variation ................................................................ 31
Changing display response rate ....................................................... 32
Rudder limit ...................................................................................... 33
Setting rudder offset ......................................................................... 33
Next actions......................................................................................... 33
2.4 Open water calibration ........................................................................ 34
Autopilots ............................................................................................ 34
Starting open water calibration ......................................................... 35
Compass calibration ......................................................................... 35
Swingingthe compass ........................................................................35
Aligningthe compassto GPS .............................................................36
Aligningthe compassmanually .........................................................36
AutoLearn ......................................................................................... 37
Requirement for a clear area............................................................ 37
Procedure ......................................................................................... 37
Next actions...................................................................................... 38
Instrumentsystem calibration.............................................................. 38
Preliminary procedure....................................................................... 38
Wind transducer setup...................................................................... 39
Linearization .......................................................................................39
Alignment ...........................................................................................40
Calibratewindspeed ..........................................................................40
Speed calibration.............................................................................. 40
85024_1.book Page ii Tuesday, January 27, 2009 11:31 AM

iii
Speed calibration for conventional speed transducer....................... 41
Startingspeed calibration ...................................................................41
Setto SOG .........................................................................................42
Manualspeedcalibration ...................................................................42
Speed calibration for smart transducer............................................. 43
Addpoint ............................................................................................44
Deletepoint ........................................................................................44
Return to normal operation.................................................................. 44
2.5 Checkingautopilot operation .............................................................. 44
General ............................................................................................... 44
Checking rudder gain .......................................................................... 45
Checkingcounter rudder..................................................................... 45
Rudderdamping.................................................................................. 46
SettingAutoTrim.................................................................................. 46
2.6 Aftercommissioning ........................................................................... 46
EMCConformance.............................................................................. 46
Chapter 3:Setup Information ........................................................................ 47
3.1 Introduction ......................................................................................... 47
3.2 Generalsetup ..................................................................................... 47
Changinglanguage............................................................................. 47
Changingvessel type.......................................................................... 48
Change time/date format..................................................................... 48
Setting date format ........................................................................... 49
Setting time format............................................................................ 49
Leaving date & time setup................................................................ 49
3.3 Autopilotsetup .................................................................................... 50
Adjustingdrive settings........................................................................ 50
Preliminary procedure....................................................................... 50
Setting response level ...................................................................... 50
Setting rudder gain ........................................................................... 51
Setting counter rudder...................................................................... 51
Setting rudder damping .................................................................... 51
Setting AutoTrim............................................................................... 51
Setting turn rate limit......................................................................... 52
Setting off course alarm.................................................................... 52
Rudder limit ...................................................................................... 52
Setting rudder offset ......................................................................... 53
Power steer....................................................................................... 53
Setting latitude compass damping.................................................... 53
AutoTurn........................................................................................... 54
Reverse rudder reference................................................................. 54
Checking autopilot operation............................................................ 54
Additional sail boat settings ................................................................. 55
Preliminary procedure....................................................................... 55
AutoTack angle................................................................................. 55
AutoTack delay................................................................................. 55
Gybe inhibit....................................................................................... 56
Wind type.......................................................................................... 56
WindTrim response........................................................................... 56
Setting up fishingpatterns ................................................................... 56
3.4 Systemconfiguration .......................................................................... 58
Changingsystem configuration........................................................... 58
85024_1.book Page iii Tuesday, January 27, 2009 11:31 AM

iv ST70+ User Reference Manual
Chapter 4:Maintenance & Troubleshooting ............................................. 59
4.1 Introduction ......................................................................................... 59
Servicing &safety................................................................................ 59
EMC.................................................................................................... 59
4.2 Maintenance ....................................................................................... 59
Cleaning.............................................................................................. 60
Cabling................................................................................................ 60
4.3 Troubleshooting .................................................................................. 60
Firstconsiderations............................................................................. 60
Procedures.......................................................................................... 60
Using the display self-monitoringfeatures........................................... 65
About Display ................................................................................... 65
About Pilot ........................................................................................ 66
Productsupport................................................................................... 66
World wide web ................................................................................ 66
Telephone help line ..........................................................................66
Appendix 1:Specifications ............................................................................ 67
Display ...........................................................................................................67
Keypads .........................................................................................................67
All types............................................................................................... 67
Instrumentkeypad............................................................................... 67
Pilot Controller (powerboat) keypad.................................................... 68
PilotController (sailboat) keypad........................................................ 68
Appendix 2:Glossary ....................................................................................... 69
Index ..................................................................................................................... 71
85024_1.book Page iv Tuesday, January 27, 2009 11:31 AM

