RCA RIR205 - Infinite Radio Tabletop Internet User manual

WAN LAN
reset
power
LAN
WAN
POWER
LAN
LAN
LAN
RIR205
QuickStartGuide
Congratulations on purchasing your new RCA Wi-Fi Internet Radio.
Please follow these instructions to set up and start using the radio.
www.rcaaudiovideo.com
v1.0 (EN)
Unpack the unit
You should nd the following items in the box:
1
Additional requirements
• Broadband Internet service
• Broadband (cable/DSL) modem, usually supplied by your Internet service provider
• Ethernet router/switch/hub with available LAN port
Setup your RCA Innite Radio accounts
To simplify setup and avoid manual conguration on the radio please complete these steps:
1. Find the Setup Information Card that contains your radio’s MAC address number (MAC:
00-00-00-00-00-00) and activation PIN # (PIN: 0000). (This number is also found in the Device
Info screen under the Settings menu in your radio.)
2. Using any Internet-connected computer, go to www.rcainniteradio.com/setup and follow
the online instructions.
• You will need to input your radio’s MAC address and PIN # to associate your radio with your
personal settings.
Wi-Fi Enabler
Connect the RCA Wi-Fi Enabler to your network
3
Insert AAA batteries in the base of the radio
4
Broadband modem or
Ethernet router/hub/switch
1. Connect an ethernet cable from the Enabler’s “WAN” port to a LAN port on your broadband
modem or Ethernet router/hub/switch.
2. Connect the power adapter to the Enabler. Plug the adapter into an electrical outlet.
3. Make sure the power, WAN, and Wireless LEDs are on. The mode LED state will vary depending
on your network conguration. If the Mode, WPS/Scan, and Wireless LEDs are blinking
simultaneously, this indicates that there is a possible error in connection. Please review your
connections and then press and hold the WPS/Scan button at the front of the Enabler for 3
seconds to rescan your network conguration. Go to www.rcainniteradio.com/enablersetup
for more information.
Follow the polarity markers in the battery
compartment.
The batteries (not included) power the
clock and alarm whenever the radio loses
electricity.
Plug in and turn on the radio
5
1. NOTE: When you turn on the radio for the rst time,
it will be in “DEMO” mode. To exit this mode, press
preset 1, then SLEEP/SNOOZE, then preset 6 on
top of the radio.
2. After exiting the DEMO mode,
the radio displays the Select
Language screen. Choose
your preferred language.
• REMINDER: If your unit is unable to connect to
your Enabler and you have already checked all the
connections to the enabler, please press and hold
the WPS/Scan button at the front of the Enabler
for 3 seconds to rescan your network conguration.
Go to www.rcainniteradio.com/enablersetup for
more information.
3. If you did not activate your Innite Radio accounts,
or if the radio cannot get your details from the
Innite Radio server, the radio may ask for your ZIP
code. Input your code.
• If your radio has successfully connected to the Internet you will hear a welcome message.
Quick Start
Guide (this
leaet)
!
Use the navigation controls to make
choices and input information:
- move highlight up
- move highlight down
- move selection/navigate left
- move selection/navigate right
SELECT - conrm selected option or
character
When inputting characters, press or
to choose among uppercase, lowercase,
numeric, or special characters.
To insert spaces or correct mistakes, press
to display the Commands list and then
press or to choose the desired
command.
Learn more about your Internet Radio
Read the user manual (download from www.rcainniteradio.com) for more information on the
player’s features, safety and warranty information, and answers to Frequently Asked Questions (FAQ’s).
Need more help? Do not return this product to the store.
Visit www.rcainniteradio.com to get the latest rmware updates and FAQ’s.
Radio Power adapter
(for radio)
Power adapter
(for Wi-Fi Enabler)
Ethernet cable AM loop antenna
Setup
Information
Card
Electrical outlet
Electrical outlet
Press preset 1, then SLEEP/
SNOOZE, then preset 6.
Deactivate the DEMO mode
after turning on
If your modem or router/hub/switch has only one LAN
port and is connected to your PC, disconnect the
Ethernet cable from the modem/router/hub/switch and
connect it to the Enabler's LAN port.
Press or to highlight,
SELECT to conrm.
