Rice Lake FlexWeigh System 101 User manual

FlexWeigh System 101
Basic Filler
Version 1.02
Operation Manual
®
June 10, 2020 PN 120491 Rev C

An ISO 9001 registered company
© Rice Lake Weighing Systems. All rights reserved.
Rice Lake Weighing Systems® is a registered trademark of
Rice Lake Weighing Systems.
All other brand or product names within this publication are trademarks or
registered trademarks of their respective companies.
All information contained within this publication is, to the best of our knowledge, complete and
accurate at the time of publication. Rice Lake Weighing Systems reserves the right to make
changes to the technology, features, specifications and design of the equipment without notice.
The most current version of this publication, software, firmware and all other product
updates can be found on our website:
www.ricelake.com

Contents
© Rice Lake Weighing Systems ● All Rights Reserved i
Contents
Technical training seminars are available through Rice Lake Weighing Systems.
Course descriptions and dates can be viewed at www.ricelake.com/training
or obtained by calling 715-234-9171 and asking for the training department.
1.0 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
1.1 Standard Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
1.2 Key Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
1.3 Operation Menu Softkeys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
2.0 Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
2.1 Unpacking and Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
2.2 Enclosure Disassembly. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
2.3 Cable Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
2.4 Cable Grounding . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
2.5 Parts Kit Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
2.6 Option Cards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
3.0 Setup Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
3.1 Entering the Setup Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
3.2 Setting the System Time and Date . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
3.3 Modifying the Setup Password . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
3.4 Enabling/Disabling Additional Data Fields . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
3.5 Modifying the Filling Speeds . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
3.6 Modifying the Auto Tare . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
3.7 Modifying Auto Print . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
3.8 Delay After Discharge . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
3.9 Test Digital I/O . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
4.0 Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
4.1 Entering Presets Softkey Menu. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
4.2 Entering Totals Softkey Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
4.3 Filling a Container . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
4.4 Pausing/Resume/Reset a Fill . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
4.5 Audit Trail Print . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
5.0 Appendix . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
5.1 Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
5.2 FCC Statement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
5.3 Product Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
5.4 Replacement Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
6.0 Limited Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
7.0 Compliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

FlexWeigh System 101
ii Visit our website www.RiceLake.com
Rice Lake continually offers web-based video training on a growing selection
of product-related topics at no cost. Visit www.ricelake.com/webinars

Introduction
© Rice Lake Weighing Systems ● All Rights Reserved 1
1.0 Introduction
This manual is intended for use by service technicians and operators responsible for installing and operating the FlexWeigh
System 101 Basic Filler.
Additional information on the actual hardware features of the 920i are explained in the 920i Installation and Operation Manual
(PN 67887) and is included with this product.
Safety Signal Definitions:
Indicates an imminently hazardous situation that, if not avoided, will result in death or serious injury. Includes
hazards that are exposed when guards are removed.
Indicates a potentially hazardous situation that, if not avoided, could result in serious injury or death. Includes
hazards that are exposed when guards are removed.
Indicates a potentially hazardous situation that, if not avoided, could result in minor or moderate injury.
Indicates information about procedures that, if not observed, could result in damage to equipment or corruption
to and loss of data.
General Safety
Do not operate or work on this equipment unless this manual has been read and all instructions are understood.
Failure to follow the instructions or heed the warnings could result in injury or death. Contact any Rice Lake
Weighing Systems dealer for replacement manuals.
Failure to heed could result in serious injury or death.
Failure to heed may result in serious injury of death.
Some procedures described in this manual require work inside the indicator enclosure. These procedures are to be performed by
qualified service personnel only.
Do not allow minors (children) or inexperienced persons to operate this unit.
Do not operate without all shields and guards in place.
Do not step on the unit.
Do not jump up and down on the scale.
Do not use for purposes other then weight taking.
Do not place fingers into slots or possible pinch points.
Do not use any load bearing component that is worn beyond 5% of the original dimension.
Do not use this product if any of the components are cracked.
Do not exceed the rated load limit of the unit.
Do not make alterations or modifications to the unit.
Do not remove or obscure warning labels.
Do not use near water.
Before opening the unit, ensure the power cord is disconnected from the outlet.
Keep hands, feet and loose clothing away from moving parts.
DANGER
WARNING
CAUTION
IMPORTANT
WARNING

