1280 Enterprise Series™
Color Touchscreen Indicator
Installation Manual
PN 169668 Rev AAugust 10, 2018

An ISO 9001 registered company
© Rice Lake Weighing Systems. All rights reserved.
Rice Lake Weighing Systems®is a registered trademark of
Rice Lake Weighing Systems.
All other brand or product names within this publication are trademarks or
registered trademarks of their respective companies.
All information contained within this publication is, to the best of our knowledge, complete and
accurate at the time of publication. Rice Lake Weighing Systems reserves the right to make
changes to the technology, features, specifications and design of the equipment without notice.
The most current version of this publication, software, firmware and all other product
updates can be found on our website:
www.ricelake.com

Contents
© Rice Lake Weighing Systems ●All Rights Reserved 1
Technical training seminars are available through Rice Lake Weighing Systems.
Course descriptions and dates can be viewed at www.ricelake.com/training
or obtained by calling 715-234-9171 and asking for the training department.
1.0 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
1.1 Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
1.1.1 Other Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
1.1.2 Enclosure Types . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
1.1.3 Option Cards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
1.2 Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
2.0 Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
2.1 Unpacking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
2.2 Mounting/Assembly. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
2.2.1 Universal Mount Enclosure with Tilt Stand. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
2.2.2 Wall Mount Enclosure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
2.2.3 Panel Mount Enclosure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
2.3 Option Card Installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
2.4 Cable Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
2.4.1 Grounding Through Cord Grips . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
2.4.2 Panel Enclosure Grounding . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
2.4.3 Load Cells . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
2.4.4 Serial Communications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
2.4.5 CPU Digital I/O Wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
2.5 Wiring Schematics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
2.5.1 Key Pad Model. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
2.5.2 Touch Screen Only (Virtual Keypad) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
2.6 Configuration Methods . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
2.7 CPU Board Replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
2.7.1 Remove CPU Board from Face Plate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
2.8 Power Supply Replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
2.9 Replace Fan Plate and Back Plane . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
2.10 Replacement Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
2.11 Label Legend . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
3.0 Configuration Menu. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
3.1 Access Setup Parameters. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
3.2 Access Configuration Menu – Sealed Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
3.3 Configuration Menu. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
3.3.1 Configuration Menu Map . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
4.0 Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

1280 Series Color Touchscreen Indicator
2 Visit our website www.RiceLake.com
Rice Lake continually offers web-based video training on a growing selection
of product-related topics at no cost. Visit www.ricelake.com/webinars

Introduction
© Rice Lake Weighing Systems ●All Rights Reserved 1
1.0 Introduction
The 1280 Enterprise Series is a color touchscreen, programmable, multi-channel digital weight indicator/controller.
Manufactured with industrial-grade components, the 1280 is built to achieve top performance, even in harsh environments. The
1280 features a Freescale i.MX6 microprocessor, Linux-based operating system and 1 GB onboard memory (expandable with
micro SD card). Configuration can be performed using the front panel, serial commands or Revolution®scale software.
For applications using the 1280 indicator as a host device, Version 1.03 or later of the 1280 indicator software must be installed.
Custom programs can be written with iRite®, a domain-based programming language based off of Basic, Pascal and Ada—
empowering programmers to customize display widgets, store and retrieve data with the onboard database and utilize the 150+
built-in-functions. From tailored basic weighing to complex process automation, the 1280 delivers uncompromising speed for
today’s most demanding applications as well as vast expandability for future needs.
Manuals are available for viewing and/or downloading from the Rice Lake Weighing Systems website at
www.ricelake.com/manuals
Warranty information can be found on the website at www.ricelake.com/warranties
1.1 Features
Features of the 1280 include:
• Support for up to eight scales (combination of analog load cell, total, serial scales or program scales)
• Eight programmable Digital I/O bits available on the CPU board (connector J1) including onboard pulse input pins, with
24 additional per option card
• Two communication ports that support RS-232, RS-485 and RS-422
• Two USB host ports
• One USB device port
• AC or DC power options
• Ethernet – wired, Wi-Fi and Wi-Fi Direct
•Bluetooth
1.1.1 Other Features
• Built in Web Server for remote access to screens
• Configurable print formats can be defined for up to 1000 characters. Additional print formats can be created with iRite.
• Truck in/out, recipe batching, counting and checkweighing iRite programs and source code included.
• 100 configurable setpoints.
• The 1280 is NTEP, OIML and Measurement Canada certified. See Specifications for more information.
1.1.2 Enclosure Types
•Universal
• Panel Mount – numeric keypad
• Panel Mount – touch only (7'' and 12'' display)
•WallMount
1.1.3 Option Cards
The CPU board provides six slots for installing scale or other option cards. Available option cards include:
• Single- and dual-channel scale cards to drive up to sixteen 350 ohmload cells per card. Scale cards support both 4- and
6-wire load cell connections.
• Single- and dual-channel analog output card for 0–10 VDC, 0–20 mA or 4-20 mA tracking of gross or net weight values.
• 24-channel digital I/O expansion card
• Dual channel serial port card (with RS-232, RS-422 and RS-485)
• Dual channel analog input card for 0–100 mV, 0-10 VDC, 0–20 mA or 4-20 mA
• 4-channel relay card
• CompactCom card that supports EtherNet/IP™, DeviceNet™, ProfiNet, Profibus® DP Modbus TCP, EtherCAT and
PowerLink networks.