Press to show “DONE”
and SELECT to conrm.
2

Controls
WEATHER
Sleep timer/
snooze
Audio source
On/standby
Station presets
Home/Main
menu
Display
“Love It”
“Ban It”
“Tag it” Play/pause
Volume
Record
Menu up
Menu select
Next/scan/fast
forward/menu
forward
Previous/scan
back/reverse/
menu back
Menu down
Weather
information
Alarm set
Clock set
Audiovox Electronics Corp.,
150 Marcus Blvd, Hauppauge, NY 11788
© 2008 Audiovox Electronics Corp.
Trademark Registered
Marca Registrada
Marque Deposée
www.rcaaudiovideo.com
Rear panel connections
You can connect USB devices to the USB port:
The radio can play MP3, WMA and RealAudio
audio les stored on the connected USB device.
Headphone/
audio line-out USB 2.0 port
For information on new and upcoming products and to register your new radio, visit
www.rcaaudiovideo.com.
FM antenna
AM loop
antenna socket
Listening to Slacker™ radio
Choose a Slacker™ station
Start playing the selected station
Pause playback
Skip to the next song
Mark the current song as a favorite
Create a custom station based on the
current artist
Ban the current song from the station
Ban the current artist from the station
Use the current station as the alarm sound
Press SOURCE to choose
Slacker Radio.
Press or to move up and
down the menu options and
press SELECT to choose the
desired genre and station.
Press SELECT.
Press . Press again to resume.
Press .
Press .
Press and hold .
Press .
Press and hold .
Press to display the options menu. Press to choose
Send to Alarm and then press SELECT.
Using the radio
General procedures
Turn on/o (standby) the radio
Choose an audio source
Choose a preset radio station
Assign the current radio station to a preset
Display the menu while listening
Record the current AM/FM/Internet radio station
Start the sleep timer
Add time or cancel the sleep timer
Display the time
Set the time
Press ON/STANDBY.
Press SOURCE to cycle through the audio sources
(Slacker Radio, Internet Radio, FM/AM Tuner, Internal
Memory, or USB Input).
Press SOURCE to choose the radio source (Slacker,
Internet, FM, or AM), then press a preset button (1–6).
Press and hold a preset button (1–6) until the radio
beeps.
Press .
Press .
Press again to stop recording.
Press SLEEP/SNOOZE.
Press SLEEP/SNOOZE repeatedly.
Press CLOCK.
Press and hold CLOCK until the hour is highlighted.
Press or to choose hours, minutes or AM/PM.
Press or to change the time.
Press SELECT to set the time.
Listening to FM/AM radio
Tune in an FM/AM radio station
Step through the radio frequencies
Use the current station as the alarm sound
Press SOURCE to choose FM or AM radio.
Press and hold or until the radio beeps to auto-
tune to the previous or next available station.
Press or .
Press to display the options menu. Press to choose
Send to Alarm and then press SELECT.
Listening to Internet radio
Choose an Internet radio station
Start playing the selected station
Mark the current station as a favorite
Remove the current station from My Favorites
Use the current station as the alarm sound
Press SOURCE to choose
Internet Radio.
Press or to move up and
down the menu options and
press SELECT to navigate to
the desired station.
Press SELECT.
Press or press to display the options menu. Press
to choose Add to Favorites and then press SELECT.
Press .
Press to display the options menu. Press to choose
Send to Alarm and then press SELECT.
Playing recordings and audio les
Play a recording
Play an audio le from a connected USB device
Pause playback
Skip to the next recording/audio le
Skip to the previous recording/audio le
Press SOURCE to choose Internal Memory.
Press or to highlight a recording and press
SELECT.
Press SOURCE to choose USB.
Press or to exit or enter folders. Press or to
highlight a le and press SELECT to start playback.
Press . Press again to resume.
Press .
Press within the rst 3 seconds of the current
recording/le.
Listening to Weather Forecasts
Listen to today’s local forecast
Listen to 3-day local forecast
Press WEATHER once.
Press WEATHER twice.
Slacker is a trademark of Slacker, Inc. in the United States and other countries.
RealAudio is a trademark or a registered trademark of RealNetworks, Inc.
Power adapter
input socket
LAN port