FlexWeigh System 101
2 Visit our website www.RiceLake.com
1.1 Standard Features
The FlexWeigh System 101 comes with the following standard features:
• Wallmount stainless steel enclosure
• Front panel switches including E-Stop, Reset/Resume, Start
• Softkeys for presets, CN#, Alpha-numeric ID#1, Alpha-numeric ID#2, and Totals
• Accumulating subtotal and total registers
• Transmitted audit trail
• Digital I/O board
• Relay rack and SSR relay outputs
• Fast feed
• Slow feed
• Fill complete (optional)
• Zero tolerance (optional)
The iRite program and source code that make up the 920i FlexWeigh 101 Basic Filler are property of the
manufacturer. Modifications to this program and equipment must be performed by Rice Lake Weighing Systems.
For more information on the iRite compiler utility program, refer to the 920i Installation and Operation Manual
(PN 67887) and is included with this product.
Note

Introduction
© Rice Lake Weighing Systems ● All Rights Reserved 3
1.2 Key Functions
The functions of the front panel keys for the FlexWeigh System 101 are listed in Table 1-1.
Figure 1-1. FlexWeigh System 101
Key Function
E-Stop Stops the filling process and removes power from the relays; It also puts the process into a paused state
Start Starts the filling process
Reset Aborts the fill process; This requires that the E-Stop button is in a stopped position
Resume Starts the fill process from a paused state; This requires that the E-Stop is in a run position
Manual Allows manual control using the manual fill switch
Auto Allows automatic control after start is pressed
Manual Fill: On Maintained selection, energizes the fill output on continuously
Manual Fill: Jog Momentary selection, energizes the fill output only when the operator holds the switch in this position
Table 1-1. Front Panel Button Functions
The highlighted switches are
only available with PN 199060

FlexWeigh System 101
4 Visit our website www.RiceLake.com
1.3 Operation Menu Softkeys
Operation menu softkeys are defined to provide flexibility of operator functions for specific applications. Softkey assignments
are listed on the tabs shown at the bottom of the LCD display and softkey functions are activated by pressing the arrow keys
below the softkey tabs (Figure 1-2). They are password protected and offer access to the following:
• Presets
• ID #1
• ID #2
• Totals
• Setup Menu
Figure 1-2. 920i Front Panel
The set of softkeys shown on the display is determined by the indicator configuration and program.
Softkey Default Softkey Description
Preset Softkeys - Target Weight
Dribble Weight
Preact Weight
Zero Tolerance Weight
Refer to Section 4.1 on page 15 for detailed information on these functions
Totals Softkeys - Consecutive Number
Print Subtotals
Print Totals
Refer to Section 4.2 on page 18 for detailed information on these functions
Time/Date Current Time/Date Time and date of 920i
System Password """"""" Setup Password Changing the password that is required for entry into the setup menu;
Setting the password to nothing will cause the system to not prompt for a
password when the Setup Menu softkey is pressed
Enabling/Disabling ID#1 - ID #1 This allows the operator to log an extra data field;
A softkey appears on the main screen to allow the operator to enter more
data (ie: formula, ID Truck, container, operator)
Enabling/Disabling ID#2 - ID #2 This allows the operator to log an extra data field;
A softkey appears on the main screen to allow the operator to enter more
data (ie: formula, ID Truck, container, operator)
Filling Speeds Single Speed Single, Dual or Parallel Allows the operator to change the filling speed operations
Auto Tare Feature Enabled Auto Tare Enabled/Disabled Allows the operator to enable/disable the auto tare feature
Auto Print Feature Enabled Auto Print Enabled/Disabled Allows the operator to enable/disable the auto print feature
Delay After Discharge - Delay After Discharge Allows the operator to enter a time in seconds to delay after completion of
Discharge before a new Start input is enabled
Test Digital I/O - Fill Complete
Slow Fill
Fast Fill
Refer to Section 3.9 on page 14 for detailed information on these functions
Table 1-2. Configurable Softkeys
PRINT
UNITS
PRESETS ID1 ID2 SETUP MENU