1280 Series Color Touchscreen Indicator
2 Visit our website www.RiceLake.com
1.2 Safety
Safety Signal Definitions:
DANGER
Indicates an imminently hazardous situation that, if not avoided, will result in death or serious injury. Includes
hazards that are exposed when guards are removed.
WARNING
Indicates a potentially hazardous situation that, if not avoided, could result in serious injury or death. Includes
hazards that are exposed when guards are removed.
CAUTION
Indicates a potentially hazardous situation that, if not avoided, could result in minor or moderate injury.
IMPORTANT
Indicates information about procedures that, if not observed, could result in damage to equipment or corruption
to and loss of data. General Safety
Do not operate or work on this equipment unless this manual has been read and all instructions are understood.
Failure to follow the instructions or heed the warnings could result in injury or death. Contact any Rice Lake
Weighing Systems dealer for replacement manuals.
Failure to heed could result in serious injury or death.
Some procedures described in this manual require work inside the indicator enclosure. These procedures are to be performed by
qualified service personnel only.
Do not allow minors (children) or inexperienced persons to operate this unit.
Do not operate without enclosure completely assembled.
Do not place fingers into slots or possible pinch points.
Do not use this product if any of the components are cracked.
Do not make alterations or modifications to the unit.
Do not remove or obscure warning labels.
Do not submerge.
Before opening the unit, ensure the power cord is disconnected from the power source.
WARNING

Installation
© Rice Lake Weighing Systems ●All Rights Reserved 3
2.0 Installation
This section describes procedures for connecting power, load cells, digital I/O and data communications cables to the 1280
indicator. Instructions for replacement of the circuit boards are also included, along with assembly drawings and replacement
parts lists for the service technician.
WARNING
Failure to heed the following statements could result in serious injury or death.
* Use a wrist strap for protection and damage to components from electrostatic discharge (ESD) when working
inside the indicator enclosure.
* Procedures requiring work inside the indicator must be performed by qualified service personnel only.
* In the wall and universal mounts, the supply cord serves as the power disconnect. The power receptacle to the
indicator must be accessible for these models.
2.1 Unpacking
Immediately after unpacking, visually inspect the 1280 to ensure all components are included and undamaged. The shipping
carton should contain the controller, display, CD, parts kit, any options ordered with the unit and the appropriate manuals. If any
parts were damaged in shipment, notify Rice Lake Weighing Systems and the shipper immediately.
2.2 Mounting/Assembly
There are three enclosure styles – universal mount, wall mount and panel mount.
2.2.1 Universal Mount Enclosure with Tilt Stand
The universal mount is shipped with a tilt stand and can be mounted on a wall, tabletop or any flat surface.
Figure 2-1. Mount Universal Enclosure
1. Using the tilt stand as a template, mark the screw locations. See Figure 2-5 on page 5 for dimensions.
The universal enclosure can mount to the same location where a 920i universal enclosure was mounted; the screw
locations for the tilt stand are the same.
Note
2. Drill holes for the screws.
3. Mount the tilt stand using the appropriate hardware (not included).
4. Place one washer on each side stud of the indicator enclosure.
5. Place the indicator side studs into the holes on the arms of the tilt stand.
6. Secure with remaining washers and hand knobs from the hardware kit.
7. Wire the indicator. See Section 2.4 on page 16.
Mark and drill holes
Use hardware to mount
Place washers on
indicator side studs
Secure with washers
and knobs

