Ricoh D127 Quick start guide

Model S-C5
Machine Code: D127/D128
Field Service Manual
24 February, 2012

Important Safety Notices
Prevention of Physical Injury
1. Be sure that the power cord is unplugged before disassembling or assembling parts of the copier or
peripherals.
2. The wall outlet should be near the copier and easily accessible.
3. Note that electrical voltage is supplied to some components of the copier and the paper tray unit
even while the main power switch is off.
4. If any adjustment or operation check has to be made with exterior covers off or open while the
main switch is turned on, keep hands away from electrified or mechanically driven components.
5. If you start a job before the copier completes the warm-up or initializing period, keep hands away
from the mechanical and electrical components until job execution has started. The copier will start
making copies as soon as warm-up or initialization is finished.
6. The inside and the metal parts of the fusing unit become extremely hot while the copier is operating.
Be careful to avoid touching those components with your bare hands.
Health Safety Conditions
Toner and developer are nontoxic, but getting either of these into your eyes may cause temporary eye
discomfort. Try to remove with eye drops or flush with water. If material remains in eye or if discomfort
continues, get medical attention.
Observance of Electrical Safety Standards
The copier and its peripherals must be installed and maintained by a customer service representative
who has completed the training course on those relevant models.
• Keep the machine away from flammable liquids, gases, and aerosols. A fire or an explosion might
occur if this precaution is not observed.
Lithium Batteries
Incorrect replacement of lithium battery(s) on the FCU, controller board and memory board unit may
pose risk of explosion. Replace only with the same type or with an equivalent type recommended by the
manufacturer. Discard used batteries in accordance with the manufacturer's instructions.
1

Safe and Ecological Disposal
1. Do not incinerate toner bottles or used toner. Toner dust may ignite suddenly if exposed to an open
flame.
2. Dispose of used toner, developer, and organic photoconductors in accordance with local
regulations. (These are nontoxic supplies.)
3. Dispose of replaced parts in accordance with local regulations.
4. When keeping used lithium batteries in order to dispose of them later, do not put more than 100
batteries per sealed box. Storing larger numbers or not sealing them apart may lead to chemical
reactions and heat build-up.
Laser Safety
The Center for Devices and Radiological Health (CDRH) prohibits the repair of laser-based optical units
in the field. The optical housing unit can only be repaired in a factory or at a location with the requisite
equipment. The laser subsystem is replaceable in the field by a qualified Customer Engineer. The laser
chassis is not repairable in the field. Customer engineers are therefore directed to return all chassis and
laser subsystems to the factory or service depot when replacement of the optical subsystem is required.
• Use of controls not specified in this manual, or performance of adjustments or procedures not
specified in this manual, may result in hazardous radiation exposure.
•Do not use the cleaner to suck spilled toner (including used toner). Sucked toner may cause firing
or explosion due to electrical contact flickering inside the cleaner. However, it is possible to use the
cleaner designed for dust explosion-proof purpose. If toner is spilled over the floor, sweep up
spilled toner slowly and clean remainder with wet cloth.
WARNING FOR LASER UNIT
2

• Turn off the main switch before attempting any of the procedures in the Laser Unit section. Laser
beams can seriously damage your eyes.
CAUTION MARKING:
3

Symbols and Abbreviations
This manual uses several symbols and abbreviations. The meaning of those symbols and abbreviations is
as follows:
See or Refer to
Clip ring
E-ring
Screw
Connector
Clamp
SEF Short Edge Feed
LEF Long Edge Feed
- Core Technology manual
Cautions, Notes, etc.
The following headings provide special information:
• Failure to obey warning information could result in serious injury or death.
• Obey these guidelines to ensure safe operation and prevent minor injuries.
• This information provides tips and advice about how to best service the machine.
4