Installation
© Rice Lake Weighing Systems ● All Rights Reserved 5
2.0 Installation
This section describes procedures for setting up the FlexWeigh System 101 to weigh.
Use a wrist strap to ground yourself and protect components from electrostatic discharge (ESD) when working
inside the indicator enclosure.
The supply cord serves as the power disconnect for the unit. The power outlet supplying the indicator must be
installed near the unit and be easily accessible.
The FlexWeigh System 101 has no on/off switch. Before opening the unit, ensure the power cord is
disconnected from the power outlet.
2.1 Unpacking and Assembly
Immediately after unpacking, visually inspect the unit to ensure all components are included and undamaged.
The shipping carton should contain the FlexWeigh System 101 unit and this manual. If any parts were damaged in shipment,
notify Rice Lake Weighing Systems and the shipper immediately.
2.2 Enclosure Disassembly
The FlexWeigh System 101 must be opened to install option cards and to connect cables for installed option cards.
Ensure power to the indicator is disconnected, then open the enclosure.
2.3 Cable Connections
The FlexWeigh System 101 provides eleven cord grips for cabling into the indicator. The parts kit includes cord grip plugs to
prevent moisture from entering the enclosure. Install these plugs into all cord grips that will not be used in your application.
Use the cable grounding instructions for wiring into the indicator.
Figure 2-1. Block Wiring Diagram
An additional adhesive label (PN 121108) is included in the parts kit and can be installed at the installer’s discretion
indicating correct terminal block numbering.
CAUTION
WARNING
Fuse F1 and F2 = 3.15 AMPS SLO-BLO (5X20MM)
Note

FlexWeigh System 101
6 Visit our website www.RiceLake.com
Figure 2-2. Block Wiring Diagram with Additional Controls
Circuit breaker = 4 A.
All wires are 18 AWG unless otherwise specified.
Figure 2-3. Wiring Diagram – Inside Enclosure
See Figure 5-3 on page 26 for wiring part numbers.
Note
AB
Detail A
Detail B
Inside Enclosure
To Terminal
Block R
To Relay
Board
J4-8
To CPU Board
J2-2
J2-5
J2-6 J2-4
Wires To CPU Board
J2-3
CPU Board
Wires to Relay Board
J4-1 J4-3 J4-5
J4-7
Relay
Board
Note

Installation
© Rice Lake Weighing Systems ● All Rights Reserved 7
2.4 Cable Grounding
Cables routed through the cord grips should be grounded against the indicator enclosure. Follow cable grounding instructions
in the 920i Installation and Operation Manual (PN 67887) which is also included with this product.
2.5 Parts Kit Contents
Table 2-1 lists the parts kit contents for the FlexWeigh System 101.
See Figure 5-2 on page 24 for a complete list of replacement parts.
Part No. Description Qty.
14626 Kep nuts, 8-32NC (6) 6
15133 Lock washers, No. 8, type A (6) 6
15631 Cable ties (4 single A/D, 6 dual A/D) 4
15665 Reducing glands for 1/2 NPT cord grips (11) 11
15887 6-position screw terminal for load cell connection (1-single A/D, 2-dual A/D) 1
19538 Cord grip plugs (10-single A/D, 9-dual A/D) 10
94422 Capacity Label (1-single A/D, 2-dual A/D) 1
53075 Cable shield ground clamps (6) 6
70599 6-position screw terminals for J2 and J10 (2) 2
71125 3-position screw terminal for J11 (1) 1
71126 4-position screw terminal for J9 and optional keyboard connection (2) 2
121108 Label, Terminal Block Identification (1) 1
Table 2-1. Parts Kits Contents (PN 121143)
Note

FlexWeigh System 101
8 Visit our website www.RiceLake.com
2.6 Option Cards
Table 2-2 list the available option card that are used in the FlexWeigh System 101. The single channel A/D card can be installed
in slot 1 and the 24 channel I/O card in slot 2.
Digital I/O
Serial Ports
Slot Type
1 Single Channel A/D Card
2 24 Channel I/O Card
Table 2-2. Option Card Locations
Slot Bit Type Function
0 1 Programmability E-Stop
0 2 Start
0 3 Resume
0 4 Reset
0 5-6 Off Currently not used
2 1 Output Fast Fill
2 2 Slow Fill
2 3 Fill Complete
2 4 Zero Tolerance
2 5-24 Off Currently not used
Table 2-3. Digital I/O Assignments
Port Type Description Setup
1 CMD Currently not used 9600 baud
8 bit
None
2
2 CMD/KEYBOARD iRev downloads/operator input 115200
8 bit
None
2
3 CMD Audit trail printer 9600 baud
8 bit
None
2
4 CMD Currently not used 9600 baud
8 bit
None
2
Table 2-4. Serial Port Setup