1280 Series Color Touchscreen Indicator
4 Visit our website www.RiceLake.com
Remove Shipping Bracket
The universal mount is shipped with a shipping bracket inside the enclosure to stabilize it during shipping.
1. Loosen the four screws securing the front door.
Figure 2-2. Remove Shipping Bracket
2. Pull the door and fully extend the hinge to swing the door open.
3. The bracket is loose, remove it from the enclosure.
Note
Retain shipping bracket for future shipping needs.
Controller Disassembly
Note
The controller can be tilted up with the locking tab or it can be completely removed from the enclosure by removing
the retaining wire bail.
1.Remove the large fillister screw in the back of the indicator to tilt or remove the controller. The seal must be
broken for this purpose.
Figure 2-3. Open Cover
2. Loosen the four screws securing the front door.
3. Pull the door and fully extend the hinge to swing the door open.
4. Pull the locking tab to the left to release the controller assembly.
5. Remove the wires connected to the controller assembly.
6. Remove the retaining wire bail connected to the controller assembly. This only needs to be removed if the controller is
being removed from the enclosure.
7. Lift controller assembly from the enclosure.
Reverse this procedure for reassembly. Upon reassembly, ensure display and keyboard wires are properly connected.
Note
To close the door to the universal enclosure, push the bail in and down so that it does not get caught on the
controller assembly.
Shipping
Bracket
Open Door
Loosen Four Screws
Open Door

Installation
© Rice Lake Weighing Systems ●All Rights Reserved 5
Figure 2-4. Remove CPU Assembly– Universal
Figure 2-5. Universal Tilt Stand Hole Pattern Dimensions
IMPORTANT
This illustration is not to scale and is forillustration purposes only. Usethe dimensions to mark the holes for the
universal mount, or use the bottom of the tilt stand as a template. Do not use Figure 2-5 as a template.
Sealing the Setup Switch
In certain Legal for Trade applications, it may be necessary to seal the indicator to restrict access from the setup switch. Use
the following instructions to seal the universal enclosure.
IMPORTANT
The audit trail jumper (JP1) needs to be disabled, in the off (right) position, in order to seal the setup switch with
a lead seal wire. Access is not prevented simply by sealing the setup switch.
1. Turn the audit trail jumper (JP1) to the right to turn off. See Section 2.7 on page 22 for instructions on how to remove
the CPU board (which is necessary to disable the audit trail jumper). This restricts access from the configuration menu
through the front panel.
2. If not previously installed, install the large fillister screw in the back of the indicator.
3. Wrap the lead wire seal through the large fillister screw and the two smaller fillister screws in order to seal the
indicator. This will restrict access to the setup switch.
Locking
Tab
Controller
Assembly
Retaining
Wire Bail
Hinge
Link
Base and Hole Pattern
is symmetrical about
C
L
9.24"
6.00"
5.25"
4.25"
Ø 0.34"
C
L
C
L
Ø 1.50"
10.86"

1280 Series Color Touchscreen Indicator
6 Visit our website www.RiceLake.com
Figure 2-6. Seal the Setup Switch (Universal Mount)
Sealing the Front Door
In Legal for Trade applications, it is necessary to seal the indicator to restrict access to the internal hardware of the indicator. To
seal the universal enclosure front door, wrap a lead wire seal through the large bottom right screw securing the front door and
the two small fillister screws on the bottom of the enclosure. Alternatively, the A/D scale card includes fillister screws and a
bracket that prevent the load cell cable from being disconnected.
Figure 2-7. Seal the Front Door (Universal Mount)
Small Fillister
Screws
Large Fillister
Screw
Small Fillister
Screws
Large Screw

Installation
© Rice Lake Weighing Systems ●All Rights Reserved 7
2.2.2 Wall Mount Enclosure
1. Using the wall mount as a template, mark the screw locations. See Figure 2-14 on page 10 for dimensions.
Note
The wall enclosure can mount to the same location where a 920i was mounted; the screw locations are the same.
2. Drill holes for the screws.
3. Mount using the appropriate hardware (not included).
Figure 2-8. Wall Mount
Remove Shipping Bracket
1. Loosen the four screws on the front door.
2. Swing the door open.
3. Remove the four screws securing the bracket in place.
4. Remove bracket from the enclosure.
Figure 2-9. Remove Shipping Bracket
Screws
Shipping
Bracket

