Ricoh FACSIMILE FAX77 Quick start guide

RICOH
FACSIMILE
RICOH FAX77/80/85
FIELD SERVICE MANUAL

CONTENTS
SECTION 1. INSTALLATION
1-1. Specifications . . . . . . . . . . . 1-1
1-2. Features . . . . . . . . . . . . . . 1-4
1-3. Installation Requirements . . . . . . 1-13
1-3-1. Environment . . . . . . . . . . . 1-13
1-3-2. Minimum Space Requirements . . . . 1-14
1-3-3. Power Requirements . . . . . . . . 1-15
1-4. Accessory Check List . . . . . . . . 1-16
1-5. Installation Procedure . . . . . . . . 1-17
1-6. Initial Programming . . . . . . . . . 1-19
1. Date and Time - Function 50 . . . . . . 1-19
2. Telephone Line Type - Function 81 . . . . 1-19
3. RTI, TTl, and CSI - Functions 63, 64, and 65 1-20
4. Polling ID Code - Function 62 . . . . . . 1-22
5. Fax Terminal’s Telephone Number -
Function 80 . . . . . . . . . . . . . 1-23
6. Password - Function 84 . . . . . . . . 1-23
SECTION 2. PROGRAMMING, TESTING,
AND PRINTING REPORTS
2-1. Operation Panel . . . . . . . . . . . 2-1
2-2. User Level Programming . . . . . . . 2-5
1. Function List . . . . . . . . . . . . . 2-5
2. Others . . . . . . . . . . . . . . . 2-10
1. Keystroke Programs . . . . . . . . . 2-10
2. Voice Message (FAX80/85 only) . . . . 2-10
2-3. Service Level Functions . . . . . . . . 2-12
1. Function List . . . . . . . . . . . . . 2-12
2. Entering and Exiting Service Mode . . . . 2-14
3. Dedicated Transmission Parameters -
Function 60 . . . . . . . . . . . . . 2-15
4. Printing All Memory Files - Function 75 . . . 2-18
5. Bit Switch Programming - Function 90 . . . 2-18
6. RAM Data Display and Rewrite - Function 91 2-19
7. Printing the System Report - Function 92 . . 2-20
8. RAM Printout - Function 93 . . . . . . . 2-20
9. Displaying Error Codes and Printing the
Service Report - Function 94 . . . . . . . 2-21
10. Programming the Serial Number -
Function 95 . . . . . . . . . . . . . 2-21
11. Programming the Thermal Head Size and
Pulse Width - Function 97 . . . . . . . 2-22
12. Programming the NCU Parameters -
Function 98 . . . . . . . . . . . . . 2-22

