Razor FLASHRIDER 360 User manual

1209_v1
Item Number:
20036559
Owner’s Manual
Read and understand this entire manual before riding!
DO NOT RETURN TO STORE!
NOTE: Manual illustrations are for demonstration purposes only.
Illustrations may not reflect exact appearance of actual product.
Specifications subject to change without notice.
Please have your 21 character product I.D. code ready before
contacting Razor for warranty assistance and/or replacement parts.
Product I.D. Code: _____________ - ____________ - ____________
FlashRideR™360°

1
CONTENTS
The recommended rider age of 6 and older for FlashRider 360˚ Caster Trike is
only an estimate, and can be affected by the rider’s size, weight or skills. Any
rider unable to fit comfortably on the FlashRider 360˚ Caster Trike should not
attempt to ride it. A parent’s decision to allow his or her child to ride
this product should be based on the child’s maturity, skill and ability
to follow rules.
Keep this product away from children under the age of 6 and remember that
this product is intended for use only by persons who are, at a minimum,
completely comfortable and competent while operating the FlashRider 360°
and who understand the risks presented by such products.
DO NOT EXCEED THE WEIGHT LIMIT OF 160 lbs (73kg).
Rider weight does not necessarily mean a person’s size is appropriate to fit or
maintain control of the FlashRider 360˚ Caster Trike.
ACCEPTABLE RIDING PRACTICES AND CONDITIONS
Always check and obey any local laws or regulations which may affect the
locations where the FlashRider 360˚ Caster Trike may be used on public
property. The FlashRider 360˚ Caster Trike is meant to be used only in
controlled environments, free of potential traffic hazards and not on public
streets. Do not ride your FlashRider 360˚ Caster Trike in any areas where
pedestrian or vehicle traffic is present.
Ride defensively. Watch out for potential obstacles that could force you to
swerve suddenly or lose control. Be careful to avoid pedestrians, skaters,
skateboards, scooters, bikes, children or animals who may enter your path
and respect the rights and property of others.
Maintain a hold on the handlebars at all times.
Never carry passengers or allow more than one person at a time to ride the
FlashRider 360˚ Caster Trike.
Never use near streets, swimming pools, hills, steps, or sloped driveways.
Never use headphones or a cell phone when riding.
Never hitch a ride with another vehicle.
The FlashRider 360˚ Caster Trike is intended for use on solid, flat, clean and
dry surfaces, such as pavement or level ground, without loose debris, such as
rocks or gravel. Wet, slick or uneven and rough surfaces may impair traction
and contribute to possible accidents. Do not ride the FlashRider 360˚ Caster
Trike in mud, ice, puddles or water. Avoid excessive speeds that can be
associated with downhill rides. Never risk damaging surfaces, such as carpet
or flooring, by use of a FlashRider 360˚ Caster Trike indoors.
Do not ride at night or when visibility is impaired.
PROPER RIDING ATTIRE
Riders should always wear a properly fitted helmet that complies with U.S.
Consumer Safety Commission (CPSC) Standard 16 CFR 1203. A helmet
may be legally required by local law or regulation in your area. Elbow and
kneepads, long sleeved shirt and long pants are recommended. Always wear
closed toed shoes, never ride barefooted or in sandals, and keep shoelaces
tied and out of the way of the wheels.
FAILURE TO USE COMMON SENSE AND HEED THE
ABOVE WARNINGS INCREASES RISK OF SERIOUS
INJURY. USE WITH APPROPRIATE CAUTION AND
SERIOUS ATTENTION TO SAFE OPERATION.
Parts Breakdown ........................................................... 6
Safety Reminders.......................................................... 7
Warranty ........................................................................ 7
WARNING: Riding the FlashRider 360˚ Caster Trike can be a
hazardous activity. Certain conditions may cause the equipment to fail
without fault of the manufacturer. The FlashRider 360˚ Caster Trike can and is
intended to move, and it is therefore possible to lose control, fall off and/or
get into dangerous situations that no amount of care, instruction or expertise
can eliminate. If such things occur you can be seriously injured or die, even
when using safety equipment and other precautions. RIDE AT YOUR OWN
RISK AND USE COMMON SENSE.
This manual contains many warnings and cautions concerning the
consequences of failing to maintain, inspect or properly use your FlashRider
360˚ Caster Trike. Because any incident can result in serious injury or even
death, we do not repeat the warning of potential serious injury or death each
time such a possibility is mentioned.
APPROPRIATE RIDER USE AND
PARENTAL SUPERVISION
This manual contains important safety information. It is your responsibility
to review this information and make sure that all riders understand all
warnings, cautions, instructions and safety topics, and assure that young
riders are able to safely and responsibly use this product. Razor recommends
that you periodically review and reinforce the information in this manual with
younger riders, and that you inspect and maintain your child’s FlashRider
360° to insure their safety.
SAFETY WARNINGS
Safety Warnings ............................................................ 1
Before You Begin........................................................... 2
Assembly and Set-Up................................................. 3-5
Set-Up and Usage Instructions...................................... 5
WARNING: SPARKS CAN INDUCE FIRE
To reduce the risk of SERIOUS INJURY or FIRE:
PARENTS and RIDERS: Make sure riders understand that sparks can start
a fire. Keep sparks away from flammable or combustible substances. Use
only under close adult supervision.
BE RESPONSIBLE: Safety is important. Parents must review the following
warnings and instructions with each rider:
• Never use your caster trike to try to start a fire. Your caster trike emits
localized sparks when the Spark Bar on a moving trike comes in contact
with hardened outdoor surfaces like asphalt or concrete. Be responsible.
• For outdoor use only on solid, clean, dry hardened surfaces. Keep sparks
away from substances that can catch fire, such as dry vegetation, paper,
chemicals or gasoline. Sparks can induce fire.
• Do not use in any area prone to wildfires or posted by fire authorities as
a Fire Hazard Zone.
• Do not ride at night.
• Keep sparks away from eyes, hair, exposed skin and clothing. Sparks can
burn.
• Pull up on the Spark Handle to operate sparking feature. NEVER push
down directly on the Spark Bar, spark cartridge or its cover itself.
• Spark Bar gets hot during use. Do not touch after use.
Observe all other spark safety warnings and instructions as provided
elsewhere in this manual.