Setup Menu
© Rice Lake Weighing Systems ● All Rights Reserved 9
3.0 Setup Menu
This section describes the various setup parameters for the FlexWeigh System 101.
3.1 Entering the Setup Menu
The front panel E-stop button must be in the stopped position (pushed in) to enable the following keypad entries.
1. Press the Setup Menu softkey on the main menu screen and the system performs one of the following actions.
• If a system password is entered, proceed to Step 2
• If no system password is entered, the Setup Menu Main Screen displays (Figure 3-2)
2. Press the Setup Password softkey. The system prompts with Enter Password.
Figure 3-1. Setup Menu Enter Password
3. Enter the password and press the Enter key on the 920i. The system checks the entered value against the system
password and performs one of the following actions:
• If the password is valid, the Setup Menu Main Screen displays (Figure 3-2)
• If the password is invalid, Invalid password displays momentarily and display exits the operation
Figure 3-2. Setup Menu Main Screen
Note
04/27/2011 02:15PM
SCALE #1
Cancel End
Enter New Password:
136.8
SCALE #1
Gross
Lb
Home
Program: Express 101 (V 1.00)
ID #1 (disabled) Start O Zero Tol
ID #2 (disabled) Resume O Fill Copt
Dual Speed (enabled) Reset O Slow Fill
Auto Tare (enabled) Stop O Fast Fill
Auto Print (disabled)
Delay After Discharge (sec) :30
04/27/2011 02:15PM
SCALE #1
ID #1 More =>
Setup Menu:
136.8 SCALE #1
Gross
Lb
SETUP MENU
Time/Date Setup
Password
ID #2
Program: Express 101 (V 1.00)
ID #1 (disabled) Start O Zero Tol
ID #2 (disabled) Resume O Fill Copt
Dual Speed (enabled) Reset O Slow Fill
Auto Tare (enabled) Stop O Fast Fill
Auto Print (disabled)
Delay After Discharge (sec) :30

FlexWeigh System 101
10 Visit our website www.RiceLake.com
3.2 Setting the System Time and Date
Use the following steps to set up the system time and date.
1. From the Main Setup Menu Screen, press the Time/Date softkey.
Figure 3-3. Select Time/Date Softkey
2. Use the arrow keys on the 920i and the numeric keypad to modify the time and or date.
3. Press the Enter key to save the settings.
Figure 3-4. Time and Date Main Screen
The Cancel softkey can be pressed at any time to exit this sequence without saving any changes.
04/27/2011 02:15PM
SCALE #1
ID #1 More =>
Setup Menu:
136.8
SCALE #1
Gross
Lb
SETUP MENU
Time/Date Setup
Password
ID #2
Program: Express 101 (V 1.00)
ID #1 (disabled) Start O Zero Tol
ID #2 (disabled) Resume O Fill Copt
Dual Speed (enabled) Reset O Slow Fill
Auto Tare (enabled) Stop O Fast Fill
Auto Print (disabled)
Delay After Discharge (sec) :30
Cancel
03:52 PM
04/17/2012
Note

Setup Menu
© Rice Lake Weighing Systems ● All Rights Reserved 11
3.3 Modifying the Setup Password
Use the following steps to modify the setup password.
1. From the Main Setup Menu Screen, press the Setup Password softkey.
2. The system prompts, Enter New Password.
Figure 3-5. Enter New Password
3. Enter the new password and press the Enter key.
4. The system prompts Re-enter password to verify.
5. Re-enter the password and press the Enter key again. The system performs one of the following actions.
• If the passwords match, the system displays Password Changed.
• If the passwords do not match, the system displays Passwords Did Not Match and exits the operation.
04/27/2011 02:15PM
SCALE #1
Cancel End
Enter New Password:
136.8 SCALE #1
Gross
Lb
Home
Program: Express 101 (V 1.00)
ID #1 (disabled) Start O Zero Tol
ID #2 (disabled) Resume O Fill Copt
Dual Speed (enabled) Reset O Slow Fill
Auto Tare (enabled) Stop O Fast Fill
Auto Print (disabled)
Delay After Discharge (sec) :30