2-4. Test Mode . . . . . . . . . . . . . 2-23
1. Entering and Exiting Test Mode . . . . . 2-23
2. ADF Mechanism Test . . . . . . . . . 2-24
3. DTMF Tone Test . . . . . . . . . . . 2-24
4. Xenon Lamp Lighting . . . . . . . . . 2-25
5. Operation Panel Test . . . . . . . . . 2-26
6. Modem Test . . . . . . . . . . . . 2-26
7. Buzzer Test . . . . . . . . . . . . . 2-28
8. Sensor Initialization . . . . . . . . . . 2-28
9. Printer Tests . . . . . . . . . . . . 2-29
10. Line Condition Check . . . . . . . . 2-29
11. Back to Back Test . . . . . . . . . . 2-30
2-5. Bit Switches . . . . . . . . . . . . 2-31
1. Factory Settings . . . . . . . . . . . 2-31
2. Bit Switch Tables . . . . . . . . . . . 2-35
2-6. NCU Parameters . . . . . . . . 2-67
2-7. Useful RAM Addresses . . . . . . .
2-69
SECTION 3. REMOVAL AND ADJUSTMENT
3-1. Covers . . . . . . . . . . . 3-1
3-1-1. Top Cover . . . . . . . . . . . . 3-1
3-1-2. Front Cover . . . . . . . . . . . 3-2
3-1-3. Rear Cover . . . . . . . . . . . 3-2
3-2. Scanner . . . . . . . . . . . . . . 3-3
3-2-1. ADF Clutch . . . . . . . . . . . 3-3
3-2-2. Pick-up and Feed Rollers . . . . . . 3-4
3-2-3. Separation Roller . . . . . . . . . 3-5
- Separation Pressure Adjustment - . . . 3-7
3-2-4. Tx Motor . . . . . . . . . . . . 3-8
- Timing Belt Tension Adjustments - . . . 3-9
3-2-5. Xenon Lamp . . . . . . . . . . . 3-10
3-2-6. Xenon Lamp Driver . . . . . . . . . 3-12
3-2-7. SBU . . . . . . . . . . . . . . . 3-12
- Adjustments - . . . . . . . . . . . . 3-13
3-3. Printer . . . . . . . . . . . . . . . 3-20
3-3-1. Rx Motor . . . . . . . . . . . . . 3-20
- Timing Belt Tension Adjustment - . . . . 3-21
3-3-2. Thermal Head . . . . . . . . . . . 3-22
3-3-3. Cutter . . . . . . . . . . . . . . 3-24
3-4. PCBs . . . . . . . . . . . . . . . 3-25
3-4-1. FCU . . . . . . . . . . . . . . . 3-25
3-4-2. Modem . . . . . . . . . . . . . 3-26
3-4-3. Memory (FAX85 only) . . . . . . . . 3-26
3-4-4. SRAM Board . . . . . . . . . . . 3-27
3-4-5. PSU . . . . . . . . . . . . . . . 3-28
3-4-6. NCU . . . . . . . . . . . . . . 3-28
3-4-7. Operation Panel . . . . . . . . . . 3-29
SECTION 4. SERVICE TABLES
4-1. Test Points . . . . . . . . . . . . . 4-1
1. NCU . . . . . . . . . . . . . . . . 4-1
1. FCU . . . . . . . . . . . . . . . . 4-1
2. NCU . . . . . . . . . . . . . . . . 4-1
4-4. Jumpers . . . . . . . . . . . . 4-2
1. NCU . . . . . . . . . . . . . . . 4-2
4-5. Special Tools and Lubricants . . . . 4-4

SECTION 5. TROUBLESHOOTING
5-1. QuaIity Checks . . . . . . . . . . . 5-1
1. Copy Quality . . . . . . . . . . . . 5-1
1. Copy Density . . . . . . . . . . . 5-2
2. Skew . . . . . . . . . . . . . . 5-2
3. Intelligibility . . . . . . . . . . . . 5-2
4. Copy Test . . . . . . . . . . . . 5-2
2. Operation Panel Display . . . . . . . . 5-3
3. Sensor Initialization . . . . . . . . . . 5-3
4. Mechanism Test . . . . . . . . . . . 5-3
5. Communication Tests . . . . . . . . . 5-3
5-2. Copy Quality Troubleshooting . . . . . 5-4
1. Received Copies . . . . . . . . . . . 5-4
2. Copies made in Copy Mode . . . . . . 5-4
3. Effects of line problems on copy quality . . 5-6
5-3. Machine Operation . . . . . . . . . 5-7
1. ADF/Scanner . . . . . . . . . . . . 5-7
2. Printer . . . . . . . . . . . . . . 5-10
5-4. Error Codes . . . . . . . . . . . . 5-14
5-5. Defective Sensor Table . . . . . . . . 5-25
5-6. Timing Charts . . . . . . . . . . . 5-26
1. Scanner . . . . . . . . . . . . . . 5-26
2. Printer . . . . . . . . . . . . . . . 5-27
SECTION 6. RICOH MEMORY OPTION
TYPE 85
7-1. Point-to-point Diagram . . . . . . . . 7-1
7-2. Signal Tables . . . . . . . . . . . . 7-2
1. FCU . . . . . . . . . . . . . . . . 7-2
2. SRAM . . . . . . . . . . . . . . . 7-6
3. SBU . . . . . . . . . . . . . . . . 7-6
4. NCU . . . . . . . . . . . . . . . . 7-7
6. Xenon Lamp Driver . . . . . . . . . . 7-8
7. PSU . . . . . . . . . . . . . . . . 7-8
7-3. Block Diagrams . . . . . . . . . . . 7-9
1. Overall Machine Control . . . . . . . . 7-9
2. Video Data Path . . . . . . . . . . . 7-10
3. Power Distribution . . . . . . . . . . . 7-13
4. Scanner Drive . . . . . . . . . . . . 7-14
5. Printer Drive . . . . . . . . . . . . . 7-15
7-4. Electrical Component Layout . . . . . . 7-16
Appendix A. Glossary
6-1. Installation Procedure . . . . . . . . 6-1
1. Preparation . . . . . . . . . . . . . 6-1
2. Installing the Memory . . . . . . . . . 6-1