Preface v
Contents
Preface
Safety notices
CAUTION: Replaceable parts
This product does not contain any user serviceable parts. Please refer all
repair requirements to an authorized Raymarine dealer. Unauthorized
repairs may affect your warranty.
EMC conformance
All Raymarine equipment and accessories are designed to the best industry
standards for use inthe recreational marine environment.
The design and manufacture of Raymarine equipment and accessories conform to
theappropriate Electromagnetic Compatibility (EMC) standards, but correct
installation is required to ensure that performance is notcompromised.
Pressure washing
Do NOT pressure wash any Raymarine product.
SubjectinganyRaymarineproducttohigh pressurewashingmaycausesubsequent
water intrusion and failure of the product. Raymarine will not warranty product
subjected to high pressure washing.
WARNING: Product installation & operation
This equipment must be installed, commissioned and operated in
accordance with the Raymarine instructions provided. Failure to do so
could result in personal injury, damage to your boat and/or poor product
performance.
WARNING: Switch off power supply
Ensure the boat’s power supply is switched OFF before starting to
install this product. Do NOT connect or disconnect equipment with the
power switched on, unless instructed in this document.
WARNING: Ensure safe navigation
This product is intended only as an aid to navigation and must never be
used in preference to sound navigational judgment. Only official
government charts and notices to mariners contain all the current
information needed for safe navigation, and the captain is responsible
for their prudent use. It is the user’s responsibility to use official
government charts, notices to mariners, caution and proper
navigational skill when operating this or any other Raymarine product.
85024_1.book Page v Tuesday, January 27, 2009 11:31 AM

vi ST70+ User Reference Manual
Certified installation
Raymarinerecommends certified installation by a Raymarine approved installer. A
certified installation qualifies for enhanced warrantybenefits.Contactyour
Raymarine dealer for further details and refer to the separate warrantydocument
packed with your product.
Product documents
The following user documents are available for ST70+:
• ST70+ Operating Guide. This comprises a series of individual operating cards,
which provide day-to-day operating and setting up procedures. Intended for all
users.
• ST70+UserReferenceManual(thisdocument).Intendedforusersingeneraland
commissioning personnel in particular. It provides:
• Commissioning procedures. These describe how to set up ST70+ displays
when first switched on after installation.
• Setup procedures not included in the Operating Guide
• Routine maintenance instructions
• Troubleshootinginstructions
• ST70+ InstallationGuide.Itprovides:
• Fitting procedures forST70+ displays and keypads.
• Connection instructionsforST70+ products
• Commissioningprocedures.
Additional information on Raymarine SeaTalkng systems is givenin the SeaTalkng
Reference Manual.
Technical accuracy
Tothebestofourknowledge,theinformationinthisdocumentwascorrectatthetime
it was produced. However, Raymarine cannot accept liability for any inaccuraciesor
omissions it may contain. In addition, our policy of continuousproduct improvement
may change specifications without notice.Asa result,Raymarine cannot accept
liability for any differences between the product and this document.
Product disposal
Waste Electrical and Electronic (WEEE) Directive
The WEEE Directive requires the recycling of waste electrical and electronic
equipment.
Whilst the WEEE Directivedoes not apply tosome ofRaymarine'sproducts,
we support its policy and ask you to be aware ofhow to dispose of this product.
The crossed out wheelie bin symbol, illustrated above, and found on our products
signifiesthatthis product should notbedisposed of in general waste or landfill.
Pleasecontactyourlocaldealer,nationaldistributororRaymarineTechnicalServices
for information on product disposal.
85024_1.book Page vi Tuesday, January 27, 2009 11:31 AM