1280 Series Color Touchscreen Indicator
8 Visit our website www.RiceLake.com
Controller Disassembly
Figure 2-10. Open Door
1. Loosen the four screws on the front door.
2. Swing the door open.
3. Remove the wires connected to the controller assembly.
Figure 2-11. Remove Controller Assembly - Wall Mount
4. While supporting the controller assembly, use a screwdriver to slide the mounting plate down.
5. Lift the controller assembly up to remove it from the DIN rail and pull it out of the enclosure.
Reverse this procedure for controller assembly installation.
Note
When closing the door, tighten screws to 15 in-lb to ensure the enclosure is securely sealed.
Slide Mounting
Plate Down Controller
Assembly

Installation
© Rice Lake Weighing Systems ●All Rights Reserved 9
Sealing the Setup Switch
In Legal for Trade applications, it is necessary to seal the indicator to restrict access to the setup switch. Use the following
instructions to seal the wall mount enclosure.
IMPORTANT
The audit trail jumper (JP1) needs to be disabled, in the off (right) position, in order to seal the setup switch with
a lead seal wire. Access is not prevented simply by sealing the setup switch.
1. Turn the audit trail jumper (JP1) to the right to turn off. See Section 2.7 on page 22 for instructions on how to remove
the CPU board (which is necessary to disable the audit trail jumper). This will restrict access from the configuration
menu through the front panel.
2. Wrap the lead wire seal through the large fillister screw and the bottom tab of the DIN rail clip to restrict access to the
setup switch.
Figure 2-12. Seal the Setup Switch
Sealing the Front Door
In Legal for Trade applications, it is necessary to seal the indicator to restrict access to the internal hardware of the indicator. To
seal the wall mount enclosure front door, wrap the lead wire seal through the large screw securing the front door and the hole in
the edge of the door enclosure. Alternatively, the A/D scale card includes fillister screws and a bracket that prevent the load cell
cable from being disconnected.
Figure 2-13. Seal the Front Door
Enclosure hidden for illustration purposes, controller assembly does not
need to be removed from the enclosure to seal the setup switch.
Large Fillister Screw DIN Rail Clip
Large Screw
Hole in Door
Enclosure

1280 Series Color Touchscreen Indicator
10 Visit our website www.RiceLake.com
Figure 2-14. Wall Mount Dimensions
IMPORTANT
This illustration is not to scale. It is for illustration purposes only. Use the dimensions to mark the holes for the
wall mount. Do not use Figure 2-14 as a template.
2.2.3 Panel Mount Enclosure
The panel mount will ship partially assembled. The display assembly must be removed from the backing plate to allow
installation on the existing panel.
Figure 2-15. Mark and Drill Holes for Panel
1. Tape the panel mount template to the outside of the panel.
2. Mark and drill holes according to the template.
11.00"
18.84"
19.64"
13.00"
14.20"
Ø 0.33"
18.22
"
Vertical Direction
Tape to outside of panel

Installation
© Rice Lake Weighing Systems ●All Rights Reserved 11
Panel Mount Dimensions
Figure 2-16. Panel Mount with Keypad Dimensions
Figure 2-17. 7'' Touch Only Panel Mount Dimensions
9.00"
9.00"
7.44"
7.44"
Ø 0.25"
Ø 1.00"
4.75"
Ø 0.25"
6.22" 4.66"
9.00"
7.44"
4.11"
1.00"
Ø 1.00"
0.78"
0.78"

1280 Series Color Touchscreen Indicator
12 Visit our website www.RiceLake.com
Figure 2-18. 12'' Touch Only Panel Mount Dimensions
IMPORTANT
The illustrations above are not to scale, they are for reference only. Use the dimensions to mark the holes for the
panel mount, or use the template provided with the indicator. Do not use Figure 2-16, Figure 2-17 and Figure 2-
18 as templates.
Figure 2-19. Panel Enclosure Mounting
3. Place the display assembly and the DIN rail bracket on either side of the panel. Ensure that the DIN rail bracket is
horizontal.
4. Use studs, nuts and washers to secure the display assembly to the DIN rail bracket.
10.00"
1.00"
Ø 1.00"
8.44"
14.00"
12.44"
0.78"
Ø 0.22"
5.62"
Display
Assembly
DIN Rail
Bracket

Installation
© Rice Lake Weighing Systems ●All Rights Reserved 13
Installing Grounding Bus Bar
The grounding bus bar is installed on the controller assembly for grounding purposes on the panel mount enclosure.
1. Remove the four corner screws from the controller assembly.
2. Align the bus bar to the screw holes and secure by reinstalling the screws.
Figure 2-20. Grounding Bus Bar Installation
Install Controller Assembly
The controller assembly can be mounted to a standard DIN rail.
1. Hook the bracket on the back of the controller assembly onto the DIN rail.
Note
The controller assembly can be installed up to 30 inches from the display of the panel mount enclosure.
Figure 2-21. Hook Bracket on DIN Rail
2. Push controller assembly against the DIN rail in order to engage the spring clip. The controller assembly locks onto the
DIN rail bracket.
3. Connect wiring. See Section 2.4 on page 16.
Hook bracket of the
controller assembly
on DIN rail.