SECTION 1
INSTALLATION

SECTION 1. INSTALLATION
1-1. Specifications . . . . . . . . . . . 1-1
1-2. Features . . . . . . . . . . . . . . 1-4
1-3. Installation Requirements . . . . . . 1-13
1-3-1. Environment . . . . . . . . . . . 1-13
1-3-2. Minimum Space Requirements . . . . 1-14
1-3-3. Power Requirements . . . . . . . . 1-15
1-4. Accessory Check List . . . . . . . . 1-16
1-5. Installation Procedure . . . . . . . . 1-17
1-6. Initial Programming . . . . . . . . . 1-19
1. Date and Time - Function 50 . . . . . . 1-19
2. Telephone Line Type - Function 81 . . . . 1-19
3. RTI, TTl, and CSI - Functions 63, 64, and 65 1-20
4. Polling ID Code - Function 62 . . . . . . 1-22
5. Fax Terminal’s Telephone Number -
Function 80 . . . . . . . . . . . . . 1-23
6. Password - Function 84 . . . . . . . . 1-23

1-1. Specifications
Type Desktop transceiver
Circuit
PSTN, PABX
Connection Direct couple
Document size Length: 105 - 600 mm
[4.13 - 23.6 ins]
Up to 14 m [46 ft] after bit switch adjustment
Width: 148 - 216 mm
[5.8 - 8.5 ins]
Thickness: 0.05 to 0.15 mm
[2 to 6 mils]
Document feed Automatic feed, face down
ADF capacity 30 (using 55 kg paper)
Scanning method Flat bed, with CCD
Maximum scan width
216 +/- 1 mm [8.5 +/- 0.04 ins]
Scan resolution
Main scan: 8 dots/mm [203 dpi]
Sub scan: Standard - 3.85 lines/mm [98 lpi]
Detail - 7.7 lines/mm [196 lpi]
Fine - 15.4 lines/mm [392 lpi]
1-1

Memory capacity
Compression
Modulation
Protocol
Data rate
Transmission time
Printing system
Paper size
Maximum printout width
ECM: FAX77 - Nothing
FAX80/85 - 128 kbytes (double buffer)
SAF: FAX77 - Nothing
FAX80 - 128 kbytes, shared with ECM
FAX85 - 0.5 Mbyte
(Optional: FAX85 - extra 0.5 M SAF)
FAX77 - MH, MR
FAX80/85 - MH, MR, EFC, MMR (only for storage in SAF memory)
V.29, V.27ter, V.21, AM-PM-VSB, QAM
Groups 2 and 3; autocompatibility
Group 3 with ECM also available (FAX80/85 only)
9600/7200/4800/2400 bps; automatic fallback
FAX77 - 20 s (G3 standard)
FAX80 -14 s (G3 ECM)
FAX85 - 13 s (G3 ECM with memory)
for a CCITT #1 test document (Slerex letter) using standard resolution
Thermal printing, automatic cutter
216 mm (A4) x 100 m
[8.5 ins x 328 ft]
210 mm [8.3 ins]
1-2

Maximum printer resolution Main scan - 8 dots/mm [203 lpi]
Power supply
Power consumption (W)
(excluding options)
Operating environment
Dimensions (W x D x H)
Weight
50% black chart
23 +/- 5 W
51 +/- 5 W
56 +/- 5 W
140 +/- 7 W
Sub scan - 15.4 lines/mm [392 lpi]
220 - 240V; 50 Hz
CCITT #1 chart
Standby: 23 +/- 5 W
Transmit:
40 +/- 5 W
Receive:
37 +/- 5 W
Copying:
48 +/- 7 W
Temperature: 17 - 28 degC
[63 - 82 degF]
Humidity: 30 - 85 %Rh
325 x 388 x 174 (mm)
12.8 x 15.3 x 6.9 (inches)
Excluding trays, sub document table, and options
9 kg [20 Ibs]
1-3