Front Fork Assembly
Front Wheel Assembly Steering Bolt
Seat
Barcode
Location
Rear Caster Wheels
Spark Bar
Spark Cartridge
Spark Handle
Spark Cartridge Cover
2
Need Help? Visit our website for replacement parts, product support and a list of authorized service centers
at www.razor.com or call toll free 866-467-2967 Monday - Friday 8AM - 5PM Pacific Time. Please have the
product I.D. code (located on the bottom of the frame) available for better assistance.
BEFORE YOU BEGIN
Remove contents from box and check parts against parts diagram found on page 6. Remove the foam separators that
protect the components from damage during shipping. Inspect the contents of the box for scratches in the paint or
dents that may have occurred during shipping. Because the FlashRider 360˚ was partially assembled and packed at the
factory there should not be any problems, even if the box has a few scars or dents.
q Estimated Assembly and Set-Up Time
Allow up to 15–20 minutes for assembly.
WARNING: DO
NOT USE NON-RAZOR
PRODUCTS WITH YOUR
FLASHRIDER 360˚.
The FlashRider 360˚ has been
built to certain Razor design
specifications. The original
equipment supplied at the time of
sale was selected on the basis of
its compatibility with the frame,
fork and all other parts. Certain
aftermarket products may or may
not be compatible and will void
your warranty.
q Required Tools
(2) 5mm
Allen wrenches
(included)
10mm and 13mm
wrench
(included)
PRODUCT I.D. CODE
1.Bottom of Frame
2.UPC Side of Box (not shown)

3
q Attaching the Spark Bar
Required Tools: 10mm wrench and 5mm Allen wrench
Need Help? Visit our website for replacement parts, product support and a list of authorized service centers
at www.razor.com or call toll free 866-467-2967 Monday - Friday 8AM - 5PM Pacific Time. Please have the
product I.D. code (located on the bottom of the frame) available for better assistance.
ASSEMBLY AND SET-UP
1Using (2) 5mm Allen wrenches,
remove coupling bolt and discard
plastic insert.
1Using a 10mm wrench and a
5mm Allen wrench, remove the
coupling bolts from the Spark
Handle.
2Insert the rear frame to the
frame assembly and using (2) 5mm
Allen wrenches, securely tighten
coupling bolts.
2Insert the Spark Handle (right
side) and the Spark Bar (left side)
into the spring mechanism. Align
the holes on the Spark Bar with the
hole on the spring mechanism and
tighten coupling bolt with 10mm
wrench and 5mm Allen wrench..
2Align the holes on the Spark
Handle with the holes on the
Spark Bar and tighten coupling
bolts with 10mm wrench and
5mm Allen wrench.
q Attaching the Frame
Required Tools: (2) 5mm Allen wrenches

4
1Remove the steering bolt and
locknut from the frame assembly
with a 13mm wrench and 5mm
Allen wrench.
2Insert the front fork into the
frame assembly.
q Attaching the Front Fork
Required Tools: 13mm wrench and 5mm Allen wrench
4Re-insert the steering bolt and
secure with locknut using a 13mm
wrench and 5mm Allen wrench.
3Be sure to properly align
slot on headtube with pin on
front fork as shown.
ASSEMBLY AND SET-UP
1Remove the (4) coupling bolts
from the front fork with a 5mm Allen
wrench and 10mm wrench.
2Insert the wheel assembly into
the front fork assembly and align
holes. When installing the wheel,
make sure the letter “F” and
arrow (located on the side of the
wheel) are facing the direction as
shown above.
q Attaching the Front Wheel
Required Tools: 5mm Allen wrench and 10mm wrench
WARNING: Failing to
properly tighten the steering bolt
that attaches the front fork assembly
to the frame assembly can cause you
to lose control and fall.
3Re-insert the coupling bolts
through the front fork and
tighten securely.