FlexWeigh System 101
12 Visit our website www.RiceLake.com
3.4 Enabling/Disabling Additional Data Fields
Use the following steps to enable or disable additional data fields.
1. From the Main Setup Menu Screen, press the Setup Password softkey (Figure 3-2 on page 9).
A setup password is not required if it has never been set or if you are already in Setup mode.
2. Press the ID #1 or ID #2 softkey. The system displays Enable ID #1 or ID #2 while displaying Yes or No softkeys or
Disable ID #1 or #2.
Figure 3-6. Enabling IDs
3. The operator does one of the following:
Press the Yes softkey, the system prompts Enter Extra Data #1 Name. Enter the name and press the Enter key on
the 920i. A new data field appears on the main display and as a softkey so that the operator can change it.
To enter alpha characters, press the Up navigation key to access a pop up alphabet.
Press the Yes softkey and this returns the operator back to Step 1.
3.5 Modifying the Filling Speeds
Use the following steps to modify the filling speeds.
1. From the Main Setup Menu Screen (Figure 3-7), press the Setup Password softkey (a password is not required).
2. Press the More=> softkey to access the second and third menu screens.
Figure 3-7. Setup Main Menu Screen #2
3. Press the Single Speed Enabled, Dual Speed Enabled or Parallel Speed Enabled softkey. The system will toggle
between the three modes of operation (Section 4.3 on page 20) and will display the selected filling speed.
Note
04/27/2011 02:15PM
SCALE #1
No
Enable ID #1:
=>
136.8 SCALE #1
Gross
Lb
SETUP MENU
Yes
Program: Express 101 (V 1.00)
ID #1 (disabled) Start O Zero Tol
ID #2 (disabled) Resume O Fill Copt
Dual Speed (enabled) Reset O Slow Fill
Auto Tare (enabled) Stop O Fast Fill
Auto Print (disabled)
Delay After Discharge (sec) :30
02:15PM SCALE #1
Auto Tare
Enabled
<= More
Setup Menu:
136.8 SCALE #1
Gross
Lb
SETUP MENU
More =>
Dual Speed
Enabled
Auto Print
Disabled
SETUP MENU
Program: Express 101 (V 1.00)
ID #1 (disabled) Start O Zero Tol
ID #2 (disabled) Resume O Fill Copt
Dual Speed (enabled) Reset O Slow Fill
Auto Tare (enabled) Stop O Fast Fill
Auto Print (disabled)
Delay After Discharge (sec) :30
04/27/2011

Setup Menu
© Rice Lake Weighing Systems ● All Rights Reserved 13
3.6 Modifying the Auto Tare
Use the following steps to modify the auto tare.
1. From the Main Setup Menu Screen (Figure 3-7 on page 12), press the More=> softkey to access the second setup
menu screen.
Figure 3-8. Auto Tare Softkey
2. Press the Auto Tare Enabled or Auto Tare Disabled softkey which allows the operator to enable or disable the auto
tare feature. The system will toggle between the two modes of operation.
3.7 Modifying Auto Print
Use the following steps to modify the auto print.
1. From the Main Setup Menu Screen (Figure 3-7 on page 12), press the More=> softkey to access the second setup
menu screen.
2. Press the Auto Print Enabled or Auto Print Disabled softkey. The system toggles between the two modes of operation.
Figure 3-9. Auto Print Disabled Softkey
3.8 Delay After Discharge
Use the following steps to modify the delay after discharge.
1. From the Main Setup Menu Screen (Figure 3-7 on page 12), cycle through pressing the More => softkey to access
the third setup menu screen which includes the Delay After Discharge softkey.
Figure 3-10. Delay After Discharge Softkey Location
2. Press the Delay After Discharge softkey to access that softkey.
Figure 3-11. Enter Time
3. Enter in the time in seconds to delay after completion of a discharge before a new start input will be allowed.
Auto Tare
Enabled
Auto Print
Disabled
Delay After
Discharge
04/27/2011 02:15PM
SCALE #1
CancelHome
Delay After Discharge (sec):
=> .30
136.8 SCALE #1
Gross
Lb
SETUP MENU
End
SETUP MENU
Program: Express 101 (V 1.00)
ID #1 (disabled) Start O Zero Tol
ID #2 (disabled) Resume O Fill Copt
Dual Speed (enabled) Reset O Slow Fill
Auto Tare (enabled) Stop O Fast Fill
Auto Print (disabled)
Delay After Discharge (sec) :30