1-2. Features
Equipment Machine Default
FAX77 FAX80 FAX85
FAX77 FAX80 FAX85
Built-in handset
x x x
Connection for external tel.
o o o
Telephone set
x x x KEY
Cabinet x x x o = Used
ADF (capacity using 55 kg paper)
30 30 30 x = Not used
Manual feed for thick originals
o o o
Monitor speaker
o o o
Microphone
xo o
Speakerphone
x x x
Stamp x x x
Remaining memory indicator
x x o
Cutter o o o
Answering machine connection
x x x
Two printer rolls x x x
1-4

Video Processing Features Machine
Default
FAX77 FAX80 FAX85 FAX77 FAX80 FAX85
Contrast (Light, Normal, Dark)
o o o
Resolution (Std, Dtl, Fine)
ooo
Halftone
o o o
MTF (selectable by service)
o o o On On On
Reduction
x x x
Smoothing - 8 x 3.85 to 8 x 7.7
o o o
- 8 x 7.7 to 8 x 15.4
o o o Not used in W. Germany
Note: 8 x 7.7 to 8 x 15.4 smoothing is only done if the tx side scanned in 8 x 15.4 resolution and in-
formed this in the set-up protocol.
Communication Features - Auto Machine
Default
FAX77 FAX80 FAX85 FAX77 FAX80 FAX85
Scanning while receiving
xxx
Redialling - basic transmission o o o Two redials
- memory mode
xo o Four redials
G2, G3 compatibility
ooo
Automatic fallback
o o o
Confidential reception
xxo Not used in W. Germany
Substitute reception
xoo
Not used in W. Germany
Page retransmission
xo o
1-5

Communication Features -
Machine Default
User Selectable
FAX77 FAX80 FAX85 FAX77 FAX80 FAX85
Auto/Manual reception
o o o
Auto Auto Auto
Auto dialling (pulse or DTMF)
o o o
On hook dial x x x
Speed Dial 30
100 100
Quick Dial Keys
15
30 30
Keystroke programs (See Note 1) 15
30 30
Groups 7 7 7
- max no of addresses/group 100 100 100
- max no of full tel nos in all groups
10 10 10
Alternative destination o o o
Department code o o o
Batch numbering o o o
Turnaround polling o o o
Immediate redial (last 10 numbers)
ooo
Auto-answer delay time xx x
Hold x x x
Voice Request
ooo
ECM xoo - On On
Automatic Voice Message
xoo
1-6

Communication Features -
Machine Default
Service Selectable FAX77 FAX80 FAX85 FAX77 FAX80 FAX85
Page retransmission
xoo
Closed network
oo o
Off Off
Off
MV1200 compatibility
xoo -
Off
Off
Short preamble
ooo
Off Off
Off
Well log (tx and rx)
ooo -
Tx - No Rx - Yes
Protection against bad connections
oooxx x
EFC
xoo -o o
(W. Ger = X)
PSTN access through PBX
oo o xxx
Polling ID code security
xx x
EFC disabling option
xxx
Auto-reduction override option
xx x
Resol’n stepdown override option (W. Germany) o
oo
On On On
Conf’l password override option
xxo
Not used in W. Germany
Special Communication Functions
Machine Default
FAX77 FAX80 FAX85 FAX77 FAX80 FAX85
Transmission from memory
xo o
- immediate
xo o
- send later
xxo
- max no of addresses/file
- 1
100
- max no of files
- 1 100
- max no of addresses over all files
- 1
300
See Note 2 (p. 1-12).
Send Later (one message stored in ADF)
ooo
1-7

Special Communication Features Machine
Default
(Continued) FAX77 FAX80 FAX85 FAX77 FAX80 FAX85
Confidential Transmission
ooo Not used in W. Germany
- immediate
oo o
- send later
xx x
- broadcasting
x x x
- remote password override
oo o
Transfer Request
o o o Not used in W. Germany
- max no of broadcasters
1 1
1
- max no of end receivers
30 30 30
- time designatable
xx x
Action as a Transfer Broadcaster
x x x
Polling Transmission
o o o
- free/secured option
oo o
- stored ID override
o o o
- from memory
xx x
Polling Reception
ooo
- free/secured option
o o o
- stored ID override
o o o
- poll later: max no of files
8 8
8
: max addresses/file
100 100 100
: max addresses overall
300 300 300
See Note 2 (p 1-12).
Batch transmission
x x x
Forwarding
xxo
Authorized reception
ooo
Notify
xxx