TABLE OF CONTENTS
Important Safety Notices...................................................................................................................................1
Prevention of Physical Injury..........................................................................................................................1
Health Safety Conditions...............................................................................................................................1
Observance of Electrical Safety Standards.................................................................................................1
Lithium Batteries..............................................................................................................................................1
Safe and Ecological Disposal.......................................................................................................................2
Laser Safety.....................................................................................................................................................2
Symbols and Abbreviations...............................................................................................................................4
1. Product Information
Specifications....................................................................................................................................................13
Machine Configuration....................................................................................................................................14
Mainframe....................................................................................................................................................14
System Components....................................................................................................................................15
Overview..........................................................................................................................................................17
Component Layout.......................................................................................................................................17
Mainframe...........................................................................................................................................17
ARDF....................................................................................................................................................18
Electrical Components.................................................................................................................................19
Electrical Components 1.....................................................................................................................19
Electrical Components 2.....................................................................................................................20
ARDF....................................................................................................................................................21
Paper Path....................................................................................................................................................22
Drive Layout..................................................................................................................................................23
Mainframe...........................................................................................................................................23
ARDF....................................................................................................................................................24
Guidance for Those Who are Familiar with Predecessor Products..............................................................25
2. Installation
Installation Cautions.........................................................................................................................................27
Installation Requirements.................................................................................................................................28
Environment..................................................................................................................................................28
Machine Level..............................................................................................................................................29
Minimum Operational Space Requirements.............................................................................................29
Power Requirements....................................................................................................................................30
5

Copier...............................................................................................................................................................31
Accessory Check..........................................................................................................................................31
Printer/Scanner (D127)/ Scanner and Fax Model (D128)..........................................................31
Installation Procedure.........................................................................................................................31
Interface settings .................................................................................................................................35
Copier settings ....................................................................................................................................35
Fax Settings..........................................................................................................................................36
Optional Handset........................................................................................................................................36
Accessory Check.................................................................................................................................36
Installation Procedure.........................................................................................................................37
Paper Tray Unit (D661)...................................................................................................................................39
Accessory Check..........................................................................................................................................39
Installation Procedure..................................................................................................................................39
Paper Tray Unit Heater....................................................................................................................................42
Accessory Check..........................................................................................................................................42
Installation Procedure (For one of PTU installed machine).......................................................................43
Installation Procedure (For two of PTU installed machine).......................................................................49
Joint bracket (Joint the copier and the upper PTU)....................................................................................56
Joint bracket (Joint the upper and the lower PTU).....................................................................................57
Controller Options............................................................................................................................................58
Overview......................................................................................................................................................58
Wireless LAN (IEEE 802.11a/g) Installation...........................................................................................58
Accessories..........................................................................................................................................58
Installation Procedure.........................................................................................................................59
SP Mode Settings for IEEE 802.11a/g Wireless LAN....................................................................60
IEEE 1284 Installation.................................................................................................................................60
Accessories..........................................................................................................................................60
Installation Procedure.........................................................................................................................61
VM Card Type S (D656)............................................................................................................................61
Accessories..........................................................................................................................................61
Installation............................................................................................................................................62
Gigabit Ethernet...........................................................................................................................................62
Fax Option (D655)......................................................................................................................................63
6

Component Check..............................................................................................................................64
Installation Procedure.........................................................................................................................65
Grounding Wire..................................................................................................................................66
HDD Option (D659)...................................................................................................................................66
Component Check..............................................................................................................................66
Installation Procedure.........................................................................................................................67
Installing the Security Card.................................................................................................................69
Activating the Security Applications..................................................................................................70
HDD Encryption Recovery from a Device Problem..........................................................................70
Restoring the Encryption key..............................................................................................................71
Clearing the NVRAM..........................................................................................................................71
3. Preventive Maintenance
Maintenance Tables........................................................................................................................................73
How to Clear the PM Counter.........................................................................................................................74
4. Replacement and Adjustment
Precautions........................................................................................................................................................75
General.........................................................................................................................................................75
Lithium Batteries............................................................................................................................................75
Halogen-free Cable....................................................................................................................................75
Static Electricity............................................................................................................................................76
Special Tools and Lubricants...........................................................................................................................77
Exterior Covers and Operation Panel............................................................................................................78
Rear Cover...................................................................................................................................................78
Copy Tray.....................................................................................................................................................78
Operation Panel...........................................................................................................................................79
Right Door.....................................................................................................................................................81
Bypass Tray..................................................................................................................................................81
Platen Cover and ARDF Sensor..................................................................................................................82
Scanner Unit.....................................................................................................................................................83
Scanner Cover and Exposure Glass..........................................................................................................83
LED Unit........................................................................................................................................................83
Scanner Motor.............................................................................................................................................84
Scanner HP Sensor......................................................................................................................................85
7