1
Chapter 1: General information
1.1 Introduction
ThismanualprovidescommissioningandothersetupinformationforST70+displays
andassociatedkeypadcontrollers.Itisalsointendedforuserswhowanttomorefully
understand the concepts of ST70+ and want to get the most out of their product.
For day-to-day use of ST70+, refer to the ST70+ Operating Guide.
1.2 Product basics
AnST70+ system comprises one or more displays controlled by oneormore
keypads. During initial setup, an ST70+ display is set up to function as either an
Instrument or a Pilot Controller. The initial setup is part ofthe commissioning
procedure (see Chapter 2:, CommissioningProcedures).
Concept
ST70+ displays are controlled by remote keypads, as follows:
• Instrument keypads control displayssetupasInstruments.
• OnetypeofPilotControllerkeypadisusedonsail boatstocontroldisplayssetup
as Pilot Controllers.
• Anothertype ofPilotControllerkeypadisusedonpowerboatstocontroldisplays
setup asPilot Controllers.
InanyST70+system,displaysandkeypadscanbeconfiguredinconvenientgroups.
For example, asystem could comprise three Instrument groups (chart table, helm
and mast), plus two Pilot Controller groups (porthelm and starboardhelm).
Adisplayor displaygroup can be controlledonlybya keypadof theappropriate type.
Keypad controls & control functions
All ST70+ setup and operating functions are controlled by the keypad buttons.All
keypadshave:
• Power button . Switches power on and off.
• SelectDisplay button . Usedin systemswithmorethanonedisplay,to select
the display you want to control or set up. Onepress highlights the currently
selecteddisplay.IfyoupressSelectDisplayagainwhilethecurrentlyselecteddis-
play is highlighted (i.e. within 6 seconds), this selects the next display in thesys-
tem or group. Repeating this action enables you to select each display in turn.
•
CANCEL button. Used during setup procedures to leave a setup function without
makingany changes.
Display instrument
keypad PilotControllerkey- pad (power boat) PilotController keypad(sailboat)
D11039-1
85024_1.book Page 1 Tuesday, January 27, 2009 11:31 AM

2 ST70+ User Reference Manual
Other buttons and their functions depend on the keypad type.
Sail boat Pilot Controller keypad
Sail boat Pilot Controller keypad buttons and functions are:
•
MENU button.Selectsthe MainMenu whichgivesaccess
to:
• Wind Vane mode.
• AutoTack Port and Starboard - Sail boats only.
• Setupandreset functions.
• Self test routines and diagnostic information.
• ThedisplayedPilotview-plain,2Dor3D(holddown).
•
-1 and +1 buttons.Usedto:
• Change course, when using the autopilot to steerthe
boat. One degree to port or one degree to starboard, respectively.
• Scroll todifferent menuoptions and change setup values, when setting up.
•
-10 and +10 buttons.Usedtochangecourse,whenusingtheautopilottosteerthe
boat. Ten degrees to port or ten degrees to starboard, respectively.
• OK button. used to confirm setup actions and values.
•
AUTO button. Engages autopilotcontrol.
•
STANDBY button. Returns to manual control.
•
TRACK button. Engages Track mode.
•
DODGE button. Interrupts autopilot control to enable you to steer around obsta-
cles on your plotted course.
Power boat Pilot Controller keypad
PowerboatPilotControllerkeypadbuttonsandfunctionsare:
•
MENU button.Selectsthe Main Menu which givesaccess
to:
• Fishing pattern selection.
• Powersteering.
• Setupandreset functions.
• Self test routines and diagnostic information.
• ThedisplayedPilotview-plain,2Dor3D(holddown).
•
Rotary Control :
• Rotate to change course, when using the autopilot to
steer the boat. Clockwise changes course to star-
board, counter-clockwise, to port.
One click = one degree of course change, except when in Power Steer mode.
• Press in to perform an ‘
OK ’ function, i.e. to confirm setup actions and values.
• Rotate to scroll to different menu options and change setup values.
•
AUTO button. Engages autopilotcontrol.
•
STANDBY button. Returns to manual control.
•
TRACK button. Engages Track mode.
•
DODGE button. Interrupts autopilot control to enable you to steer around obsta-
cles on your plotted course.
D11402-1
D11403-1
Rotary Control.
Press in to OK setup
values & selections
85024_1.book Page 2 Tuesday, January 27, 2009 11:31 AM