5
ASSEMBLY AND SET-UP
2Place a new cartridge in back of the bracket making sure to align the slots
on the cartridge with the two legs of the bracket. Slide cartridge forward
until you hear a click and the thumb tabs are locked in place.
1Using your thumbs, press tabs
on both sides of the cartridge to
release from the bracket. Slide
cartridge away from you and
remove from bracket.
q Replacing the Spark Cartridge:
q Using the Spark Handle
SET UP AND USAGE INSTRUCTIONS
WARNING: Pulling
the Spark Handle upwards too
strenuously may cause loss of
control.
NOTE:Sparks and Spark
cartridge life will vary based on
the amount of pressure applied
by Spark Handle, the length of
time pressure is applied and
the smoothness of the riding
surface.
WARNING: Do not
attempt to replace cartridge
immediately after riding as
cartridge will be hot. Handle only
when cool.
WARNING: Keep fingers
clear of Spark Bar hinge.
Friction during sparking will eventually wear out the replaceable cartridge and cause the scooter to stop making
sparks. Worn out cartridges should be replaced.
1 Pull back on the Spark Handle to operate
sparking feature.
NEVER push down directly on the Spark Bar, Spark
Cartridge or Spark Cartridge Cover itself.
1Using (2) 5mm Allen wrenches,
remove the (4) coupling bolts from
the frame.
2Align the (4) holes in seat
with the (4) holes in frame. Insert
coupling bolts through the top and
bottom of the frame.
q Attaching the Seat
Required Tools: (2) 5mm Allen wrench
3Tighten the coupling bolts using
(2) 5mm Allen wrenches.

4
4-1
2
2-1
5
1
3
4
8
7-1 7
9
11
10
6-1
2
3
5
6
Need Help? Visit our website for replacement parts, product support and a list of authorized service centers
at www.razor.com or call toll free 866-467-2967 Monday - Friday 8AM - 5PM Pacific Time. Please have the
product I.D. code (located on the bottom of the frame) available for better assistance.
Keep your FlashRider 360˚ rolling for years with genuine Razor parts. Visit our website to purchase replacement parts.
(Specifications subject to change without notice.)
6 Rear Wheel Assembly (x2)
6-1 Rear Wheel Cover
6-2 Spring Washer
6-3 Caster
6-4 Axle Bolts
6-5 Wheel
7 Seat
7-1 Seat Coupling Bolts (x4)
8 Spark Handle
9 Spark Bar
10 Spark Cartridge
11 Spark Cartridge Cover
FLASHRIDER 360˚ CASTER TRIKE PARTS
1 Handlebar Grip (x2)
2 Front Fork
2-1 Front Fork Coupling Bolts (x4)
3 Front Cover
4 Steering Bolt
4-1 Lock Nut
5 Front Wheel w/ Pedals and Cranks Complete

Need Help? Visit our website for replacement parts, product support and a list of authorized service centers
at www.razor.com or call toll free 866-467-2967 Monday - Friday 8AM - 5PM Pacific Time. Please have the
product I.D. code (located on the bottom of the frame) available for better assistance.
7
DO NOT RETURN TO STORE
Failure to follow these instructions may damage
your product and void your warranty.
Razor Limited Warranty
The manufacturer warranties this product to be free of manufacturing defects
for a period of 6 months from date of purchase. This Limited Warranty does
not cover normal wear and tear, or any damage, failure or loss caused by
improper assembly, maintenance, storage or use of the Razor FlashRider 360˚.
This Limited Warranty will be void if the product is ever
• used in a manner other than for recreation;
• modied in any way;
• rented.
The manufacturer is not liable for incidental or consequential loss or damage
due directly or indirectly to the use of this product.
Razor does not offer an extended warranty. If you have purchased an
extended warranty, it must be honored by the store at which it was
purchased.
WARRANTY
U.S. Patent No. D593,910 S
Printed in China for:
Razor USA LLC
PO Box 3610
Cerritos, CA 90703
Copyright © 2003-2012 Razor USA, LLC. All rights reserved. RAZOR and the Razor Logo
Design are among the registered trademarks of Razor USA LLC in the United States and/or
select foreign countries. FlashRider is a trademark of Razor USA LLC.
For your records, save your original sales receipt with this manual.
__________________________________________
Item Number:
20036559
Loose Parts
Check and secure all fasteners before every ride. Make sure
the steering bolt and casters are tight. There should not be any
unusual rattles or sounds from loose parts or broken components.
If you are not sure, ask an experienced mechanic to check.
Frame, Fork and Handlebars
Check for cracks or broken connections. Although broken frames
are rare, it is possible for an aggressive rider to crash into a curb or
wall, and wreck, and bend or break a frame. Get into the habit of
inspecting yours regularly.
SAFETY REMINDERS
q
qq
qWheel Care
Periodically inspect the wheels for excess wear.
Safety Gear
Always wear proper protective equipment, such as an approved
safety helmet. Elbow pads and knee pads are recommended.
Always wear closed toe shoes (lace-up shoes with rubber soles),
never ride barefooted or in sandals, and keep shoe laces tied and
out of the way of the wheels.
PRE-RIDE CHECKLIST
09/2012