Fusing................................................................................................................................................................86
Fusing Unit....................................................................................................................................................86
Exit Sensor....................................................................................................................................................87
Hot Roller Stripper Pawls.............................................................................................................................87
Hot Roller and Fusing Lamp........................................................................................................................88
Thermoswitches and Thermistor..................................................................................................................90
Pressure Roller..............................................................................................................................................91
Fusing NIP Band Check By-pass (Checking the NIP band).....................................................................92
PCU and Quenching Lamp..............................................................................................................................93
PCU...............................................................................................................................................................93
Quenching Lamp..........................................................................................................................................94
Exhaust Fan and Main Motor.........................................................................................................................95
Exhaust Fan..................................................................................................................................................95
Main Motor..................................................................................................................................................95
Paper Feed........................................................................................................................................................97
Paper Feed Roller and Friction Pad............................................................................................................97
Paper End Sensor.........................................................................................................................................98
Registration Sensor......................................................................................................................................98
Bypass Paper End Sensor............................................................................................................................99
Bypass Feed Roller....................................................................................................................................100
Bypass Feed Clutch and Friction Pad......................................................................................................101
Paper Feed and Registration Clutches.....................................................................................................102
Image Transfer...............................................................................................................................................103
Transfer Roller............................................................................................................................................103
ID Sensor and Duplex Roller....................................................................................................................104
Discharge plate.........................................................................................................................................106
BICU and Controller Board..........................................................................................................................107
BICU...........................................................................................................................................................107
Preparation........................................................................................................................................107
Procedure..........................................................................................................................................107
Controller Board........................................................................................................................................108
Preparation:.......................................................................................................................................108
Procedure..........................................................................................................................................108
8

When installing a new controller board.........................................................................................110
When replacing the NVRAM on the controller board..................................................................111
Other Replacements......................................................................................................................................113
Duplex Motor............................................................................................................................................113
High-Voltage Power Supply Board ........................................................................................................114
PSU.............................................................................................................................................................115
Contact-Release Solenoid........................................................................................................................116
Toner Supply Motor..................................................................................................................................116
FCU.............................................................................................................................................................117
Lithium Batteries.................................................................................................................................117
Procedure..........................................................................................................................................117
Laser Unit........................................................................................................................................................119
Location of the Caution Decal..................................................................................................................119
Laser Unit....................................................................................................................................................120
LD Unit and Polygon Mirror Motor..........................................................................................................121
ARDF...............................................................................................................................................................122
ARDF Unit...................................................................................................................................................122
When installing the ARDF................................................................................................................123
ARDF Rear Cover......................................................................................................................................124
Original Feed Unit.....................................................................................................................................124
Pick-up Roller.............................................................................................................................................125
Feed Roller.................................................................................................................................................125
Friction Pad................................................................................................................................................127
DFRB...........................................................................................................................................................128
ARDF Top Cover Sensor/ Original Set Sensor......................................................................................128
ARDF Drive Motor.....................................................................................................................................128
White Plate.................................................................................................................................................131
When installing the white plate.......................................................................................................132
Registration Sensor....................................................................................................................................132
Adjusting Copy Image Area.........................................................................................................................134
Printing........................................................................................................................................................134
Adjusting Registration.......................................................................................................................134
Adjusting Blank Margin....................................................................................................................135
9

Adjusting Main-Scan Magnification...............................................................................................136
Scanning....................................................................................................................................................136
Adjusting Registration.......................................................................................................................137
Adjusting Magnification...................................................................................................................138
DF Image Adjustment................................................................................................................................138
5. System Maintenance Reference
Service Program.............................................................................................................................................141
SP Tables....................................................................................................................................................141
Using SP and SSP Modes.........................................................................................................................141
Starting SP Mode..............................................................................................................................142
Selecting Programs...........................................................................................................................142
Specifying Values.............................................................................................................................142
Activating Copy Mode.....................................................................................................................142
Quitting Programs/Ending (S) SP Mode........................................................................................142
Conventions used in the tables:.......................................................................................................142
Using SP Mode..............................................................................................................................................144
NVRAM Data Upload/Download..........................................................................................................144
Uploading Content of NVRAM to an SD card...............................................................................144
Downloading an SD Card to NVRAM...........................................................................................144
Firmware Update Procedure....................................................................................................................145
Before You Begin…...........................................................................................................................145
Firmware Update Procedure...........................................................................................................146
Error Messages.................................................................................................................................147
Firmware Update Error.....................................................................................................................147
Recovery after Power Loss...............................................................................................................148
Browser Unit Update Procedure..............................................................................................................148
Handling Firmware Update Errors...........................................................................................................149
Error Message Table........................................................................................................................149
Test Pattern Print (SP2-109-001).............................................................................................................150
Executing Test Pattern Printing.........................................................................................................150
Test Patterns.......................................................................................................................................151
Memory Clear...........................................................................................................................................152
Exceptions.........................................................................................................................................152
10