Chapter 1: General information 3
Instrument keypad
Instrument keypad buttons and functions are:
•
MENU button. Selects the Main Menu whichprovides
access to:
• Setup and reset functions.
• Self test routines and diagnostic information.
•
PAGE UP & PAGE DN buttons:
• Scroll to different operating pages.
• Select choices on setup screens.
•
Rotary Control :
• Press in toperform an ‘ OK ’ function, i.e. to confirm
setup actions and values.
• Rotate to scroll to different menu options and change
setupvalues.
Keypad shortcuts
Keypad shortcuts are available to access some functions. These are detailed in the
following table.
Function Conditions Simultaneously press
InitiatePowerSteering
mode Available from Pilot Controller key- padon power boat, whenautopilot
is in Standby orAuto mode
AUTO and STANDBY
(pressand release)
Initiate Vane mode Available from Pilot Controller key-
padon sail boat, when autopilot is
inStandbyorAutomode
AUTO and STANDBY
(pressand release)
Initiate tack to starboard Available from sail boatPilot Con-
troller keypad, when autopilot is in
Automode
+1 and +10
(pressand release)
Initiate tack to port Available from sail boatPilot Con-
troller keypad, when autopilot is in
Automode
-1 and -10
(pressand release)
Accessheadingresponse
page Availablefromany Pilot Controller keypad
MENU and CANCEL
(pressand release)
Accessrudder response
page Available from Pilot Controller key- padonsailboat
+1 and -1
(pressand release)
Access rudder gainpage Available from Pilot Controller key-
padonsailboat
+1 and -1
(holddown for3 s)
StartSetup wizard Availablefromany keypad SelectDisplay and
MENU
(holddown for3 s)
D11404-1
Rotary Control.
Press in to OK setup
values & selections
85024_1.book Page 3 Tuesday, January 27, 2009 11:31 AM

4 ST70+ User Reference Manual
Maximum, minimum & average indicators
Maximum,minimum & average value indicators aredisplayed on speed, wind speed
and wind angle screens, as in the following illustration:
Commonly used control functions
Many ST70+ setup functions and values, plus many display options are selected by
scrolling to the required function or value, then confirming the value.
The manner in which you scroll to a function or value you want and confirm your
selection, depends on keypad type.
Scrolling .
Toscroll toan option or set a value, either:
• Pressthe
< and > buttons on the sail boat Pilot Con-
troller keypad, or
• TurntheRotaryControlonthepowerboatPilotCon-
troller keypad or theInstrument keypad
OK function
The manner in which you confirm,(i.e.‘OK’)selections and
edited values depends on which keypad type you are using.
• On a sailboat Pilot Controller keypad, press and release
the OK button.
• On a power boat Pilot Controller keypad or an Instrument
keypad,pressandreleasethecenteroftheRotaryControl.
Maximum value indicator
Minimum value indicator Average value indicator
D11606-1
or
Scrolling
=
OK functions
85024_1.book Page 4 Tuesday, January 27, 2009 11:31 AM

Chapter 1: General information 5
1.3 Setup principles
A newly-installed ST70+ systemmust be commissioned asdescribed in Chapter 2:,
Commissioning Procedures, before being used for operational purposes.
First use after installation
The first part of the commissioning procedure is initial setup (summarized in
Figure 1-1). This startsautomatically on when a display is first switched on after
installation.
Figure 1-1: Initial switch on and setup procedures
POWER ON
First switch on
Save and exit setup wizard
Initial setup
Language select
page
OK
Welcome page
OK
SELECT VESSEL TYPE
OK
Display type & group setup
See Figure 1-2
TIME & DATE SETUP
UNITS SUMMARY
OK
OK
OK
UNITS SETUP
Hold down
D111134-1
If the display is set up as a Pilot Controller, and the
autopilot has NOT been commissioned, the
commissioning process starts automatically. Refer
to Chapter 2.
Setup wizard
If the display function has changed (i.e. from
Instrument to Pilot Controller or vice versa), the
display reboots
at this point.
TIME & DATE SUMMARY
OK
If the display is set up as an Instrument, an
operating page is displayed.
Language
English (UK)
Press OK to select
MENU
85024_1.book Page 5 Tuesday, January 27, 2009 11:31 AM