FlexWeigh System 101
14 Visit our website www.RiceLake.com
3.9 Test Digital I/O
Press the Test Digital I/O softkey to test the Zero Tolerance, Fill Complete, Slow Fill and Fast Fill relay outputs.
Figure 3-12. Test Digital I/O
Zero Tolerance
Press the Zero Tolerance softkey to test the zero tolerance output. If the weight is within the preset zero tolerance, a front
panel light will indicate this as being on. It is an optional output.
Fill Complete
Press the Fill Complete softkey to test the digital I/O. A front panel light will indicate this as being on. This is an optional output.
Slow Fill
By pressing the Slow Fill softkey, the digital I/O is tested and the Slow Fill icon on the setup menu screen is darkened
while it’s being tested. Press the Slow Fill softkey again and the icon clears again.
Fast Fill
By pressing the Fast Fill softkey, the digital I/O is tested and the Fast Fill icon on the setup menu screen is darkened while
it’s being tested. Press the Fast Fill softkey again and the icon clears again.
04/27/2011 02:15PM
SCALE #1
Fast Fill Exit
Setup Menu:
136.8 SCALE #1
Gross
Lb
SETUP MENU
Fill
Complete Slow Fill
Program: Express 101 (V 1.00)
ID #1 (disabled) Start O Zero Tol
ID #2 (disabled) Resume O Fill Copt
Dual Speed (enabled) Reset O Slow Fill
Auto Tare (enabled) Stop O Fast Fill
Auto Print (disabled)
Delay After Discharge (sec) :30

Operation
© Rice Lake Weighing Systems ● All Rights Reserved 15
4.0 Operation
The section describes the basic sequence of operation for the FlexWeigh System 101.
4.1 Entering Presets Softkey Menu
The FlexWeigh System 101 has the capability to allow the operator to modify the presets/weights. See the following procedure:
The front panel E-stop button must be in the stopped position (pushed in) to enable the following keypad entries.
Figure 4-1. Presets Menu Screen
1. Press the Presets softkey. Softkeys in Figure 4-2 are displayed.
Figure 4-2. Presets Softkey Parameters
2. Press the corresponding softkey to edit the data. Parameters that can be edited include:
• Target weight
• Dribble weight
• Preact weight
• Zero tolerance weight
Note
89
Target Dribble Preact Near Zero
Consec. # Subtotal Total
200.0 Lb 75 0.0 10.0
23 1687 Lb 3468 Lb
Presets Setup
Menu
Totals
04/27/2011 10:29AM SCALE #1
SCALE
#1
Gross
Net
89
Target Dribble Preact Near Zero
Consec. # Subtotal Total
200.0 Lb 75 0.0 10.0
23 1687 Lb 3468 Lb
Dribble
Weight Exit
Target
Weight
Preact
Weight
Zero Tol
Weight
04/27/2011 10:45AM SCALE #1
SCALE
#1
Gross
Net

FlexWeigh System 101
16 Visit our website www.RiceLake.com
Target Weight
This is the desired weight value for a final fill weight. The existing number needs to first be cleared by using the Clear key.
1. Enter the target weight using the arrow keys and the numeric keypad.
2. Press Enter on the 920i to save that value.
Figure 4-3. Enter Target Weight
Dribble Weight
When a 2-speed fill is enabled (either Parallel or Sequential), this is the desired weight value below the Target Weight that the
cycle switches from Fast Feed to Dribble Feed.
1. Enter the dribble weight using the arrow keys and the numeric keypad.
2. Press Enter on the 920i to save that value.
The existing number needs to first be cleared by using the Clear key.
Figure 4-4. Enter Dribble Weight
89
Target Dribble Preact Near Zero
Consec. # Subtotal Total
200.0 Lb 75 0.0 10.0
23 1687 Lb 3468 Lb
Home Exit Cancel
Enter Target Weight
=> 25
04/27/2011 10:34AM SCALE #1
SCALE
#1
Gross
Net
Enter Target Weight
Note
89
Target Dribble Preact Near Zero
Consec. # Subtotal Total
200.0 Lb 75 0.0 10.0
23 1687 Lb 3468 Lb
Home End Cancel
Enter Dribble Weight
Enter Dribble Weight
=> 12.0
04/27/2011 10:16AM SCALE #1
SCALE
#1
Gross
Net