Memory Clear Procedure................................................................................................................153
SMC Print (SP5-990)................................................................................................................................153
ID Sensor Error Analysis (SP2-220)........................................................................................................153
Fax Service Tables.........................................................................................................................................155
6. Troubleshooting
SC Tables.......................................................................................................................................................157
Summary....................................................................................................................................................157
Engine SC Code Descriptions..................................................................................................................158
SC Code Descriptions...............................................................................................................................169
SC6xx................................................................................................................................................169
SC8xx................................................................................................................................................172
SC9xx................................................................................................................................................187
Electrical Component Defects.......................................................................................................................190
Sensor/Switch...........................................................................................................................................190
Blown Fuse Conditions..............................................................................................................................191
Card Save Function.......................................................................................................................................192
Overview....................................................................................................................................................192
Card Save:........................................................................................................................................192
Procedure...................................................................................................................................................192
Error Messages.................................................................................................................................194
Fax Troubleshooting Guide..........................................................................................................................195
7. Energy Saving
Energy Save...................................................................................................................................................197
Energy Saver Modes................................................................................................................................197
Timer Settings....................................................................................................................................197
Recommendation..............................................................................................................................198
Energy Save Effectiveness........................................................................................................................198
Paper Save.....................................................................................................................................................200
Effectiveness of Duplex/Combine Function............................................................................................200
1. Duplex:..........................................................................................................................................200
2. Combine mode:............................................................................................................................200
3. Duplex + Combine:......................................................................................................................200
Recommendation..............................................................................................................................201
11

Model S-C5......................................................................................................................................201
12

1. Product Information
Specifications
See "Appendices" for the following information:
• General Specifications
• Supported Paper Sizes
13

Machine Configuration
Mainframe
Standard Component Machine Code Remarks
1 Copier [A] D127/D128 -
2 ARDF [C] D606 Standard expect for EU
Option for EU
3 Platen Cover D607 Standard for EU
4 Fax Unit [D] D655 Standard only for D128
Option only for D127
Optional Components Machine Code Remarks
5 500-sheet Paper Feed Unit [B] D661 Two units can be added at
maximum.
1. Product Information
14

6 Handset [F] D645 NA only
System Components
Item Machine Code Remarks
Controller Box - [A] Standard
Printer/Scanner unit D468 [B] SD card for the Printer/Scanner Unit
Standard
FAX Option D655 [F]
FAX Connection Unit D660 [B]
Browser Unit D656 [B]
VM Card D656 [C] In SD slot 2 (lower)
Net Ware D659 [C] SD Card for Net Ware printing Type 1
Machine Configuration
15

IEEE 1284 B679 [D]
One from the two
Gigabit Ethernet Board G874 [D]
HDD D659 [E]
Optional HDD with Interface board
Merge the Security Card into the Printer/
Scanner SD card.
1. Product Information
16

Overview
Component Layout
Mainframe
1. Exposure Glass 17. Bypass Tray
2. LED Unit 18. Bypass Paper End Sensor
3. Platen Cover Sensor 19. Bypass Friction Pad
4. Exit Roller 20. Registration Roller
5. Hot Roller 21. Registration Sensor
6. Exit Sensor 22. (Main) Friction Pad
7. Pressure Roller 23. Paper Feed Roller
Overview
17

8. Scanner Motor 24. Paper End Sensor
9. Cleaning Web Roller 25. TD (Toner Density) Sensor
10. Toner Collection Coil 26. Bottom Plate
11. Cleaning Blade 27. Polygon Mirror Motor
12. OPC drum 28. Laser Unit
13. Discharge Plate 29. Mixing Augers
14. Transfer Roller 30. Development Roller
15. ID (Image Density) Sensor 31. Toner Supply Bottle
16. Bypass Paper Feed Roller 32. Scanner HP Sensor
ARDF
1. Pull-out Roller 10. Registration Roller
2. Feed Roller 11. Registration Sensor
3. Friction Pad 12. Scanner Guide
4. Paper Stopper 13. ARDF drive motor
5. Pick-up Roller 14. Exit Roller
6. Original Set Feeler 15. Junction Gate
7. Original Set Sensor 16. Inverter Roller
8. Upper Cover Sensor 17. Platen Sheet
9. Original Set Tray
1. Product Information
18