6 ST70+ User Reference Manual
The initial setup procedure enables you to:
• Select system language.
• Select vessel type.
• Set up display types & groups (see Figure1-2)
• Set time and date formats.
• Set local time value.
•Setunits.
Display types & grouping
Figure 1-2: Display type & group setup summary
Duringinitialsetup,youallocateeachST70+displayaseitheranInstrumentoraPilot
Controller, then define groups of Instruments and Pilot Controllers (see Figure 1-2: ,
Displaytype&groupsetupsummary).Eachgroupiscontrolledbyacommonkeypad
or keypads. For example, you could group together all Instruments fitted atthe helm
and control them with a single keypad.
When grouping displays together, the following rules apply:
• All displays in a group must be set to be the sametype, i.e. all Instruments or all
PilotControllers.
• A‘group’canbejustone display,oranumberofdisplaysuptoamaximumoffour.
• Thekeypad(s)allocatedtoagroupmustbeappropriatetothedisplayfunction,i.e.
InstrumentkeypadforInstrumentgroups,PilotControllerkeypadforPilotControl-
lergroups.
OK OK
OK
OK
To
Time & Date
summary
OK
OK
Link keypad
to group
Display type
Select display to assign function and allocate to group
To be the same type for all
displays in a Group
To be different for each
display in a Group
Popup
On keypad you want to link,
press
YES
NO
OK
From
Vessel type
setup
System
configuration
Configure
this display
Are
all displays &
groups set as
required?
YES
NO
D11148-1
MENU
MENU
Assign order
in group
Assign group
Link keypad
to group
Keypad linked
Link keypad
to this group?
85024_1.book Page 6 Tuesday, January 27, 2009 11:31 AM

Chapter 1: General information 7
1.4 Normal operation
ST70+ Pilot Controllers and Instruments are controlled by dedicated Pilot Controller
keypads and Instrument keypads, respectively. There two types of Pilot Controller
keypad, one for sail boat installations, another for power boats.
Pilot Controllers
ST70+ Pilot Controllers are used to control Raymarine autopilots. A summary of
generic ST70+ Pilot Controller day-to-day functions is shown in Figure 1-3 .
Sail boat functions
In addition to the generic Pilot Controller functions in Figure 1-3, Pilot Controllers on
sailboatsalsohaveaccesstoWindVaneandAutoTackmodesofautopilotoperation.
These are accessed via the Pilot Controller
Main menu .
Wind Vane mode.
WindVanemodeautomaticallymaintainstheboat’sheadingwithrespecttothewind
angle. Thus if the wind angle changes, theboat’s heading changes accordingly to
maintain the same relative wind angle (see ST70+Operating Guide).
AutoTack operation
AutoTackenables you to select pre-defined tackoperations. Tack port and Tack
starboard
options are available.
WhenusingAutoTackoutsideofWindVanemode(standardAutoTack),theAutoTack
angleistheanglebetweenaporttackandastarboardtack.Thedefaultangleis100°.
This can be changed in User calibration (see page55).
When using AutoTack in Wind Vane mode, the tack angle relative to the wind on one
tack ismirrored on the other side of the wind onthe next tack.
Refer to the ST70+ Operating Guide for details of how to use AutoTack.
85024_1.book Page 7 Tuesday, January 27, 2009 11:31 AM

8 ST70+ User Reference Manual
Figure 1-3: GenericPilot Controllerfunctions
Count down to
POWER OFF
ADVANCED OPTIONS
POWER ON
Select next Pilot
Controller in group
Select Standby mode
(you have manual control)
MENU
Normal Operation
STANDBY
Select Auto mode
(autopilot steers to locked heading)
AUTO
Select Track mode
(autopilot tracks to preset course)
TRACK
Carry out Dodge manoever
(manually steer round an obstacle)
DODGE
PILOT VIEW
RESPONSE LEVEL
DIAGNOSTICS
DISPLAY SETTINGS
Hold down
Hold down to cycle to
different pilot view
Press & release to
select Main menu
User setup
* also part of initial setup
Hold down
D11136-1
Plain
2D
3D
Profile dependent options for:
Fishing boat
Power boat
Sail boat
Time & Date setup*
Brightness setup
Colors (day/night options)
Units setup*
Response setup
Data box setup
Setup Wizard
Transducer Setup
Set Language*
Set Vessel Type*
Set Ground Wind
Set Variation
Select Boat Show Mode
Factory Reset
About Display
Self Test
The pilot view at switch
on, is same as when
Pilot Controller last
switched off
Press & release
Keypad functions
Main menu
85024_1.book Page 8 Tuesday, January 27, 2009 11:31 AM