1280 Series Color Touchscreen Indicator
14 Visit our website www.RiceLake.com
Removing Controller Assembly
1. Disconnect wiring.
2. Supporting the controller assembly and use a screwdriver to slide the mounting plate down.
3. Unhook the controller assembly from the DIN rail bracket.
4. Carefully remove the controller assembly from the DIN rail bracket and release the mounting plate.
Figure 2-22. Remove Controller Assembly
Seal Setup Switch
In Legal for Trade applications, it is necessary to seal the indicator to restrict access to the setup switch. Use the following
instructions to seal the panel mount enclosure.
IMPORTANT
The audit trail jumper (JP1) needs to be disabled, in the off (right) position, in order to seal the setup switch with
a lead seal wire. Access is not prevented simply by sealing the setup switch.
Wrap the lead wire seal through the large fillister screw and through the bottom tab of the DIN rail clip to restrict access to the
setup switch. Alternatively, the A/D scale card includes fillister screws and a bracket that prevent the load cell cable from being
disconnected.
Figure 2-23. Seal the Setup Switch (Panel Mount Enclosure)
Enclosure and grounding bus bar hidden for illustration purposes. Controller
Assembly does not need to be removed from the enclosure to seal the setup switch
and the grounding bus bar can remain attached, if installed.
Large Fillister Screw DIN Rail Clip

Installation
© Rice Lake Weighing Systems ●All Rights Reserved 15
2.3 Option Card Installation
Use the following instructions to install option cards. There are two SPI communication buses for the six option card slots: one
for slots 1, 2 and 3 and one for slots 4, 5 and 6. Communication is faster with less traffic on an SPI bus. For optimal
performance, populate slots 1 and 4 first in order to keep cards on their own SPI bus.
Figure 2-24. Label on Top of Controller Assembly
Note
Figure 2-25 on page 15 illustrates label location.
WARNING
Failure to heed the following statements could result in serious injury or death.
Note
* Use a wrist strap for protection and damage to components from electrostatic discharge (ESD) when working
inside the indicator enclosure.
* Procedures requiring work inside the indicator must be performed by qualified service personnel only.
* In the wall and universal mounts, the supply cord serves as the power disconnect. The power receptacle to the
indicator must be accessible for these models.
* Option cards are not hot-swappable. Disconnect power to the indicator before installing option cards.
It is recommended to remove the controller assembly from the universal enclosure for easier installation of the
option cards. See Section 2.2.1 on page 3.
1. Remove the hardware securing the slot cover plate.
2. Remove the slot cover plate.
3. Slide the option card into place.
4. Secure the card using the hardware that secured the slot cover plate.
5. Connect cables. See Section 2.4 on page 16.
Figure 2-25. Option Card Installation
Option Card
Slot Cover
Plate
Controller Label
Slot 1 on this side.
Installed Option Card

1280 Series Color Touchscreen Indicator
16 Visit our website www.RiceLake.com
Seal the Scale Card
Once an option card has been put into place and cable connections have been made, a seal can be placed over the card and
connections to restrict access and keep them from being removed.
Figure 2-26. Seal Option Card
1. Align the sealing bracket over the connectors on the option card.
2. Secure with two fillister screws.
3. Insert the lead wire seal through the holes in the sealing bracket and the fillister screws.
2.4 Cable Connections
The universal and wall enclosures provide cord grips for cabling into the indicator; one for the power cord and the rest are to
accommodate interface cables. Install plugs in unused cord grips to prevent moisture from entering the enclosure. Secure wires
after cabling is complete to avoid low voltage circuits contacting high voltage circuits.
2.4.1 Grounding Through Cord Grips
To ground cables to the universal or wall enclosures, route the cable through one of the metal cord grips. Ensure the exposed
shielding makes contact with the tabs of the grounding washer inside the cord grip.
Figure 2-27. Universal and Wall Enclosure Grounding
Note
Ensure contact between the exposed shielding and the tabs of the grounding washer.
Grounding
Washer
