The Reliable Automatic Sprinkler Co., Inc., 103 Fairview Park Drive, Elmsford, New York 10523
Bulletin 132 June 2019
Bulletin 132 June 2019
Model GL112
Quick Response
Upright and Pendent Storage
& Non-Storage Sprinklers
K-factor: 11.2 (160 metric)
(SIN R3226)Upright
(SIN R3216) Pendent
Product Description
The Reliable Model GL112 is a standard coverage, Quick
Response sprinkler utilizing a levered fusible alloy solder
link in 165°F (74°C) or 212°F (100°C). The sprinkler has
been designed to control high challenge fires in both pallet-
ized and rack storage occupancies, utilizing relatively low
water pressures. This sprinkler is available with ¾” NPT or
ISO7-1R3/4 threads.
Listings & Approvals
Approved by Factory Mutual (FM) as a storage and non-
storage sprinkler.
Optional Guards and Water Shields
GL112 Upright Water Shield (factory installed)
D-7 Guard & Water Shield
GL112 Pendent
D-8 Guard
D-9 Guard & Water Shield
S-2 Water Shield
Temperature Ratings
Classification
Sprinkler
Rating
Maximum Ceiling
Temperature Frame
Color
°F °C °F °C
Ordinary 165 74 100 38 Uncolored
Intermediate 212 100 150 66 White
Maintenance
Model GL112 QR Sprinklers should be inspected and
the sprinkler system maintained in accordance with NFPA
25. Do not clean sprinklers with soap and water, ammo-
nia or any other cleaning fluids. Remove dust by using
a soft brush or gentle vacuuming. Remove any sprinkler
which has been painted (other than factory applied) or
damaged in any way. A stock of spare sprinklers should
be maintained to allow quick replacement of damaged or
operated sprinklers. Prior to installation, sprinklers should
be maintained in the original cartons and packaging until
used to minimize the potential for damage to sprinklers
that would cause improper operation or non-operation.
Model GL112 QR Upright
Model GL112 QR Pendent

Installation
Reliable’s Model GL112 QR sprinkler must be installed
according to NFPA Standards or the appropriate FM
Global Data Sheets for all area/density methods of design
as well as the Authority Having Jurisdiction. Use only
the Model H sprinkler wrench for sprinkler removal and
installation. Any other type of wrench may damage the
sprinkler.
Note: Sprinklers should be tightened between 14-20 ft/
lbs (19-27,1 N-m) torque. Sprinklers not tightened to
recommended torque may cause leakage or impairment
of the sprinklers. Damage sprinklers must be replaced
immediately.
Model H Wrench
2.
Ordering Information
Specify:
1. Sprinkler Model [GL112 Upright] [GL112 Pendent]
2. Temperature Rating[165 F (74C)], [212 °F (100 °C)]
3. Optional Guard or Water Shield
Fig. 1

The Reliable Automatic Sprinkler Co., Inc.
[phone] Sales Offices
[phone] Sales Fax
[phone] Corporate Offices
www.reliablesprinkler.com Internet Address
Manufactured by
Recycled
Paper
Revision lines indicate updated or new data.
EG. Printed in U.S.A. 06/19 P/N 9999970422
The equipment presented in this bulletin is to be installed in accordance with the latest published Standards of the National Fire Protection Association, Factory
Mutual Research Corporation, or other similar organizations and also with the provisions of governmental codes or ordinances whenever applicable.
Products manufactured and distributed by Reliable have been protecting life and property for over 90 years.
ITEM DESCRIPTION
Sprinkler Identification Number (SIN) Upright R3226
Pendent R3216
K Factor US (Metric) 11.2 (160)
Thread Size 3/4" (ISO 7-IR3/4)
Sprinkler Orientation Upright or Pendent
Maximum Working Pressure, PSI (bar) 175 PSI (12 bar)
Model GL112 Technical Data Table A
Storage Type NFPA FM GLOBAL
Sprinkler Type CMDA Storage
Response Type QR QR
System Type Pendent - Wet
Upright - Wet, Dry, Preaction
Pendent- Wet
Upright- Wet, Dry, Preaction
Temperature Rating F (C) 165,212 (74,100) 165,212 (74, 100)
Roof Construction See NFPA 13 See FM Global 2-0
Ceiling Slope See NFPA 13 See FM Global 2-0
Maximum Coverage Area See NFPA 13 See FM Global 2-0
Minimum Coverage Area See NFPA 13 See FM Global 2-0
Maximum Spacing See NFPA 13 See FM Global 2-0
Minimum Spacing See NFPA 13 See FM Global 2-0
Minimum Clearance to Commodity See NFPA 13 See FM Global 2-0
Sprinkler Distance to Ceiling See NFPA 13 See FM Global 2-0
Open Frame, Single, Double, Multi-
ple Row, or Portable Rack Storage of
Class I - IV, Cartoned Unexp Plastics
See NFPA 13 See FM 2-0 & 8-9
Solid Pile or Palletized Stor-
age of Class I - IV and Car-
toned Unexp Plastics
See NFPA 13 See FM 2-0 & 8-9
Idle Pallet Storage See NFPA 13 See FM 2-0, 8-9 & 8-24
Rubber Tire Storage See NFPA 13 "Upright N/A
Pendent-See FM 8-3"
Rolled Paper Storage See NFPA 13 See FM 8-21
Flammable Liquid Storage See NFPA 13 See FM 7-29 & 8-9
Aerosol Storage See NFPA 13 See FM 7-31
Auto Components in Portable Racks See NFPA 13 N/A
Model GL112 Commodity Selection and Design Criteria Overview Table B