Chapter 1: General information 9
Power boat functions
In addition to the generic Pilot Controller functions (Figure1-3 ),Pilot Controllers on
power boats also have access tofishing patterns, via the Pilot Controller Main menu .
Fishing patterns
Fishing patterns enable you to automatically navigate over a preset course in Auto
mode. The patterns available are:
• Circle
• Zigzag
• Cloverleaf
•Spiral
• Circle against heading
• Figure 8
• Patternsearch
•180°turn
• Boxsearch
Youcancustomizeeachpatterntogiveexactlythecoverageyouwant(seepage56).
Onfishingboats,
PATTERN1 and PATTERN2 optionsenableyoutoselecteitherofthe
twomost frequentlyusedpatterns.
Instruments
Asummaryoftheday-to-dayfunctionsforST70+InstrumentsisshowninFigure1-4,
Normaloperation . Detailed operating instructions are given inthe ST70+ Operating
Guide.
85024_1.book Page 9 Tuesday, January 27, 2009 11:31 AM

10 ST70+ User Reference Manual
Figure 1-4: Normal operation
Count down to
POWER OFF
ADVANCED OPTIONS
ALARMS
Edit alarm
POWER ON
Select next Instrument
in group
OK
MENU
Normal Operation
PAGE DN
PAGE UP
Select previous
operational page
Select next
operational page
PAGE LAYOUT
DIAGNOSTICS
Reset data pages
Only resettable data types on the
current operational page are available.
DISPLAY SETTINGS
Hold down Hold downPress & release
User setup
* also part of initial setup
Hold down
D11135-1
Turn page on/off
Rebuild page from new
Change data
Time & Date setup*
Brightness setup
Colors (day/night options)
Units setup*
Response setup
Rollover setup
Timers setup
Setup Wizard
Transducer Setup
Set Language*
Set Vessel Type*
Set Ground Wind
Set Variation
Select Boat Show Mode
Factory Reset
About Display
Self Test
The operating page at
switch on, is same as
when intrument last
switched off
Press & release
Instrument keypad
85024_1.book Page 10 Tuesday, January 27, 2009 11:31 AM

Chapter 1: General information 11
1.5 System information
ST70+ displays and keypads connect toRaymarine SeaTalkng systems. Further
informationon SeaTalkng is given in the SeaTalkng Reference Manual.
When connected to a SeaTalkng system, the ST70+ displays repeat the dataon the
bus.You can set the display response as required. You can set the system variation
only if it hasnot been set at another product.
Youcanalsocalibratethesystemtransducersandsetthedataunitsyouwanttoapply
to the system.
Power protocol
Power to ST70+ is switched on and off using the power button (as described in
the ST70+ Operating Guide). However, where instruments are part of a system,it
maybe more convenient to switch power for the entire system from acentral circuit
breaker.
In this case, whensystem power is switched ONagain:
• ST70+ instrumentsthat were switchedon when power was last switched offwill
return to the switchedON state.
• ST70+instrumentsthatwereOFFwhensystempowerwaslastswitchedOFFwill
remain OFF and will need to be switched ON individually using their power but-
tons.
85024_1.book Page 11 Tuesday, January 27, 2009 11:31 AM

12 ST70+ User Reference Manual
1.6 Commissioning requirement
WARNING: Product installation & operation
ST70+ products must be prepared for use in accordance with the
Commissioning Procedures, before they are used for operational
purposes, unless they are part of a SeaTalk
ng
system in which at least one
other ST70+ display is already set up and working. Failure to comply with
this could result in death, personal injury, damage to your boat and/or poor
product performance.
Afterinstallation,eachST70+display that isNOTpartof aSeaTalkngsysteminwhich
atleastoneotherST70+displayisalreadysetupandworkingmustbecommissioned
in accordance with Chapter 2: Commissioning Procedures, before it is used for
operational purposes.
Refer to the ST70+ Operating Guide for instructions on how to use the ST70+
products on aday-to-day basis.
Autopilot calibration
The detailed requirement for autopilot calibration depends on the autopilot type. The
proceduresgiven in thismanualare thosefor a ‘typical’Raymarine autopilotsystem.
If necessary adapt the procedures in this manual to suit your system.If you need
assistance,contact your Raymarine dealer.
85024_1.book Page 12 Tuesday, January 27, 2009 11:31 AM