Other Features
Machine
Default
FAX77 FAX80
FAX85
FAX77 FAX80 FAX85
Multicopy: max 9 copies/original
x x o- -x
Copy mode
o o o
Printing out a memory file
x x o
Reports - Automatic
Machine Default
FAX77 FAX80 FAX85 FAX77 FAX80 FAX85
Jorrnal (optional)
oo o
On On On
Transmission Report (optional)
o o o
On On On
(Off in Asia)
Error Report (optioal) o o o On On On
Transfer Result Report
o o o
Polling FiIe List (optional)
o o o
On On On
New File Report (optional)
x x o - -
On
Power Failure Report
xo o
Memory Trans Report (optional)
xoo -
On On
Telephone List (after programming)
xxx
1-9

Reports - User Machine Default
FAX77 FAX80 FAX85 FAX77 FAX80 FAX85
Journal
o o o
Telephone List (includes Group List)
o o o
Polling File List
ooo
SAF File List
x x o
Authorized Reception List
o o o
Program List
o o o
Reports - Service
Machine Default
FAX77 FAX80 FAX85 FAX77 FAX80 FAX85
Auto Service Call x x x
System Report o o o
Memory Dump
o o o
Servie Report ooo
1-10

Programming - User Machine Default
FAX77 FAX80 FAX85 FAX77 FAX80 FAX85
Clock
oo o
Auto/Manual Receive setting
ooo
Auto Auto Auto
Tx/Rx page, sheet feed counter display
o o o
Batch number, department code on/off
oo o
On On On
Speaker volume adjustment
o o o
Voice Message recording, playback, on/off x oo -
Off Off
Transmission Report on/off
o o o
On On On (Off in Asia)
Quick Dial/Group programming
o o o
Polling ID code
ooo
RTl/TTl/CSl
oo o Italy/W. Ger.: CSI = Service mode
Direct entry of labels and identifiers
oo o
Polling file clearance
oo o
Memory file clearance
xxo
Own telephone number
o o o
Telephone line type (ltaly/W. Ger./Univ: Service) o
o o Pulse (Except Asia)
TTI on/off
o o o
On On On
ECM on/off
xoo -
On On
Password
x x o
Addresses for Authorized Reception, on/off o o o
Off Off Off
Forwarding on/off, tel. number
xxo - - Off
Rx mode switching timer
ooo
Substitute reception on/off (not used in W. Ger.) x
ox -
Keystroke programs
o o o
1-11

Service Mode and System Tests Machine
Default
FAX77 FAX80 FAX85 FAX77 FAX80 FAX85
LCD brightness (by RAM address)
o o o
Dedicated Tx Parameters
o o o
Printout of all memory files
xxo
Bit switches
o o o
RAM rewriting - to local fax only
o o o
Error code display
o o o
Thermal head parameters
o o o
Serial number programming o o o
NCU parameters
o o o
Modem/DTMF tone tests
o o o
Operation panel test oo o
Xenon lamp lighting
o o o
Sensor initialization
ooo
Back-to-back test
o o o
Buzzer test
o o o
Line condition check o o o
Printer test patterns o o o
Protocol dump list o o o
Maximum address limitation ooo
ADF/printer mechanism tests oo o
Notes
1. The keystroke programs are stored in Quick Dial Keys, so the no. of programmed Quick Dial Keys plus the
no. of programs cannot exceed 30.
2. The no. of addresses programmed for polling rx and for memory tx, when combined, cannot exceed 300.
1-12

1-3. Installation Requirements
1-3-1. Environment
Temperature range: 17 to 28 degrees C [63 to 82 degrees F]
Humidity range: 30 to 85 %Rh - no condensation
Ventilation: Room air should turn over at least three times per hour
Avoid placing the machine where it will be exposed to corrosive gases.9
Place the machine on a strong and level base.
Place the machine where it will be:
• Not subject to direct sunlight
• Not subject to strong vibration
• Condensation free
• Away from other electronic equipment, to avoid interference
• Away from heaters and air conditioners, to avoid sudden temperature changes.
1-13

1-3-2. Minimum Space Requirements
1-14
