Reliable F1FR-FS LO Manual

The Reliable Automatic Sprinkler Co., Inc., 103 Fairview Park Drive, Elmsford, New York 10523
Model F1FR-FS LO
Large Orifice
Quick Response
Flat Spray Sprinkler
With 1 /
2” Connection Thread
Bulletin 037 Rev. B
Bulletin 037 Rev. B
Model F1FR-FS LO Large Orifice Flat Spray
Sprinkler Types
Standard Pendent
Listings & Approvals
• VdS Schadenverhütung GmbH: Certificate
• EC-Certificate: EC Certificate: 0786-CPD-40284
Product Description
The F1FR-FS LO Flat Spray Sprinklers are designed for
installation in accordance with CEA 4001 or EN 12845
(Automatic Sprinkler Systems - Design, Installation and
Maintenance). The spray pattern created by this sprin-
kler makes this an excellent choice for applications with
lower clearance above the suspended open ceilings and
in racks.
The F1FR-FS LO Flat Spray Sprinkler utilizes a frangible
3.0mm glass bulb. The glass bulb consists of an accurate-
ly controlled amount of special fluid hermetically sealed
inside of a precisely manufactured glass capsule. This
glass bulb is specially constructed to provide fast thermal
response.
At normal temperatures, the glass bulb contains the fluid
in both the liquid phase and in the vapor phase. The vapor
phase can be seen as a small bubble. As heat is applied,
the liquid expands forcing the bubble smaller and smaller
as the liquid pressure increases. Continued heating forces
the liquid to push out against the bulb, causing the glass
to shatter, opening the waterway and allowing the deflec-
tor to distribute the discharging water.
The F1FR-FS LO Flat Spray Sprinkler temperature rating
is identified by the color of the glass bulb capsule.
Pendent

Model F1FR-FS5 LO Quick Response Pendent Sprinkler
Installation Wrench: Model D Sprinkler Wrench
Installation Data:
Sprinkler Type
Standard–Pendent (SSP)
Deflectors Marked to Indicate Position
K Factor Sprinkler
Height
Approval
Organizations
US Metric
(20mm) Standard Orifice with R1/2 Thread 8.0 115 58mm VdS
Pendent
Application
Model F1FR-FS LO Flat Spray Sprinkler is used in con-
cealed spaces, suspended open ceiling and in racks in
accordance with CEA 4001 Sprinkler System Planning)
and EN 12845 (Automatic Sprinkler Systems - Design In-
stallation and Maintenance).
Installation
Model F1FR-FS LO Flat Spray Sprinklers are quick re-
sponse sprinklers intended for installation as specified in
CEA 4001 and EN 12845. They must also be installed with
the Model D Sprinkler Wrench specifically designed by
Reliable for use with these sprinklers.
Note: A leak tight ½” NPT sprinkler joint can be obtained
with a torque of 8-18 ft-lbs (10,8 - 24,4 N-m). Do not tight-
en sprinklers over maximum recommended torque. It may
cause leakage or impairment of the sprinklers.
Ordering Information
Specify:
1. Sprinkler Model
2. Sprinkler Type
3. Orifice Size
4. Deflector Type
5. Temperature Rating
- Specify Bulb Size when ordering
6. Sprinkler Finish - Bronze only
Maintenance
The Model F1FR-FS LO Pendent should be inspected
quarterly. Do not clean sprinklers with soap and water, am-
monia or any other cleaning fluid. Remove any sprinkler
which has been painted (other than factory applied) or
damaged in any way. A stock of spare sprinklers should
be maintained to allow quick replacement of damaged or
operated sprinklers. Prior to installation, sprinklers should
be maintained in the original cartons and packaging until
used to minimize the potential for damage to sprinklers
that would cause improper operation or non-operation.
Temperature Ratings
Classification
Sprinkler
Temperature Max. Ambient
Temp.
Bulb
Color
°C °F
Ordinary
Ordinary
Intermediate
Intermediate
High
57
68
79
93
141
135
155
175
200
286
100°F (38°C)
100°F (38°C)
150°F (66°C)
150°F (66°C)
225°F (107°C)
Orange
Red
Yellow
Green
Blue
The Reliable Automatic Sprinkler Co., Inc.
(800)431–1588 Sales Offices
(800)848–6051 Sales Fax
(914)829–2042 Corporate Offices
www.reliablesprinkler.com Internet Address
Manufactured by
Recycled
Paper
EG. Printed in U.S.A. 11/17 P/N 9999970415
The equipment presented in this bulletin is to be installed in accordance with the latest pertinent Standards of the National Fire Protection Association, Factory Mutual Research
Corporation, or other similar organizations and also with the provisions of governmental codes or ordinances whenever applicable.
Products manufactured and distributed by Reliable have been protecting life and property for over 90 years, and are installed and serviced by the most highly qualified and reputable
sprinkler contractors located throughout the United States, Canada and foreign countries.
Revision lines indicate updated or new data
